Minicom PHANTOM MX II User manual

Same Rack... More Control, More Servers, Less Cabling
• Simultaneously access multiple servers from two different locations
• Multi-platform support – PS/2, SUN, USB, and S-232 in one system
• Unique feature – connect local computer to administrator’s KVM
• Built in KVM extension for flexible design of your server room
• Scalable – start with one user and expand as your business grows
• Pure hardware solution – out-of-band software/network independent
• Specter units take up Zero U rack space – more room for servers
• Advanced On Screen Display (OSD) management
• Open S-232 protocol for vendor application software
• Multi-layer security and individual user profiles
• CAT5 cable technology – flexible, smoother and cheaper installation
• 3 Year Warranty

Website: www.minicom.com
Authorized Reseller:
5DO20074
International HQ
Jerusalem, Israel
Main: [phone]
Support: [phone]
[email protected]om
orth American HQ
Linden, NJ, USA
Tel: [phone]
Fax: [phone]
[email protected]om
German Europe
Zurich, Switzerland
Tel: [phone]
Fax: [phone]
[email protected]om
Italy
ome, Italy
Tel: [phone]
Fax: [phone]
[email protected]om
Product Order No.
Phantom MX II (Multi User) 0SU52016
Universal Phantom Manager 0SU52015
Phantom Specter II PS/2 0SU51012
Phantom Specter II 0SU51011
USB / SUN USB
Phantom Specter II SUN 0SU51013
Phantom Specter II RS232 0SU51014
Phantom Specter II Starter 0SU51017
Kit PS 1+3 Two user ready
Rack Mounting Plate for 5AC00202
UPM & MX II
ORDERING INFORMATION:
Specifications:
63
CAT5 FTP 2x4x24 AWG Solid Wire
110m/360ft
Up To 1600x1200 @ 75Hz
PS/2, Wheel mouse
DOS, Windows (3x, 9x, 2000, NT4, ME, XP), LINUX, UNIX, HP UX QNX, SGI, Free BSD,
BeOS, Open VMS, Novell 3.12-6, On Screen Display (OSD), RS-232 Control Software
Password, multiple user profiles
Automatically view all screens at adjustable intervals from 5-995 seconds
Up to 40˚C / 104˚F
40˚C to 70˚C / -40˚F to 158˚F
3 years
SYSTEM
Number of Remote Units
System Cable
Maximum Distance
Resolution
Mouse Support
Operating Systems,
Management
Security
Scan
Operating Temperature
Storage Temperature
Warranty
The Phantom MX II system is a multi-user, multi-platform solution for KVM server management that
is geared towards high-density server and computer environments. It allows two users to simultaneously
access and control 63 servers while placing their KVM (Keyboard, Video & Mouse) anywhere in the
server room. It features advanced OSD management, multi-layer security and advanced CAT5 technology.
The Phantom MX II is based on Minicom’s original DS (Distributed Switching) technology making it
the most scalable and flexible KVM solution for server management.
The Phantom MX II system consists of one Phantom MX II manager unit, one Universal
Phantom Manager (UPM) unit and up to 63 Specter II remote units (one for each server).
All components are connected to each other via one standard CAT5 cable. Both manager
units are rack mountable. No external power is needed at the remote Specter units.
From Server Racks to Data Centers
The Phantom MX II is an ideal solution for small to large data centers that require more
than one supervisor and need the flexibility of operating from both local and extended
locations. The Phantom MX II supports multiple platforms and is also designed for
non-computer based S-232 devices.
The Phantom MX II system is compatible with Minicom’s Smart KVM Extender, allowing
still greater user/server distance for different configurations.
The Phantom Specter II line
PS/2 SUN S-232 USB
Phantom MX II Manager
Phantom MX II Manager
Universal Phantom Manager
Universal Phantom Manager
