Mobicool T45 User manual

GB
D
F
E
I
NL
DK
N
S
FIN
Thermoelectric cooler
Instruction Manual 6
Thermoelektrische Kühlbox
Bedienungsanleitung 14
Glacière thermoélectrique
Notice d’emploi 22
Nevera con extractor
Instrucciones de uso 31
Frigorifero termoelettrico
Istruzioni per l’uso 40
Thermo-elektrische koelbox
Gebruiksaanwijzingen 48
Termoelektrisk køleboks
Betjeningsanvisning 56
Termoelektrisk kjøleboks
Bruksanvisning 64
Termoelektrisk kylbox
Bruksanvisning 72
Sähkökäyttöinen kylmälaukku
Käyttöohjeet 80
T45
W45
_T45_W45_B_10s_.book Seite 1 Donnerstag, 8. März 2007 12:39 12

_T45_W45_B_10s_.book Seite 2 Donnerstag, 8. März 2007 12:39 12

T45, W45
3
12V
DC
1
A
B
C
DE F
G
A
T45 W45
2
_T45_W45_B_10s_.book Seite 3 Donnerstag, 8. März 2007 12:39 12

T45, W45
4
3
A
B
C
4
AB
CDE
5
A
_T45_W45_B_10s_.book Seite 4 Donnerstag, 8. März 2007 12:39 12

T45, W45
5
600 395
475
270
335
450
6
T45
600 395
490
270
335
450
7
W45
_T45_W45_B_10s_.book Seite 5 Donnerstag, 8. März 2007 12:39 12

Safety information T45, W45
6
Read these instructions carefully before the installation and
commissioning and keep them in a safe place. Pass it on to the buyer
in case of the further sale of the unit.
List of contents
1 Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 Use as intended . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
6 Cleaning and servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7 Troubleshootings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
8 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
9 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Please also observe the following safety notes.
1 Safety information
1.1 General safety
zConnect the device only as follows:
– in combination with a mains rectifier to the alternating current circuit
– with the connecting cable contained in the scope of delivery to the
cigarette lighter or to a 12 V socket in the vehicle (see figure 1, page 3).
zThe appliance shall not be exposed to rain.
zNever pull the plug at the connecting cable out of the cigarette lighter or
the socket.
zIf the supply cord is damaged, it must be replaced with same type and
rating AC cord in order avoid a hazard.
zIf the unit shows visible damage, you may not put it into operation.
zRepairs on this unit may be executed only by specialists. Considerable
dangers can occur as a result of improper repairs.
_T45_W45_B_10s_.book Seite 6 Donnerstag, 8. März 2007 12:39 12

T45, W45 Safety information
7
zDisconnect the connecting cable
– before each cleaning and servicing,
– after each use.
zMake sure that the venting slots will not be covered!
zWith boats: Make sure with mains operation that your power supply is
protected via a FI-switch! Danger to life!
zDisconnect your refrigerator and other consuming units from the battery
before connecting a fast battery recharger!
zCompare the voltage indicated on the type plate to the present energy
supply.
zThe refrigerator is not suitable for the transport of corrosive or solvent-
based substances!
zDon´t use any electric appliance inside the cooling compartment.
zPersons (including children) whose physical, sensory or mental
capabilities or lack of experience and knowledge prevents them from
using the appliance safely should not use this appliance without initial
supervision or instruction by a responsible person.
Electrical devices are no toys!
Please keep and use the device out of the reach of children.
zChildren must be supervised to ensure that they do not play with the
device.
1.2 Safety when operating the device
zCaution! Danger of overheating!
Ensure at all times that there is sufficient ventilation so that the heat that
arises during operation does not build up. Make sure that the device is
sufficiently far away from walls and other objects so that the air can
circulate.
zEnsure before starting up that supply line and plug are dry.
zDo not place the device in the proximity of open flames or other heat
sources (heating, strong solar rays, gas ovens etc.).
zDo not fill any liquids or ice into the interior container.
zNever immerse the device into water.
_T45_W45_B_10s_.book Seite 7 Donnerstag, 8. März 2007 12:39 12

