Minox BD 9.5x42 IF User manual

BD 9.5x42IF
Instruction manual

MINOX BD 9.5x42 IF
•English
Do not use the binoculars to look at the sun.
This could lead to eye injuries.
Attention!

MINOX BD 9.5x42 IF
5
47
1 2 3
6

Content
Introduction Page 3
Operating parts Page 4
Preparing the binocular Page 5
- Attaching the neck strap
Adjusting the binocular for use Page 5
- Interpupillary distance adjustment
- Individual eye focus system
- Note for spectacle wearers
- Using the binoculars with and
without eyeglasses
Other features Page 6
- Tripod adapter
- Ocular lens covers
Maintenance of your binocular Page 7
- Binocular case
- Cleaning your binocular
- Lens cleaning
- Serial number
Helpful tips for binocular users Page 8
Customer service Page 8
Technical data Page 9
2

3
Introduction
Congratulations!
The MINOX BD 9,5 x 42 IF represents an outstanding
combination of advanced optical design and high
tech manufacturing. With its roots in military service,
your binocular will give you outstanding service in the
roughest conditions.
To completely understand its features, and derive maxi-
mum enjoyment from your purchase please read the
following information before using your new MINOX
binocular.

4
•Rugged “Military Style” roof prism binocular
•Water proof
•Armor coated
•Individual eye focus
•Rugged lightweight body
Operating parts
1. Focussing, right handside
2. Eyepieces with adjustable eyecups
for spectacle wearers
3. Neck strap buckle
4. Collapsible tubes
5. Focussing, left handside
6. Tripod adapter threaded socket
7. Lens

5
Preparing the binocular
Your MINOX binocular comes with a neck strap. We re-
commend you to install the neck strap and use it when
ever you’re using the binocular.
Note
Many accidents can be avoided by using the neck strap.
Attaching the neck strap
Thread the neck strap through the neck strap loop (3)
on the body of the binocular. Bring the end of the strap
back to the neck strap buckle.Thread the neck strap end
from the back, through the buckle. This will secure the
neck strap. Use the same procedure on the other side.
Adjust the length of the neck strap for the comfort of
the user.
The ocular lens cover or “rain guard” has a loop for the
neck strap to thread through one side. This cover pro-
tects the ocular lenses from debris and rain while the bi-
nocular is being carried by use of the neck strap. The
rain guard hangs down out of the way when the bino-
cular is being used.
Adjusting the binocular for use
Your binocular must be adjusted to the individual using
the binocular. The following procedures will assure ma-
ximum enjoyment and proper use.
Interpupillary Distance Adjustment
This adjustment uses the binoculars hinge pin to adjust
to the distance between the user’s eyes. With the pro-
per adjustment the user sees a round full circle, not two
circles. Move the barrels in or out until a round full circle
is seen through the unit. With this adjustment made, you
are now ready to focus the binocular.
Individual Eye Focus System
The MINOX BD 9.5 x 42 IF is equipped with the indi-
vidual eye focus system (1+5). Once you adjust the
binocular to your vision at approximately 75 yards, the
unit will be in focus without additional adjustment to
infinity. To focus the binocular, close your right eye and
look through the left barrel. Choose an adequate obser-
vation object. Turn the left ocular eyepiece right or left
until you see a sharp, clear image. Use the same proce-
dure for the right eye. Now your binocular is focused.

6
Both right and left ocular eyepieces have +/- diopter
markings. Remembering the setting or marking the di-
opter setting with a permanent marker makes refocu-
sing the unit easy if another person has used the
binocular and changed the settings.
Caution
Do not use the binoculars to look at the sun. This could
lead to eye injuries.
Note for spectacle wearers
To suit the requirements of spectacle wearers, the MINOX
binoculars are equipped with adjustable eyecups (2).
This allows the glasses wearer a better overall view.
Using the binoculars with and without eyeglasses
If you do not wear glasses, leave the eyecups in the
initial state.This places your eyes at the correct distance
from the eyepiece lens and ensures firm positioning of
the binoculars and reduces stray light from the side. If
you wear glasses, fold down the rubber eye cup. This
allows you to see the full field of view.
Other features
Tripod Adapter
To ensure blur-free viewing it is advisable to only use a
tripod at high magnifications.Your MINOX BD 9.5 x 42 IF
is designed to be used with a tripod or window mount.
To use this feature requires the use of a tripod adapter.
Tripod adapters are available from MINOX or your sport
optic dealer (order no. 69725). To install the tripod ad-
apter unscrew the knurled cap that is attached to the
center hinge pin (6). Under the cap is a 1/4 x 20 N.C.
treaded hole. Follow the instructions included with the
tripod adapter for proper installation.
Note
Severe damage to the binocular can occur if the tripod
collapses or is knocked over. It is recommended to re-
move the binocular from the tripod if the user is not wit-
hin arms reach of the tripod.
Ocular Lens Covers
Ocular lens covers are provided to protect the objective
lenses of your binocular. Keeping the lenses protected
when not in use reduces the amount of the dust or de-
bris that settles on the lenses.

