Mocka Bentley Tall Shelf User manual

mocka.co.nzImocka.com.au
Thank you for your purchase. Please follow the instructions for correct assembly.
While we took great effort to ensure these assembly instructions were correct at
the time of printing, sometimes updates are required post production. For the
most up to date versions please refer to the product page on our website.
mocka.com.au/mocka.co.nz
A
screw mm14
x1
B C D
Phillips&Flatheadscrewdriversrequired.
Forquickerassembly,werecommendthe
useofapowerdrillonalow-speedsetting.
WARNING: Anyfurniturethatisnotanchoredtoawallhasthepotentialtotip
overincertaincircumstances,i.e.ifachildattemptstoclimbuponthe
furnitureorintheeventofanearthquake.Accordingly,werecommendthat
allfurnitureisanchoredtoawall.Wesupplyafreesafetywallanchorwithall
furnituresoldandwerecommend theseareusedto preventyourproduct
tipping.Thefixingdeviceprovidedshouldfitmostwalltypes,butpleasenote
thatdifferentwallmaterialsmayrequiredifferentfixingdevicesfromthose
supplied.
x2
E
F G
screw mm25
x1 x1
x1
screw mm15
x10
screw mm50
x20
Bentley
TallShelf
screw

mocka.co.nzImocka.com.au
1 2
A
1
G
2
2
2
2
2
B
B
E
C
Bentley
TallShelf
3
4
4
3
Attach frames [4] with 1 × screw (G) and 1 × screw (A). Attach frames [3] to panels [1] and [2] with 20 × screws (B).
Attach 1 × safety (E) to panel [1] with 1 × screw (C).

mocka.co.nzImocka.com.au
34
A
A
A
A
A
A
A
A
F
D
E
Bentley
TallShelf
3
3
4
4
Attach frames [4] to frames [3] with 8 × screw (A). Once assembled lift furniture into place, do not drag.
Use a drill to create a small hole lining up with the
top of the 1 × safety strap (E). Fasten to the wall
using 1 × wall plug (F) and 1 × screw (D). Ensure
unit is balanced and steady before use.

mocka.co.nzImocka.com.au
5
Bentley
TallShelf
You`re done, enjoy!
