Mocka Kuranda User manual

Kuranda Console Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
1
allen
key x1
AB
screw
x22
Wall Strap
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
Hardware Supplied
Phillips screwdrivers
x2
washer
Z
Y
wall
anchor
x1
X
safety
strap x1
WV
screw
x1
wall
screw
x1

Kuranda Console Table
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
2
12
2
2
3
3
3
34
4
4
4
Attach panels [3] and [4] to panel [2] as shown with 6x screws (A). Tighten
with an allen key (B).
Attach panel [2] to panels [3] and [4] as shown with 6x screws (A). Tighten
with an allen key (B).
A
A
A
A
A
A
A
B
A
A
A
A
A
A
B

Kuranda Console Table
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
3
34
1
1
2
2
3
Attach panel [1] to panels [3] and secure with 10x screws (A).
Tighten with an allen key (B).
Attach 1x safety strap (V) to the back edge of panel [1] using 1x washer (Z)
and 1x screw (W). Tighten with a screwdriver.
A
A
AA
A
A
3
B
A
A
A
A
V
Z
W
V
Z
W

Kuranda Console Table
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
4
56
Once assembled lift furniture into place, do not drag. Use a drill to
create a small hole lining up with the top of the safety strap (V).
Fasten to the wall using1x washer (Z), 1x wall anchor (X)
and 1x wall screw (Y). Ensure unit is balanced and steady before
use.
You’re done, enjoy!
X
Y
Z
wall
anchor
screw
strap
washer
