INSTRUCTION MANUAL
State-of-the-art technology digital clock
ECO-SLH-DC series
addition to the standard DC series instruction manual (for ECO-SLH-DC only)

© MOBATIME 2 / 12 801318.01
Certification of the Producer
STANDARDS
The digital clock ECO-SLH-DC has been developed and produced in accordance with the
EU Standards 2014/35/EU (LVD), 2014/30/EU (EMC), 2014/53/EU (RED), 2011/65/EU (RoHS),
2012/19/EU (WEEE):
Electrical safety: EN 62368-1
EMC: EN 55032; EN 55024; EN 50121-4
References to the Instruction Manual
1. The information in this Instruction Manual can be changed at any time without notice.
The current version is available for download on www.mobatime.com.
2. This Instruction Manual has been composed with the utmost care, in order to explain all details in
respect of the operation of the product. Should you, nevertheless, have questions or discover errors
on this manual, please contact us.
3. We do not answer for direct or indirect damages, which could occur, when using this Manual.
4. Please read the instructions carefully and only start setting-up the product, after you have correctly
understood all the information for the installation and operation.
5. The installation must only be carried out by skilled staff.
6. It is prohibited to reproduce, to store in a computer system or to transfer this publication in a way
or another, even part of it. The copyright remains with all the rights with BÜRK MOBATIME GmbH,
D-78026 VS-Schwenningen and MOSER-BAER AG –CH 3454 Sumiswald / SWITZERLAND.

© MOBATIME 3 / 12 801318.01
Table of contents
1Description .....................................................................................................................................................4
1.1 Advantages ..............................................................................................................................................4
1.2 The clock..................................................................................................................................................4
1.3 Display features........................................................................................................................................4
1.4 Housing....................................................................................................................................................4
1.5 Stopwatch.................................................................................................................................................5
1.6 Clock and Stopwatch control....................................................................................................................5
1.7 Accessories..............................................................................................................................................5
2Assembly........................................................................................................................................................6
2.1 Clock without back cover .........................................................................................................................6
2.2 Clock with back cover ..............................................................................................................................7
16 Engineering data............................................................................................................................................8
16.1 Standard design of the clock....................................................................................................................8
16.2 Voltage range and electric current consumption of the lines...................................................................8
17 Accessories..................................................................................................................................................10
17.1 Clock without back cover .......................................................................................................................10
17.2 Clock with back cover ............................................................................................................................10
18 Cleaning........................................................................................................................................................10
19 DISPOSAL OF USED BATTERIES..............................................................................................................10
20 GUARANTEE AND MAINTENANCE............................................................................................................10
NOTE:
Chapters 2.7 - 15 are the same as in the DC Instruction manual.
Use the DC user manual to control and set parameters for the ECO-SLH-DC clock.

© MOBATIME 4 / 12 801318.01
1 Description
The models series ECO-SLH-DC series are optimally suited for use in operating rooms, clean room environments, chemical
plants, labs, swimming and fitness centres, as well as in the food and beverage industry, canteen, kitchens, etc.
▪ various synchronization options ▪ anti-glare front polycarbonate glass ▪ protection against water jets, easily washable with
water and detergents, harmless to health, reliable ▪ simple keyboard / IR control ▪ front side protection IP 54 make the
product suitable for various purposes
1.1 Advantages
•high-quality stainless-steel housing
•flush design, brushed stainless-steel frame, simple installation using four screws
•easily washable with water
•high resistance to washing disinfectants
•anti-glare polycarbonate front glass prevents glare and improves readability
•dust-proof housing, splash proof, IP 54 on the front side
1.2 The clock
•display of time values (either 12 or 24 hours format), four or six-digit, HH:MM
or HH:MM:SS format
•display of calendar date in four or six-digit, DD.MM
or DD.MM.YY format
•display of temperature in °C or °F, up to two sensors connectable
1.3 Display features
•7-segment LED display
•digit height for hours and minutes 57 resp. 100 mm, for seconds 38 resp. 57 mm
•readability distance of 25 or 40 m
•single-line or two-line display
•digits in red, pure green, blue, yellow, white or green
colour
•manual or automatic adjustment of the luminosity of LED displays
•excellent visibility, even from extremely sharp angles
•alternating time, date and temperature display, duration of the display can
be customized
1.4 Housing
•single-sided design
•flush mounting into the wall or panel, fixation by means of four allen screws placed
on the front panel
•stainless steel front panel (1.4301, AISI 304, brushed) particularly resistant to acids,
cleaning and disinfectant, protected against direct sprays from all direction (limited
ingress permitted) and dust
•other kind of stainless steel material on request
•easy installation
•structural depth 39 mm

