Mohawk ML-220 User manual

MOHAWK MODEL ML-220
READ MANUAL
THOROUGHLY BEFORE
INSTALLING, OPERATING,
SERVICING OR
MAINTAINING THIS LIFT !!
Deliver these instructions to lift
owner/user/employer along with
other instructional materials
furnished with this lift.
MADE IN THE USA
ML-220 20,000 LB. CAPACITY TWO POST
VEHICLE LIFT MANUAL
INSTALLATION
OPERATION
MAINTENANCE
PARTS
.
65 VROOMAN AVE.
AMSTERDAM, NY 12010
TOLL FREE: 1-800-833-2006
LOCAL: 1-518-842-1431
FAX: [phone]
INTERNET: WWW.MOHAWKLIFTS.COM
E-MAIL: [e-mail]
ML-220_5-9-19.doc
Rev Date 5/9/19
Part #601-800-493
MODEL ML-220

MOHAWK MODEL ML-220
i
IMPORTANT SAFETY INSTRUCTIONS
When using your garage equipment, basic safety precautions should always be followed, including the
following:
1. READ ALL INSTRUCTIONS.
2. Care must be taken as burns can occur from touching hot parts.
3. Do not operate equipment with a damaged cord or if the equipment has been dropped or damaged -
until it has been examined by a qualified serviceman.
3. Do not let cord or hoses come in contact with hot manifolds or moving fan blades.
4. If an extension cord is necessary, a cord with a current rating equal to or more than that of the
equipment should be used. Cords rated for less current than the equipment may overheat. Care
should be taken to arrange the cord so that it will not be tripped over or pulled.
5. Always unplug equipment from electrical outlet when not in use. Never use the cord to pull the
plug from the outlet. Grasp plug and pull to disconnect
6. To reduce the risk of fire, do not operate equipment in the vicinity of open containers of flammable
liquids (gasoline). WARNING: Risk of Explosion: This equipment has internal arcing and
sparking parts which should not be exposed to flammable vapors. This equipment is only suitable
for installation in a garage having sufficient air circulation to be considered a non-hazardous
location.
7. Adequate ventilation should be provided when working on operating internal combustion engines.
8. Keep hair, loose clothing, fingers, and all parts of body away from moving parts.
9. To reduce the risk of electric shock, do not use on wet surfaces or expose to rain.
10. 
11. ALWAYS WEAR SAFETY GLASSES. Everyday eyeglasses only have impact resistant lenses,
they are NOT safety glasses.
SAVE THESE INSTRUCTIONS
Rev (8/3/98)

ii
MOHAWK MODEL ML-220
APPENDAGE:
Rev (6/19/2012)
LIFT ENVIRONMENT:
Mohawk prohibits the outdoor installation of this standard lift, which is APPROVED FOR INDOOR USAGE ONLY,
in a normal garage type environment. Any concerns in applications that expose the lift to additional environmental
effects, such as paint booths, wash bays, outdoors, high or low temperatures, etc. must be addressed to our engineering
department, where provisions could/may be made to the lift to accommodate the area of use. Our engineering
department must be made aware in advance of these conditions and any additional code requirements that must be met.
Also, the foundation for which this lift must be installed on must comply to the minimum specifications as set forth in
this manual. Any drainage slopes in the bay where the lift is to be installed must be directed away from the posts to
prevent water accumulation at the post bases.
Standard foundation flooring and anchorage specifications are contained within this manual. For installation within a
seismic area, a qualified person must be consulted to address seismic loads and other local or state requirements.
ACCESSORIES:
All accessories (i.e. Lifting Pads, Height Adapters, Wheel Adapters, Turf Adapters) supplied with this lift are to be
used on this lift only. Accessories from other lifts are not acceptable and could result in injury to the user. Contact the
. for information pertaining to approved attachments, accessories or configuration modifying
components.
LOCK WARNING:
Latches do not automatically reset after disengagement. After the latches have been manually disengaged, this lift must
be raised approximately 2 inches to reactivate the latches.
LOCKOUT/TAGOUT REQUIREMENTS:
The start switch provided with this unit must not be used as a primary disconnecting means. A separate disconnecting
means must be provided in accordance with all applicable codes. It is the responsibility of the owner/user of this unit to
provide a proper lockout/tagout device for this unit before or during installation in conformance to ANSI Z244.1 and
any local/state/national electrical codes and any OSHA regulations.
PROPER SELECTION OF POWER SUPPLY CORD:
Acceptable Cord Types: SO, SEO,STO, SOW, SEOO, SOW-A
Cord Size: 12/4
Cord Ampacity: 20 Amps
Cord Wiring: Use Female NEMA Plug supplied with lift and wire as follows (See Diagram Below),
G: Ground (green)
W: Neutral (white)
X: 208 VAC Hot, 110 VAC to ground (Red)
Y: 208 VAC Hot, 110 VAC to ground (Black)
Face of Plug Represented:

MOHAWK MODEL ML-220
iii
HAVE A QUESTION?
Call your local
Mohawk distributor
For parts, service and technical support.
Distributor Place Card Here
e.
Model Number ______________________
Serial Number ______________________
OR CONTACT:
. 65
Vrooman Ave.
P.O. Box 110
Amsterdam, NY 12010
Toll Free: 1-800-833-2006
Local: 1-518-842-1431
Fax: [phone]
Internet: www.MOHAWKLIFTS.com E-
Mail: [email protected]

MOHAWK MODEL ML-220
iv
MOHAWK WARRANTIES
EFFECTIVE DATE: 12/1/2015*
READ THIS WARRANTY IN ITS ENTIRETY
GENERAL WARRANTY INFORMATION:
              
RETURNED TO THIS FACTORY, TRANSPORTATION CHARGES PREPAID BY CUSTOMER WITH AUTHORIZED RETURN (RGA),
WHICH PROVE UPON INSPECTION TO BE DEFECTIVE AND WHICH HAVE NOT BEEN MISUSED. DAMAGE OR FAILURE TO ANY
PART DUE TO FREIGHT DAMAGE OR LACK OF REQUIRED REGULAR DOCUMENTED MAINTENANCE IS NOT COVERED UNDER
THIS WARRANTY. ALL WARRANTY CLAIMS MUST BE P      

THIS WARRANTY DOES NOT COVER MIS-DIAGNOSING OF UNIT OR PARTS RETURNED THAT ARE NON-DEFECTIVE. THIS
WARRANTY DOES NOT COVER ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES INCLUDING, BUT NOT LIMITED TO, LOST
REVENUES OR BUSINESS HARM. THIS EQUIPMENT HAS BEEN DESIGNED FOR USE IN NORMAL VEHICLE MAINTENANCE
APPLICATIONS. A SPECIFIC INDIVIDUAL WARRANTY MUST BE ISSUED FOR UNITS THAT DEVIATE FROM INTENDED USAGE,
SUCH AS HIGH CYCLE USAGE IN INDUSTRIAL APPLICATIONS, OR USAGE IN EXTREMELY ABUSIVE ENVIRONMENTS.
MOHAWK RESERVES THE RIGHT TO DECLINE RESPONSIBILITY WHEN REPAIRS OR MODIFICATIONS HAVE BEEN MADE OR
ATTEMPTED BY OTHERS WITHOUT WRITTEN AUTHORIZATION FROM .. THIS WARRANTY DOES NOT
COVER LABOR OR TRANSPORTATION. THIS WARRANTY DOES NOT COVER DOWNTIME EXPENSES INCURRED WHEN
UNIT IS IN REPAIR. THE LIFT MUST BE REGISTERED WITHIN 30 DAYS OF INSTALLATION BY MAILING SUPPLIED
WARRANTY REGISTRATION CARD TO MOHAWK AND MUST BE SIGNED BY A LICENSED ELECTRICIAN. THE MODEL
NUMBER AND SERIAL NUMBER OF THE EQUIPMENT MUST BE FURNISHED WITH ALL WARRANTY CLAIMS. THIS WARRANTY
STATEMENT CONTAINS THE ENTIRE AGREEMENT BETWEEN   . AND THE PURCHASER UNLESS
OTHERWISE SPECIFICALLY EXPRESSED IN WRITING. THIS NON-TRANSFERABLE WARRANTY APPLIES TO THE ORIGINAL
PURCHASER ONLY.
THIS WARRANTY DOES NOT COVER NORMAL SURFACE WEAR ITEMS, ITEMS SUBJECT TO ABRASION, OR ITEMS USED IN A
CORROSIVE ENV
UNDER THIS WARRANTY.
STRUCTURAL AND MECHANICAL COMPONENTS (ALL LIFTS):
STRUCTURAL AND MECHANICAL COMPONENTS OF THIS UNIT ARE GUARANTEED FOR THE BELOW STATED TIME FRAME,
SPECIFIC TO MODEL LISTED, FROM THE DATE OF SHIPMENT FROM FACTORY, AGAINST DEFECTS IN WORKMANSHIP
AND/OR MATERIALS WHEN LIFT IS INSTALLED AND USED ACCORDING TO SPECIFICATIONS.
25-YEARS STRUCTURAL / 10 YEARS MECHANICAL:TWO-POST MODELS A-7, SYSTEM IA-10, LC-12, LMF-12, TP-
16, TP-18, ML-220, TP-20, TP-26, TP-30. STRUCTURAL ITEMS COVERED INCLUDE LEG, CARRIAGE, SWING ARM
AND SLIDER WELDMENTS (EXCLUDING NORMAL WEAR AREAS AS STATED ABOVE). MECHANICAL ITEMS
COVERED INCLUDE ROLLER BEARINGS AND LIFTING CHAIN.
5-YEAR: MODELS TL-7.
3-YEAR: MODELS TR-19, TR-25, FL-25, TR-30, TR-33, TR-35, TR-50, TR-75, TR-110, TR-120, MP-SERIES LIFTS.
2-YEAR: MODELS PARALLELOGRAM SERIES LIFTS.
1-YEAR: MODELS TD-1000, TD-2000, CT-1000, USL-6000.
POWER UNIT (ALL LIFTS):
ALL POWER UNIT COMPONENTS (MOTOR, PUMP AND RESERVOIR) ARE GUARANTEED FOR TWO YEARS FOR PARTS,
FROM THE DATE OF SHIPMENT FROM FACTORY, AGAINST DEFECTS IN WORKMANSHIP AND/OR MATERIALS WHEN THE
LIFT IS INSTALLED, WIRED BY A LICENSED ELECTRICIAN AND USED ACCORDING TO SPECIFICATIONS.
ELECTRICAL COMPONENTS (ALL LIFTS):
ALL ELECTRICAL COMPONENTS (EXCLUDING MOTOR) ARE GUARANTEED FOR ONE YEAR FOR PARTS, FROM THE DATE
OF SHIPMENT FROM FACTORY, AGAINST DEFECTS IN WORKMANSHIP AND/OR MATERIALS WHEN THE LIFT IS
INSTALLED AND USED ACCORDING TO SPECIFICATIONS. SEE WARRANTY EXCEPTIONS SECTION FOR BATTERIES.
PNEUMATIC-AIR COMPONENTS (ALL LIFTS):
ALL PNEUMATIC (AIR) COMPONENTS (I.E. AIR CYLINDERS AND POPPET AIR VALVES) ARE GUARANTEED FOR ONE YEAR
FOR PARTS, FROM THE DATE OF SHIPMENT FROM FACTORY, AGAINST DEFECTS IN WORKMANSHIP AND/OR
MATERIALS WHEN THE LIFT IS INSTALLED AND USED ACCORDING TO SPECIFICATIONS. COMPONENTS IN A PNEUMATIC
SYSTEM THAT ARE NOT PROPERLY REGULATED, LUBRICATED AND CONDITIONED WITH AN AIR DRYING SYSTEM ARE
NOT COVERED UNDER WARRANTY.
HYDRAULIC COMPONENTS (ALL LIFTS):
EXCLUDING CYLINDERS AND PUMPS (COVERED IN OTHER SECTIONS), ALL HYDRAULIC COMPONENTS (I.E. VALVES AND
FITTINGS) ARE GUARANTEED FOR ONE YEAR FOR PARTS, FROM THE DATE OF SHIPMENT FROM FACTORY, AGAINST
DEFECTS IN WORKMANSHIP AND/OR MATERIALS WHEN THE LIFT IS INSTALLED AND USED ACCORDING TO
SPECIFICATIONS.

