Mitsubishi MELSEC Q Series User manual

Channel Isolated High Resolution Analog-Digital
Converter Module / Channel Isolated High
Resolution Analog-Digital Converter Module (With
Signal Conditioning Function) User's Manual
-Q64AD-GH
-Q62AD-DGH
-GX Configurator-AD (SW2D5C-QADU-E)

A - 1 A - 1
SAFETY PRECAUTIONS 
(Always read these instructions before using this equipment.)
Before using this product, please read this manual and the relevant manuals introduced in this manual
carefully and pay full attention to safety to handle the product correctly.
The instructions given in this manual are concerned with this product. For the safety instructions of the
programmable controller system, please read the user's manual for the CPU module to use.
In this manual, the safety instructions are ranked as " !WARNING" and " !CAUTION".
Note that the !CAUTION level may lead to a serious consequence according to the circumstances.
Always follow the instructions of both levels because they are important to personal safety.
Please store this manual in a safe place and make it accessible when required. Always forward it to the
end user.
[DESIGN PRECAUTION]
!WARNING
Do not write data into the "system area" of the buffer memory of intelligent function modules.
Also, do not use any "prohibited to use" signals as an output signal to an intelligent function
module from the programmable controller CPU.
Writing data into the "system area" or outputting a signal for "prohibited to use" may cause a
programmable controller system malfunction.
!CAUTION
Do not bunch the control wires or communication cables with the main circuit or power wires, or
install them close to each other.
They should be installed 100mm(3.9inch) or more from each other.
Not doing so could result in noise that may cause malfunction.

A - 2 A - 2
[INSTALLATION PRECAUTIONS]
!CAUTION
Use the programmable controller in an environment that meets the general specifications
contained in the user's manual of the CPU module to use.
Using this programmable controller in an environment outside the range of the general
specifications may cause electric shock, fire, malfunction, and damage to or deterioration of the
product.
While pressing the installation lever located at the bottom of module, insert the module fixing tab
into the fixing hole in the base unit until it stops. Then, securely mount the module with the fixing
hole as a supporting point.
Improper installation may result in malfunction, breakdown or the module coming loose and
dropping.
Securely fix the module with screws if it is subject to vibration during use.
Tighten the screws within the range of specified torque.
If the screws are loose, it may cause the module to fallout, short circuits, or malfunction.
If the screws are tightened too much, it may cause damage to the screw and/or the module,
resulting in fallout, short circuits or malfunction.
Be sure to shut off all phases of the external power supply used by the system before mounting
or removing the module.
Not doing so may cause damage to the module.
In the system where a CPU module supporting the online module change is used and on the
MELSECNET/H remote I/O stations, modules can be replaced online (during energizing).
However, there are some restrictions on replaceable modules and the replacement procedures
are predetermined for each module.
For details, refer to the chapter of the online module change in this manual.
Do not directly touch the conductive area or electronic components of the module.
Doing so may cause malfunction or failure in the module.
[WIRING PRECAUTIONS]
!WARNING
After installation and wiring, attach the included terminal cover to the module before turning it on
for operation.
Failure to do so may result in electric shock.

A - 3 A - 3
[WIRING PRECAUTIONS]
!CAUTION
Always ground the FG terminal of the Q62AD-DGH.
Not doing so can cause an electric shock or malfunction.
When turning on the power and operating the module after wiring is completed, always attach
the terminal cover that comes with the product.
There is a risk of electric shock if the terminal cover is not attached.
Use applicable solderless terminals and tighten them with the specified torque.If any solderless
spade terminal is used, it may be disconnected when the terminal screw comes loose, resulting
in failure.
Tighten the terminal screws within the range of specified torque.
Undertightening can cause short circuit, fire, or malfunction.
Overtightening can damage the screw and/or module, resulting in drop, short circuit, or
malfunction.
Be careful not to let foreign matter such as sawdust or wire chips get inside the module.
They may cause fires, failure or malfunction.
The top surface of the module is covered with protective film to prevent foreign objects such as
cable offcuts from entering the module when wiring.
Do not remove this film until the wiring is complete.
Before operating the system, be sure to remove the film to provide adequate ventilation.
[STARTING AND MAINTENANCE PRECAUTIONS]
!WARNING
Do not touch the connector while the power is on.
Doing so may cause electric shock or malfunction.
Be sure to switch off all phases of the externally supplied power used in the system before
cleaning the module or retightening the terminal screws, connector mounting screws, and
module fixing screws.
Not doing so may cause electric shock, or failure and malfunction of the module.
If the screws are loose, it may cause the module to fallout, short circuits, or malfunction.
If the screws are tightened too much, it may cause damages to the screws and/or the module,
resulting in the module falling out, short circuits or malfunction.

