Mocka Nava Three Drawer User manual

Nava Three Drawer
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
1
Wall Strap
x2
washer
Z
Y
wall
anchor
x1
X
safety
strap x1
WV
screw
x1
wall
screw
x1
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
bolt
x10
x8
ABC D E F G HJ
KLM N
I
O P
dowel
x17
screw
x39
slide
rail x3
slide
rail x3
slide
rail x3
slide
rail x3
locking
nut x10
screw
x14 x8
x4 bolt
x15
locking
nut x15
small small
Q
wedge
x4
screw
x3
bracket
cover
x3
bolt
washer
x34
R
screw seal
x3
ST
key x1
Allen plastic
glide x4
U
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
Phillips & Flathead screwdrivers
and hammer required
Hardware Supplied

Nava Three Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
2
12
Attach 3x slide rails (F) and 3x slide rails (G) to panels [3] and [4] as shown
with 18x screws (E). Insert 6x bolts (C) into panels [3] and [4]. Tighten with
a screwdriver.
F
CL
E
Attach 3x brackets (M) to panels [5] and [2], secure with 6x
screws (E). Tighten with a screwdriver. Place 3x covers (N) over
the brackets (M) as shown.
G
CR
E
N
M
E
E
4
3
2
5
E
E
E
E
E
E
E
E
EG
G
G
F
F
F
E
E
E
E
E
E
E
E
E
C
C
C
C
C
C
EE
M
EE
M
x2

Nava Three Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
3
3 4
Attach panels [5] and [6] to panel [3] with 3x dowels (A) and secure
with 3x locking nuts (D). Tighten with a screwdriver.
Attach panel [4] to panels [5] and [6] with 3x dowels (A) and secure
with 3x locking nuts (D). Tighten with a screwdriver.
4
3
5
5
5 5
6
6
A
A
A
D
D
D
A
A
A
D
D
D
D

Nava Three Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
4
65
Slide panel [7] down along the grooves between the panels [3] and [4]. Attach panel [2] to the rest of the unit using 4x dowels (A) and secure
with 4x screws (B) as shown. Tighten with a screwdriver.
B
B
B
A
7
2
4
4
3
3
A
B
B
A

Nava Three Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
5
7 8
Attach panels [8] and [9] to panel [2] using 10x screws (B). Tighten with
a screwdriver.
R
R
R
8
8
8
9
9
10
9
2
R
Attach panels [10] to panels [8] and [9] with 16x screws (R).
Tighten with a screwdriver.
R
B
B
B
B
B
B
B
B
B
B
10
10
10
3
8
3
9

Nava Three Drawer
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
6
910
Assembly Instructions
Attach Legs [11] to panels [10] with 4x washers (L) and 4x bolts (Q).
Tighten with the Allen key (T). Attach 4x plastic glides (U) to the
legs using a hammer as shown.
Slide panel [7] down along the grooves between the panels [3] and [4].
4
7
3
U
U
U
U
L
Q
11 10
3
11
3
11
3
11
3
10
3
10
3
10
T
L
Q

Nava Three Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
7
1211
Insert 4x bolts (C) into panel [1] and tighten with a screwdriver.
4
1
1
3
Attach panel [3] and [4] to [1] with 4x dowels (A) and secure
with 4x locking nuts (D). Tighten with a screwdriver.
C
C
C
C
A
D
D
A
AD

Nava Three Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
8
13 Drawers x3 14 Drawers x3
OO
OO
E
S
O
P
A
P
P
PP
RR
RR
RR
H
E
E
E
E
I
12
12
13
13
13
13
16
17
14
14
14
14
15
Insert 5x small bolts (O) to panel [12]. Attach 1x seal (S) using
1x screw (E) to panel [12]. Attach panels [13], [14] and [15] to panel
[12] with 1x dowel (A) and using 5x small locking nuts (P). Tighten
with a screwdriver. Slide panel [16] along the grooves between the
panels [13] and [14] to form the base of the drawer.
Attach panels [13], [14], [15] and [17] as shown using 6x screws (R).
Tighten with a screwdriver. Attach slide rail (I) and slide rail (H) to the
underside of the side panels as shown. Secure with 4x screws (E) and
tighten with a screwdriver.

7
7
Nava Three Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
9
15 16
Insert the assembled drawers into the corresponding compartments as
shown. Ensure the drawers slide easily along the rails. If the door is not
catching or sitting flush, twist the end of the cover (N) until it catches on
the seal (S).
Attach 8x wedges (J) into the corners of the back of the unit and secure
with 8x screws (K). Tighten with a screwdriver. Attach 1x safety strap(V)
to the top of the back side of the unit as shown using 1x washer (Z) and
1x screw (W). Tighten with a screwdriver.
N
J
K
V
W
Z
screw
strap
washer
12
12
12
J
K

Nava Three Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
10
17 18
Once assembled lift furniture into place, do not drag. Attach the other
end of the safety straps (V). Fasten to the wall using 1x washer (Z), 1x
wall anchor (X) and 1x screw (Y). Ensure the unit is balanced and steady
before use.
You’re done, enjoy!
X
Y
Z
wall
anchor
screw
strap
washer