MOHAWK MODEL ML-220
v
HYDRAULIC CYLINDERS (MODEL SPECIFIC LIFTS):
THE FOLLOWING MODELS ARE GUARANTEED FOR 5 YEARS (PARTS ONLY), FROM DATE OF SHIPMENT FROM FACTORY,
FOR HYDRAULIC CYLINDERS, AGAINST DEFECTS IN WORKMANSHIP AND/OR MATERIALS WHEN THE LIFT IS INSTALLED
AND USED ACCORDING TO SPECIFICATIONS: TWO-POST MODELS A-7, SYSTEM IA-10, LC-12, LMF-12, TP-16, TP-18, TP-20,
ML-220, TP-26, TP-30.
ALL OTHER MODELS ARE GUARANTEED FOR TWO YEARS (PARTS ONLY), FROM THE DATE OF SHIPMENT FROM
FACTORY, FOR HYDRAULIC CYLINDERS, AGAINST DEFECTS IN WORKMANSHIP AND/OR MATERIALS WHEN THE LIFT IS
INSTALLED AND USED ACCORDING TO SPECIFICATIONS (EXCLUDING USL-6000, WHICH IS ONE YEAR).
EXTENDED LIFETIME CYLINDER SEAL WARRANTY
ONLY: TWO-POST MODELS A-7, SYSTEM IA-10, LC-12, LMF-12, TP-16, TP-18, ML-220, TP-20, TP-26, TP-
EXTENDED LIFETIME CYLINDER SEAL WARRANTYFIC WARRANTY PROVISIONS FOR HYDRAULIC
CYLINDERS.
EXTENDED LIFETIME CYLINDER SEAL WARRANTY
AS THE ORIGINAL PURCHASER OF A MOHAWK LIFT MANUFACTURED BY . YOU ARE ENTITLED TO
AN EXTENDED CYLINDER SEAL WARRANTY.
MOHA
CUSTOMER IS RESPONSIBLE FOR SHIPPING AND HANDLING OF THE SEALS. MOHAWK IS NOT RESPONSIBLE/LIABLE
FOR THE REBUILD OF CYLINDERS BY OTHERS. THIS WARRANTY IS NON-TRANSFERABLE AND RUNS TO THE ORIGINAL
PURCHASER ONLY.
STANDARD OPTIONS (ALL LIFTS):
ALL STANDARD OPTIONS OF THIS UNIT ARE GUARANTEED FOR ONE YEAR FOR PARTS, FROM THE DATE OF SHIPMENT
FROM FACTORY, AGAINST DEFECTS IN WORKMANSHIP AND/OR MATERIALS WHEN LIFT IS INSTALLED AND USED
ACCORDING TO SPECIFICATIONS.
CUSTOM LIFTS AND CUSTOM OPTIONS:
GUARANTEED FOR ONE YEAR FOR PARTS, FROM THE DATE OF
SHIPMENT FROM FACTORY, AGAINST DEFECTS IN WORKMANSHIP AND/OR MATERIALS WHEN LIFT IS INSTALLED AND
USED ACCORDING TO SPECIFICATIONS.
WARRANTY EXCEPTIONS (ALL LIFTS):
ADJUSTMENTS: THIS WARRANTY DOES NOT COVER CASUAL AND ROUTINE ADJUSTMENTS SUCH AS, BUT NOT LIMITED
TO: FITTINGS, SENSORS AND SWITCHES, ANCHOR BOLT RE-TIGHTENING, OR ANY SHIMMING OR ADJUSTMENTS
REQUIRED DURING A PROPER AND PROFESSIONAL INSTALLATION BY A QUALIFIED INSTALLER.
MAINTENANCE AND INSPECTIONS: IF THIS UNIT IS NOT MAINTAINED AND INSPECTED IN ACCORDANCE TO THE
RELEVANT SECTIONS IN THE USERS MANUAL FOR THIS SPECIFIC MODEL, WARRANTY IS VOID. OSHA, ANSI AND
MOHAWK REQUIRE THAT RECORDS MUST BE MAINTAINED TO PROVE THAT INSPECTIONS AND MAINTENANCE OF THIS
UNIT HAVE BEEN ROUTINELY PERFORMED BY QUALIFIED INDIVIDUALS.
ABUSE: IF THIS UNIT IS FOUND TO BE OVERLOADED (PURPOSELY OR UNKNOWINGLY), USED IN A SITUATION BEYOND
ITS INTENDED FUNCTION, NOT MAINTAINED & INSPECTED REGULARLY, USED IN AN ABUSIVE ENVIRONMENT OR
BEYOND NORMAL SHOP USAGE, THIS WARRANTY IS VOID IN ITS ENTIRETY.
NON-EXISTENT PROBLEMS: FOR SERVICE VISITS, PART REPLACEMENTS, LABOR, ETC. FOR PARTS FOUND TO BE NON-
DEFECTIVE, OR FOR A UNIT DIS-FUNCTION THAT DOES NOT EXIST, IT IS THE LIFT OWNER THAT REQUESTED THE
SERVICE VISIT WHO BEARS THE RESPONSIBILITY OF ALL RELATED EXPENSES.
BATTERIES: ALL BATTERIES CARRY THE BAT

WARRANTY.
SPECIAL/MODIFIED INSTALLATIONS: -
INSTALLATIONS ARE TO BE DONE ACCORDING TO SPECIFICATIONS, OR THE WARRANTY IS VOID.
WEARABLE COMPONENTS: SOME ITEMS ON LIFTS 
COVERED UNDER THIS WARRANTY.
NON-VEHICLE / RE-PURPOSED LIFTS: THIS WARRANTY DOES NO-
AND LOWER EQUIPMENT THAT ARE NOT CONSIDERED VEHICLES.
* THIS WARRANTY SUPERSEDES ALL OTHER WARRANTY POLICIES PREVIOUSLY STATED AND IN ALL OTHER MOHAWK
PRODUCT SPECIFIC LITERATURE (MANUALS, BROCHURES, ETC.).
Rev 12/1/2015

MOHAWK MODEL ML-220
1
CONTENTS
TEXT
PAGE
APPENDAGES 2
SPECIFICATIONS 3
PACKING LIST 4
RECOMMENDED TOOL LIST 5
BEFORE INSTALLING A LIFT / WEJ-IT INSTALLATION 6
INSTALLATION INSTRUCTIONS 7-8
SAFETY TIPS 9
LIFT FINAL CHECKOUT 10
2-POST LIMITATIONS AND ADAPTER USAGE 11
PRE - OPERATION CHECK LIST / LIFTING PROCEDURES 12
MAINTENANCE PROCEDURES 13
HYDRAULIC SAFETY CHECKS 14
TROUBLE SHOOTING 15-16
SERVICE CHART 17
MAINTENANCE CHART 17
ELEC
FIGURES / DIAGRAMS
FIGURE PAGE
BAY SIGHT LAYOUT / INSTALLATION DIMENSIONS 1 20
CARRIAGE STOP ASSEMBLY 2 21
WEJ-IT INSTALLATION 3, 4A, 4B 22-24
POST-LEVELING 5 25
POST-SHIMMING 6,6A 26-27
ADJUSTING CARRIAGE NUTS 7 28
CENTERING VEHICLE 8 29
UNEVEN FLOORS 9 30
SPECIAL LIFTING PADS 10 31
POWER UNIT 11 32
ELECTRICAL SCHEMATIC 12 33
LIFTING PAD PROCEDURES 13 34
SWING ARM BOLT CAP PLACEMENT 14 35
PARTS
FIGURE PAGE
ISOMETRIC FINAL ASSEMBLY MAN500 37
MAIN SIDE ASSEMBLY MAN500-A 38
OFF SIDE ASSEMBLY MAN500-B 39
HYDRAULIC SYSTEM MAN501 40
CARRIAGE ASST & ARM LOCK MAN502 41
LATCH BODY ASSEMBLY MAN503 42
DIVERTER VALVE ASSEMBLY MAN504 43
HEIGHT ADAPTER & BRACKET / CYLINDER CLAMPS MAN505 44
CARRIAGE / SWING ARMS / SLIDERS / LIFTING PADS MAN506 45
LEG WELDMENT / LINE SUPPORTS / CARRIAGE STOPS MAN507 46
TAG & DECAL LOCATIONS MAN508 47
MAIN SIDE CYLINDER ASSEMBLY MAN509 48
OFF SIDE CYLINDER ASSEMBLY MAN510 49
SMALL PARTS BAG MAN511 50
PARTS BOX #1 MAN512 51
PARTS BOX #2 MAN513 52
NEW SLAB RECOMMENDATIONS
PAGE
SLAB REQUIREMENTS & NEW SLAB RECOMMENDATIONS 53-61
ALI WARNING, CAUTION AND SAFETY MESSAGES 62-63
ALL INFORMATION, ILLUSTRATIONS, AND SPECIFICATIONS IN THIS MANUAL ARE BASED ON THE LATEST PRODUCT INFORMATION
AVAILABLE AT THE TIME OF PRINTING. WE RESERVE THE RIGHT TO MAKE CHANGES AT ANY TIME WITHOUT NOTICE.