A - 4 A - 4
[STARTING AND MAINTENANCE PRECAUTIONS]
!CAUTION
Do not disassemble or modify the modules.
Doing so could cause failure, malfunction injury or fire.
Be sure to shut off all phases of the external power supply used by the system before mounting
or removing the module.
Not doing so may cause failure or malfunction of the module.
In the system where a CPU module supporting the online module change is used and on the
MELSECNET/H remote I/O stations, modules can be replaced online (during energizing).
However, there are some restrictions on replaceable modules and the replacement procedures
are predetermined for each module.
For details, refer to the chapter of the online module change in this manual.
Do not install/remove the module to/from the base unit, or the terminal block to/from the module
more than 50 times after the first use of the product. (IEC 61131-2 compliant)
Failure to do so may cause malfunction.
Always make sure to touch the grounded metal to discharge the electricity charged in the body,
etc., before touching the module.
Failure to do so may cause a failure or malfunctions of the module.
[DISPOSAL PRECAUTIONS]
!CAUTION
When disposing of this product, treat it as industrial waste.

A - 5 A - 5
CONDITIONS OF USE FOR THE PRODUCT 
(1) Mitsubishi programmable controller ("the PRODUCT") shall be used in conditions;
i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major
or serious accident; and
ii) where the backup and fail-safe function are systematically or automatically provided outside of the
PRODUCT for the case of any problem, fault or failure occurring in the PRODUCT.
(2) The PRODUCT has been designed and manufactured for the purpose of being used in general
industries.
MITSUBISHI SHALL HAVE NO RESPONSIBILITY OR LIABILITY (INCLUDING, BUT NOT LIMITED
TO ANY AND ALL RESPONSIBILITY OR LIABILITY BASED ON CONTRACT, WARRANTY, TORT,
PRODUCT LIABILITY) FOR ANY INJURY OR DEATH TO PERSONS OR LOSS OR DAMAGE TO
PROPERTY CAUSED BY the PRODUCT THAT ARE OPERATED OR USED IN APPLICATION NOT
INTENDED OR EXCLUDED BY INSTRUCTIONS, PRECAUTIONS, OR WARNING CONTAINED IN
MITSUBISHI'S USER, INSTRUCTION AND/OR SAFETY MANUALS, TECHNICAL BULLETINS AND
GUIDELINES FOR the PRODUCT.
("Prohibited Application")
Prohibited Applications include, but not limited to, the use of the PRODUCT in;
Nuclear Power Plants and any other power plants operated by Power companies, and/or any other
cases in which the public could be affected if any problem or fault occurs in the PRODUCT.
Railway companies or Public service purposes, and/or any other cases in which establishment of a
special quality assurance system is required by the Purchaser or End User.
Aircraft or Aerospace, Medical applications, Train equipment, transport equipment such as Elevator
and Escalator, Incineration and Fuel devices, Vehicles, Manned transportation, Equipment for
Recreation and Amusement, and Safety devices, handling of Nuclear or Hazardous Materials or
Chemicals, Mining and Drilling, and/or other applications where there is a significant risk of injury to
the public or property.
Notwithstanding the above, restrictions Mitsubishi may in its sole discretion, authorize use of the
PRODUCT in one or more of the Prohibited Applications, provided that the usage of the PRODUCT is
limited only for the specific applications agreed to by Mitsubishi and provided further that no special
quality assurance or fail-safe, redundant or other safety features which exceed the general
specifications of the PRODUCTs are required. For details, please contact the Mitsubishi
representative in your region.

