Mocka Aspen Change Table with Drawers User manual

Aspen Change Table with Drawers
1
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A
Hardware Supplied
Bolt M6*30
x20
F
Knob
x2
L
Right Slide
x3
L
Right Slide
x3
M
Wood Screw
x24
G
Bolt M4*25mm
x2
H
Allen Key
J
Left Slide
x2
K
Left Slide
x3
B
Wood Dowel
x12
C
Bolt M6*40
x8
D
Bolt M6*50
x16
E
Barrel Nut
x16
Phillips & Flathead screwdrivers required.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
WARNING: Any furniture that is not anchored to a wall has the potential to tip
over in certain circumstances, i.e. if a child attempts to climb up on the furniture
or in the event of an earthquake. Accordingly, we recommend that all furniture
is anchored to a wall. We supply a free safety wall anchor with all furniture sold
and we recommend these are used to prevent your product tipping. The fixing
device provided should fit most wall types, but please note that different wall
materials may require different fixing devices from those supplied.
N O
Wall Strap
1x
screw
1x
wall screw
F
2x
washer
G
1x
wall anchor
H
1x
wall strap

12
Aspen Change Table with Drawers
2
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Attach 2 x left slides (J) to panel [1] and 2 x right slides (L) to panel [2]
as shown and secure with 12 x screws (M). Tighten with a screwdriver.
Attach 4 x panels [4] to panel [3] and secure with 8 x bolts (C). Tighten
with an Allen Key (H).
12
M x6
M x6
J x2
L x2
3
4
4
4
4
C x8
H
C
C

7
8
9
A
A
A
B
B
A
A
B
B
B
5
6
3
3
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Attach panels [5] and [6] to assembled frame as shown and secure with
6 x bolts (A). Tighten with an Allen Key (H).
Insert 6 x dowels (B) into panels [8], [9] and [10] as shown. Attach
panel [7] to panels [8], [9] and [10] and secure with 7 x bolts (A).
Tighten with an Allen Key (H).
Aspen Change Table with Drawers
4
H
H
5
6
A x6
7
8
9
10
A
A
A
A
B
B
A
A
A
B
B
B
B

A x7
B x6
2
5
4
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Slide panels [11], [12] and [13] into position as shown. Insert 6 x dowels (B) into assembled frame as shown. Attach panel [2]
to assembled frame and secure with 7 x bolts (A). Tighten with an Allen
Key (H).
Aspen Change Table with Drawers
6
11
12
13
A x7
B x6
2
H

Ex2
Ex2
Dx2
D
14
16
15
7x2
5
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Attach left rail (K) to panel [14] and right rail (L) to panel [15] and secure
with 6 x screws (M). Tighten with a screwdriver.
Attach panels [14] and [15] to panel [16] and secure with 4 x bolts (D)
and 4 x barrel nuts (E). Tighten with an Allen Key (H).
Aspen Change Table with Drawers
8x2
M
M
M
M
M
M
14
15
K L
Ex2
D
14
16
H

D
Ex2
G
9x2
6
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Slide panel [17] into position as shown. Attach 1 x knob (F) to panel [18] and secure with 1 x screw (G). Attach
panel [18] to assembled frame and secure with 4 x bolts (D) and 4 x
barrel nuts (E). Tighten with an Allen Key (H) and a screwdriver.
Aspen Change Table with Drawers
10 x2
Ex2
Dx2
15
17
18
Dx2
Dx2
Ex2
Ex2
G
F
H

18
Dx2
Ex2
F
11
7
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Slide assembled drawers into position as shown. Once assembled lift furniture into place, do not drag.
Attach wall strap (H) to unit with 2 x washers (F) and 1x screw (N).
Use a drill to create a small hole lining up with the safety strap (H).
Fasten to wall using 1 x wall anchor (H), 2 x washers (F), 1 x wall screw
(O) and 1 x screw (N).
Ensure unit is balanced and steady before use. You’re done, enjoy!
Aspen Change Table with Drawers
12
NO
FG
H
F