MOHAWK MODEL ML-220
2
APPENDAGES
RECOMMENDATIONS BY THE INDIVIDUAL USER OR USING
ORGANIZATION FOR IMPROVING THIS PUBLICATION OR ANY
ASPECT OF THE PRODUCT ARE ENCOURAGED AND SHOULD BE
FORWARDED IN WRITING TO:
.
PRODUCT IMPROVEMENTS
65 VROOMAN AVE.
AMSTERDAM, NY, 12010
THIS IS NOT A VEHICLE LIFTING PROCEDURE MANUAL AND NO
ATTEMPT IS MADE OR IMPLIED HEREIN TO INSTRUCT THE USER
IN LIFTING METHODS PARTICULARLY TO THE INDIVIDUAL
APPLICATION OF THE EQUIPMENT DESCRIBED IN THIS MANUAL.
RATHER, THE CONTENTS OF THIS MANUAL ARE INTENDED AS A
BASE LINE FOR OPERATION, MAINTENANCE, TROUBLE
SHOOTING, AND PARTS LISTING OF THE UNIT AS IT STANDS
ALONE AND AS IT IS INTENDED AND ANTICIPATED TO BE USED
IN CONJUNCTION WITH OTHER EQUIPMENT.
PROPER APPLICATION OF THE EQUIPMENT DESCRIBED HEREIN
IS LIMITED TO THE PARAMETERS DETAILED IN THE
SPECIFICATIONS AND THE USES SET FORTH IN THE
DESCRIPTIVE PASSAGES. ANY OTHER PROPOSED APPLICATION
OF THIS EQUIPMENT SHOULD BE DOCUMENTED AND
SUBMITTED IN WRITING TO   . FOR
EXAMINATION. THE USER ASSUMES FULL RESPONSIBILITY FOR
ANY EQUIPMENT DAMAGE, PERSONAL INJURY, OR ALTERATION
OF THE EQUIPMENT DESCRIBED IN THIS MANUAL OR ANY
SUBSEQUENT DAMAGES.
DO NOT WELD, APPLY HEAT, OR MODIFY THIS EQUIPMENT IN
ANY
MANNER WITHOUT WRITTEN AUTHORIZATION FROM
.CERTAIN ALLOY OR HEAT-
TREATED COMPONENTS MAY BE DISTORTED OR WEAKENED,
RESULTING IN AN UNSAFE CONDITION.
  .IS NOT RESPONSIBLE FOR
DISTORTIONS, WHICH RESULT FROM WELDING ON THIS
EQUIPMENT AFTER MANUFACTURING IS COMPLETED.
UNAUTHORIZED WELDING, APPLICATION OF HEAT, OR
MODIFICATION OF THIS EQUIPMENT VOIDS ANY AND / OR ALL
APPLICABLE WARRANTIES COVERING THIS EQUIPMENT.
ALL WARRANTIES APPLICABLE TO THIS EQUIPMENT ARE
CONTINGENT ON STRICT ADHERENCE TO THE MAINTENANCE
SCHEDULES AND PROCEDURES IN THIS MANUAL.
KEEP ALL SHIELDS AND GUARDS IN PLACE. INSURE ALL SAFETY
MECHANISMS ARE OPERABLE. KEEP HANDS, FEET, AND
CLOTHING AWAY FROM POWER-DRIVEN AND MOVING PARTS.
WARNING

DO NOT INSTALL THIS UNIT IN A PIT OR DEPRESSION DUE
TO FIRE OR EXPLOSION RISK
IMPORTANT NOTE
A LEVEL FLOOR IS SUGGESTED FOR A PROPER INSTALLATION
SITE AND WILL ENSURE LEVEL LIFTING. SMALL DIFFERENCES
IN FLOOR SLOPES MAY BE COMPENSATED FOR WITH SPECIAL
LIFTING PADS. ANY MAJOR SLOPE CHANGES WILL AFFECT THE
LOW PROFILE HEIGHT OF THE LIFTING PADS AND / OR THE
UNITS LEVEL LIFTING PERFORMANCE. IF A FLOOR IS OF
QUESTIONABLE SLOPE, CONSIDER A SURVEY OF THE SIGHT
AND / OR THE POSSIBILITY OF POURING A NEW LEVEL
CONCRETE SLAB SECTION. SIMPLY STATED, FOR OPTIMUM
LEVEL LIFTING, THE EQUIPMENT, AT BEST, CAN LIFT ONLY AS
LEVEL AS THE FLOOR ON WHICH IT IS LOCATED... AND SHOULD
NOT BE EXPECTED TO COMPENSATE FOR DRASTIC FLOOR
SLOPE DIFFERENCES.
THIS EQUIPMENT MUST BE INSTALLED ON A LEVEL CONCRETE
FLOOR WITH A MINIMUM THICKNESS OF 6-1/2 INCHES THE
CONCRETE MUST BE AGED AT LEAST (28) TWENTY EIGHT DAYS
PRIOR TO INSTALLATION AND HAVE A MINIMUM COMPRESSIVE
STRENGTH OF 4000 P.S.I.
DO NOT INSTALL THIS UNIT ON ANY ASPHALT SURFACE.
DO NOT INSTALL THIS UNIT ON ANY SURFACE OTHER THAN
CONCRETE CONFORMING TO THE MINIMUM SPECIFICATIONS
STATED IN THE PRE-EXISTING FLOOR
REQUIREMENTS SECTION.
DO NOT INSTALL THIS UNIT ON EXPANSION SEAMS OR ON
CRACKED, DEFECTIVE CONCRETE. CHECK WITH BUILDING
ARCHITECT.
DO NOT INSTALL THIS UNIT ON A SECOND FLOOR OR ANY
GROUND FLOOR WITH A BASEMENT BENEATH WITHOUT
WRITTEN AUTHORIZATION FROM THE BUILDING ARCHITECT.
INSTALL THIS EQUIPMENT ON CONCRETE ONLY
IF, FOR ANY REASON, A NEW CONCRETE SLAB SECTION IS
REQUIRED, THE MINIMUM THICKNESS, COMPRESSIVE
STRENGTH, AND AGING ARE MANDATORY. FOR YOUR
PROTECTION, CERTIFIED STRENGTH DOCUMENTATION SHOULD
BE OBTAINED FROM THE FIRM WHO SUPPLIES THE CONCRETE
MIXTURE AT THE TIME OF THE POUR. SPECIAL CONSIDERATION
SHOULD BE MADE TO THE JOINING OF THE EXISTING FLOOR
AND THE NEW SECTION BEING ADDED. CHECK WITH BUILDING
ARCHITECT. THE SUGGESTED SIZE OF THE NEW CONCRETE
SLAB SECTION IS SHOWN IN THE NEW SLAB
RECOMMENDATIONS SECTION.
CAUTION
THE EQUIPMENT DESCRIBED IN THIS MANUAL COULD BE
POTENTIALLY DANGEROUS IF IMPROPERLY OR CARELESSLY
OPERATED. FOR THE PROTECTION OF ALL PERSONS AND
EQUIPMENT, ONLY COMPETENTLY TRAINED OPERATORS WHO
ARE CRITICALLY AWARE OF THE PROPER OPERATING
PROCEDURES, POTENTIAL DANGERS, AND SPECIFIC
APPLICATION OF THIS EQUIPMENT SHOULD BE ALLOWED TO
TOUCH THE CONTROLS AT ANY TIME.
SAFE OPERATION OF THIS EQUIPMENT IS DEPENDENT ON USE,
IN COMPLIANCE WITH THE OPERATION PROCEDURES OUTLINED
IN THIS MANUAL ALONG WITH THE MAINTENANCE AND
INSPECTION PROCEDURES WITH CONSIDERATION OF
PREVAILING CONDITIONS.
THE EQUIPMENT DESCRIBED IN THIS MANUAL IS NEITHER
DESIGNED NOR INTENDED FOR ANY APPLICATION ALONE OR IN
CONJUNCTION WITH ANY OTHER EQUIPMENT THAT INVOLVES
THE LIFTING OR MOVING OF PERSONS.
ALWAYS CONSULT THE VEHICLE LIFTING GUIDE FOR THE
PROPER LIFTING POINTS ON ANY VEHICLE. THESE GUIDES ARE
AVAILABLE FROM THE VEHICLE MANUFACTURERS.
AFTER LIFTING THE VEHICLE TO THE DESIRED HEIGHT,
ALWAYS LOWER THE UNIT ONTO THE MECHANICAL SAFETIES.
THE FORMING OF GOOD OPERATIONAL WORK HABITS WILL
ELIMINATE OVERSIGHTS IN THE USE OF PROVIDED SAFETY
DEVICES.

