Mitsubishi Electric Melservo-J5 MR-J5 Series User manual

MR-J5
User's Manual
(Function)
-MR-J5-_G_
-MR-J5W_-_G_
-MR-J5-_A_
Mitsubishi Electric AC Servo System

1
SAFETY INSTRUCTIONS
Please read the instructions carefully before using the equipment.
To use the equipment correctly, do not attempt to install, operate, maintain, or inspect the equipment until you have read
through this manual, installation guide, and appended documents carefully. Do not use the equipment until you have a full
knowledge of the equipment, safety information and instructions.
In this manual, the safety instruction levels are classified into "WARNING" and "CAUTION".
Note that the CAUTION level may lead to a serious consequence depending on conditions.
Please follow the instructions of both levels because they are important to personnel safety.
Forbidden actions and required actions are indicated by the following diagrammatic symbols.
In this manual, precautions for hazards that can lead to property damage, instructions for other functions, and other
information are shown separately in the "POINT" area.
After reading this manual, keep it accessible to the operator.
WARNING
Indicates that incorrect handling may cause hazardous conditions, resulting in
death or severe injury.
CAUTION
Indicates that incorrect handling may cause hazardous conditions, resulting in
medium or slight injury.
Indicates a forbidden action. For example, "No Fire" is indicated by .
Indicates a required action. For example, grounding is indicated by .

2
[Installation/wiring]
[Setting/adjustment]
[Operation]
[Maintenance]
WARNING
●To prevent an electric shock, turn off the power and wait for 15 minutes or more before starting wiring
and/or inspection.
●To prevent an electric shock, ground the servo amplifier.
●To prevent an electric shock, any person who is involved in wiring should be fully competent to do the
work.
●To prevent an electric shock, mount the servo amplifier before wiring.
●To prevent an electric shock, connect the protective earth (PE) terminal of the servo amplifier to the
protective earth (PE) of the cabinet, then connect the grounding lead wire to the ground.
●To prevent an electric shock, do not touch the conductive parts.
WARNING
●To prevent an electric shock, do not operate the switches with wet hands.
WARNING
●To prevent an electric shock, do not operate the switches with wet hands.
WARNING
●To prevent an electric shock, any person who is involved in inspection should be fully competent to do
the work.
●To prevent an electric shock, do not operate the switches with wet hands.

3
ABOUT THE MANUAL
e-Manuals are Mitsubishi Electric FA electronic book manuals that can be browsed with a dedicated tool.
e-Manuals enable the following:
• Searching for desired information in multiple manuals at the same time (manual cross searching)
• Jumping from a link in a manual to another manual for reference
• Browsing for hardware specifications by scrolling over the components shown in product illustrations
• Bookmarking frequently referenced information
• Copying sample programs to engineering tools
If using the servo for the first time, prepare and use the following related manuals to ensure that the servo is used safely. The
manuals used differ depending on the interface of the servo amplifier. For details, refer to the User's Manual (Introduction).
This manual covers the following servo amplifiers.
• MR-J5-_G_/MR-J5W_-_G_/MR-J5-_A_
In this manual, the servo amplifier names are abbreviated as shown below.
Symbol Servo amplifier
[G] MR-J5-_G_
[WG] MR-J5W_-_G_
[A] MR-J5-_A_
Rotary Servo Motor
Linear Servo Motor
Direct Drive Motor
Partner Encoder
Function
Adjustment
Object Dictionary
Troubleshooting
This manual is necessary primarily for installing, wiring,
and using options.
The manual is necessary for operation of servo amplifiers.
The manual is necessary for adjustment of operation status.
The manual is necessary when looking up details of each
function.
Introduction
Hardware
Communication FunctionThe manual is necessary for using communication functions.
Parameters
The manual is necessary for specifying the causes of alarms
and warnings.