© MOBATIME 5 / 12 801318.01
•anti-glare polycarbonate front glass prevents reflections
and improves the readability
•working temperature 0 to + 50°C
•protection degree IP 54
1.5 Stopwatch
•counting upwards from zero, up to 24 hours
•counting downwards from a specified value,
with stop at zero, with automatic restart or counting into negative values
•display of intermediate time values, "freezing"
of display, cumulated intermediate time
•counting in steps of 1 minute, 1 second or 1/100 seconds
•operation via keyboard or remote IR controller
•possibility to connect another display unit(s)
•possibility of parallel switching over into the time/date or temperature display mode
1.6 Clock and Stopwatch control
•operation of the clock and stopwatch operation via stainless steel keyboard
or remote IR controller
1.7 Accessories
•back cover
•DCF 77 signal receiver
•temperature sensor with protection degree IP 66
•stainless steel keyboard for clock and stopwatch control, flush mounting
•remote IR controller for clock set up and stopwatch control

© MOBATIME 6 / 12 801318.01
2 Assembly
The connection to the 110/230 V AC power network can only be done by authorized personnel
with appropriate qualification and training.
Danger of electric shock when dismounting the cover with warning triangle.
The connection to the 110/230 V AC power network should be carried out when the mains
power is off
2.1 Clock without back cover
•There exist two basic possibilities of mounting. Mounting of clocks into the wall niche
and mounting into the panel. For both mountings is very important to prepare
the appropriate holes according to drawings and the clock body.
•For wall niche mounting drill four anchoring holes into the wall, of a diameter
adequate to accommodate appropriate screws of 4 to 5 mm diameter. As a template
for marking the position of the holes the clock body can be used.
•For panel mounting drill four anchoring holes (diameter 2,6mm) into the panel,
of a diameter adequate to accommodate wood-type screws of 4 -5 mm diameter.
As a template for marking the position of the holes the clock body can be used.
•On mains powered clock connect the incoming conductors in accordance with
the description on the power supply unit using WAGO or equivalent clamps.
•Mount the connectors to the cable of the synchronisation signal line, the temperature
sensor cable, to the keyboard cable, Ethernet or to the RS 232 and RS 485 interface
cables, if these are used.
•Push the synchronisation line connector, the temperature sensor connector,
the keyboard connector, Ethernet connector or the RS 232 and RS 485 jacks into
the corresponding terminals on the control PCB (DC user manual chapters 2.8, 2.9).
Check the marking of the jack-plugs, in order to prevent their mix-up.
•Put the clock into prepared hole. Check if any cable is not pinched between the clock
body and hole / niche edges.
•Fix the clock by four screws to wall / panel.
•

© MOBATIME 7 / 12 801318.01
2.2 Clock with back cover
•The clock consist from clock part and back cover. Dismount the 4 screws and remove
the cover.
•There exist two basic possibilities of mounting. Mounting of clocks into the wall niche
and mounting into the panel. For both mountings is very important to prepare the
appropriate holes according to drawings and the clock back cover.
•For wall niche mounting drill two anchoring holes into the wall, of a diameter adequate
to accommodate appropriate screws of 4 to 5 mm diameter. As a template for
marking the position of the holes the back cover can be used.
•For panel mounting drill two anchoring holes (diameter 2,6mm) into the panel, of a
diameter adequate to accommodate wood-type screws of 4 -5 mm diameter.
As a template for marking the position of the holes the back cover can be used.
•Pull the incoming conductors through the hole in the back side of the cover and fix
the cover to the wall or into panel using appropriate screws.
•On mains powered clock connect the incoming conductors in accordance with
the description on the power supply unit using WAGO or equivalent clamps.
•Mount the connectors to the cable of the synchronisation signal line, the temperature
sensor cable, to the keyboard cable, Ethernet or to the RS 232 and RS 485 interface
cables, if these are used.
•Push the synchronisation line connector, the temperature sensor connector,
the keyboard connector, Ethernet connector or the RS 232 and RS 485 jacks into
the corresponding terminals on the control PCB (DC user manual chapters 2.8, 2.9).
Check the marking of the jack-plugs, in order to prevent their mix-up.
•Put the clock into prepared hole. Check if any cable is not pinched between the clock
body and back cover.
•Fix the clock by four delivered screws to back cover.

