INSTALLATION MANUAL
FOR INSTALLER
MANUEL D’INSTALLATION
POUR L’INSTALLATEUR
MANUAL DE INSTALACIÓN
PARA EL INSTALADOR
Air-Conditioners For Building Application
INDOOR UNIT
TPKFYP·KM142✱
English (EN)
Français (FR)
Español (ES)
VG79G972H01_cover.indd 1 2019/02/08 17:26:35
2
Before installing the unit, make sure you read all the “Safety
precautions”.
Please report to your supply authority or obtain their consent before
connecting this equipment to the power supply system.
Warning:
Describes precautions that must be observed to prevent danger of injury or
death to the user.
Caution:
Describes precautions that must be observed to prevent damage to the unit.
Contents
Warning:
• Ask the dealer or an authorized technician to install the air conditioner.
• Do not alter the unit. It may cause fire, electric shock, injury or water
leakage.
• Install the unit at a place that can withstand its weight.
• Use the specified cables for wiring.
• Use only accessories authorized by Mitsubishi Electric and ask the dealer
or an authorized technician to install them.
• Do not touch the heat exchanger fins.
• Install the air conditioner according to this Installation Manual.
• Have all electric work done by a licensed electrician according to local
regulations.
• Do not use intermediate connection of the electric wires.
• If the air conditioner is installed in a small room, measures must be taken
to prevent the refrigerant concentration from exceeding the safety limit
even if the refrigerant should leak.
• The cut face punched parts may cause injury by cut, etc. The installers are
requested to wear protective equipment such as gloves, etc.
• When installing or relocating, or servicing the air conditioner, use only the
specified refrigerant (R410A) to charge the refrigerant lines. Do not mix it
with any other refrigerant and do not allow air to remain in the lines.
If air is mixed with the refrigerant, then it can be the cause of abnormal
high pressure in the refrigerant line, and may result in an explosion and
other hazards.
The use of any refrigerant other than that specified for the system will
cause mechanical failure or system malfunction or unit breakdown. In the
worst case, this could lead to a serious impediment to securing product
safety.
1. Safety precautions
ELV
Warning:
Carefully read the labels affixed to the main unit.
Caution:
• Do not use the existing refrigerant piping, when use R410A refrigerant.
• Use ester oil, either oil or alkylbenzene (small amount) as the refrigerator
oil to coat flares and flange connections, when use R410A refrigerant.
• Do not use the air conditioner where food, pets, plants, precision
instruments, or artwork are kept.
• Do not use the air conditioner in special environments.
• Ground the unit.
• Install an leak molded case circuit breaker, as required.
• Use power line cables of sufficient current carrying capacity and rating.
• Use only a molded case circuit breaker and fuse of the specified capacity.
• Do not touch the switches with wet fingers.
• Do not touch the refrigerant pipes during and immediately after operation.
• Do not operate the air conditioner with the panels and guards removed.
• Do not turn off the power immediately after stopping operation.
Note:
The phrase “Wired remote controller” in this installation manual refers to the TAR-40MAA.
If you need any information for the other remote controller, please refer to either the installation manual or initial setting manual which are included in these
box.
VG79G972H01_en.indd 2 2019/02/08 17:28:39
3
2. Installation location
3. Installing the indoor unit
3.1. Check the indoor unit accessories (Fig. 3-1)
1
2×
3
4
5
3.2. Installing the wall mounting fixture
3.2.1. Setting the wall mounting fixture and piping positions
Using the wall mounting fixture, determine the unit’s installation position
and the locations of the piping holes to be drilled.
Warning:
Before drilling a hole in the wall, you must consult the building contractor.
TPKFYP·KM142✱(Fig. 3-2)
A 1
B
C
D
E
F
G
H
I
J
K
3.2.2. Drilling the piping hole (Fig. 3-3)
Use a core drill to make a hole of 75-80 mm, 2-61/64~3-5/32 inch diameter
in the wall in the piping direction, at the position shown in the diagram to
the left.
The hole should incline so that the outside opening is lower than the
inside opening.
Insert a sleeve (with a 75 mm, 2-61/64 inch diameter and purchased
locally) through the hole.
Note:
The purpose of the hole’s inclination is to promote drain flow.
Fig. 2-1
2.1. Outline dimensions (Indoor unit) (Fig. 2-1)
TPKFYP·KM142✱
ABCDE
F
G
H
I
J
K
L
Fig. 3-1
TPKFYP·KM142✱
Fig. 3-2
A
B
C
D
F
G
D
E
A
K
J
I
TPKFYP·KM142✱
Fig. 3-3
A
C
D
E
B
A
B
C
D
E
G
F
A
B
H
E
J
L
I
D
C
K
123
4 5
VG79G972H01_en.indd 3 2019/02/08 17:28:40
4
3. Installing the indoor unit
TPKFYP·KM142✱
Fig. 3-7Fig. 3-6
AA
Fig. 3-8
A
B
D
C
E
Fig. 3-10Fig. 3-9
3.2.3. Installing the wall mounting fixture
Since the indoor unit weighs near 21 kg, 46 lbs selection of the mounting
location requires thorough consideration. If the wall does not seem to be
strong enough, reinforce it with boards or beams before installation.
The mounting fixture must be secured at both ends and at the centre, if
possible. Never fix it at a single spot or in any nonsymetrical way.
(If possible, secure the fixture at all the positions marked with a bold
arrow.)
Warning:
If possible, secure the fixture at all positions indicated with a bold arrow.
Caution:
• The unit body must be mounted horizontally.
• Fastenattheholesmarkedwith▲asshownbythearrows.
TPKFYP·KM142✱(Fig. 3-4)
A
B
C
D 2
E
F
G
H
I 1
3.3. When embedding pipes into the wall (Fig. 3-5)
A
1
B
C
D
3.4. Preparing the indoor unit
TPKFYP·KM142✱
Attachment of L-shaped connection pipe 4
Right, left and rear piping (Fig. 3-6)
4
5
4
5
4
A
4
B
C
D
E
Lower piping (Fig. 3-7)
4
4
4
5
4
5
4
TPKFYP·KM142✱
Fig. 3-4
A
B
C
DI
G
F
H
E
Fig. 3-5
B
A
C
D
VG79G972H01_en.indd 4 2019/02/08 17:28:40
5
3. Installing the indoor unit
Fig. 3-11
B
A
C
E
D
Leakage check of the L-shaped connection pipe connection portion
5
Extraction and processing of the piping and wiring (Fig. 3-11)
3
3
3
A
B
C
D
E 3
Rear, right and lower piping (Fig. 3-12)
3
3
A
B
Left and left rear piping (Fig. 3-13)
C
3
3
D
Fig. 3-12
B
A
Fig. 3-13
C
D
VG79G972H01_en.indd 5 2019/02/08 17:28:41