Use as intended T45, W45
8
zProtect the device and the cables against heat and wetness.
zNever grasp with your bare hands the bare lines. This applies above all
when operating on the alternating current circuit: Danger to life!
zMOBICOOL is not liable for damages which are caused by non- intended
use or wrong operation.
2 Use as intended
The refrigerator can be used to cool and keep foodstuffs warm. It is
possible to change between the heating and cooling operation by
means of a switch.
The device can be also used for camping purposes.
The device is designed only for the operation on a 12 VDC on-board
socket of a vehicle (cigarette lighter), boats or camper van. For the
connection to a mains voltage range from 100 - 240 VAC a mains
rectifier (attached in the scope of delivery of the T45 DC/AC) of
MOBICOOL/WAECO (series Y40 or MPA-40) can be used.
The cover can be opened in two halves for to remove the goods from the
cooling box. The cover halves can be closed via a rotary button (see „Open/
close cooling box“ page 10).
If you want to cool medicine, check please if the cooling capacity
of the device corresponds to the requirements of the respective
pharmaceuticals.
3 Scope of delivery
Check before starting up the device that all parts are available belonging to
the scope of delivery.
Quantity Designation
1Refrigerator
1 Connecting cable for 12-VDC on-board mains socket
1Only T45 DC/AC, W45 DC/AC
Mains rectifier for 100-240 volts alternating current circuit
_T45_W45_B_10s_.book Seite 8 Donnerstag, 8. März 2007 12:39 12

T45, W45 Technical description
9
4 Technical description
The cooling box is suitable for mobile use. It can cool goods up to max. 20 °
under ambient temperature or keep them cool or warm them up to max. 65 °
or keep them warm.
The W45 has two wheels and a multi-function handle so that it can be pulled
along. Alternatively, you can carry with two hands.
The cooling is a wear and CFC-free thermo-electric cooler with heat removal
through a ventilator.
4.1 Description of device
Your cooling box consists of the following parts (see figure 2, page 3)
5 Operation
The cooling box is switched on or off via a control panel (see figure 2, page 3,
pos C).
Before you put the new refrigerator into operation, you should
clean it inside and outside with a damp cloth for hygienic reasons
(see also “Cleaning and servicing” chapter on page 11).
5.1 Tips to save energy
zSelect a well ventilated location which is protected against sunrays.
zLet warm foods first cool down before you bin them.
zDo not open the refrigerator more often than necessary!
zDo not leave the lid or door open longer than necessary!
Pos. in fig. 2 Designation
A Handle
B Air outlet openings
C Control panel and connection for voltage supply
D left cover halves
E right cover halves
F Rotary button for opening/closing the cover halves
G Cable compartment (at the back of the second cover)
_T45_W45_B_10s_.book Seite 9 Donnerstag, 8. März 2007 12:39 12

Operation T45, W45
10
5.2 Open/close cooling box
The cover halves of the cooling box can be closed by means of a rotary
button (see figure 2, page 3, pos. F). The following settings can be selected
with the rotary button:
Caution! Tilting danger!
The cooler might tilt when the left cover-half is open. Close the left
cover-half and turn the rotary button to position A or B after using
the left cabinet (see figure 3, page 4).
5.3 Use the cooling box
➤Place the cooling box on a stable base.
➤Connect the cooling box
– with a mains rectifier to a alternating current socket.
or
– with the supplied connecting cable to the cigarette lighter in the
vehicle.
➤Push the switch on the control panel to the position „HEISS/HOT” (see
figure 4, page 4, Pos. E) or „KALT/COLD” (see figure 4, page 4, Pos. C)
in order to switch on the cooling box.
Lock the box firmly by shutting the cover again and setting the
rotary button to the position “Lock” (see figure 3, page 4, pos. A).
Already after a short period you can convince yourself from the
proper functioning of your cooling box at the interior of the cover.
✓The cooling box starts to cool or heat the interior space.
Pos. in fig. 3 Designation
A Both cover halves are closed.
B The right cover half is unlocked.
C Both cover halves are unlocked.
Operating display Operating mode
red
(see figure 4, page 4 (Pos B)
Heating
green
(see figure 4, page 4 (Pos A)
Cooling
_T45_W45_B_10s_.book Seite 10 Donnerstag, 8. März 2007 12:39 12
