Mindeo MD6100S User manual

MD6100S Handheld Image Scanner
User Manual
Version: MD6100S_UM_EN_V2.1.0

i
Notice
Ensure that the optional DC adapter works at +5 VDC, especially for the RS-232 interface
cable.
1. All software, including firmware, furnished to the user is on a licensed basis.
2. The right is reserved to make changes to any software or product to improve reliability, function, or
design.
3. The material in this manual is subject to change without notice.
4. A standard packing includes a scanner, a USB cable and a quick guide. Accessories include a stand,
a RS-232 cable, and a 5 VDC adaptor.

ii

iii
Contents
Contents................................................................................................................................................iii
1 Specifications ..................................................................................................................................... 1
1-1 Technical specifications ................................................................................................................... 1
1-2 Default setting for each barcode ...................................................................................................... 2
2 Get started ......................................................................................................................................... 3
2-1 Dimensions....................................................................................................................................... 3
2-2 Parts of the scanner ......................................................................................................................... 4
2-3 Cable connector pin-outs descriptions............................................................................................. 5
2-4 Installation and uninstallation of cable ............................................................................................. 6
2-4-1 Installation - USB....................................................................................................................... 6
2-4-2 Installation - RS-232 .................................................................................................................. 6
2-4-3 Uninstallation of cable ............................................................................................................... 7
2-5 Assembling the stand ....................................................................................................................... 7
3 Programming......................................................................................................................................8
3-1 Example 1: Single-parameter setting by scanning 1D barcodes..................................................... 8
3-2 Example 2: Multiple-parameter setting by scanning a QR code barcode ....................................... 9
3-3 Operate the scanner by receiving command via UART................................................................. 10
3-4 Interface selection .......................................................................................................................... 11
3-5 RS-232 interface............................................................................................................................. 12
3-6 USB interface ................................................................................................................................. 15
3-7 Scan mode & some global settings................................................................................................ 18
3-8 Indication ........................................................................................................................................ 23
3-9 Decode illumination and decode aiming pattern............................................................................ 24
3-10 Other settings ............................................................................................................................... 26
Note 1 : The instruction of calibrating the aimer in vertical centering direction................................ 28
Note 2 : Scan barcode or send command to enter upgrade mode .................................................. 29
3-11 UPC-A........................................................................................................................................... 30
3-12 UPC-E........................................................................................................................................... 32
3-13 UPC-E1......................................................................................................................................... 34
3-14 EAN-13 (ISBN/ISSN).................................................................................................................... 36
3-15 EAN-8 ........................................................................................................................................... 38
3-16 Code 39 (Code 32, Trioptic Code 39) .......................................................................................... 40
3-17 Interleaved 2 of 5.......................................................................................................................... 43
3-18 Industrial 2 of 5 (Discrete 2 of 5) .................................................................................................. 45
3-19 Matrix 2 of 5.................................................................................................................................. 46
3-20 Codabar........................................................................................................................................ 47
3-21 Code 128 ...................................................................................................................................... 49
3-22 UCC/EAN 128 .............................................................................................................................. 51

iv
3-23 ISBT 128....................................................................................................................................... 53
3-24 Code 93 ........................................................................................................................................ 54
3-25 Code 11 ........................................................................................................................................ 55
3-26 MSI/Plessey.................................................................................................................................. 57
3-27 UK/Plessey ................................................................................................................................... 59
3-28 China Post.................................................................................................................................... 60
3-29 GS1 DataBar (GS1 DataBar Truncated)...................................................................................... 61
3-30 GS1 DataBar Limited ................................................................................................................... 62
3-31 GS1 DataBar Expanded............................................................................................................... 63
3-32 PDF417......................................................................................................................................... 64
3-33 MicroPDF417 Code...................................................................................................................... 65
3-34 QR Code....................................................................................................................................... 66
3-35 MicroQR Code.............................................................................................................................. 67
3-36 Data Matrix ................................................................................................................................... 68
3-37 Han Xin Code ............................................................................................................................... 69
3-38 Aztec Code ................................................................................................................................... 70
3-39 G1-G6 & C1-C3 & FN1 substitution string setting ....................................................................... 71
3-40 G1-G4 string position & Code ID position.................................................................................... 76
3-41 String transmission....................................................................................................................... 77
4 Maintenance..................................................................................................................................... 80
5 Barcode representing non-printable character .................................................................................. 81
6 ASCII Table...................................................................................................................................... 82
7 Test barcode .................................................................................................................................... 83
8 Return default parameters & list firmware version............................................................................. 86
9 Configuration alphanumeric entry barcode ....................................................................................... 87