MOHAWK MODEL ML-220
3
LIFT SPECIFICATIONS
ML-220 SPECIFICATIONS
LIFT TYPE / TWO POST
ELEC / HYDRAULIC
LIFTING CAPACITY ML-220
20,000 LBS.
PER ARM CAPACITY ML-220
5,000 LBS.
LIFTING SPEED (LOADED)
80-90 SEC APPROX
LOWERING SPEED (LOADED)
75 SECONDS APPROX
LIFTING HEIGHT (STROKE)
72 INCHES
OVERALL WIDTH
151-1/2 INCHES
WIDTH BETWEEN POST
120 INCHES
WIDTH BETWEEN LIFTING ARMS
102 7/8 INCHES
POST HEIGHT
104 INCHES
CYLINDER EXTENSION
162 INCHES
OVERHEAD HYDRAULIC LINES
180 INCHES
LIFTING PAD HEIGHT (MIN)
5 INCHES
LIFTING PAD HEIGHT (MAX)
87 INCHES
SHIPPING WEIGHT
3,100 LBS.
POWER UNIT SPECIFICATIONS
BRAND NAME
Bucher
MODEL
M-4509-0194
POWER UNIT TYPE
VERTICAL
MOTOR VOLTAGE
208 / 230
F.L.A. AT RATED CAPACITY
22.5 / 20.4
MOTOR HORSEPOWER
4
MOTOR PHASE
SINGLE
MOTOR CYCLE / HERTZ
60
MOTOR SPEED (R.P.M.)
3450
PUMP FLOW (G.P.M.)
2.5 @ 3450 R.P.M.
RELIEF VALVE SETTING ML-220
2650 PSI
RESERVOIR CAPACITY
5 GALLONS
HYDRAULIC FLUID MEDIUM
DEXRON III
Performance Table
0
2000
4000
6000
8000
10000
12000
14000
16000
0500 1000 1500 2000
Pump Pressure (PSI)
Load (LBS)
SUGGESTED SITE SELECTION / BAY SIZE
WIDTH
DEPTH
HEIGHT
15 FEET
30 FEET
15 FEET
NOTE
THE PLACEMENT OF THE UNIT IS DETERMINED BY THE TYPE
(LENGTH, WIDTH, HEIGHT) OF VEHICLE BEING SERVICED.
WEJ-IT ANCHOR SPECIFICATIONS
LENGTH
DRILL
DEPTH
DRILL
SIZE
DRILL SIZE
MIN. MAX.
TORQUE
6 IN.
THRU
3/4 IN.
.775 IN. .787 IN.
SEE
ANCHOR
SPECS
PRE-EXISTING FLOOR REQUIREMENTS
MINIMUM
THICKNESS
MINIMUM COMPRESSIVE
STRENGTH
MINIMUM
AGING
6 - 1/2 IN
4000 P.S.I.
28 DAYS
DO NOT INSTALL ANY MOHAWK LIFT ON ANY SURFACE OTHER
THAN CONCRETE CONFORMING TO THE MINIMUM
COMPRESSIVE STRENGTH, MINIMUM AGING, AND THE
MINIMUM THICKNESS STATED ABOVE.
DO NOT INSTALL ANY MOHAWK LIFT ON EXPANSION SEAMS OR
ON CRACKED, OR DEFECTIVE CONCRETE.
DO NOT INSTALL ANY MOHAWK LIFT ON SECONDARY FLOOR
LEVELS OR ANY SURFACE WITH A BASEMENT BENEATH
WITHOUT WRITTEN AUTHORIZATION FROM THE BUILDING
ARCHITECT. NEVER HAND MIX YOUR OWN CONCRETE.
IF FOR ANY REASON A NEW CONCRETE SLAB SECTION IS
REQUIRED, FOLLOW THE INSTRUCTIONS FOR THE FLOOR
MODIFICATION DATA.
FLOOR MODIFICATION DATA
NEW FLOOR SECTION
THICKNESS
SLAB SIZE
WIDTH X LENGTH
CUBIC
YARDS
12 INCHES
72 INCHES x 168 INCHES
3.1
IF, FOR ANY REASON, A NEW CONCRETE SLAB SECTION IS
REQUIRED, MINIMUM THICKNESS, COMPRESSIVE STRENGTH,
AND PROPER AGING IS MANDATORY.
THE NEW SLAB SECTION MUST BE TOTALLY SURROUNDED BY
AN EXISTING CONCRETE FLOOR THAT IS STRUCTURALLY
SOUND. CERTIFIED STRENGTH DOCUMENTATION SHOULD BE
OBTAINED FROM THE FIRM WHO SUPPLIES THE CONCRETE
MIXTURE AT THE TIME OF THE POUR.
NEVER HAND MIX THE CONCRETE. REFER TO NEW SLAB
RECOMMENDATIONS SECTION.

MOHAWK MODEL ML-220
4
ML-220 PACKING LIST
*** ALSO SEE DRAWINGS MAN511, MAN512, & MAN513 IN PARTS MANUAL ***
ORDER
NUMBER
PART
NUMBER
PART
DESCRIPTION
QTY.
015-000-014
PARTS BOX #1CONTENTS
1
623
007-007-075
SHIM BAG
1
040
012-012-047
LIFTING PAD
4
627
012-012-058
SMALL PARTS BAG
1
145
012-012-113
SWING ARM PIN
4
600-670-003
WEJ-)
16
482
600-690-008
LOCK NUT, 1-3/8-12 NF
8
460
601-170-008
HUBBLE CONNECTOR (FEMALE)
1
020-001-017
MANUAL, ML-220 (Installation/Operation/Maintenance)
1
627
012-012-058
SMALL PARTS BAG CONTENTS
171
600-640-019
BOLT, 1/4-20 X 1-1/2
10
258
600-690-005
LOCK NUT, 1/4-20 NC
10
259
600-710-004
WASHER, 1/4 SAE FLAT
4
021
601-310-005
BREATHER CAP
1
094
601-420-011
FITTING, DOUBLE MALE UNION # 6 JIC
4
409
601-710-001
DOUBLE LINE CLIP
6
600-710-006
WASHER, FLAT, FENDER, 5/16 ID X 1 ½OD
6
601-460-010
SWING ARM BOLT CAPS
4
623
007-007-075
SHIM BAG CONTENTS
633
600-740-001
SHIM, 1/16 (BLUE)
8
634
600-740-002
SHIM, 1/8 (RED)
8
635
600-740-003
SHIM, 1/4 (BLACK)
8
012-012-057
PARTS BOX #2 CONTENTS
057
012-012-151
HEIGHT ADAPTER (7 1/2 INCH)
4
047
018-000-105
HEIGHT ADAPTER (10 INCH)
4
046
018-000-106
HEIGHT ADAPTER (5 INCH)
4

MOHAWK MODEL ML-220
5
RECOMMENDED TOOL LIST
SIZE / QTY
DESCRIPTION
USED IN
1 - 1/8 IN
WRENCH & SOCKET
WEJ-IT ANCHORS
15 / 16 IN
WRENCH & SOCKET
CARRIAGE STOPS
11/16 IN
WRENCH
HYDRAULIC LINES
5/8 IN
WRENCH
HYDRAULIC LINES
1/2 IN
WRENCH & SOCKET
BACKBOARD
7/16 IN
WRENCH & SOCKET
LINE CLIPS
1
RATCHET WRENCH
AS NEEDED
1
SNAP RING PLIERS
AS NEEDED
2IN
WRENCH & SOCKET
SWING ARM PINS
1
VICE GRIPS
AS NEEDED
2 1/4 IN
CRESCENT WRENCH
AS NEEDED
1
4 FT BUBBLE LEVEL
VERIFY LEVEL ASSEMBLY
1
PRY BAR
MOVING HEAVY ITEMS
1
TIN SNIPS
PACKAGING BANDING
1
CHALK LINE
FLOOR LAYOUT
1
SOAP STONE
FLOOR LAYOUT
1
25 FT TAPE MEASURE
FLOOR LAYOUT / SQUARING POST
1
MEDIUM HAMMER
WEJ-IT ANCHORS
1
HAMMER DRILL
DRILLING CONCRETE
1
DRILL BIT (3/4 INCH)
DRILLING CONCRETE
1 TON
LIFTING DEVICE W/SLING
LIFTING / MOVING HEAVY ITEMS
8 FT
STEP LADDER
ASSEMBLE ELEVATED ITEMS
100 FT
LEAD CORD
OPERATE ELECTRICAL TOOLS

MOHAWK MODEL ML-220
6
BEFORE INSTALLING A LIFT
IMPORTANT
BEFORE INSTALLING A MOHAWK LIFT THERE ARE A FEW ITEMS THAT MUST BE INSPECTED. EACH REPAIR SHOP BAY IS DIFFERENT. IN
AN ATTEMPT TO PREVENT OVERSIGHTS, ALL OF THE FOLLOWING INFORMATION IS TO BE VERIFIED.
OVERHEAD OBSTRUCTIONS
THE AREA WHERE THE LIFT WILL BE LOCATED SHALL BE FREE
OF OBSTRUCTIONS. HEATERS, BUILDING SUPPORTS,
ELECTRICAL CONDUIT; ALL OF THESE ITEMS ARE TO BE
TWELVE FEET ABOVE THE BAY FLOOR. SEE FIGURE 1 & 8.
DEFECTIVE CONCRETE
VISUALLY INSPECT THE BAY FLOOR AREA. THE UNIT CANNOT
BE INSTALLED ON EXPANSION SEAMS, OR CONCRETE THAT IS
CRACKED. THE UNIT IS ONLY AS STRONG AS THE FLOOR IT IS
INSTALLED ON.
FLOOR REQUIREMENTS
THIS INFORMATION IS IN THE GENERAL FLOOR REQUIREMENTS.
IF THE BAY FLOOR DOES NOT CONFORM TO THESE
     

