Mitsubishi MELSEC System Q User manual

DANGER
CAUTION
Mitsubishi General-Purpose
Programmable Logic Controller
QJ61BT11 Control & Communication
Link System Master/Local Module
Thank you for purchasing the Mitsubishi general-purpose PLC MELSEC-Q Series.
Before starting use, please read through this manual and the details manual to
ensure correct usage.
User's Manual
(Hardware)
Type QJ61BT11-U-H-JE
Type code 13JQ41
IB(NA)-0800026-C(0009)MEE
© 1999 MITSUBISHI ELECTRIC CORPORATION
!SAFETY PRECAUTIONS !
(Always read these instructions before using this equipment.)
Before using this product, please read this manual and the relevant manuals introduced in
this manual carefully and pay full attention to safety to handle the product correctly.
The instructions given in this manual are concerned with this product. For the safety
instructions of the programmable controller system, please read the CPU module user's
manual.
In this manual, the safety instructions are ranked as "DANGER" and "CAUTION".
Indicates that incorrect handling may cause hazardous conditions,
resulting in death or severe injury.
Indicates that incorrect handling may cause hazardous conditions,
resulting in medium or slight personal injury or physical damage.
Note that the CAUTION level may lead to a serious consequence according to the
circumstances.
Always follow the instructions of both levels because they are important to personal safety.
Please save this manual to make it accessible when required and always forward it to the
end user.
Downloaded from ManualsNet.com search engine

[DESIGN PRECAUTIONS] CAUTION
!Do not bunch the control wires or communication cables with the main circuit or power
wires, or install them close to each other.
They should be installed 100mm (3.9inch) or more from each other.
Not doing so could result in noise that may cause malfunction.
[INSTALLATION PRECAUTIONS]
CAUTION
!Use the PLC in an environment that meets the general specifications contained in the
CPU user's manual to use.
Using this PLC in an environment outside the range of the general specifications may
cause electric shock, fire, malfunction, and damage to or deterioration of the product.
!When installing the module, securely insert the module fixing tabs into the mounting
holes of the base unit while pressing the installation lever located at the bottom of the
module downward.Improper installation may result in malfunction , breakdown or
dropping out of the module.
Securely fix the module with screws if it is subject to vibration during use.
!Tighten the screws within the range of specified torque.
If the screws are loose, it may cause fallout, short circuits, or malfunction.
If the screws are tightened too much, it may cause damage to the screw and/or the
module, resulting in fallout, short circuits or malfunction.
!Switch all phases of the external power supply off when mounting or removing the
module. Not doing so may cause damage to the module.
!Do not directly touch the conductive area or electronic components of the module.
Doing so may cause malfunction or failure in the module.
[WIRING PRECAUTIONS] CAUTION
!When turning on the power and operating the module after wiring is completed, always
attach the terminal cover that comes with the product.
There is a risk of malfunction if the terminal cover is not attached.
!Tighten the terminal screws within the range of specified torque.
If the terminal screws are loose, it may cause fallout, short circuits, or malfunction.
If the terminal screws are tightened too much, it may cause damage to the screw
and/or the module, resulting in fallout, short circuits or malfunction.
!Be careful not to let foreign matters such as sawdust or wire chips get inside the
module. These may cause fires, failure or malfunction.
!The top surface of the module is covered with protective film to prevent foreign objects
such as cable offcuts from entering the module when wiring.
Do not remove this film until the wiring is complete. Before operating the system, be
sure to remove the film to provide adequate heat ventilation.
!Be sure to fix communication cables or power supply cables leading from the module
by placing them in the duct or clamping them.
Cables not placed in the duct or without clamping may hang or shift, allowing them to
be accidentally pulled, which may cause a module malfunction and cable damage.
!When removing the communication cable or power supply cable from the module, do
not pull the cable. When removing the cable with a connector, hold the connector on
the side that is connected to the module.
When removing the cable connected to the terminal block, first loosen the screws on
the part that is connected to the terminal block. Pulling the cable that is still connected
to the module may cause malfunction or damage to the module or cable.
Downloaded from ManualsNet.com search engine