1
1 Specifications
1-1 Technical specifications
Dimensions
Height × Width × Depth：82 mm × 69 mm × 178 mm
Weight
146 g, without cable
Cable
Straight 2.0 m
Connector Type
RJ-45 phone jack connector
Case Material
PC+TPU
Exit Window Material
Tempered glass
Indicator
Beeper, LED
Interface Supported
RS-232, USB Keyboard, USB virtual COM
Operating Mode
Hand-held, Auto-detection
Programming Method
Manual (reading special barcode)
Firmware Upgrade
Online
Input Voltage
4.40~5.25 VDC
Current
Standby: 160 mA , Scanning: 300 mA (Max:480 mA)
Image Size
1280 × 800 pixels
Light Source
Illumination : 5000 K , white LED
Aiming: 525 nm peak wavelength, green LED
Imager Field of View
Horizontal: 41°, vertical: 28°
Scanning Angle
±70°, ±75°, 360° (skew, pitch, roll)
Print Contrast
20% minimum reflective difference
Decoding Capability
1D: UPC-A, UPC-E, UPC-E1, EAN-13, EAN-8, ISBN (Bookland EAN), ISSN, Code 39, Code
39 full ASCII, Code 32, Trioptic Code 39, Interleaved 2 of 5, Industrial 2 of 5 (Discrete 2 of 5),
Matrix 2 of 5, Codabar (NW7), Code 128, UCC/EAN 128, ISBT 128, Code 93, Code 11
(USD-8), MSI/Plessey, UK/Plessey, China Post, GS1 DataBar (formerly RSS) variants
2D: PDF417, QR Code, DataMatrix, Han Xin Code, Aztec Code, MicroQR Code,
MicroPDF417
Minimum Resolution
1D（Code 128）： 4mil
Decoding Depth
4 mil Code39 (9 chars)
30 mm –90 mm
5 mil Code39 (3 chars)
20 mm –120 mm
13 mil UPC (6 chars)
0 mm –280 mm
20 mil Code39 (1 char)
15 mm –430 mm
6.7 mil PDF417 (20 chars)
15 mm –120 mm
10 mil QR (20 chars)
0 mm –165 mm
10 mil DM (20 chars)
0 mm –165 mm
20 mil QR (20 chars)
0 mm –340 mm
Temperature
-10° to 50°C (14° to 122°F), operating; -20° to 70°C (-4° to 158°F), storage
Humidity
5% to 95% (non-condensing)
Safety
EMC: EN55032, Protection: EN55024
RF Immunity: IEC61000-4-3, 10 V/m
Photobiological Safety: EN62471 | Immunity: 0~100,000 lux
Sealing: IP52
Drop Resistance: Withstands multiple 2.0 m drops to concrete

2
1-2 Default setting for each barcode
Code type
Read
enable
Check digit
verification
Check digit
transmissio
n
Min. code
length
Proprietary
code ID
AIM
code ID
UPC-A
√
√
√
(12)2
A
]Em
UPC-E
√
√
√
(8)2
D
]Em
UPC-E1
-
√
√
(8)2
D
]Em
EAN-13
√
√
√
(13)2
A
]Em
EAN-8
√
√
√
(8)2
C
]Em
ISBN (Bookland EAN)
/ ISSN1
√
√
√
(13)2
B
]Em
Code 39
√
-
-
1
M
]Am
Interleaved 2 of 5
√
-
-
6
I
]Im
Industrial 2 of 5
-
-
-
4
H
]Im
Matrix 2 of 5
√
-
-
6
X
]Im
Codabar
√
-
-
4
N
]Fm
Code 128
√
√
-
1
K
]Cm
UCC/EAN 128
√
√
-
1
K
]Cm
ISBT 128
√
√
-
1
K
]Cm
Code 93
√
√
-
1
L
]Gm
Code 11
-
√
-
4
V
-
MSI/Plessey
-
-
-
4
O
]Mm
UK/Plessey
-
√
-
1
U
]Mm
China Post
√
-
-
(11)2
T
]Im
GS1 DataBar
√
-
-
(16)2
R
]em
GS1 DataBar
Truncated3
√
-
-
(16)2
R
]em
GS1 DataBar Limited
√
-
-
(16)2
R
]em
GS1 DataBar Expanded
√
-
-
1
R
]em
PDF417
√
-
-
-
p
]Lm
MicroPDF417
√
-
-
-
p
]Lm
DataMatrix
√
-
-
-
d
]dm
QR code
√
-
-
-
q
]Qm
MicroQR Code
-
-
-
-
q
]Qm
Aztec Code
-
-
-
-
a
]zm
Han Xin Code
-
-
-
-
h
]Xm
Note: 1The settings for ISBN/ISSN and EAN-13 must be the same except the code ID.
2Fixed-length barcodes.
3The settings for GS1 DataBar Truncated and GS1 DataBar must be the same.