LOCATE THE MAIN SIDE POST ON THE HIGH SIDE OF THE FLOOR
IF A SLOPE IS NOTED. REFER TO FIGURE 9.
POWER SUPPLY
THE STANDARD POWER UNIT IS 220-VOLT SINGLE PHASE. REFER
TO THE POWER UNIT SPECIFICATIONS SECTION. REQUIREMENTS
MAY VARY ON SPECIAL ORDERS.
THE MAIN SIDE POST WILL REQUIRE THE POWER SUPPLY FOR
THE UNIT. NOTE THE LOCATION OF THE POWER SUPPLY.
BAY SIZE
TO OPTIMIZE SHOP SPACE, IT IS ADVISED TO LOCATE A VEHICLE
 
OBSTRUCTIONS, AND ABILITY TO MOVE EQUIPMENT IN THE
BAY AREA. REFER TO FIGURE 1 & 8.
REQUIREMENTS MAY VARY ON SPECIAL ORDERS.
SPECIFICATIONS
REFERENCE ALL SPECIFICATIONS PRIOR TO INSTALLING A LIFT.
WARNING
BEFORE DRILLING THE MOUNTING HOLES

ALL ANCHORS MUST BE A MINIMUM OF 6 INCHES AWAY
FROM ANY EXPANSION SEAMS, CONTROL JOINTS, OR OTHER
INCONSISTENCIES IN THE CONCRETE. REFER TO ANCHOR
MANUFACTURER SPECIFICATIONS FOR SPECIFIC
INFORMATION CONCERNING EDGE DISTANCES AND BOLT TO
BOLT DISTANCE REQUIREMENTS. REFER TO FIGURES 3 & 4.

REFERENCE ALL FIGURES PERTAINING TO DRILLING, WEJ-IT
WARNINGS, AND INSTALLATION INSTRUCTIONS. REFER TO
FIGURES 3 & 4.

CHECK THE INSIDE DIMENSIONS OF THE POST AT THE
BOTTOM FROM THE FACE OF THE MAIN SIDE POST TO THE
FACE OF THE OFF SIDE POST. THE INSIDE DIMENSION IS 120
INCHES.

USE A SHARP DRILL BIT TO PREVENT DRILLING AN
UNDERSIZED HOLE. DRILL THE HOLE EQUAL TO THE LENGTH
OF THE WEJ-IT ANCHOR. BLOW OUT THE HOLE WITH SHOP
AIR, OR VACUUM. INSERT THE WEJ-IT ANCHOR SO THAT THE
WASHER RESTS AGAINST THE POST FOOTING.

NEVER USE AN IMPACT TOOL TO TIGHTEN THE WEJ-IT
ANCHORS. USE A TORQUE WRENCH ONLY.

MAKE SURE THE CONCRETE IS SOLID WHEN DRILLING.
CRACKS AND EXPANSION SEAMS REDUCE THE
EFFECTIVENESS OF THE WEJ-IT ANCHOR. NEVER INSTALL
THE ANCHOR UNDER THESE CONDITIONS.

DRILL EIGHT 3/4-INCH HOLES ALONG THE OUTSIDE OF THE
MAIN SIDE POST USING THE HOLES AT THE BASE OF THE POST
AS A GUIDE. INSERT AND TIGHTEN WEJ-IT ANCHORS PER
SPECS LOCATED IN THE BACK OF THIS MANUAL.

INSURE THE INSIDE DIMENSIONS BETWEEN THE MAIN AND
OFF SIDE POST IS STILL CORRECT. 120 INCHES.

DRILL EIGHT 3/4-INCH HOLES ALONG THE OUTSIDE OF THE
OFF SIDE POST USING THE HOLES AT THE BASE OF THE POST
AS A GUIDE. INSERT AND TIGHTEN THE WEJ-IT ANCHORS PER
SPECS LOCATED IN THE BACK OF THIS MANUAL.

MOHAWK MODEL ML-220
7
INSTALLATION INSTRUCTIONS
IMPORTANT
READ THIS MANUAL IN ITS ENTIRETY. BE FAMILIAR WITH PART NAMES AND HAVE A GOOD UNDERSTANDING
OF HOW THIS UNIT IS TO BE ASSEMBLED AND OF HOW INDIVIDUAL
PARTS OPERATE, BEFORE ASSEMBLING THE UNIT.
USING A CHALK LINE, LAYOUT THE FLOOR DIMENSIONS WHERE
THE UNIT WILL BE LOCATED. REFER TO FIGURES 1 & 8.
CUT THE SWING ARM BANDING AND REMOVE THE SWING
ARMS.
SECURE THE OVERHEAD LIFTING DEVICE TO THE MAIN SIDE
POST USING STRAPS OR CHAINS.
WARNING

EACH POST WEIGHS OVER 900 LBS. ERECT THE POSTS WITH
CHAINS AND STRAPS ATTACHED TO THE TOP OF THE POST.
DO NOT REMOVE THE CHAINS AND STRAPS UNTIL THE
POST HAS BEEN SECURED.
SEPARATE THE POSTS. REMOVE THE PARTS BOX, HYDRAULIC
LINES AND SUPPORTS. VERIFY PARTS BOX CONTENTS. IF
MISSING PARTS ARE NOTED, THEY CAN BE OBTAINED BY
CALLING 1-800-833-2006 OR BY CONTACTING YOUR LOCAL
MOHAWK DISTRIBUTOR.
USING THE 5/8-INCH PACKING BOLTS, NUTS AND WASHERS,
ASSEMBLE THE CARRIAGE STOPS TO THE TOP OF THE MAIN
SIDE POST. TIGHTEN TO 150 FOOT POUNDS. REFER TO FIGURE 2.
ERECT THE MAIN AND OFF SIDE POSTS TO THE UP-RIGHT
POSITION. ALIGN THE POST FOOTINGS TO THE CHALK LINE
LAYOUTS.
SECURE THE MAIN AND OFF SIDE POSTS TO THE BAY FLOOR
USING THE (16) 3/4 X 6 INCH WEJ-IT ANCHORS. REFER TO

USING THE 5/8-INCH PACKING BOLTS, NUTS AND WASHERS,
ASSEMBLE THE CARRIAGE STOPS TO THE TOP OF THE OFF SIDE
POST. TIGHTEN TO 150 FOOT POUNDS. REFER TO FIGURE 2.
ASSEMBLE THE TWO OVERHEAD HYDRAULIC LINES (FLAT ON
THE FLOOR) USING THE FOUR DOUBLE MALE UNIONS. SEE
MAN501.
ASSEMBLE TWO OF THE DOUBLE LINE CLIPS TO THE CENTER
SPAN OF THE OVERHEAD LINES APPROXIMATELY 3 INCHES
FROM THE DOUBLE UNIONS.
ASSEMBLE THE TWO OVERHEAD LINE SUPPORT BRACKETS TO
THE TOP OF THE MAIN AND OFF SIDE POST.
ERECT THE OVERHEAD HYDRAULIC LINE ASSEMBLIES. ROUTE
THE LINES THROUGH THE TOP OF EACH POST. ASSEMBLE THE
LINES TO THE HYDRAULIC CONNECTIONS AT THE TOP OF EACH
POST.
SECURE THE LINES TO THE OVERHEAD LINE SUPPORTS USING
THE TWO DOUBLE LINE CLIPS.
REMOVE THE BREATHER PORT PLUG ON THE POWER UNITS
RESERVOIR AND DISCARD. REFER TO FIGURE 11.
VERIFY FLUID LEVEL. (1/2 IN. BELOW BREATHER PORT IN THE
POWER UNIT RESERVOIR WHEN BOTH CYLINDERS ARE FULLY
RETRACTED) INSTALL THE BREATHER CAP.
AT THIS TIME HAVE A QUALIFIED ELECTRICIAN
CONNECT THE POWER SUPPLY TO THE UNIT
ENGAGE THE UP BUTTON ON THE POWER UNIT AND RAISE THE
CARRIAGES APPROX. 3 FEET, OR TO A HEIGHT SUITABLE FOR
INSTALLING THE SWING ARMS.
REMOVE & REASSEMBLE THE FOUR SWING ARM RESTRAINTS
ONTO THE MAIN AND OFF SIDE CARRIAGES. REFER TO MAN502.
LIFTING UP ON THE SWING ARM RESTRAINT. INSERT THE FOUR
SWING ARMS INTO THE CARRIAGES. REFER TO MAN506.
ALIGN THE THROUGH HOLES IN THE CARRIAGES WITH THE
THROUGH HOLES IN THE SWING ARMS. SECURE THE SWING
ARMS TO THE CARRIAGES USING THE FOUR SWING ARM PINS
AND EIGHT NYLON LOCK NUTS.
PLACE THE FOUR LIFTING PADS INTO PLACE IN THE MOUNTING
HOLE AT THE END OF EACH SLIDER. REFER TO MAN506.

MOHAWK MODEL ML-220
8
INSTALLATION INSTRUCTIONS, CONT.
BLEEDING PROCEDURE
ENGAGE THE UP BUTTON ON THE POWER UNIT. OBSERVE THE
CARRIAGE. WHEN THE MAIN AND OFF SIDE CARRIAGES HAVE
REACHED FULL HEIGHT CONTINUE TO RUN THE UNIT FOR 10
SECONDS.
RELEASE THE UP BUTTON AND WAIT ONE MINUTE, THEN HOLD
THE UP BUTTON AGAIN FOR 10 SECONDS. REPEAT THIS
PROCEDURE THREE TIMES (THIS WILL PURGE THE AIR FROM
THE HYDRAULIC SYSTEM)
NOTE

LISTEN FOR THE PRESSURE RELIEF VALVE. A NOTICEABLE
INCREASE IN POWER UNIT VOLUME THIS MAY INDICATE
THAT THE NUTS ON THE LIFTING RODS NEED TO BE
ADJUSTED. ADJUST THE NUTS EVENLY ON BOTH SIDES OF
THE CARRIAGE TO ALLOW THE CYLINDERS TO FULLY
STOKE AT THE TOP.
PLACE THE FOUR 5 INCH., 7 ½INCH AND 10 INCH HEIGHT
ADAPTERS INTO PLACE INTO THE HEIGHT ADAPTER BRACKETS.
REFER TO MAN505.
SHIMMING THE POST
LEVEL THE POST BY INSERTING THE SUPPLIED SHIMS UNDER
THE POST FOOTING AROUND THE WEJ-IT ANCHOR. THE LIFT
MUST BE LEVEL BOTH FRONT TO REAR AND SIDE TO SIDE. A
LEVELING DEVICE AND A MEASURING TAPE MUST BE USED.
REFER TO FIGURES 5 & 6.