4
Object units
This section explains the pos units, vel units, and acc units used in this manual.
■pos units
The unit is pulse.
■vel units
The unit can be changed using [Pr. PT01.1 Speed/acceleration/deceleration unit selection] as shown in the following table.
*1 0.01 mm/s is used in the linear servo motor control mode.
■acc units
The unit can be changed using [Pr. PT01.1] as shown in the following table.
U.S. CUSTOMARY UNITS
U.S. customary units are not shown in this manual. Convert the values if necessary according to the following table.
Setting value Unit
00.01 r/min, 0.01 mm/s *1
1pulse/s
Setting value Unit
0ms
1pulse/s2
Quantity SI (metric) unit U.S. customary unit
Mass 1 [kg] 2.2046 [lb]
Length 1 [mm] 0.03937 [inch]
Torque 1 [N•m] 141.6 [oz•inch]
Moment of inertia 1 [(× 10-4 kg•m2)] 5.4675 [oz•inch2]
Load (thrust load/axial load) 1 [N] 0.2248 [lbf]
Temperature N [°C] × 9/5 + 32 N [°F]

5
CONTENTS
CONTENTS
SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
ABOUT THE MANUAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
U.S. CUSTOMARY UNITS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
CHAPTER 1 FUNCTION 10
1.1 Function explanation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
CHAPTER 2 CONTROL MODE 17
2.1 Control mode [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Control switching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cyclic synchronous position mode (csp) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Cyclic synchronous velocity mode (csv) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Cyclic synchronous torque mode (cst) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Profile position mode (pp) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Profile velocity mode (pv) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Profile torque mode (tq). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Continuous operation to torque control mode (ct) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Homing mode (hm) and homing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
2.2 Control mode [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Control switching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Position control mode (P) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Speed control mode (S). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Torque control mode (T) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Position/speed control switching mode (P/S) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
Speed/torque control switching mode (S/T) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Torque/position control switch mode (T/P) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
CHAPTER 3 BASIC FUNCTION 81
3.1 Outline of servo parameter and object dictionary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Servo parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Object dictionary [G] [WG]. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
3.2 Rotation/travel direction selection [G] [WG]. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Setting methods of functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
3.3 Rotation/travel direction selection [A]. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Setting methods of functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
3.4 Stroke limit function [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Explanation of the stroke limit signal names . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Setting methods of functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Stop method at stroke limit detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Servo parameter list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
3.5 Stroke limit function [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Setting methods of functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Stop method at stroke limit detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Servo parameter list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
3.6 Limit switch release position assessment function [G] [WG]. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Outline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98
Setting methods of functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

6
3.7 Command unit select function [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Speed command unit selection function [G] [WG]. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
3.8 Command unit select function [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Torque command unit selection function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
3.9 Electronic gear function [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Setting example. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
3.10 Electronic gear function [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Setting example. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Electronic gear selection function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
3.11 In-position range setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Setting method [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Setting method [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
3.12 Assigning I/O devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Setting method [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Setting method [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
3.13 Regenerative option selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Regenerative option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
3.14 Alarm function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Operation status at alarm occurrence [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Operation status at alarm occurrence [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Operation status at warning occurrence [G] [WG]. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Operation status at warning occurrence [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Returning from an alarm [G] [WG]. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Returning from an alarm [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Returning from a warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Alarm history [G] [WG]. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Alarm history [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Stop method at occurrence of alarms/warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Timing chart at alarm occurrence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
3.15 Forced stop deceleration function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Setting method [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Setting method [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Timing chart [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Timing chart [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
3.16 Electromagnetic brake interlock function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Base circuit shut-off delay time function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Setting method [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Setting method [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Timing chart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
3.17 Vertical axis freefall prevention function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Setting method [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Setting method [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Timing chart [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Timing chart [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
3.18 Acceleration/deceleration function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Acceleration/deceleration time constant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
S-pattern acceleration/deceleration time constant [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
S-pattern acceleration/deceleration time constant [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Acceleration/deceleration [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

