Mocka Locka User manual

A B C
D E F
Phillips screwdriver required
Hardware Supplied
clip
x8
ring
x1
rod
x2
handle
x1
bolt
x2
wall mount
x1
WARNING: Any furniture that is not anchored to a wall
has the potential to tip over in certain circumstances, i.e.
if a child attempts to climb up on the furniture or in the
event of an earthquake. Accordingly, we recommend
that all furniture is anchored to a wall. We supply a free
safety wall anchor with all furniture sold and we
recommend these are used to prevent your product
tipping. The fixing device provided should fit most wall
types, but please note that different wall materials may
require different fixing devices from those supplied.
Locka Single
1
mocka.co.nz | mocka.com.au
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.

12
Slide the legs [3] and [4] into the bottom of the panels [1] and [2] until
they click into place.
Insert the back panel [5] between panels [1] and [2] as shown.
CLICK!
CLICK!
CLICK!
CLICK!
4
3
2
1
2
1
5
Locka Single
2
mocka.co.nz | mocka.com.au
Assembly Instructions

12
Slide the legs [3] and [4] into the bottom of the panels [1] and [2] until
they click into place.
Insert the back panel [5] between panels [1] and [2] as shown.
CLICK!
CLICK!
CLICK!
CLICK!
4
3
2
1
2
1
5
34
Attach the top panel [6] to the rest of the unit. Secure the top panel by clicking into place as shown.
6
2
1
2
1
Locka Single
3
mocka.co.nz | mocka.com.au
Assembly Instructions

56
Insert bottom panel [7] by clicking into place as shown.
NB. If you ever need to take the shelves out to readjust their height,
please use a flat head screwdriver to loosen the clips from underneath.
Insert 8x clips (A) into the back and front clip brackets at your desired
shelf height as shown. Place the two shelf panels [8] into the unit over
the clips to form the shelves.
x8
A
A
8
7
8
Locka Single
Assembly Instructions
4
mocka.co.nz | mocka.com.au

Jolt Wardrobe
ASSEMBLY INSTRUCTIONS
5
mocka.co.nz | mocka.com.au
56
Insert bottom panel [7] by clicking into place as shown.
NB. If you ever need to take the shelves out to readjust their height,
please use a flat head screwdriver to loosen the clips from underneath.
Insert 8x clips (A) into the back and front clip brackets at your desired
shelf height as shown. Place the two shelf panels [8] into the unit over
the clips to form the shelves.
x8
A
A
8
7
8
78
Attach handle (D) to door panel [9] with 2x bolts (E) and tighten with a
screwdriver.
To attach the bottom of the door, insert 1x ring (B) and 1x rod (C) through
the door panel [9] as shown. Twist the rod into place and secure by
bending the clasp down.
E
ED
B
C
C
9
9
Locka Single
Assembly Instructions
5
mocka.co.nz | mocka.com.au

910
To attach the top of the door, insert 1x rod (C) through the door panel
as shown. Twist the rod into place and secure by bending the clasp up
onto it.
Lift the completed unit into place, do not drag. Mark its height on the wall
with a pencil. Attach one end of the wall mount strap to the back of the
unit with a 1x screw (F). Screw the other end into the wall at the marked
height with a wall screw (not supplied). You’re done, enjoy!
C
C
F
Wall Mount
Locka Single
Assembly Instructions
6
mocka.co.nz | mocka.com.au