LEVEL THE MAIN SIDE POST FRONT TO REAR AND SIDE-TO-
SIDE USING A BUBBLE LEVEL.

LEVEL THE OFF SIDE POST FRONT TO REAR USING A
BUBBLE LEVEL. SET THE POST PARALLEL TO THE MAIN
SIDE POST USING A MEASURING TAPE, MEASURING FROM
THE EDGE OF THE MAIN SIDE CHANNEL TO THE EDGE OF
THE OFF SIDE CHANNEL AT THE BASE AND AT THE TOP OF
THE POST.

THE MEASUREMENT AT THE TOP OF THE POST MUST BE
THE SAME AS THE MEASUREMENT AT THE BASE OF THE
POST.
AT THIS TIME PERFORM THE PRE-OPERATION CHECK LIST AND
MAINTENANCE PROCEDURES (DAILY - WEEKLY - MONTHLY)
MAKE ALL ADJUSTMENTS PERTAINING TO THESE PROCEDURES.
DIVERTER VALVE OPERATION
WARNING
AS WITH ALL FUNCTIONS OF THE LIFT UNIT, NEVER OPERATE
THE DIVERTER VALVE UNLESS YOU HAVE FIRST PERFORMED
THIS OPERATION WITH NO VEHICLE, AND FULLY UNDERSTAND
ITS FUNCTIONS.
BOTH MECHANICAL SAFETIES MUST BE ENGAGED BEFORE
OPERATING THE DIVERTER VALVE.
PURPOSE

THE PURPOSE OF THE DIVERTER VALVE IS TO ENABLE THE
OPERATOR TO RAISE OR LOWER THE OFF SIDE CARRIAGE
INDEPENDENTLY OF THE MAIN SIDE CARRIAGE.
TO OPERATE THE DIVERTER VALVE
ENGAGE THE DIVERTER VALVE BY PULLING DOWN ON THE
DIVERTER VALVE PULL KNOB. REFER TO MAN504

THIS WILL DIVERT ALL FUNCTIONS OF THE POWER UNIT TO
THE OFF SIDE CYLINDER.
WITH THE VALVE ENGAGED, ENERGIZE THE POWER UNIT BY
PUSHING THE UP BUTTON.
WHEN THE DESIRED HEIGHT HAS BEEN ACHIEVED, RELEASE
THE DIVERTER VALVE PULL KNOB AND THE UP BUTTON.
PULLING DOWN ON THE LOWERING HANDLE, LOWER THE UNIT
ONTO BOTH MECHANICAL SAFETIES ENDING THIS PROCEDURE.

MOHAWK MODEL ML-220
9
SAFETY TIPS
PLEASE POST THE AUTOMOTIVE LIFT SAFETY TIPS CARD, (A COPY IS INCLUDED
IN THE PARTS BOX) WHERE THEY WILL BE CONSTANTLY REMINDED TO YOUR LIFT
OPERATOR. FOR INFORMATION SPECIFIC TO THE LIFT, ALWAYS REFER TO THE MOHAWK
MANUAL.
INSPECT YOUR LIFT DAILY. NEVER OPERATE IT
IF IT MALFUNCTIONS OR IF IT HAS BROKEN OR
DAMAGED PARTS. REPAIRS SHOULD BE MADE
WITH ORIGINAL MOHAWK PARTS.
OPERATING CONTROLS ARE DESIGNED TO
CLOSE WHEN RELEASED. DO NOT BLOCK OPEN
OR OVERRIDE THEM.

NEVER OVERLOAD YOUR LIFT BEYOND
STATED LIFTING CAPACITY. RATED CAPACITY
IS SHOWN ON NAMEPLATE AFFIXED TO THE
LIFT.
ONLY TRAINED AND AUTHORIZED PERSONNEL
SHOULD DO POSITIONING OF VEHICLE AND
OPERATION OF THE LIFT.

DO NOT ALLOW CUSTOMERS OR BY- STANDERS
TO OPERATE THE LIFT OR TO BE IN A LIFTING
AREA DURING ITS OPERATION. ONLY
PROPERLY TRAINED PERSONNEL SHOULD BE
ALLOWED TO OPERATE LIFT.

NEVER RAISE A VEHICLE WITH PERSONS
INSIDE.

ALWAYS KEEP LIFT AREA FREE OF
OBSTRUCTIONS, DEBRIS, GREASE, AND OIL.

PERFORM THE PRE-OPERATION CHECK LIST,
PER INSTRUCTIONS, BEFORE RAISING VEHICLE
TO DESIRED HEIGHT.
BEFORE DRIVING VEHICLE INTO THE BAY,
POSITION ARMS AND SUPPORTS TO PROVIDE
UNOBSTRUCTED CLEARANCE. DO NOT HIT OR
RUN OVER LIFT ARMS, ADAPTERS, OR AXLE
SUPPORTS. THIS COULD DAMAGE LIFT OR
VEHICLE.
LOAD VEHICLE ON LIFT CAREFULLY. POSITION
LIFT SUPPORTS TO CONTACT AT THE VEHICLE
  
POINTS. RAISE LIFT UNTIL SUPPORTS CONTACT
VEHICLE. CHECK SUPPORTS FOR SECURE
CONTACT WITH VEHICLE. RAISE LIFT TO
DESIRED WORKING HEIGHT. CAUTION: IF
YOU ARE WORKING UNDER VEHICLE, LIFT
SHOULD BE RAISED HIGH ENOUGH FOR
LOCKING DEVICE TO BE ENGAGED.
NOTE THAT WITH SOME VEHICLES, THE
REMOVAL OR INSTALLATION OF COMPONENTS
MAY CAUSE A CRITICAL SHIFT IN THE CENTER
OF GRAVITY, AND RESULT IN RAISED VEHICLE
INSTABILITY. REFER TO THE VEHICLE
   
RECOMMENDED PROCEDURES WHEN VEHICLE
COMPONENTS ARE REMOVED.
BEFORE LOWERING LIFT, BE SURE TOOL
     
UNDER VEHICLE. RELEASE LOCKING DEVICES
BEFORE ATTEMPTING TO LOWER LIFT.

BEFORE REMOVING VEHICLE FROM THE LIFT
AREA, POSITION LIFT ARMS AND SUPPORTS TO
PROVIDE AN UNOBSTRUCTED EXIT.