A - 6 A - 6
REVISIONS
The manual number is given on the bottom left of the back cover.
Print Date Manual Number Revision
May, 2002 SH (NA)-080277-A First edition
Feb., 2003 SH (NA)-080277-B Correction
SAFETY PRECAUTIONS, Section 2.1, 3.4.1, 3.4.23, 4.4.2, 5.1, 5.5.2,
5.6.1, 5.6.3, 6.3.2, 6.5.2, 7.3.4, 7.3.6, 7.4, Appendix 1.2, Appendix 1.3
May, 2003 SH (NA)-080277-C Addition
Section 2.3
Correction
Section 2.2, 3.4.1, 3.4.22, 3.4.23, 4.5, 4.6, 4.6.1, 4.6.2, 5.3.1
May, 2004 SH (NA)-080277-D Correction
Section 2.2, 2.3, 3.1.1, 3.1.3, 3.2.1, 7.1, 7.3.1 to 7.3.6, 8.2.6
Aug., 2004 SH (NA)-080277-E Addition
Section 5.6.3, 5.7, 5.8
Correction
Section 1.1, 5.1, 5.2.1, 5.2.2, 5.3.1, 5.3.2, 5.3.3, 5.6.1, 5.6.2,
Appendix 1.3
Oct., 2004 SH (NA)-080277-F Correction
SAFETY PRECAUTIONS, Section 2.1, 3.1.1, 4.1, 6.3, 6.5.1
Sep., 2005 SH (NA)-080277-G Correction
SAFETY PRECAUTIONS, Section 2.1, 3.1.1, 5.2.2, 6.3.2
Feb., 2006 SH (NA)-080277-H Correction
Section 2.2, 6.2.1, 6.2.2, 6.3.1, 6.3.2, 6.4.1, 6.4.2, 6.5.1, 6.5.2,
Appendix1
Jan., 2007 SH (NA)-080277-I Correction
SAFETY PRECAUTIONS, Section 3.3.2, 4.4.2, 4.6.2, 6.3.1, 6.3.2, 6.5.1,
6.5.2, Chapter 7
Jun., 2007 SH (NA)-080277-J Correction
Section 4.3, Appendix3
Jan., 2008 SH (NA)-080277-K Addition
Section 2.2
Correction
SAFETY PRECAUTIONS, About the Generic Terms and Abbreviations,
Section 1.1, Section 2.1, Section 2.3, Section 4.1, Section 4.6.1, Section
4.6.2, Section 5.2.1, Section 5.2.2, Section 5.3.2, Section 5.3.3, Section
5.4, Section 5.6.1, Section 5.6.4, Section 5.6.5, Section 6.2.1, Section
6.3.1, Section 6.4.1, Section 6.5.1, Section 7.3.1, Section 7.3.3, Section
7.3.4, Section 7.3.5, Section 8.1, Appendix 1.1, Appendix 1.2, Appendix
1.3

A - 7 A - 7
Print Date Manual Number Revision
May, 2008 SH (NA)-080277-L Correction
SAFETY PRECAUTIONS, Compliance with the EMC and Low Voltage
Directives, About the Generic Terms and Abbreviations, Section 2.1,
2.3, Section 3.1.1, 3.2.4, Section 4.1, Section 5.2.1, 5.2.2, 5.3.1 to 5.3.3,
Chapter 7, Section 7.1, 7.4
Oct., 2008 SH (NA)-080277-M Addition
Appendix 3
Correction
Section 2.1, Section 3.1.1, 3.2.2, 3.2.3, 3.3.2, 3.4.1, 3.4.2, 3.4.5, 3.4.6,
3.4.7, 3.4.9, 3.4.11, 3.4.12, 3.4.14, 3.4.17, 3.4.20, Section 4.4.2, 4.5,
Section 5.1, 5.4, Section 8.1, 8.2.4, Appendix 1.1, 1.2, 1.3, 2, 4
Sep., 2015 SH (NA)-080277-N Addition
CONDITIONS OF USE FOR THE PRODUCT
Correction
SAFETY PRECAUTIONS, COMPLIANCE WITH EMC AND LOW
VOLTAGE DIRECTIVES, TERMS, Section 1.1, 2.1, 2.2, 2.3, 2.4, 3.1.1,
3.1.2, 3.2, 3.2.1, 3.2.3, 3.2.4, 3.3.1, 3.3.2, 3.4.1, 3.4.6, 3.4.7, 3.4.9,
3.4.11, 3.4.15, 3.4.16, 3.4.17, 3.4.19, 3.4.20, 3.4.23, 4.1, 4.3, 4.4.2, 4.5,
4.6.1, 4.6.2, 5.2.1, 5.2.2, 5.3.1, 5.3.3, 5.4, 5.5, 5.6.1, 5.6.2, 5.7, 6.2.1,
6.2.2, 6.3, 6.3.1, 6.3.2, 6.4.1, 6.4.2, 6.5, 6.5.1, 6.5.2, Chapter 7, Section
7.1, 7.2, 7.3.1, 7.3.2, 7.3.3, 7.3.4, 7.3.5, 7.3.6, 7.4, 7.5, 8.1, 8.2.3, 8.2.4,
8.2.5, 8.2.6, Appendix 1, 1.2, 2, 3, 4
Japanese Manual Version SH-080262-S
This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent
licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property
rights which may occur as a result of using the contents noted in this manual.
2002 MITSUBISHI ELECTRIC CORPORATION