7
Maintenance of your binocular
Your binocular is designed for years of trouble free use.
Following a few service recommendations will insure
years of service.
Binocular Case
A rugged binocular case is provided to protect your unit
when travelling and not in use.
Cleaning your Binocular
Keeping your binocular clean and dry will allow you ma-
ximum enjoyment and trouble free service. Remove dust
and debris with a soft brush or compressed air.
If your binocular is used at sea, or near a salt-water en-
vironment, it is strongly recommended that your rinse
the binocular in fresh water. This removes salt that may
damage your unit.
Lens Cleaning
Dust, salt and the oil left from fingerprint smudges im-
pairs your binoculars’ brightness and should never be
allowed to remain on the lenses because they can harm
the multi-coating applied to the lens surfaces.
Loose dust and debris should be removed by blowing
the debris off, using an optical lens cleaning bush or
compressed air. If fingerprints or smudges remain on the
lens, use optical lens tissue and lens cleaner solution to
clean the lenses. Follow the instructions on the lens
cleaning tissue and cleaner. Lens cleaning supplies are
available from sporting goods or all camera or optical
stores.
Note
Do not “over clean” lenses. Excessive cleaning can da-
mage the multi-coatings. Do not use household cleaners
on the lenses of the binocular.
Serial number
On the bottom of every pair of MINOX binoculars,
you will find an individual serial number. It is of great
importance to record this number in case of loss of your
binoculars.

8
Helpful tips for binocular users
•Never leave your binocular exposed to direct sunlight
for extended periods. This can cause damage to the
armor coatings or eyepieces.The dashboard of an au-
tomobile is not a proper storage location for your bi-
nocular; the sunlight is greatly magnified through the
windshield.
•Use the neck strap as your “insurance policy” against
dropping the binocular.
•Never walk away from a binocular on a tripod; remove
it if you are not within arm length of the tripod.
•Store your binocular in its case and in a cool, dry
location.
•Avoid severe temperature fluctuations. For example,
bringing it from an extremely cold condition in to a
heated environment could
Customer service
If you experience any problems with your binocular,
never attempt to repair it yourself. Unauthorized repairs
void the factory warranty. Contact your MINOX agency or
contact MINOX directly.
For service contact:
MINOX GmbH
Walter-Zapp-Str. 4
D-35578 Wetzlar
Germany
Telephone: +49 6441 / 917-0
Telefax: +49 6441 / 917-612
[email protected]
www.minox.com

9
Technical data
Magnification 9,5-fach
Front lens diameter 1.65 in. / 42 mm
Exit pupil 0.16 in. / 4.4 mm
Field of view 330 ft / 1000 yds, 6.3°
110 m / 1000 m, 6.3°
Eye relief 0.75 in. / 19 mm
Twilight number 20
Geom. Twilight no. 19,4
Operating temperature 14 °F up to 113 °F
-10 °C bis +45 °C
Water proof yes, up to 6.56 ft / 2 m
Height x Width x Depth 6.46 x 5.08 x 2.17 in.
164 x 129 x 55 mm
Weight approx. 25.04 oz / 710 g
For your notes

Design subject to alterations without notice.
MINOX is a registered trademark of MINOX GmbH, Wetzlar.
MINOX GmbH
Walter-Zapp-Str. 4
D-35578 Wetzlar, Germany
Tel.: [phone] / 917-0
Fax: [phone] / 917-612
e-mail: [e-mail]
www.minox.com 99428