MOHAWK MODEL ML-220
10
LIFT FINAL CHECKOUT (AFTER
INSTALLATION):
REV (6/28/2012)
THIS PROCEDURE OUTLINES THE FINAL CHECKS TO MAKE
AFTER INITIAL INSTALLATION OF THE LIFT UNIT. REPEAT
THIS PROCEDURE IF THE LIFT IS RELOCATED.
AFTER THE LIFT IS FULLY ASSEMBLED, RAISE THE LIFT
EMPTY A FEW TIMES TO VERIFY:
PROPER SYNCHRONIZATION OF LIFT ARMS
UNIT IS RAISING SMOOTHLY (AIR IS BLEED FROM
HYDRAULIC SYSTEM - SEE BLEEDING PROCEDURE FOR
MORE DETAILS)
NO LEAKS PRESENT AT ANY FITTING JUNCTIONS
LOCKS ARE ENGAGING ON BOTH POSTS AS LIFT IS
RAISING
LOCKS ARE DIS-ENGAGING ON BOTH POSTS WHEN
RELEASE CABLE PULLED (SEE J-BAR ADJUSTMENT
PROCEDURE)
LOCKS ARE RE-ENGAGING AFTER DIS-ENGAGED WHEN
LIFT IS RAISED
LIFT IS NOT DRIFTING DOWN WHEN RAISED (RAISE
LIFT, THEN STOP, AND VERIFY DRIFT DOWN OF
CYLINDERS)
NO VIBRATIONS FROM LOOSE CLAMPING, ETC.
SWING ARMS ROTATE SMOOTHLY WHEN LIFT FULLY
LOWERED AND LOCK IN PLACE WHEN LIFT RAISED
ONCE THIS IS COMPLETE, LOCATE A REPRESENTATIVE VEHICLE
INTO THE LIFTING AREA. USE A VEHICLE THAT WEIGHS AT
LEAST 75 PERCENT OF THE CAPACITY OF THE LIFT.
OBSERVING LIFTING PROCEDURES CONTAINED IN THIS
MANUAL TO LOCATE VEHICLE IN LIFTING AREA, AND TO
LOCATE LIFTING PADS AT LIFTING POINTS FOR VEHICLE, AND
WHILE RAISING AND LOWERING.
RAISE LIFT APPROXIMATELY 1 FOOT. VERIFTY THE
FOLLOWING:
PROPER SYNCHRONIZATION OF LIFT ARMS
NO LOOSENING OF REAR ANCHOR BOLTS IN BASE
PLATES AT FLOOR (LOOK FOR GAP BETWEEN FLOOR
AND BASES)
UNIT IS RAISING SMOOTHLY (AIR IS BLEED FROM
HYDRAULIC SYSTEM - SEE BLEEDING PROCEDURE FOR
MORE DETAILS)
NO LEAKS PRESENT AT ANY FITTING JUNCTIONS
LOCKS ARE ENGAGING ON BOTH POSTS AS LIFT IS
RAISING
LIFT IS NOT DRIFTING DOWN WHEN RAISED (RAISE
LIFT, THEN STOP, AND VERIFY DRIFT DOWN OF
CYLINDERS)
NO VIBRATIONS FROM LOOSE CLAMPING, ETC.
RELEASE LOCKS AND LOWER UNIT. VERIFY THE
FOLLOWING:
PROPER SYNCHRONIZATION OF LIFT ARMS
UNIT IS LOWERING SMOOTHLY (AIR IS BLEED FROM
HYDRAULIC SYSTEM - SEE BLEEDING PROCEDURE FOR
MORE DETAILS)
NO LEAKS PRESENT AT ANY FITTING JUNCTIONS
NO VIBRATIONS FROM LOOSE CLAMPING, ETC.
LOCKS ARE NOT RE-ENGAGING WHILE LOWERING
RAISE LIFT TO FULL STROKE. VERIFY THE FOLLOWING:
PROPER SYNCHRONIZATION OF LIFT ARMS
NO EXCESSIVE DEFLECTION OF POSTS OR ARMS
NO LOOSENING OF REAR ANCHOR BOLTS IN BASE
PLATES AT FLOOR (LOOK FOR GAP BETWEEN FLOOR
AND BASES)
UNIT IS RAISING SMOOTHLY (AIR IS BLEED FROM
HYDRAULIC SYSTEM - SEE BLEEDING PROCEDURE FOR
MORE DETAILS)
NO LEAKS PRESENT AT ANY FITTING JUNCTIONS
LOCKS ARE ENGAGING ON BOTH POSTS AS LIFT IS
RAISING
LIFT IS NOT DRIFTING DOWN WHEN RAISED (RAISE
LIFT, THEN STOP, AND VERIFY DRIFT DOWN OF
CYLINDERS)
NO VIBRATIONS FROM LOOSE CLAMPING, ETC.
LOWER LIFT ONTO LOCKS. VERIFY THE FOLLOWING:
LOCK IS ENGAGING UPON DESCENT
PROPER SYNCHRONIZATION OF LIFT ARMS
RAISE, THEN RELEASE LOCKS, THEN LOWER VEHICLE TO
FLOOR. VERIFY THE FOLLOWING:
PROPER SYNCHRONIZATION OF LIFT ARMS
UNIT IS RAISING & LOWERING SMOOTHLY (AIR IS
BLEED FROM HYDRAULIC SYSTEM - SEE BLEEDING
PROCEDURE FOR MORE DETAILS)
NO LEAKS PRESENT AT ANY FITTING JUNCTIONS
NO VIBRATIONS FROM LOOSE CLAMPING, ETC.
LOCKS ARE NOT RE-ENGAGING WHILE LOWERING
NO LOOSENING OF REAR ANCHOR BOLTS IN BASE
PLATES AT FLOOR (LOOK FOR GAP BETWEEN FLOOR
AND BASES)
ENSURE THAT ALL MANUALS AND OTHER INSTRUCTIONAL
MATERIALS ARE DELIVERED TO OWNER/USER/EMPLOYER.
ENSURE THAT USERS ARE INSTRUCTED IN THE SAFE AND
PROPER USER OF THE LIFT.
FINAL CHECKOUT OF LIFT IS COMPLETE.

MOHAWK MODEL ML-220
11
2-POST LIMITATIONS AND ADAPTER
USAGE:
REV (2/9/2006)
2-POST LIMITATIONS:
ALL MOHAWK 2-POST LIFTS ARE FOR INDOOR USE UNLESS
SPECIFICALLY QUALIFIED AND MODIFIED FOR A CUSTOM
ENVIRONMENT.
ALL MOHAWK 2-POST LIFTS MUST ACCOMPLISH THREE MAIN
CRITERIA IN ORDER TO LIFT A VEHICLE SAFELY:
1. PROPER FRAME ENGAGEMENT WITH PADS. ALL 2-
POST FRAME ENGAGING LIFTS ARE DESIGNED TO LIFT
STANDARD VEHICLES WITHIN THEIR RATED
CAPACITY BY THE VEHICLE FRAME. IF SUITABLE
FRAME CONTACT LIFT POINTS CAN NOT BE REACHED
OR ACCOMMODATED BY THE LIFTING PADS, THE
VEHICLE MUST NOT BE RAISED WITH THE LIFT. REFER
TO VEHICLE MANUFACTURER LIFTING POINT
SPECIFICATIONS (AND VEHICLE LIFT POINT LABEL PER
SAE J2184, VEHICLE LIFT POINTS FOR SERVICE
GARAGE LIFTING).
2. PROPER CENTER OF GRAVITY PLACEMENT OF
VEHICLE ON LIFT ENSURE THAT THE CENTER OF
GRAVITY OF THE VEHICLE LIES CENTERED BETWEEN
THE LIFTING ARMS. THIS SHOULD PLACE THE CENTER
OF GRAVITY OF THE VEHICLE IN LINE WITH THE
CENTER OF THE POSTS AS WELL.
3. PROPER LOADING OF ARMS. INDIVIDUAL ARM
CAPACITIES ARE ¼OF THE RATED LIFT CAPACITY,
AND MUST NOT BE EXCEEDED. FOR INSTANCE, A 10,000
LB RATED 2-POST LIFT HAS ARMS THAT ARE RATED
FOR 2,500 LBS EACH. IT IS POSSIBLE THAT A 10,000 LB
VEHICLE CAN OVERLOAD THE ARMS ON A 10,000 LB
LIFT IF THE FRONT AND REAR LOADING ARE NOT
EQUAL.
WITH RESPECT TO HEAVY ENDED VEHICLES SUCH AS FORK
TRUCKS, DELIVERY VANS, PICKUP TRUCKS, ETC, ATTENTION
MUST BE MADE TO ENSURE THAT THE PER ARM CAPACITY OF
THE LIFTING ARMS IS NOT EXCEEDED AND THAT THE CENTER
OF GRAVITY OF THE VEHICLE LIES CENTERED BETWEEN THE
LIFTING ARMS.
SPECIAL SAFETY PRECAUTIONS MUST BE OBSERVED IN
APPLICATIONS INVOLVING VERY LONG AND VERY SHORT
WHEELBASE VEHICLES. 2-POST LIFTS ARE NOT DESIGNED TO
RAISE STRETCHED LIMOS AND OTHER TYPES OF LONG WHEEL
BASE VEHICLES. AS A RULE OF THUMB, THE VEHICLE LENGTH
ON A 2-POST MUST BE LIMITED TO 4 TIMES THE LENGTH OF THE
ARM SPREAD TO RAISE IT. THE CENTER OF GRAVITY ON THIS
VEHICLE MUST LIE BETWEEN THE LIFTING PADS TO
ACCOMPLISH THIS. NOTE THAT SOME VEHICLES, PER VEHICLE
MANUFACTURER GUIDELINES, ARE NOT TO BE RAISED BY THE
FRAME. REFER TO VEHICLE MANUFACTURER GUIDELINES FOR
PROPER LIFTING TECHNIQUES.
THIS LIFT IS NOT INTENDED, NOR DESIGNED, TO LIFT VEHICLE
FRONT OR BACK ENDS USING ONLY TWO ARMS.
CARE MUST BE OBSERVED WHEN REMOVING ANY HEAVY
COMPONENTS FROM A VEHICLE AND THEREBY DRASTICALLY
SHIFTING THE VEHICLE CENTER OF GRAVITY (I.E. ENGINE
REMOVAL, TRANSMISSION REMOVAL, ETC.). THE USE OF JACK
STANDS AT THE FRONT AND REAR ENDS OF THE VEHICLE IS
HIGHLY RECOMMENDED WHEN PERFORMING THIS TYPE OF
WORK.
ADAPTER USAGE AND LIMITATIONS:
THE USE OF HEIGHT ADAPTERS IS COMMON FOR MOST LIFTING
SITUATIONS TO ACCOMMODATE HIGH FRAMES AND LOW
OVERHANGING BODIES OF VEHICLES.
FOR A-7, A-7A, SYSTEM IA, SYSTEM IA-10, TOMAHAWK-9000:

ADAPTERS.
THESE LIFTS ARE ONLY ALLOWED TO USE 2 ADAPTERS WHEN

MAXIMUM STACKING HEIGHT. LONGER CUSTOM SINGLE PIECE
ADAPTERS ARE AVAILABLE UPON REQUEST.
FOR LMF-12, TP-15, TP-16, TP-18, ML-220, TP-20, TP-26, TP-30:

HEIGHT ADAPTERS.
THESE LIFTS ARE ONLY ALLOWED TO USE 2 ADAPTERS WHEN
ESULTING IN

PIECE ADAPTERS ARE AVAILABLE UPON REQUEST.
THE USER SHOULD BE WARNED THAT ANY SITUATION
PRODUCING AN OFF-VERTICAL SLANTING OF THE HEIGHT
ADAPTERS, SUCH AS DEFLECTION OF THE ARM DUE TO HEAVY
LOAD, DEFLECTION OF THE ARM DUE TO SLOP, ECCENTRIC
CORNER LOADING OF THE LIFT PAD, ETC. MUST BE AVOIDED.
CUPPED OR YOKE STYLE LIFTING PADS (WHICH DO NOT RELY
ON FRICTION) ARE ALSO AVAILABLE FOR SITUATIONS
INVOLVING LIFTING NON-FLAT SURFACES. CONSULT MOHAWK
SERVICE DEPARTMENT FOR CUSTOM PAD REQUESTS FOR YOU
APPLICATION.