A - 8 A - 8
INTRODUCTION
Thank you for purchasing the MELSEC-Q series programmable controller.
Before using this product, please read this manual carefully to develop familiarity with the functions and
performance of the Q series programmable controller to handle the product correctly.
CONTENTS
SAFETY PRECAUTIONS..............................................................................................................................A- 1
CONDITIONS OF USE FOR THE PRODUCT .............................................................................................A- 5
REVISIONS ....................................................................................................................................................A- 6
INTRODUCTION............................................................................................................................................A- 8
CONTENTS....................................................................................................................................................A- 8
ABOUT MANUALS ........................................................................................................................................A-12
COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES ...............................................................A-12
TERMS ...........................................................................................................................................................A-13
PRODUCT STRUCTURE..............................................................................................................................A-14
1 OVERVIEW 1- 1 to 1- 3
1.1 Features .................................................................................................................................................. 1- 1
2 SYSTEM CONFIGURATION 2- 1 to 2- 9
2.1 Applicable Systems................................................................................................................................. 2- 1
2.2 Precautions on System Configuration.................................................................................................... 2- 5
2.3 How to Check the Function Version, Serial Number, and Software Version........................................ 2- 6
2.4 Cautions for Power Supply from Q61P-A1/A2 to Q64AD-GH............................................................... 2- 9
3 SPECIFICATIONS 3- 1 to 3-68
3.1 Performance Specifications .................................................................................................................... 3- 1
3.1.1 Performance specifications list ........................................................................................................ 3- 1
3.1.2 I/O conversion characteristic............................................................................................................ 3- 4
3.1.3 Accuracy........................................................................................................................................... 3-10
3.2 Function List ............................................................................................................................................ 3-11
3.2.1 A/D conversion methods.................................................................................................................. 3-13
3.2.2 Maximum and minimum values hold function ................................................................................. 3-16
3.2.3 Input signal error detection function ................................................................................................ 3-16
3.2.4 Warning output function ................................................................................................................... 3-23
3.2.5 A/D conversion starting time setting function (Q62AD-DGH only) ................................................. 3-27
3.3 I/O Signals for the Programmable Controller CPU ................................................................................ 3-28
3.3.1 List of I/O signals .............................................................................................................................. 3-28
3.3.2 Details of I/O signals ........................................................................................................................ 3-30
3.4 Buffer Memory......................................................................................................................................... 3-37
3.4.1 Buffer memory assignment.............................................................................................................. 3-37
3.4.2 A/D conversion enable/disable setting (buffer memory address 0: Un\G0)................................... 3-51
3.4.3 CH average time/average number of times/move average/time constant settings
(buffer memory addresses 1 to 4: Un\G1 to Un\G4)....................................................................... 3-52