About the Manuals
The following manuals are also related to this product.
Order them if necessary.
Related Manuals
Manual name Manual number
(Model code)
QJ61BT11 Control & Communication Link System Master/Local
Module User's Manual SH-080016 (13JL91)
Conformation to the EMC Directive and Low Voltage Instruction
For details on making Mitsubishi PLC conform to the EMC directive and low voltage instruction
when installing it in your product,please refer to Chapter 3,"EMC Directive and Low Voltage
Instruction"of the PLC CPU User's Manual (Hardware).The CE logo is printed on the rating plate on
the main body of the PLC that conforms to the EMC directive and low voltage instruction.
1. OVERVIEW
This manual explains the specifications, names of each part and the settings, etc., for the QJ61BT11
Control & Communication Link System (abbreviated as CC-Link from here on) Master/Local Module
(hereinafter QJ61BT11) used in combination with the MELSEC-Q Series PLC CPU. After unpacking,
confirm that the following products are enclosed.
Part name Qty.
QJ61BT11 body 1
Terminal resister 110 Ω1/2W (brown, brown, brown) 2
Terminal resister 130 Ω1/2W (brown, orange, brown) 2
1.1 Definition of Ver.1.10
The module of which the cable length between station and station is uniformly 20cm or more by
improving the conventional limit of the cable length between station and station is defined as Ver.1.10.
The conventional modules are defined as Ver.1.00.
The conditions for setting the cable length between station and station uniformly to 20cm or more are
indicated below.
1) All modules configuring the CC-Link system must use Version 1.10.
2) All data link cables must be Version 1.10 compatible CC-Link dedicated cable.
Point
The Ver.1.00 specifications are applied for the maximum overall cable distance and the cable
length between station and station, when the CC-Link system is configured with the modules and
cables of Ver.1.00 and Ver.1.10.
(1) Checking Version 1.10
The “CC-Link”logo is stamped on the “plate”for the Version 1.10 modules.
2. Performance specifications
2.1 Performance specifications
The performance specifications of the QJ61BT11 are shown below.
Refer to the User's Manual of the CPU in use for the general specifications of the QJ61BT11.
Downloaded from ManualsNet.com search engine

Item Specifications
Transmission rate Select from 156kbps/625kbps/2.5Mbps/5Mbps/10Mbps
Maximum overall cable distance
(Maximum transmission distance) Differs according to transmission rate (Refer to section 2.2.)
Maximum No. of connected
modules (for master station) 64 modules
No. of occupied stations (for local
station) One station or four
Maximum No. of link points per
system
Remote input/output (RX, RY) : 2048 points
Remote register (RWw) : 256 points (Master station →remote
device station/local station/intelligent
device station/standby master station)
Remote register (RWr) : 256 points (Remote device station/local
station/intelligent device station/standby
master station →master station)
No. of link points per remote
station/local station/intelligent
device station/standby master
station
Remote input/output (RX, RY) : 32 points (30 points for local station)
Remote register (RWw) : 4 points (Master station →remote device
station/local station/intelligent device
station/standby master station)
Remote register (RWr) : 4 points (Remote device station/local
station/intelligent device station/standby
master station →master station)
Communication method Polling method
Synchronization method Flag synchronous system
Coding method NRZI method
Transmission path Bus (RS-485)
Transmission format HDLC compliant
Error control system CRC (X16+X12+X5+1)
Connection cable CC-Link dedicated cable/CC-Link dedicated high-performance cable*
RAS functions "Automatic return function "Slave station cutoff function
"Error detection with link special relay/register
No. of I/O occupied points 32 points (I/O assignment: 32 intelligent points)
5VDC internal current
consumption (A) 0.46
Weight (kg) 0.12
* The CC-Link dedicated cable and CC-Link dedicated high-performance cable cannot be used
together. Also attach the terminal resister which matches the kind of the cable.
2.2 Maximum overall cable distance
The maximum overall cable distance differs according to the transmission rate. For the relationship
between transmission rate and max. total cable length, refer to CC-Link Catalog, L(NA)-74108143E.
2.3 CC-Link dedicated cable specifications
Use the CC-Link dedicated cable with the CC-Link system.
The performance of the CC-Link system cannot be guaranteed with cables other than the CC-Link
dedicated cables. For the specifications of CC-Link dedicated cable and the reference office, refer to
CC-Link catalog L (NA) 74108143E.
3. Mounting and installation
3.1 Precautions for handling
The precautions for handling the module are given below.
1) The module case is made of resin, so do not drop it or apply strong impacts on it.
2) Crimp terminals with insulated sleeves cannot be used with the terminal block. Covering the wire
connection section of the crimp terminals with mark tubes or insulated tubes is recommended.
Downloaded from ManualsNet.com search engine

