Mocka Reese User manual

mocka.co.nzImocka.com.au
Reese
6SeaterDiningTable
Thank you for your purchase. Please follow the instructions for correct assembly.
While we took great effort to ensure these assembly instructions were correct at
the time of printing, sometimes updates are required post production. For the
most up to date versions please refer to the product page on our website.
mocka.com.au/mocka.co.nz
A B C D
Phillips&Flatheadscrewdriversrequired.
Forquickerassembly,werecommendthe
useofapowerdrillonalow-speedsetting.
E
screw 30mm
x22 screw 12mm
x22 foot
×4 plate
×2 screwdriver
×1

mocka.co.nzImocka.com.au
1 2
Insert 4 × foot (C) into frames [2] and [3]. Attach frames [2] and [3] with 2 × plates (D), secure
with 14× screws (B), tighten with a screwdriver.
C
C
C
C
C
C
B
D
Reese 
6SeaterDiningTable
2
2
3
3
2
2

mocka.co.nzImocka.com.au
34
Attach frame [4] to panel [1] with 14 × screws (A).
1
A
Attach frames [2] and [3] to panel [1] with 8 × screws (A).
A
1
Reese 
6SeaterDiningTable
4
3
2
2

mocka.co.nzImocka.com.au
56
Attach frames [5] to the frames [2] and [3] with 8 × screws (B). You`re done, enjoy!
B
1
Reese 
6SeaterDiningTable
5
5