A - 9 A - 9
3.4.4 CH A/D conversion starting time setting
(buffer memory addresses 5, 6: Un\G5, Un\G6) (Q62AD-DGH only)............................................ 3-52
3.4.5 Averaging process specification (buffer memory address 9: Un\G9)............................................. 3-54
3.4.6 A/D conversion completed flag (buffer memory address 10: Un\G10) .......................................... 3-55
3.4.7 CH digital output value (16bit) (buffer memory addresses 11 to 14: Un\G11 to Un\G14).......... 3-56
3.4.8 Write data error codes (buffer memory address 19: Un\G19) ........................................................ 3-56
3.4.9 Setting range (buffer memory address 20: Un\G20)....................................................................... 3-57
3.4.10 Offset/gain setting mode (buffer memory addresses 22, 23: Un\G22, Un\G23) ......................... 3-58
3.4.11 CH maximum value/minimum value storage area (16bit)
(buffer memory addresses 30 to 37: Un\G30 to Un\G37) ............................................................3-58
3.4.12 Input signal error detection extended/input signal error detection/warning output settings (buffer
memory address 47: Un\G47) ....................................................................................................... 3-59
3.4.13 Warning output flag (buffer memory address 48 :Un\G48) .......................................................... 3-60
3.4.14 Input signal error detection flag (buffer memory address 49: Un\G49)........................................ 3-61
3.4.15 CH digital output value (32bit) (buffer memory addresses 54 to 61: Un\G54 to Un\G61)........ 3-61
3.4.16 CH maximum value/minimum value storage area (32bit)
(buffer memory addresses 62 to 77: Un\G62 to Un\G77) ............................................................3-62
3.4.17 CH process alarm upper/lower limit value
(buffer memory addresses 86 to 117: Un\G86 to Un\G117) ........................................................ 3-62
3.4.18 CH rate alarm warning detection period
(buffer memory addresses 118 to 121: Un\G118 to Un\G121) .................................................... 3-63
3.4.19 CH rate alarm upper/lower limit value
(buffer memory addresses 122 to 137: Un\G122 to Un\G137) .................................................... 3-64
3.4.20 CH input signal error detection setting value/CH input signal error detection lower limit
setting value (buffer memory addresses 138 to 141: Un\G138 to Un\G141)
CH input signal error detection setting upper value
(buffer memory addresses 142 to 145: Un\G142 to Un\G145) .................................................... 3-65
3.4.21 Mode switching setting (buffer memory addresses 158, 159: Un\G158, Un\G159).................... 3-67
3.4.22 Pass data classification setting (buffer memory addresses 200: Un\G200) (Q64AD-GH only).. 3-67
3.4.23 Industrial shipment settings and user range settings offset/gain value
(buffer memory addresses 202 to 233: Un\G202 to Un\G233) .................................................... 3-68
4 SETUP AND PROCEDURES BEFORE OPERATION 4- 1 to 4-21
4.1 Handling Precautions.............................................................................................................................. 4- 1
4.2 Setup and Procedures before Operation ............................................................................................... 4- 2
4.3 Part Identification Nomenclature ............................................................................................................ 4- 3
4.4 Wiring....................................................................................................................................................... 4- 5
4.4.1 Wiring precautions............................................................................................................................ 4- 5
4.4.2 External wiring .................................................................................................................................. 4- 6
4.5 Switch Setting for Intelligent Function Module ....................................................................................... 4- 9
4.6 Offset/Gain Settings ................................................................................................................................ 4-11
4.6.1 Offset/gain settings (Q64AD-GH) .................................................................................................... 4-11
4.6.2 Offset/gain settings (Q62AD-DGH) ................................................................................................. 4-16
4.6.3 A/D conversion value storage during offset/gain setting ................................................................ 4-21
5 UTILITY PACKAGE (GX Configurator-AD) 5- 1 to 5-32
5.1 Utility Package Functions........................................................................................................................ 5- 1