3
2 Get started
2-1 Dimensions

4
2-2 Parts of the scanner
Figure 2-1
①Beeper
②LED
③Scan window
④Trigger
⑤Cable interface port
⑥Release-hole of the cable

5
2-3 Cable connector pin-outs descriptions
The scanner provides a RJ-45 cable connector.
Figure 2-2 Cable connector interface pin-outs
The pin-outs descriptions in Table 2-1 apply to the cable connector on the scanner and are for reference
only.
Table 2-1 Cable connector pin-outs descriptions
Pin
RS232
USB
1
Power (+5V)
Power (+5V)
2
Reserved
Reserved
3
Ground
Ground
4
+3.3V
( for interface auto selection purpose)
Ground
(for interface auto selection purpose)
5
TxD
Reserved
6
RxD
Reserved
7
Reserved
Reserved
8
Reserved
Reserved
9
CTS
D-
10
RTS
D+
Note: Voltage level of all RS232 Pin-outs (RxD, TxD, CTS and RTS) is 0V for logic low and 3.3V for logic
high.

6
2-4 Installation and uninstallation of cable
Note: If any of the below operation is incorrect, turn off the power immediately and check the scanner for
any improper connections. Go through all steps again.
2-4-1 Installation - USB
The scanner attaches directly to a USB host, and is powered by it. No additional power supply is
required.
1. Refer to Figure 2-3, connect the USB interface cable to the bottom of the scanner.
2. Plug the series A connector in the USB host, or an available port of the terminal.
3. Windows will automatically detect the USB device.
Figure 2-3
2-4-2 Installation - RS-232
1. Connect the RS-232 interface cable to the bottom of the scanner.
2. Connect the other end of the interface cable to the serial port on the host. Tighten the two screws to
secure the connector to the port.
3. If the host does not have power supply (on PIN 9), connect the external power supply (DC adapter)
to the RS-232 cable.
Figure 2-4

7
2-4-3 Uninstallation of cable
Figure 2-5
Remove the interface cable:
1. Find the release-hole.
2. Insert a thin wire into the hole and pull out the cable gently.
2-5 Assembling the stand
Note: The stand is an optional accessory.
1. See the figure above, tighten the screws.
2. Bend the neck to the desired position for scanning.
3. Screw mounting: Screw one #10 wood screw into each screw-mount-hole until the base of the stand
is secured.
4. Tape mounting: ①Peel the paper liner off one side of each piece of tape and place the sticky
surface over each of the three rectangular tape holders. ②Peel the paper liner off the exposed
sides of each piece of tape and press the stand on a flat surface until it is secure.

8
3 Programming
3-1 Example 1: Single-parameter setting by scanning 1D barcodes
Important notes:
1. During the process of programming, LED is lighting to indicate the programming correctness. LED
will go off if any incorrect programming operation performed.
2. After each successful programming, LED will go off and the scanner will beep twice.
3. Throughout the programming barcode menus, the factory default settings are indicated with
asterisks (*).
Two programming modes have been provided as bellows:
❶Single-scan setting
Scan the appropriate Single-scan setting (e.g. %0101D00%) according to the user‘s demand.
Example: To set Flow control to be XON/XOFF.
Steps: Scan the following barcode.
❷Multiple-scan setting
Step 1. Scan the Option barcode barcode (e.g. %0101M%) according to the user‘s demand.
Step 2. To the right of the option barcode, the necessary alphanumeric inputs are listed. Scan
two alphanumeric entries from 0 to 9 or A to F, refer to 10 Configuration alphanumeric entry
barcode .
Step 3. Repeat Step 2, if more user parameters input are required.
Step 4. Scan the %END% barcode, listed on the lower left hand corner of each parameter
setting part.
Example: To set Flow control to be XON/XOFF.
Steps: Referring to 3-6 RS-232 interface , scan the following barcodes in order.