7
CONTENTS
3.19 Quick stop [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Objects for setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Timing chart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
3.20 Halt [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Objects for setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Timing chart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
3.21 Command pulse train monitoring function [A]. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Setting a command frequency error threshold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Setting PEN (Command input permission signal) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
CHAPTER 4 APPLICABLE FUNCTIONS 148
4.1 Tough drive function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Vibration tough drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Instantaneous power failure tough drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
4.2 Compliance with SEMI-F47 standard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Requirements of the SEMI-F47 standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Calculation method of tolerance against instantaneous power failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .155
4.3 Scale measurement function [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
Outline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
Function block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
System configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
Scale measurement encoders. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Procedure for replacing the Mitsubishi Electric servo motor equipped with a batteryless absolute position encoder
165
Related objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166
4.4 Touch probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
Outline [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
Setting method [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
4.5 Machine diagnosis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Friction vibration estimation function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
Friction failure prediction function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184
Vibration failure prediction function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
Total travel distance failure prediction function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Gear failure diagnosis function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208
Belt diagnosis function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 215
4.6 Drive recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 234
Specification outline. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 236
How to use the function [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 236
How to use the function [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239
Servo parameter/object dictionary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 241
Standard acquisition waveform list [G] [WG]. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 254
Standard acquisition waveform list [A]. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 256
Waveform recording inapplicable alarm list. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 258
List of auxiliary recording data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259
4.7 Software reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260
Software reset in MR Configurator2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260
Software reset via network communication [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260

8
4.8 Software position limit [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 261
Setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 261
4.9 Torque limit [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262
Setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262
Checking "Limiting torque" status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 264
4.10 Torque limit [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265
Setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
Checking "Limiting torque" status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
4.11 Speed limit [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
Setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
Checking "Limiting speed" status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
4.12 Speed limit [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 269
Setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 269
Checking "Limiting speed" status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 271
4.13 A/B/Z-phase pulse output function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272
Setting method [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 273
Setting method [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 276
Z-phase pulse output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 279
4.14 Infinite feed function [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280
4.15 Servo amplifier life diagnosis function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280
Cumulative energization time function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280
Relay usage count display function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 281
4.16 Encoder communication diagnosis function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 282
Usage [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 282
Usage [A]. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 283
Diagnostic procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 283
4.17 Disconnection/incorrect wiring detection function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 284
Input open-phase detection function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 284
Output open phase detection function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 286
Servo motor incorrect wiring detection function [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 288
4.18 Overload protection (electronic thermal) function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 290
4.19 Command offset [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 291
CHAPTER 5 MONITORING 293
5.1 Explanation of monitor signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 293
Name and description of the monitor signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 293
Signal block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 305
5.2 Checking with MR Configurator2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 308
"Display all" function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 308
Graph function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 308
I/O monitor display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 309
System configuration display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 310
5.3 Analog monitor [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 311
Setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 311
Setting details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 312
5.4 Analog monitor [A] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 316
Setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 316
Setting details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 317
CHAPTER 6 FUNCTIONAL SAFETY 321

9
CONTENTS
6.1 Functions and configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 321
Outline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 321
Outline of safety sub-functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 321
Risk assessments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 322
6.2 Signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 323
Explanation of signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 323
Power-on sequence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 325
6.3 Setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 326
Setting functional safety parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .326
Functional safety parameters that must be set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 327
Test operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 328
6.4 Safety sub-function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 329
Achievable safety level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 329
I/O function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 331
STO function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 342
SS1 function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 345
SS2/SOS function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 352
SLS function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 358
SSM function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 362
SBC function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 363
SDI function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 364
SLI function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 367
SLT function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 369
Status monitor (SM) function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 373
Multiple operation commands for safety sub-functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 373
Simultaneous operation of STO and SS1 functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 374
At alarm occurrence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 375
6.5 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 377
Parameter combinations that trigger [AL. 537.2 Parameter combination error A (safety sub-function)] . . . . . . 377
CHAPTER 7 NETWORK FUNCTION 379
7.1 IP address setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 379
Setting an IP address [G] [WG] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 379
Setting an IP address [A]. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .379
7.2 Managing accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 379
Setting an account. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 380
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .380
7.3 FTP server function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 381
Restrictions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 381
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .381
Directory structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 382
Steps of accessing the FTP server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 382
7.4 Firmware update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 383
REVISIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .384
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .385
TRADEMARKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .386