A - 10 A - 10
5.2 Installing and Uninstalling the Utility Package ....................................................................................... 5- 2
5.2.1 Handling precautions ....................................................................................................................... 5- 2
5.2.2 Operating environment .................................................................................................................... 5- 4
5.3 Utility Package Operation ....................................................................................................................... 5- 6
5.3.1 Common utility package operations ................................................................................................ 5- 6
5.3.2 Operation overview .......................................................................................................................... 5- 9
5.3.3 Starting the intelligent function module utility .................................................................................. 5-11
5.4 Initial Setting ............................................................................................................................................ 5-14
5.5 Auto Refresh Settings ............................................................................................................................. 5-16
5.6 Monitoring /Test....................................................................................................................................... 5-18
5.6.1 Monitor/test screen........................................................................................................................... 5-18
5.6.2 Offset/gain setting operation ............................................................................................................ 5-21
5.6.3 Confirmation of conversion characteristic ....................................................................................... 5-23
5.6.4 Pass data (Q64AD-GH) ................................................................................................................... 5-25
5.6.5 Pass data (Q62AD-DGH) ................................................................................................................ 5-27
5.7 FB Conversion of Initial Setting/Auto Refresh Setting ............................................................................ 5-28
5.8 Usage of FB ............................................................................................................................................. 5-29
5.8.1 Outline .............................................................................................................................................. 5-29
5.8.2 Paste an FB to a sequence program............................................................................................... 5-31
5.8.3 Convert (compile) a sequence program .......................................................................................... 5-32
6 PROGRAMMING 6- 1 to 6-27
6.1 Programming Procedure......................................................................................................................... 6- 1
6.2 For Use in Normal System Configuration (Q64AD-GH) ........................................................................ 6- 2
6.2.1 Programming example using the utility package ............................................................................ 6- 3
6.2.2 Programming example without using the utility package................................................................ 6- 5
6.3 For Use in Remote I/O Network (Q64AD-GH)....................................................................................... 6- 7
6.3.1 Programming example using the utility package ............................................................................ 6- 9
6.3.2 Programming example without using the utility package................................................................ 6-12
6.4 For Use in Normal System Configuration (Q62AD-DGH) ..................................................................... 6-16
6.4.1 Programming example using the utility package ............................................................................ 6-17
6.4.2 Programming example without using the utility package................................................................ 6-19
6.5 For Use in Remote I/O Network (Q62AD-DGH) .................................................................................... 6-20
6.5.1 Programming example using the utility package ............................................................................ 6-21
6.5.2 Programming example without using the utility package................................................................ 6-24
7 ONLINE MODULE CHANGE 7- 1 to 7-36
7.1 Online Module Change Conditions......................................................................................................... 7- 2
7.2 Online Module Change Operations ........................................................................................................ 7- 3
7.3 Online Module Change Procedure......................................................................................................... 7- 4
7.3.1 When industrial shipment setting is used and initial setting was made with
GX Configurator-AD ......................................................................................................................... 7- 4
7.3.2 When industrial shipment setting is used and initial setting was made with sequence program.. 7- 9
7.3.3 When user range setting is used and initial setting was made with GX Configurator-AD
(other system is available) ............................................................................................................... 7-14
7.3.4 When user range setting is used and initial setting was made with GX Configurator-AD
(other system is unavailable) ........................................................................................................... 7-19

A - 11 A - 11
7.3.5 When user range setting is used and initial setting was made with sequence program
(other system is available) ............................................................................................................... 7-25
7.3.6 When user range setting is used and initial setting was made with sequence program
(other system is unavailable) ........................................................................................................... 7-30
7.4 Range Reference Table.......................................................................................................................... 7-35
7.5 Precautions for Online Module Change ................................................................................................. 7-36
8 TROUBLESHOOTING 8- 1 to 8- 7
8.1 Error Code List ........................................................................................................................................ 8- 1
8.2 Troubleshooting ...................................................................................................................................... 8- 4
8.2.1 When the "RUN" LED is flashing or turned off................................................................................ 8- 4
8.2.2 When the "ERR." LED is on or flashing........................................................................................... 8- 4
8.2.3 When the "ALM" LED is on or flashing............................................................................................ 8- 4
8.2.4 When the digital output values cannot be read............................................................................... 8- 5
8.2.5 When A/D conversion completed flag does not turn ON during use in normal mode ................... 8- 6
8.2.6 Checking the A/D converter module status using GX Developer system monitor ........................8- 6
APPENDIX App.- 1 to App.-17
Appendix 1 Dedicated Instruction List and Available Devices................................................................App.- 1
Appendix 1.1 G(P).OFFGAN ...............................................................................................................App.- 2
Appendix 1.2 G(P).OGLOAD...............................................................................................................App.- 4
Appendix 1.3 G(P).OGSTOR...............................................................................................................App.- 8
Appendix 2 Performance Comparison between Q64AD-GH and Q64AD............................................ App.-13
Appendix 3 Functions Added or Changed Due to Version Upgrade..................................................... App.-15
Appendix 4 External Dimensions............................................................................................................ App.-17
INDEX Index- 1 to Index- 3

A - 12 A - 12
ABOUT MANUALS
The following manuals are also related to this product.
If necessary, order them by quoting the details in the tables below.
Related Manuals
Manual Name Manual Number
(Model Code)
GX Developer Version 8 Operating Manual
Describes the methods of using GX Developer to create a program and print out, monitor, and debug
the program. (Sold separately)
SH-080373E
(13JU41)
GX Developer Version 8 Operating Manual (Function Block)
Describes the methods of using GX Developer to create a function block and print out the function
block. (Sold separately)
SH-080376E
(13JU44)
GX Works2 Version 1 Operating Manual (Common)
Describes the system configuration, parameter settings, and online operations (common to Simple
project and Structured project) of GX Works2. (Sold separately)
SH-080779E
(13JU63)
REMARK
If you would like to obtain a manual individually, printed matters are available
separately. Order the manual by quoting the manual number on the table above
(model code).
COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES
(1) Method of ensuring compliance
To ensure that Mitsubishi programmable controllers maintain EMC and Low
Voltage Directives when incorporated into other machinery or equipment, certain
measures may be necessary. Please refer to one of the following manuals.
• QCPU User’s Manual (Hardware Design, Maintenance and Inspection)
• Safety Guidelines
(This manual is included with the CPU module or base unit.)
The CE mark on the side of the programmable controller indicates compliance
with EMC and Low Voltage Directives.
(2) Additional measures
No additional measures are necessary for the compliance of this product with the
EMC and Low Voltage Directives.