3) Tighten the module installation screws within the following ranges.
Screw position Tightening torque range
Module installation screw (M3 screw) 36 to 48N "cm
Terminal block terminal screw (M3 screw) 42 to 58N "cm
Terminal block installation screw (M3.5 screw) 66 to 89N "cm
POINT
Always turn the power of the corresponding station OFF before mounting or removing the terminal
block. If the terminal block is mounted or removed without turning the corresponding station's power
OFF, correct data transmission by the mounted or removed station will not be guaranteed.
3.2 Installation environment
Refer to the User's Manual of the CPU module in use.
4. Names and settings of each part
NC
MODE
X1
X10
RUN
MST
SD
ERR.
L RUN
QJ61BT11
S MST
RD
L ERR.
STATION NO.
DA
NC
SLD
DB
DG
1
3
5
2
4
6
7
(FG)
0
5
8
3
0
8
C
4
0
5
8
3
1)
2)
3)
4)
No. Name Details
Confirms the data link state by turning the LEDs ON and OFF.
LED name Details
RUN ON: Module is normal
OFF: Watch dog timer error
ERR. ON: Communication error in all stations
Turns ON when the following type of error occurs.
"When switch settings are incorrect
"When master station is duplicated on same line
"When there is an error in the parameter details
"When the data link monitor timer functioned
"When the cable is disconnected, or the transmission route is
being affected by noise, etc.
Flicker: Station with communication error found
MST ON: Operating as master station
S MST ON: Operating as standby master station
L RUN ON: Executing data link
L ERR. ON: Communication error (host)
Flicker: Setting of switch 2) or 3) was changed while power was ON
SD ON: Sending data
1) LED display
RUN
MST
SD
ERR.
L RUN
QJ61BT11
S MST
RD
L ERR.
RD ON: Receiving data
Downloaded from ManualsNet.com search engine

No. Name Details
2) Station No. setting
switch
X1
X10
STATION NO.
0
5
9
4
8
3
7
2
6
1
0
5
9
4
8
3
7
2
6
1
Set the module's station No. (Default setting: 0)
<Setting range>
Master station : 0
Local station : 1 to 64
Standby master station : 1 to 64
The "ERR." LED will turn ON if a value other than 0 to 64 is set.
Set the module's transmission rate and operation state. (Default setting:
0)
No. Transmission rate setting Mode
0 Transmission rate 156kbps
1 Transmission rate 625kbps
2 Transmission rate 2.5Mbps
3 Transmission rate 5Mbps
4 Transmission rate 10Mbps
On-line
5 Transmission rate 156kbps
6 Transmission rate 625kbps
7 Transmission rate 2.5Mbps
8 Transmission rate 5Mbps
9 Transmission rate 10Mbps
Line test
When station NO. setting switch
is 0: Line test 1
When station NO. setting switch is
1 to 64: Line test 2
A Transmission rate 156kbps
B Transmission rate 625kbps
C Transmission rate 2.5Mbps
D Transmission rate 5Mbps
E Transmission rate 10Mbps
Hardware test
3) Transmission rate/
mode setting switch
MODE
0
8
F
7
E
6
D
5
C
4
B
3
A
2
9
1
F Setting is inhibited.
4) Terminal block
NC
DA
NC
SLDDB
DG
2
4
6
(FG)
1
3
5
7
Connect the CC-Link dedicated cable for the data link.
Refer to section 5.1 for details on the connection methods.
The terminals SLD and FG are connected inside the module.
This is a 2-piece method terminal block, and the module can be
exchanged without disconnecting the signal wires connected
to the terminal block.
POINT
The station No. setting switch and transmission rate/mode setting switch details are validated when
the module power is turned OFF to ON or when the PLC CPU is reset. If the setting details are
changed while the module's power is ON, turn the module's power OFF and ON, or reset the PLC
CPU.
5. External wiring
5.1 CC-Link dedicated cable wiring
The methods for connecting the CC-Link dedicated cable for the master module, local module,
standby master module, remote module and intelligent module.
Downloaded from ManualsNet.com search engine

1) The cable connecting sequence is not related with the station No.
2) Be sure to connect “terminal resistor” of the unit accessory to the units on both ends CC-Link
system. Connect the terminal resistor between “DA” and “DB”.
3) In CC-Link system, the terminal resistor is different depending on the applied cable.
"CC-Link dedicated cable : 110Ω1/2W (brown, brown, brown)
"CC-Link dedicated high-performance cable : 130Ω1/2W (brown, orange, brown)
4) The master module can be connected to a place other than both ends.
5) A star connection cannot be used.
6) The connection method is shown below.
DA
DB
DG
SLD
FG
DA
DB
DG
SLD
FG
DA
DB
DG
SLD
FG
Master module Remote module
CC-Link
dedicated cable
Local module
Terminal
resistor
Terminal
resistor
CC-Link
dedicated cable
IMPORTANT
The CC-Link dedicated cable and CC-Link dedicated high-performance cable cannot be used
together. If used together, correct data transmission will not be guaranteed.
POINT
Connect the shielded wire of the CC-Link dedicated cable to “SLD” of each module, and ground
both ends of the shielded wire using D type grounding via “FG”.
The SLD and FG are connected into the module.
6. Outline dimensions
NC
MODE
X1
X10
RUN
MST
SD
ERR.
L RUN
QJ61BT11
S MST
RD
L ERR.
STATION NO.
DA
NC
SLDDB
DG
1
3
5
2
4
6
7
(FG)
0
5
8
3
7
2
0
8
F
7
D
5
C
4
B
3
9
1
0
5
8
3
7
2
98(3.86)
90(3.54) 27.4(1.08)
Unit: mm(inch)
Downloaded from ManualsNet.com search engine