10 1 FUNCTION
1.1 Function explanation
1FUNCTION
1.1 Function explanation
This section lists the functions mentioned in this manual. For details of the functions, refer to each section indicated in the
detailed explanation column.
For the functions which are not listed here, refer to "FUNCTION" in the User's Manual (Introduction).
Control mode
*1 This control mode is not available for multi-axis servo amplifiers.
Network
Functions Detailed functions Description MR-J5
firmware
version
Detailed explanation
G A
CiA 402 control
mode
Cyclic synchronous position
mode (csp)
This function operates the servo motor in the
cyclic synchronous position mode.
A0 Page 18 Cyclic
synchronous position
mode (csp)
Cyclic synchronous velocity
mode (csv)
This function operates the servo motor in the
cyclic synchronous velocity mode.
A0 Page 20 Cyclic
synchronous velocity mode
(csv)
Cyclic synchronous torque
mode (cst)
This function operates the servo motor in the
cyclic synchronous torque mode.
A0 Page 22 Cyclic
synchronous torque mode
(cst)
Profile position mode (pp) This function operates the servo motor in the
profile position mode.
A5 Page 24 Profile
position mode (pp)
Profile velocity mode (pv) *1 This function operates the servo motor in the
profile velocity mode.
A5 Page 28 Profile
velocity mode (pv)
Profile torque mode (tq) *1 This function operates the servo motor in the
profile torque mode.
A5 Page 32 Profile torque
mode (tq)
Homing mode (hm)/homing This function either operates the servo motor in
the homing mode or performs homing.
A0 Page 40 Homing
mode (hm) and homing
Thrust/torque
control
Continuous operation to torque
control mode (ct)
This function enables smooth switching to torque
control from the position control mode or speed
control mode without stopping the servo motor.
This eliminates rapid change of speed and
torque, contributing to reduction in load to the
machine and high-quality product molding.
B0 Page 35 Continuous
operation to torque control
mode (ct)
Pulse/analog/DI
command
Position control mode (P)
(pulse train input)
This function operates the servo motor in the
position control mode by the pulse train input.
A0 Page 67 Position
control mode (P)
Speed control mode (S)
(Internal speed command/
analog speed command)
This function operates the servo motor in the
speed control mode by the internal speed
command or analog speed command.
A0 Page 71 Speed control
mode (S)
Torque control mode (T)
(Analog torque command)
This function operates the servo motor in the
torque control mode by the analog torque
command.
A0 Page 73 Torque
control mode (T)
Functions Detailed functions Description MR-J5
firmware
version
Detailed explanation
G A
Remote
maintenance
Firmware update This function updates the firmware of the servo
amplifier.
A0 A0 Page 383 Firmware
update

