Mocka Addi Entertainment Unit User manual

Addi Entertainment Unit
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
1
Wall Strap
Hardware Supplied
x2
washer
Z
Y
wall
anchor
x1
X
safety
strap x1
WV
screw
x1
wall
screw
x1
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
Phillips & Flathead screwdrivers
and hammer required
bolt
x12
x4
A B C D E F G
H J K L MN
I
OP
dowel
x18
screw
x20
slide
rail x2
slide
rail x2
slide
rail x2
slide
rail x2
locking
nut x12
screw
x6
x4
bolt
x10
locking
nut x10
small small
QR
wedge screw
screw
x14
x4
nut
S
key x1
Allen plastic
glide x4
dowel
x4
big
T
dowel
x2
long
U A1
WARNING: Any furniture that is not anchored to a wall
has the potential to tip over in certain circumstances, i.e.
if a child attempts to climb up on the furniture or in the
event of an earthquake. Accordingly, we recommend
that all furniture is anchored to a wall. We supply a free
safety wall anchor with all furniture sold and we
recommend these are used to prevent your product
tipping. The fixing device provided should fit most wall
types, but please note that different wall materials may
require different fixing devices from those supplied.
height
adjuster
x1
double
ended
screw
x1
long
Allen
bolt x 4

Addi Entertainment Unit
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
2
12
Attach 1x slide rail (F) and 1x slide rail (G) to panels [3] and [4]
as shown and secure with 6x screws (E). Tighten with a screwdriver.
Insert 4x bolts (C) into panels [3] and [4]. Tighten with a screwdriver.
Attach 1x slide rail (G) to panel [6] as shown and secure with
3x screws (E). Flip the panel [6] and attach 1x slide rail (F) to
the other side of the panel as shown and secure with 3x screws
(E). Tighten with a screwdriver.
G
CR
E
F
E
F
F
E
C
C
C
C
E
E
E
E
E
E
E
E
E
E
E
E
G
G
CR
E
G
F
6
6
4
3
FLIP

Addi Entertainment Unit
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
3
34
Insert 2x bolts (C) into panel [7]. Tighten with a screwdriver. Attach panels [3] and [4] to panel [7] with 4x dowel (A) and secure with
4x locking nuts (D). Tighten with a screwdriver.
C
C
A
D
D
D
D
A
A
A
77
3
4
A
D

Addi Entertainment Unit
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
4
65
Attach panel [5] to panel [7] with 2x long dowels (T) and secure with
2x screws (R). Tighten with a screwdriver.
Attach panel [6] to the panel [7] and secure with 2x locking nuts (D).
Tighten with a screwdriver.
T
R
R
D
D
T
5
776

Addi Entertainment Unit
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
5
7 8
Slide panel [8] between the grooves of panels [3] and [4] to form the
back of the unit, as shown.
Attach the legs [9] to panel [2] with 4x big dowels (S) and 4x nuts (L)
as shown. Secure with 4x long Allen bolts (Q). Tighten with an Allen
key (M). Attach support leg panel [10] to panel [2] and secure with 1x
double ended screw (A1).
×
Q
L
L
A1
S
S
Q
L
Q
L
S
2
9
9
9
9
10
Q
L
S
M
3
8
4

Addi Entertainment Unit
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
6
910
Assembly Instructions
Attach panel [2] to the panels [3], [4] and [6] with 6x dowels (A) and
secure with 6x screws (B). Tighten with a screwdriver.
Attach 4x plastic glides (N) to the end of legs [9] and
insert the adjuster (U) into the end of support leg panel [10].
2
A
A
B
BA
B
B
A
B
B
N
N
N
N
U
9
9
9
9
10
N
3
6
4

Addi Entertainment Unit
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
7
1211
Slide panel [11] between the grooves of panels [3] and [4]. Insert 6x bolts (C) into panel [1]. Tighten with a screwdriver.
C
C
C
C
C
C
11
1
3
4

Drawers x2
Addi Entertainment Unit
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
8
13 14
Attach panel [1] to the unit with 6x dowels (A) and secure with 6x
locking nuts (D). Tighten with a screwdriver.
Insert 10x small bolts (O) into panels [12] and [13]. Secure panels [14],
[15] and [16] to panels [12] and [13] with 2x dowel (A) and 10x small locking
nuts (P). Tighten with a screwdriver. Slide panel [17] down along the
grooves between panels [14] and [15] to form the base of the drawer.
O
O
O
O
O
A
P
P
P
14
14
15
15
16
17
12
13
12
13
12
13
A
A
D
D
AD
A
D
1
3
4
5

Drawers x2
Addi Entertainment Unit
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
9
15 16
Attach panel [18] to panels [14], [15] and [16] using 6x screws (R).
Now attach 1x slide rail (I) to panel [15] and 1x slide rail (H) to panel
[14] as shown. Secure with 4x small screws (E) and tighten with a
screwdriver.
R
R
R
E
EH
E
I
E
14
14
15
15
18
Insert the assembled drawers into the unit ensuring they slide smoothly
along the rails.
12
13
12
13
12
13

Addi Entertainment Unit
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
10
17 18
Attach 4x wedges (J) into the corners of the back of the unit and secure
with 4x screws (K). Tighten with a screwdriver. Attach 1x safety strap (V)
to the top of the back side of the unit as shown using 1x washer (Z) and
1x screw (W). Tighten with a screwdriver.
Once assembled lift furniture into place, do not drag. Use a drill to create
a small hole lining up with the top of the safety strap (V). Fasten to wall
using 1x washer (Z), 1x wall anchor (X) and 1x screw (Y). Ensure unit is
balanced and steady before use. You’re done, enjoy!
J
K
J
K
V
W
Z
V
W
Z
X
Y
Z
wall
anchor
screw
strap
washer