A - 13 A - 13
TERMS
Unless otherwise specified, this manual uses the following general terms and
abbreviations.
Abbreviation/general terms Description of the abbreviation/general terms
A/D converter module Generic term for Q64AD-GH and Q62AD-DGH
DOS/V personal computer IBM PC/AT®or compatible computer with DOS/V.
GX Developer Product name of the software package for the MELSEC programmable controllers.
GX Works2
GX Configurator-AD Generic term for analog-digital converter module setting and monitor tool GX
Configurator-AD (SW2D5C-QADU-E)
QCPU (Q mode) Generic term for Basic model QCPU, High performance model QCPU, Process CPU,
Redundant CPU, and Universal model QCPU
Basic module QCPU Generic term for Q00JCPU, Q00CPU, and Q01CPU
High performance model QCPU Generic term for Q02CPU, Q02HCPU, Q06HCPU, Q12HCPU, and Q25HCPU
Process CPU Generic term for Q02PHCPU, Q06PHCPU, Q12PHCPU and Q25PHCPU.
Redundant CPU Generic term for Q12PRHCPU and Q25PRHCPU
Universal model QCPU
Generic term for Q00UJCPU, Q00UCPU, Q01UCPU, Q02UCPU, Q03UDCPU,
Q03UDVCPU, Q03UDECPU, Q04UDHCPU, Q04UDVCPU, Q04UDEHCPU,
Q06UDHCPU, Q06UDVCPU, Q06UDEHCPU, Q10UDHCPU, Q10UDEHCPU,
Q13UDHCPU, Q13UDVCPU, Q13UDEHCPU, Q20UDHCPU, Q20UDEHCPU,
Q26UDHCPU, Q26UDVCPU, Q26UDEHCPU, Q50UDEHCPU, and Q100UDEHCPU
Personal computer Generic term for DOS/V personal computer
Industrial shipment setting Generic term for analog input ranges 0 to 10V, 0 to 5V, 1 to 5V, -10 to 10V, 0 to 20mA
and 4 to 20mA
FB Abbreviation of function block.
Windows Vista®
Generic term for the following:
Microsoft®Windows Vista®Home Basic Operating System,
Microsoft®Windows Vista®Home Premium Operating System,
Microsoft®Windows Vista®Business Operating System,
Microsoft®Windows Vista®Ultimate Operating System,
Microsoft®Windows Vista®Enterprise Operating System
Windows®XP
Generic term for the following:
Microsoft®Windows®XP Professional Operating System,
Microsoft®Windows®XP Home Edition Operating System
Windows®7
Generic term for the following:
Microsoft®Windows®7 Starter Operating System,
Microsoft®Windows®7 Home Premium Operating System,
Microsoft®Windows®7 Professional Operating System,
Microsoft®Windows®7 Ultimate Operating System,
Microsoft®Windows®7 Enterprise Operating System,
Note that the description "Windows®7 (32-bit version)" indicates the 32-bit version,
and "Windows®7 (64-bit version)" indicates the 64-bit version.

A - 14 A - 14
PRODUCT STRUCTURE
The product structure of this product is given in the table below.
Model code Product name Quantity
Q64AD-GH Type Q64AD-GH Channel Isolated High Resolution Analog-Digital
Converter Module 1
Q62AD-DGH Type Q62AD-DGH Channel Isolated High Resolution Analog-Digital
Converter Module (with Signal Conditioning Function) 1
SW2D5C-QADU-E GX Configurator-AD Version 2 (1-license product) (CD-ROM) 1
SW2D5C-QADU-EA GX Configurator-AD Version 2 (Multiple-license product) (CD-ROM) 1