1 FUNCTION
1.1 Function explanation 11
1
Position detection
Operation function
Functions Detailed functions Description MR-J5
firmware
version
Detailed explanation
G A
Control method Scale measurement function This function connects the scale measurement
encoder in the state of the semi closed loop
control to transmit the position information of the
scale measurement encoder to the controller.
A5 Page 156 Scale
measurement function [G]
[WG]
Functions Detailed functions Description MR-J5
firmware
version
Detailed explanation
G A
Stop function Quick Stop This function stops the servo motor with a
specified method and switches to the servo-off
status.
A0 Page 144 Quick stop
[G] [WG]
Halt This function stops the servo motor while the
servo-on status is maintained.
A0 Page 146 Halt [G]
[WG]
Stroke limit function This function uses LSP (Forward rotation stroke
end) and LSN (Reverse rotation stroke end) to
limit the travel interval of the servo motor.
A0 A0 Page 90 Stroke limit
function [G] [WG]
Page 96 Stroke limit
function [A]
This function limits the travel interval of the servo
motor using FLS (Upper stroke limit) and RLS
(Lower stroke limit) via a controller.
A0 Page 90 Stroke limit
function [G] [WG]
Software position limit This function uses servo parameters to limit the
travel intervals by address. A function equivalent
to the stroke limit function can be set with the
servo parameter.
A0 Page 261 Software
position limit [G] [WG]
Command
generation
Command pulse selection The command pulse train form can be selected
from among three different types.
A0 Page 67 Position
control mode (P)
Rotation/travel direction
selection
This function sets the rotation direction of the
servo motor without changing the command
polarity.
A0 A0 Page 84 Rotation/
travel direction selection
[G] [WG]
Page 88 Rotation/
travel direction selection
[A]
Electronic gear This function performs positioning control with the
value obtained by multiplying the position
command from the upper controller by a set
electronic gear ratio.
A0 A0 Page 101 Electronic
gear function [G] [WG]
Page 106 Electronic
gear function [A]
Acceleration/deceleration
function
This function enables smooth acceleration/
deceleration.
A0 A0 Page 138
Acceleration/deceleration
function
S-pattern acceleration/
deceleration time constant
This function performs smooth acceleration and
deceleration.
A5 A0 Page 140 S-pattern
acceleration/deceleration
time constant [G] [WG]
Page 141 S-pattern
acceleration/deceleration
time constant [A]
Torque limit This function limits the servo motor torque. A0 A0 Page 262 Torque limit
[G] [WG]
Page 265 Torque limit
[A]
Speed limit This function limits the servo motor speed in the
torque control mode.
A0 A0 Page 268 Speed limit
[G] [WG]
Page 269 Speed limit
[A]
Command offset This function compensates the position/speed/
torque commands by adding a desired amount of
offset to the commands.
A5 Page 291 Command
offset [G] [WG]

12 1 FUNCTION
1.1 Function explanation
I/O, monitor
Option
Functions Detailed functions Description MR-J5
firmware
version
Detailed explanation
G A
DI/DO Input signal selection (device
selection)
This function assigns input devices such as LSP
(Forward rotation stroke end) to certain pins of
the connector.
A0 A0 Page 112 Assigning I/
O devices
Output signal selection (device
setting)
This function assigns output devices such as
MBR (Electromagnetic brake interlock) to certain
pins of the connector.
A0 A0 Page 112 Assigning I/
O devices
A/B/Z-phase output This function outputs the positions of the encoder
and linear encoder in the A/B/Z-phase signal.
A0 A0 Page 272 A/B/Z-phase
pulse output function
Analog input/output Analog monitor This function outputs the servo status in voltage
in real time.
A0 A0 Page 293
MONITORING
Monitor Power monitoring function This function calculates the running power and
the regenerative power from the data in the servo
amplifier such as speed and current. The power
consumption and other values are displayed on
MR Configurator2.
A0 A0
Touch probe Current position latch function This function latches the current position when
TPR1 (Touch probe 1), TPR2 (Touch probe 2), or
TPR3 (Touch probe 3) is turned on.
A5 Page 167 Touch probe
Functions Detailed functions Description MR-J5
firmware
version
Detailed explanation
G A
Regenerative
capacity
enhancement
Regenerative option Use this function if the built-in regenerative
resistor of the servo amplifier does not have
sufficient regenerative capacity for the generated
regenerative power.
A0 A0 Page 115
Regenerative option
selection