Warranty
Mitsubishi will not be held liable for damage caused by factors found not to be the cause of
Mitsubishi; machine damage or lost profits caused by faults in the Mitsubishi products;
damage, secondary damage, accident compensation caused by special factors
unpredictable by Mitsubishi; damages to products other than Mitsubishi products; and to
other duties.
For safe use
"This product has been manufactured as a general-purpose part for general industries, and
has not been designed or manufactured to be incorporated in a device or system used in
purposes related to human life.
"Before using the product for special purposes such as nuclear power, electric power,
aerospace, medicine or passenger movement vehicles, consult with Mitsubishi.
"This product has been manufactured under strict quality control. However, when installing
the product where major accidents or losses could occur if the product fails, install
appropriate backup or failsafe functions in the system.
U.S.A Mitsubishi Electric Automation Inc.
500 Corporate Woods Parkway Vernon
Hills, IL 60061
Tel : [phone]
Brazil MELCO-TEC Rep. Com.e Assessoria
Tecnica Ltda.
Av. Rio Branco, 123-15 ,and S/1507,
Rio de Janeiro, RJ CEP 20040-005,
Brazil
Tel : [phone]
Germany Mitsubishi Electric Europe B.V. German
Branch
Gothaer Strasse 8 D-40880 Ratingen,
GERMANY
Tel : [phone]
U.K Mitsubishi Electric Europe B.V. UK
Branch
Travellers Lane, Hatfield, Herts., AL10
8XB,UK
Tel : [phone]
South Africa MSA Manufacturing (Pty) Ltd.
P O Box 39733 Bramley 201 8
Johannesburg, South Africa
Tel : [phone]
Hong Kong Ryoden International Ltd.
10th Floor, Manulife Tower, 169 Electric
Road, North Point, HongKong
Tel : [phone]
China Ryoden International Shanghai Ltd.
3F Block5 Building Automation
Instrumentation Plaza 103 Cao Bao Rd.
Shanghai 200233 China
Tel : [phone]
HEAD OFFICE:MITSUBISHI DENKI BLDG MARUNOUCHI TOKYO 100-8310 TELEX:J24532 CABLE MELCO TOKYO
NAGOYA WORKS:1-14, YADA-MINAMI 5, HIGASHI-KU, NAGOYA, JAPAN
Taiwan Setsuyo Enterprise Co., Ltd.
6F., No.105 Wu-Kung 3rd.RD, Wu-Ku
Hsiang, Taipei Hsine, Taiwan R.O.C.
Tel : [phone]
Korea STC Techno Seoul Co., Ltd.
1F Dong Seo Game Channel Bldg.,
660-11, Deungchon-dong Kangsec-ku,
Seoul, Korea
Tel : [phone]
Singapore Mitsubishi Electric Asia Pte, Ltd.
307 ALEXANDRA ROAD #05-01/02,
MITSUBISHI ELECTRIC BUILDING
SINGAPORE 159943
Tel : [phone]
Thailand F. A. Tech Co.,Ltd.
1138/33-34 Rama 3 Road, Yannawa,
Bangkok 10120, Thailand
Tel : [phone]
Indonesia P.T. Autoteknindo SUMBER MAKMUR
Kompleks Agung Sedayu Propertindo
(Harco Mangga Dua)
Blok H No.4 JI Mangga Dua Raya
Jakarta Pusat 10730-Indonesia.
Tel : [phone]
India Messung Systems Put,Ltd.
Electronic Sadan NO:111 Unit No15,
M.I.D.C BHOSARI,PUNE-411026
Tel : [phone]
Australia Mitsubishi Electric Australia Pty. Ltd.
348 Victoria Road, PostalBag, No 2,
Rydalmere, N.S.W 2116, Australia
Tel : [phone]
Country/Region Sales office/Tel Country/Region Sales office/Tel
When exported from Japan, this manual does not require application to the Ministry
of International Trade and Industry for service transaction permission.
Specifications subject to change without notice.
Printed in Japan on recycled paper.
Downloaded from ManualsNet.com search engine