A - 15 A - 15
MEMO

1 - 1 1 - 1
MELSEC-Q
1 OVERVIEW
1 OVERVIEW
This User's Manual describes the specifications, handling and programming methods
for the type Q64AD-GH channel isolated high resolution analog-digital converter
module (hereinafter referred to as the Q64AD-GH) and type Q62AD-DGH channel
isolated high resolution analog-digital converter module (with signal conditioning
function) (hereinafter referred to as the Q62AD-DGH), which are used with the
MELSEC-Q series CPU modules.
The Q62AD-DGH is exclusively used for current input.
In this manual, the Q64AD-GH and Q62AD-DGH are collectively referred to as the A/D
converter modules.
1.1 Features
(1) Channel isolated
The channels are isolated.
The Q62AD-DGH is also isolated between the external supply power and
channels.
(2) High resolution
The resolution is as high as 32-bit signed binary (data part is 16 bits long). (When
the range -10 to 10V is selected)
(3) Power supply to 2-wire transmitter (Q62AD-DGH only)
Supplying power to the 2-wire transmitter, the Q62AD-DGH does not require the
power supply for the 2-wire transmitter.
Supply power can be switched ON/OFF channel-by-channel by the A/D
conversion enable/disable setting.
(4) Module protection provided by short-circuit protection circuit
(Q62AD-DGH only)
If an excessive current flows into the module due to a short circuit of the wiring,
the short-circuit protection circuit limits the current to within 25 to 35mA,
protecting the module.
(5) Analog input check by check terminals (Q62AD-DGH only)
Measurement of a voltage at the check terminals allows the mA of the 2-wire
transmitter output to be checked without the wiring being disconnected.
(6) High accuracy
The reference accuracy 1is as high as ±0.05% and the temperature coefficient 2
is as high as ±71.4ppm/°C.
1 Accuracy of offset/gain setting at ambient temperature
2 Accuracy per temperature change of 1°C
Example) Accuracy when the temperature varies from 25°C to 30°C
0.05% (reference accuracy) + 0.00714%/°C (temperature
coefficient) 5°C (temperature variation difference) = 0.0857%
1

1 - 2 1 - 2
MELSEC-Q
1 OVERVIEW
(7) Changing the input range
The input range 1can easily be set from the GX Developer.
1: Input range refers to the type of offset/gain settings. The most frequently
used range is set as the default but the user can also set the offset/gain.
(8) A/D conversion system
There are the following five A/D conversion systems.
(a) Sampling processing
Analog input values are converted into digital values one by one on a
channel basis and the digital output value is output at every conversion.
(b) Averaging processing
1) Time averaging
A/D conversion is averaged in terms of time on a channel basis and a
digital average value is output.
2) Count averaging
A/D conversion is averaged in terms of count on a channel basis and a
digital average value is output.
3) Move averaging
The specified number of digital output values measured per sampling
time are averaged.
(c) Primary delay filter
A digital output value is smoothed according to the preset time constant.
(9) Input signal error detection function
The voltage/current outside the setting range is detected.
(10) Warning output
There are the following two warning outputs.
(a) Process alarm
A warning is output if a digital output value falls outside the setting range.
(b) Rate alarm
A warning is output if the varying rate of a digital output value falls outside
the preset varying rate range.
(11) Online module change
The module can be replaced without stopping the system.
Using a sequence program further enables the following (limited to same model
pairs, though).
• Inheritance of offset/gain values to the A/D converter module after online module
change.
• Transfer of offset/gain values to a different A/D converter module mounted on
another slot.
1

1 - 3 1 - 3
MELSEC-Q
1 OVERVIEW
(12) Offset/gain setting
GX Configurator-AD, dedicated instruction (G(P). OFFGAN) or mode switching
setting allows a shift to the offset/gain setting mode easily.
(13) Easy configuration with GX Configurator-AD
GX Configurator-AD, which is sold separately, allows the configuration of an A/D
converter module on its screen, thus resulting in a reduction of sequence
programs.
The setting status and operating status of the modules can be checked easily.
FB 1can be generated automatically from the intelligent function module
parameters that have been set up, and is available in a sequence program.
1: FB is the function for making a circuit block used in a sequence program
repeatedly a part (FB) to use it in the sequence program.
This function can improve the efficiency of program development and
minimize program bugs to improve program qualities.
For the details of FB, refer to "GX Developer Version 8 Operating Manual
(Function Block)."