1 FUNCTION
1.1 Function explanation 13
1
Protective functions
Functions Detailed functions Description MR-J5
firmware
version
Detailed explanation
G A
Alarm Alarm function This function displays an alarm or warning when
an error occurs during operation. When an alarm
occurs, ALM (Malfunction) turns off and stops the
servo motor. When a warning occurs, WNG
(Warning) will turn on. The servo motor may stop
or continue operation depending on the warning.
A0 A0 Page 116 Alarm
function
Alarm history clear This function clears alarm histories. A0 A0 Page 118 Alarm
history [G] [WG]
Page 120 Alarm
history [A]
Power error
detection
Disconnection detection
function
This function detects a disconnection in the main
circuit power supply input and the servo motor
power supply output.
A0 A0 Page 284
Disconnection/incorrect
wiring detection function
Coasting distance
reduction
Forced stop deceleration
function
This function decelerates the servo motor to a
stop at EM2 (Forced stop 2) off or when there is
an alarm.
A0 A0 Page 123 Forced stop
deceleration function
Drop protection Electromagnetic brake interlock
function
This function operates the electromagnetic brake
at servo off and error occurrence, and prevents
the vertical axis from dropping.
A0 A0 Page 126
Electromagnetic brake
interlock function
Vertical axis freefall prevention
function
This function moves the axis up by the
mechanical backlash amount of the
electromagnetic brake to prevent damage to
machines.
A0 A0 Page 136 Vertical axis
freefall prevention function

14 1 FUNCTION
1.1 Function explanation
Functional safety
Functions Detailed functions Description MR-J5
firmware
version
Detailed explanation
G A
Safety sub-function STO (Safe torque off) This function electrically shuts off the servo motor
driving energy with input signals from external
devices (shut-off by the secondary-side output).
This is equivalent to the stop category 0 of IEC/
EN 60204-1.
B2 Page 342 STO
function
SS1 (Safe stop 1) This function starts deceleration with input
signals from external devices. After the specified
time to confirm the motor stop, the STO function
is executed (SS1). This is equivalent to the stop
category 1 of IEC/EN 60204-1.
B2 Page 345 SS1
function
SS2 (Safe stop 2) This function starts deceleration with input
signals from external devices. After the specified
time to confirm the motor stop, the SOS function
is executed (SS2). This is equivalent to the stop
category 2 of IEC/EN 60204-1.
B2 Page 352 SS2/SOS
function
SOS (Safe operating stop) This function monitors whether the servo motor
stops within the prescribed range. Energy is
supplied to the servo motor.
B2 
SLS (Safely-limited speed) This function monitors whether the speed is
within the prescribed speed limit. If the speed
exceeds the specified speed limit, the STO will
shut off energy.
B2 Page 358 SLS
function
SSM (Safe speed monitor) This function outputs signals when the servo
motor speed is below the prescribed speed.
B2 Page 362 SSM
function
SBC (Safe brake control) This function outputs signals for controlling the
external brake.
B2 Page 363 SBC
function
SDI (Safe direction) This function monitors whether the servo motor
travels in the specified direction. If the servo
motor travels in a direction different from the
specified direction, the STO will shut off energy.
B2 Page 364 SDI function
SLI (Safely-limited increment) This function monitors whether the travel
distance of the servo motor is within the specified
range. If the travel distance of the servo motor
exceeds the specified range, the STO will shut off
energy.
B2 Page 367 SLI function
SLT (Safely-limited torque) This function monitors whether the torque is
below the specified torque. If the torque exceeds
the specified torque, the STO will shut off energy.
B2 Page 369 SLT function
Status monitor (SM: Status
monitor)
This function outputs the statuses of the safety
sub-functions as signals. This is a function
designed specifically for the safety sub-functions
and differs from the function defined in IEC/EN
61800-5-2.
B2 Page 373 Status
monitor (SM) function

