Mocka Addi Three Drawer User manual

Addi Three Drawer
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
1
Wall Strap
x2
washer
Z
Y
wall
anchor
x1
X
safety
strap x1
WV
screw
x1
wall
screw
x1
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
Phillips & Flathead screwdrivers
and hammer required
bolt
x10
x8
A B C D E F G HJ
KLMN
I
O
Hardware Supplied
P
dowel
x17
screw
x30
slide
rail x3
slide
rail x3
slide
rail x3
slide
rail x3
locking
nut x10
screw
x4 x8
bolt
x15
locking
nut x15
small small
QR
wedge
screw screw
x18
x4
nut
S
key x1
Allen plastic
glide x4 dowel
x4
big
long
Allen
bolt x 4

Addi Three Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
2
12
Insert 3x bolts (C) into panel [3] and 3x bolts (C) into panel [4]. Attach 3x
slide rails (G) to panel [4] and secure with 9x small screws (E) . Attach
3x slide rails (F) to panel [3] and secure with 9x small screws (E).Tighten
with a screwdriver.
Insert 3x dowels (A) into panel [3]. Attach panels [5], [6] and [7]
to the panel [3] and secure with 3x locking nuts (D). Tighten with a
screwdriver.
E
G
E
EE
G
E
EE
G
E
E
E
E
F
E
E
E
F
E
E
E
F
E
G
CR
E
F
CL
E
D
A
A
DD
3
4
C
C
C
C
C
C
3
7
5
6
DD

Addi Three Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
3
3 4
Insert 3x dowels (A) into the ends of panels [5] and [6].
Attach panel [4] to the unit and secure with 3x locking nuts (D).
Tighten with a screwdriver.
Slide panel [8] between the grooves of panels [3] and [4] to form the
back of the unit, as shown.
A
A
DDD
4
7
5
6
8
4
3

Addi Three Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
4
65
Attach the legs [9] to panel [2] with 4x big dowels (S) and
4x nuts (L) as shown. Secure with 4x long Allen bolts (Q).
Tighten with an Allen key (M).
Attach panel [2] to the panels [3] and [4] with 4x dowels (A) and secure
with 4x screws (B). Tighten with a screwdriver. Attach 4x plastic glides (N)
to the end of legs [9] as shown.
×
S
L
Q
M
SL
Q
SL
Q
Q
Q
S
L
A
B
A
B
B
B
A
2
2
9
9
9
4
3
N
N
N
N
N

Addi Three Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
5
7 8
Slide panel [8] between the grooves of panels [3] and [4]. Insert 4x bolts (C) into panel [1]. Tighten with a screwdriver.
C
C
C
C
4
3
1
8

Addi Three Drawer
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
6
910
Assembly Instructions
Attach panel [1] to the unit with 4x dowels (A) and secure
with 4x locking nuts (D). Tighten with a screwdriver.
Insert 5x small bolts (O) into panels [10] and [11]. Secure panels
[12], [13] and [14] to panels [10] and [11] with 1x dowel (A) and
5x small locking nuts (P). Tighten with a screwdriver. Slide panel
[15] down along the grooves between panels [12] and [13] to form
the base of the drawer.
Drawers x3
O
O
O
OO
x2
PP
P
P
P
A
11
10
12
13
14
15
12
13
D
A
D
A
A
D
1
3
4
x2
11
10
x2
11
10

Addi Three Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
7
1211
Attach panel [16] to panels [12], [13] and [14] using 6x screws (R).
Now attach 1x slide rail (I) to panel [13] and 1x slide rail (H) to panel
[12] as shown. Secure with 4x small screws (E) and tighten with a
screwdriver.
Drawers x3
RR
RR
RR
E
E
E
E
13
12
H
I
16 13
12
Insert the assembled drawers into the unit ensuring they slide smoothly
along the rails.
10
11
11
x2
11
10
x2
11
10

Addi Three Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
8
13 14
Attach 8x wedges (J) into the corners of the back of the unit and secure
with 8x screws (K). Tighten with a screwdriver. Attach 1x safety strap (V)
to the top of the back side of the unit as shown using 1x washer (Z) and
1x screw (W). Tighten with a screwdriver.
Once assembled lift furniture into place, do not drag. Use a drill to create
a small hole lining up with the top of the safety strap (V). Fasten to wall
using 1x washer (Z), 1x wall anchor (X) and 1x screw (Y). Ensure unit is
balanced and steady before use. You’re done, enjoy!
X
Y
Z
V
W
Z
screw
strap
washer
J
K
J
K
wall
anchor
screw
strap
washer
8
1
8