© MOBATIME 8 / 12 801318.01
16 Engineering data
16.1 Standard design of the clock
Specification
ECO-SLH-DC.57.4
ECO-SLH-DC.57.4.2
ECO-SLH-DC.57.6
ECO-SLH-DC.57.6.2
ECO-SLH-DC.57x.6
ECO-SLH-DC.57x.6.2
ECO-SLH-DC.100.4
ECO-SLH-DC.100.6
ECO-SLH-DC.100x.6
height of the digits [mm]
57
57
57/38
57/38
57
57
100
100 / 57
100
Display
number of digits
4
4
4+2
4+2
6
6
4
4+2
6
number of lines
1
2
1
2
1
2
1
1
1
Time/Date display
format
HH : MM
DD.MM
✓
✓
✓
HH : MM.SS
DD. MM.YY
✓
✓
✓
HH : MM : SS
DD. MM.YY
✓
✓
✓
Powering
standard
100 - 240 VAC, 50 - 60 Hz
VDC (on request)
18—56 VDC (18—40 VAC)
PoE variant (IEEE 802.3af)
1 LAN input
Power consumption
[VA]
single sided, mains powered
7
11
8
16
8
16
7
8
10
single sided, PoE
7
11
8
15
8
15
7
8
10
Crystal timebase
passive running reserve
(time + date)
6 years (except PoE)
running reserve PoE version
12 hours
accuracy at 20° C
± 0,1 s / day without synchronization
(after 24 hours of synchronization at constant temperature)
Accuracy of
temperature
meassurement
range -10 ÷ +85 °C
±0,5 °C
range -50 ÷ +125 °C
±2,0 °C
Operating
environment
temperature
-5 ÷ +50 °C
humidity
0 –95 % (without condensation)
protection degree
IP 54
Weight [kg]
flush mounting N.F
2,6
4
3,3
5
3,5
5,5
4,7
5,8
6,5
Dimensions [mm]
(W x H x D)
flush mounting N.F
380
150
39
380
260
39
470
150
39
470
260
39
500
150
39
500
260
39
555
220
39
695
220
39
770
220
39
flush mounting back cover
dimension W1 x H1
318
123
618
233
408
123
408
233
438
123
438
233
493
193
633
193
708
193
Stainless steel keyboard
ECO-SLH-SKF
ECO-SLH-SKF
back cover dimension
W1 x H1
Dimensions [mm]
(W x H x D)
82 x 152 x 50
67 x 139
16.2 Voltage range and electric current consumption of the lines

© MOBATIME 9 / 12 801318.01
Type of slave line
Voltage range
Electric current consumption
MOBALine
5 –30 VAC
6 –34 uA
MIN, CODE
+- 12 –30 V
3 –7 mA
MIN, CODE (on request)
+- 30 –60 V
3 –7 mA
IRIG B
20 mVpp –2 Vpp
20 uA –2 mA

© MOBATIME 10 / 12 801318.01
17 Accessories
17.1 Clock without back cover
•Instruction manual ECO-SLH-DC 1 pc
•Instruction manual DC 1 pc
•Wood screws for fixing the anchoring 4 pcs
plate inclusive dowels
17.2 Clock with back cover
•Instruction manual ECO-SLH-DC 1 pc
•Instruction manual DC
•Wood screws for fixing the suspension 2 pcs
I ncluding dowels
18 Cleaning
Clean surface of clock only. Use soft rags and antistatic detergents. Don’t use synthetics.
19 DISPOSAL OF USED BATTERIES
The user is lawfully obligated to return unusable batteries. Disposal of used
batteries through household waste is prohibited! Batteries which contain
dangerous substances are labelled with a picture of a crossed out trash bin.
The symbol means that this product may not be disposed through
household waste. Below the symbol, the dangerous substance is indicated
with an abbreviation: Cd = Cadmium, Hg = Quicksilver, Pb = Lead.
Unusable batteries can be returned free of charge at appropriate collection
points of your waste disposal company or at shops that sell batteries. By
doing so, you fulfil your legal responsibilities and help protect the
environment.
20 GUARANTEE AND MAINTENANCE
•The device is intended for a normal operational environment according to the
corresponding norm.
•The following circumstances are excluded from the guarantee:
- inappropriate handling or interventions
- chemical influences
- mechanical defects
- external environmental influences (natural catastrophes)
•Repairs during and after the guarantee period are assured by the manufacturer.

© MOBATIME 11 / 12 801318.01

© MOBATIME 12 / 12 801318.01
BÜRK MOBATIME GmbH
Postfach 3760, D-78026 VS-Schwenningen
Steinkirchring 46, D-78056 VS-Schwenningen
Tel. [phone] / Fax [phone]
[email protected] / www.buerk-mobatime.de
MOBATIME AG
Stettbachstrasse 5, CH-8600 Dübendorf
Tel. [phone] / Fax [phone]
[email protected] / www.mobatime.ch
MOSER-BAER SA EXPORT DIVISION
19 ch. du Champ-des-Filles, CH-1228 Plan-les-Ouates
Tel. [phone] / Fax + 41 22 884 96 90
[email protected] / www.mobatime.com
MOSER-BAER AG
Spitalstrasse 7, CH-3454 Sumiswald
Tel. [phone] / Fax [phone]
[email protected] / www.mobatime.com
SALES SWITZERLAND
HEADQUARTERS / PRODUCTION SALES WORLDWIDE
SALES GERMANY, AUSTRIA
MOBATIME SA
En Budron H 20, CH-1052 Le Mont-sur-Lausanne
Tél. [phone] / Fax [phone]
[email protected] / www.mobatime.ch