1 FUNCTION
1.1 Function explanation 15
1
Instantaneous power failure measures
Functions Detailed functions Description MR-J5
firmware
version
Detailed explanation
G A
Tough drive SEMI-F47 function This function uses the electrical energy charged
in the capacitor to avoid triggering [AL. 010
Undervoltage] in case that an instantaneous
power failure occurs during operation. Use a 3-
phase power supply for the input power supply of
the servo amplifier. Using a 1-phase 200 V AC for
the input power supply will not comply with SEMI-
F47 standard.
A0 A0 Page 154 Compliance
with SEMI-F47 standard
Tough drive function This function makes the equipment continue
operating even under conditions where an alarm
would normally occur. There are two types of
tough drive function: the vibration tough drive and
the instantaneous power failure tough drive.
A0 A0 Page 150 Tough drive
function

16 1 FUNCTION
1.1 Function explanation
Diagnostics
History
Functions Detailed functions Description MR-J5
firmware
version
Detailed explanation
G A
Drive data
diagnosis
Drive recorder This function continuously monitors the servo
status and records the state transition before and
after an alarm for a fixed period of time. The
recorded data can be checked by the Waveform-
Display button on the drive recorder window of
MR Configurator2 being clicked.
A0 A0 Page 234 Drive
recorder
Graph function This function obtains the servo status in the
graph.
A0 A0 Page 308 Graph
function
Failure diagnosis Encoder communication
diagnosis function
This function diagnoses with MR Configurator2
whether the encoder communication error is
caused by the circuit malfunction of the servo
amplifier or by the malfunction of the cables/
encoder.
A0 A0 Page 282 Encoder
communication diagnosis
function
Service life
diagnosis
Servo amplifier life diagnosis
function
This function enables checking of the cumulative
energization time, the number of the inrush relay
on/off times, and the number of dynamic brake
usage times. It gives an indication of the
replacement time for parts on the servo amplifier
with a service life (such as the capacitor and the
relay) before they malfunction. MR Configurator2
is required for this function.
A0 A0 Page 280 Servo
amplifier life diagnosis
function
Motor life diagnosis function This function predicts failures of the equipment
and the servo motor based on the machine total
travel distance. It gives an indication of the
replacement time for the servo motor.
A0 A0
Machine diagnosis function This function uses the data in the servo amplifier
to estimate the friction and vibrational component
of the drive system in the equipment and to
recognize an error in machine parts such as ball
screws and bearings.
A0 A0 Page 177 Machine
diagnosis
This function automatically sets the threshold
used for detecting the error of machine parts
such as ball screws and bearings. It outputs the
warning when the friction, vibrational component,
and total revolution of the servo motor are out of
the set threshold. The error in the machine parts
such as ball screws and bearings can be
detected automatically.
A0 A0
This function estimates the friction of gears and
loosening of belts (decrease in the belt tension),
and detects errors in the gears and belts.
A0 A0
System diagnosis System configuration
information
This function uses MR Configurator2 to monitor
the servo amplifier model, connected servo
motor, encoder, and other information.
A0 A0 Page 310 System
configuration display
Functions Detailed functions Description MR-J5
firmware
version
Detailed explanation
G A
Alarm history This function saves information of the alarm that
occurred in the servo amplifier. The information is
saved in chronological order and used for
occasions such as analyzing the cause of the
alarm.
A0 A0 Page 118 Alarm
history [G] [WG]
Page 120 Alarm
history [A]