9
3-2 Example 2: Multiple-parameter setting by scanning a QR code barcode
User can customize a QR code to set multiple parameters. The scanner can set multiple parameters by
scanning this single QR code barcode.
1. The data format of the QR code barcode is as following.
% Parameter set 1 % Parameter set 2 % Parameter set N %
<Option barcode index><D/H><Alpha. entries>
···
Note that:
<Option barcode index> means the corresponding 4 digits of Option barcode.
<D/H> means “D”or “H”character. D means that the type of alphanumeric entry is decimal; and H
means that the type of alphanumeric entry is hexadecimal.
<Alpha. entries> is a character string with various length of 2, 4, or other values.
Example: Set 0401->03 (decimal); 8002->0D0A (hexadecimal); 8202->01 (decimal). The customized
QR code barcode contents and symbol are as following.
%0401D03%8002H0D0A%8202D01%
2. Notes of making QR code barcode
The model is chosen as M2. Other requirements, e.g. ECC level, Start mode, etc, are not specified.
Other notes
The contents of a QR code barcode can include several same <Option barcode index> associated
with same or different <Alpha. entries>. In the case of with different <Alpha. entries>, the latest
<Alpha. entries> is the valid one.
If any one of the parameter settings is invalid, the total setting is failed. The invalid setting can be
caused by one of the following problems: invalid <Option barcode index>, invalid type of <D/H>,
invalid type, length or value range of <Alpha. entries>, etc.

10
3-3 Operate the scanner by receiving command via UART
Note:
1- The information in this chapter is provided for the scanner with RS232 cable or USB cable.
2- If the scanner is with USB cable, the setting of USB device type must be set as “USB virtual COM”.
Please refer to 3-6 USB interface.
3- Please read 3-7 Scan mode & some global settings about the setting of Scan mode in details.
UART parameter should be set as below:
(1) Baud rate: 9600 bps;
(2) Data bits: 8 bits;
(3) Stop bit: 1 bit;
(4) Parity check bit: None;
(5) Flow control: None.
Guide of control command: all commands are sent by UART
1) Start command: “0x16 0x54 0x0D”
When the scanner received the above command, it will start barcode scanning following the setting of
Scan mode.
2) Stop command: “0x16 0x55 0x0D”
If the Scan mode is set as “Alternate continue”or “Continue”, and the scanner received the above
command, it will stop barcode scanning and act as in an idle mode.

11
3-4 Interface selection
This scanner supports interfaces such as RS-232 serial wedge and USB interface. In most of the cases,
simply selecting an appropriate cable provided by the manufacturer will work for a specific interface.
Interface selection:
Auto detection- By setting this function, the scanner will automatically detect the RS-232 interface or
USB interface for user.
Multiple-scan setting
Single-scan setting
Option barcode
Option
Alpha. entry
Interface selection
Auto detection
(RS-232/USB)
00*
*

12
3-5 RS-232 interface
Host type:
Standard- The scanner is connected to a standard RS-232 interface.
OPOS/JPOS- The scanner is connected to a POS terminal which may be necessary to install the
OPOS/JPOS driver to be compatible with the manufacturer's scanner. The OPOS/JPOS driver is
provided by the scanner manufacturer; please contact the scanner manufacturer for the instruction.
Flow control:
None-The communication only uses TXD and RXD signals without any hardware or software
handshaking protocol.
RTS/CTS- If the scanner wants to send the barcode data to host computer, it will issue the RTS signal
first, wait for the CTS signal from the host computer, and then perform the normal data communication.
If there is no replied CTS signal from the host computer after the timeout duration, the scanner will
issue an error indication. By setting (Host idle: Low RTS) or (Host idle: High RTS), the scanner can be
set to match the Serial Host RTS line.
XON/XOFF- An XOFF character turns the scanner transmission off until the scanner receives an XON
character.
ACK/NAK- After transmitting data, the scanner expects either an ACK (acknowledge) or NAK (not
acknowledge) response from the host. When a NAK is received, the scanner transmits the same data
again and waits for either an ACK or NAK. After three unsuccessful attempts to send data when NAKs
are received, the scanner issues an error indication and discards the data.
Inter-character delay: This delay is inserted after each data character transmitted.
Response delay: This delay is used for serial communication of the scanner when it waits for a
handshaking acknowledgment from the host.

13
Multiple-scan setting
Single-scan setting
Option barcode
Option
Alpha. entry
Host type
Standard
00*
*
OPOS/JPOS
01
Flow control
None
00*
*
RTS/CTS
(Host idle: Low RTS)
01
RTS/CTS
(Host idle: High RTS)
02
XON/XOFF
03
ACK/NAK
04
Inter-character delay
0 ms
00*
*
5 ms
01
10 ms
02
20 ms
03
40 ms
04
80 ms
05
Response delay
00-99 (100 ms)
00-99
00*
*
Baud rate
300
00
600
01
1200
02
2400
03
4800
04
9600
05*
*

14
Multiple-scan setting
Single-scan setting
Option barcode
Option
Alpha. entry
19200
06
38400
07
57600
08
115200
09
Parity bit
None
00*
*
Odd
01
Even
02
Data bit
8 bits
00*
*
7 bits
01
Stop bit
One bit
00*
*
Two bits
01