2 CONTROL MODE
2.1 Control mode [G] [WG] 17
2
2CONTROL MODE
2.1 Control mode [G] [WG]
The method for driving a servo motor varies depending on each control mode. The characteristics of each control mode are
shown in the following.
*1 Available on servo amplifiers with firmware version A5 or later.
*2 Available on servo amplifiers with firmware version B0 or later.
Control switching
In the motion mode, the control mode can be switched with [Modes of operation (Obj. 6060h)]. Switching the control modes
with [Modes of operation (Obj. 6060h)] applies to the cyclic modes (csp, csv, and cst), profile modes (pp, pv, and tq), homing
mode (hm), and continuous operation to torque control mode (ct).
Category Control mode Symbol Description
CiA 402 control mode Cyclic synchronous position
mode
csp This is a control mode to drive servo motors by receiving a position
command at a constant period in the synchronous communication with a
controller.
Use an absolute position address for the command.
Cyclic synchronous velocity
mode
csv This is a control mode to drive servo motors by receiving a speed
command at a constant period in the synchronous communication with a
controller.
Cyclic synchronous torque mode cst This is a control mode to drive servo motors by receiving a torque
command at a constant period in the synchronous communication with a
controller.
Profile position mode *1 pp This is a positioning mode to drive servo motors by receiving an end
position command via either synchronous or asynchronous
communication with a controller.
Use an absolute position address or a relative position address for the
command.
Profile velocity mode *1 pv This is a control mode to drive servo motors by receiving a target speed
command via either synchronous or asynchronous communication with a
controller.
Profile torque mode *1 tq This is a control mode to drive servo motors by receiving a target torque
command via either synchronous or asynchronous communication with a
controller.
Homing mode hm This is a control mode to perform homing with the method specified by the
controller.
Thrust/torque control Continuous operation to torque
control mode *2
ct This function enables smooth switching to torque control from the position
control mode or speed control mode without stopping the servo motor.
This eliminates rapid change of speed and torque, contributing to
reduction in load to the machine and high-quality product molding.

18 2 CONTROL MODE
2.1 Control mode [G] [WG]
Cyclic synchronous position mode (csp)
The functions and related objects of the cyclic synchronous position mode (csp) are shown in the following.
Related objects
For details on the objects, refer to the User's Manual (Object Dictionary).
Index Sub Object Name Description
607Ah VAR Target position Command position
Unit: pos units
607Bh 0 ARRAY Position range limit Number of entries
1 Min position range limit Minimum value of the position range limit
Unit: pos units
2 Max position range limit Maximum value of the position range limit
Unit: pos units
607Dh 0 ARRAY Software position limit Number of entries
1 Min position limit Minimum position address
Unit: pos units
2 Max position limit Maximum position address
Unit: pos units
6085h VAR Quick stop deceleration Deceleration at deceleration to a stop with Quick stop
Unit: acc units
605Ah VAR Quick stop option code Operation setting for Quick stop
Page 144 Quick stop [G] [WG]
6080h VAR Max motor speed Servo motor maximum speed
Unit: r/min, mm/s
6063h VAR Position actual internal value Current position
Unit: Enc inc
6064h VAR Position actual value Current position
Unit: pos units
606Ch VAR Velocity actual value Current speed
Unit: vel units
6077h VAR Torque actual value Current torque
Unit: 0.1 % (with rated torque being 100 %)
6092h 0 ARRAY Feed constant Travel distance per revolution of an output shaft
1 Feed Travel distance setting
2 Shaft revolutions Number of servo motor shaft revolutions
60F4h VAR Following error actual value Droop pulses
Unit: pos units
60FAh VAR Control effort Position control loop output (speed command)
Unit: vel units
Position
trajectry
Generator
[Quick stop deceleration (Obj. 6085h)]
[Quick stop option code (Obj. 605Ah)]
[Torque offset (Obj. 60B2h)]
[Velocity offset (Obj. 60B1h)]
[Position offset (Obj. 60B0h)]
[Target position (Obj. 607Ah)]
[Gear ratio (Obj. 6091h)]
[Polarity (Obj. 607Eh)]
[Following error actual value
(Obj. 60F4h)]
[Position actual value
(Obj. 6064h)]
[Velocity actual value (Obj. 606Ch)]
[Torque actual value (Obj. 6077h)]
[pos units] +
×
×
××
×
×
×
×
×
-
[pos units]
[Enc inc]
[Control effort
(Obj. 60FAh)]
[Position actual internal value
(Obj. 6063h)]
Position
limit
function
Position
control
Velocity
control
Torque
control Motor
Encoder
[Positive torque limit value (Obj. 60E0h)]
[Negative torque limit value (Obj. 60E1h)]
[Software position limit (Obj. 607Dh)]
[pos units]
×
×
+
+
+
+
+
+