MOHAWK MODEL ML-220
12
PRE - OPERATION CHECK LIST
TRAINED OPERATOR

THE OPERATOR MUST BE FULLY TRAINED AND QUALIFIED
TO SAFELY AND EFFECTIVELY OPERATE THIS EQUIPMENT
OF THIS SPECIFIC MAKE AND MODEL.
ABSENCE OF OBSTRUCTIONS

THE TOTAL WORK AREA MUST BE FREE OF ANY AND ALL
OBSTRUCTIONS AND BE GENERALLY CLEAN. (FREE OF OIL
AND DEBRIS)
VISUAL INSPECTION
THOROUGHLY INSPECT THE UNIT WITH A TRAINED EYE,
NOTING ANY PROBLEM AREAS. INSPECT THE FLOOR AND
THE ANCHORING FASTENERS AS WELL. REPORT ANY
QUESTIONABLE ITEMS.
THROUGHLY INSPECT ALL LIFTING PADS AND HEIGHT
ADAPTERS FOR ANY WEAR, RUST, DEBRIS, OR
DEFORMITIES. IF NEEDED, THROUGHLY CLEAN AND OIL
WITH LIGHT OIL OR LUBRICANT, SUCH AS WD-40. ENSURE
NO OIL OR GREASE IS PRESENT ON TOP SURFACE OF PADS,
WHERE PADS CONTACT VEHICLE PICK POINTS.
NO LOAD PERFORMANCE CHECK

ALL MECHANICAL SAFETIES OPERATE PROPERLY AND
CONSISTENTLY.

NO EXTERNAL FLUID LEAKS.

NO BLEED DOWN.

EFFORTLESS AND SIMULTANEOUS MOVEMENT.

LEVEL LIFTING.

CONTROLS FUNCTION PROPERLY.

ALL SAFETY MECHANISMS FULLY FUNCTIONAL.
PREVIOUS DAY' S OPERATION REPORT

VERIFY WITH SUPERVISOR THAT THERE WAS NO
PROBLEMS EXPERIENCED THE PREVIOUS DAY. IF THERE
WERE ANY PROBLEMS, VERIFY THAT ALL NECESSARY
REPAIRS HAVE BEEN COMPLETED.
LIFTING PROCEDURES
LIFT PREPARATION AND VEHICLE POSITIONING

PERFORM PRE-OPERATION CHECK LIST ITEM BY ITEM.

POSITION THE SWING ARM TO THE OUTSIDE OF THE UNIT.

POSITION THE VEHICLE CENTERED BETWEEN THE POSTS
NOTE:
       
CENTERLINE OF THE POSTS. THIS CAN BE VERIFIED BY
VIEWING THE CAM FOLLOWER BEARINGS ON THE
CARRIAGE. THESE BEARINGS ARE LOCATED AT EACH
CORNER OF THE CARRIAGE. CENTERING OF VEHICLE IS
ACHIEVED WHEN ALL 4 CAM FOLLOWER BEARINGS ARE
FREE TO SPIN.

PLACE THE LIFTING 
POINTS FOR THE VEHICLE. REFER TO ALI/LP-GUIDE,
ALI/SM01-
RECOMMENDED LOCATION AND FORMAT OF THE VEHICLE
LIFT POINT LABEL PER ANSI/SAE J2184-OCT92.
FRAME RAILS/PICK POINTS ARE TO BE CENTERED ON
LIFTING PADS AND REST FLAT ON LIFTING PAD SURFACES
(SEE FIGURE 15)
LIFT PAD IS TO BE FULLY INSERTED INTO SLIDER HOLE OR
HEIGHT ADAPTER.
NO MORE THAN (2) TWO HEIGHT ADAPTERS ARE TO BE
USED AT ANY TIME FOR ANY SINGLE LIFTING PAD.
CAUTION:
IF PROPER AND SAFE LIFTING POINTS ON THE FRAME OF
THE VEHICLE CAN NOT BE REACHED BY THE LIFTING PADS,
DO NOT RAISE THIS VEHICLE!
TO RAISE

ENGAGE THE UP-BUTTON ON THE POWER UNIT.

RAISE VEHICLE TO THE DESIRED WORKING HEIGHT.

LOWER THE UNIT ONTO THE MECHANICAL SAFETIES.
TO LOWER

INSPECT THE LIFTING AREA TO INSURE THAT ALL
PERSONNEL AND DEBRIS HAVE BEEN CLEARED FROM THE
LIFTING AREA.

ENGAGE THE UP-BUTTON ON THE POWER UNIT.

RAISE UNIT APPROXIMATELY TWO INCHES.

DISENGAGE THE MECHANICAL SAFETIES.

LOWER UNIT TO THE DESIRED WORKING HEIGHT.

ALWAYS ENGAGE THE UP-BUTTON ON THE POWER UNIT
AND RAISE UNIT UNTIL BOTH MECHANICAL SAFETIES RE-
ENGAGE.
LOWER THE UNIT ONTO THE MECHANICAL SAFETIES.
IF WORK IS COMPLETE, CONTINUE LOWERING THE
UNIT UNTIL BOTH CARRIAGES ARE FULLY LOWERED.
NOTE: IF FOR ANY REASON, THE LIFT BECOMES INOPERATIVE
IN THE RAISED POSITION WITH A VEHICLE ON IT, CONTACT
YOUR LOCAL MOHAWK REPRESENTATIVE OR THE MOHAWK
FACTORY.

MOHAWK MODEL ML-220
13
MAINTENANCE PROCEDURES
-- TRAINED LIFT SERVICE PERSONNEL ONLY 
DAILY

PERFORM THE PRE-OPERATION CHECK LIST.

REPORT ANY AND ALL EQUIPMENT MALFUNCTIONS
IMMEDIATELY.

CLEAN ALL MOVING PARTS. (IT IS NOT RECOMMENDED TO
GREASE THE INSIDE OF THE CHANNEL ON THE POST,
SWING ARMS OR SWING ARM RESTRAINTS.) IF
OXIDIZATION IS OCCURRING USE A LIGHT LUBRICANT. (WD
- 40 OR EQUIVALENT)

KEEP AREA AROUND THIS EQUIPMENT FREE OF DIRT,
SAND, WATER, ETC.
WEEKLY

PERFORM THE DAILY OPERATION CHECK LIST.

WIPE CLEAN, THE CYLINDERS' WIPER SEALS AND THE BASE
OF EACH POST TO REMOVE ANY WEEPING OIL AND DUST.

VERIFY FLUID LEVEL. WITH THE UNIT FULLY LOWERED,
THE FLUID LEVEL WILL BE 1/2 INCH BELOW THE BREATHER
CAP PORT. USE DEXRON III AS REPLACEMENT FLUID.

LUBRICATE THE ARM RESTRAINT ASSEMBLIES AS NEEDED
TO INSURE FREE, AND SMOOTH OPERATION.
(DO NOT USE GREASE)
CYCLE UNIT TO FULL HEIGHT, AND BLEED
APPROXIMATELY 30 SECONDS.
MONTHLY

INSPECT LIFTING COMPONENTS FOR DEFORMATION, WEAR
OR CORROSION.

INSPECT ALL HYDRAULIC COMPONENTS FOR LEAKS,
DEFORMATION, WEAR OR CORROSION.

TIGHTEN ALL FASTENERS AND HYDRAULIC FITTINGS AS
REQUIRED.
1. ALL O - RING BOSS FITTINGS JAM NUTS ARE TO BE
TIGHTENED TO 15-FOOT POUNDS TORQUE.
2. ALL PIPE FITTINGS, IF LEAKING IS TO BE REMOVED,
RE-SEALED, AND RE - INSTALLED. (SELECT - UNITE
THREAD SEALANT OR EQUIVALENT ON FITTING
THREADS)

INSPECT ANCHOR CONDITIONS FOR ANY POSSIBLE
CORROSION AND INSPECT THE FLOOR FOR ANY SIGNS OF
FATIGUE OR FRACTURES.
SEMI- ANNUAL

QUALIFY / RE-QUALIFY ALL PERSONNEL IN THE SAFE
OPERATION OF THIS UNIT.
VERIFY ALL FASTENERS TO PROPER TORQUE:
SWING ARM NUTS TIGHTEN TO 1000 FT-LB,
THEN BACK OFF UNTIL ARMS MOVE FREELY.
CARRIAGE STOP FASTENERS TO 150 FT-LB
CARRIAGE SIDE ROLLER NUTS TO 250 FT-LB
LIFTING ROD NUTS TO 650 FT-LB
CYLINDER TOP BOLT TO 650 FT-LB
ANCHORS (SEE ANCHOR SPECIFICATION SECTION)
LUBRICATE LOCK BODY MAIN PIVOT PINS. REMOVE WITH
SNAP RING PLIERS WHEN FULLY LOWERED AND CLEAN
LOCK PIVOT PIN AND LOCK BODY HOLE. SPRAY PIN WITH A
LIGHT LUBRICANT (WD-40 OR EQUIVALENT), THEN RE-
ASSEMBLE, ENSURING SMOOTH MOTION.
THE CHANNEL SECTIONS WHERE THE CARRIAGE BEARINGS
RIDE AGAINST SHOULD BE CLEANED AND LUBRICATED
USING SLIP PLATE OR A LIGHT LUBRICANT (WD-40).
THE MAIN CARRIAGE BEARINGS ARE FACTORY
LUBRICATED AND SEALED. THEY DO NOT REQUIRE ANY
ADDITIONAL PERIODIC LUBRICATION. HOWEVER, IF
ADDITIONAL LUBRICATION IS DESIRED ON THESE UNDER
     
PROGRAM, IT IS RECOMMENDED TO USE CAM2 
MULTIPURPOSE #2 GREASE (PART NO. 86035) OR
EQUIVALENT. USE APPROXIMATELY 2 OZ. PER BEARING.
ANNUALLY

CHECK YOUR HYDRAULIC FLUID VOLUME ANNUALLY.
EVERY TEN YEARS REPLACE AND RE-BLEED THE
HYDRAULIC FLUID. ALWAYS USE A CLEAN FUNNEL AND
FILTER. USE DEXRON III HYDRAULIC FLUID.

INSPECT ALL BEARINGS FOR UNUSUAL OR EXCESSIVE
WEAR. (REPLACE IF NEEDED)

REMOVE THE SWING ARM RESTRAINTS. THOROUGHLY
CLEAN. USE A LIGHT LUBRICANT (WD-40 OR EQUIVALENT)
REINSTALL. DO NOT USE GREASE.

REMOVE THE SWING ARMS. THOROUGHLY CLEAN. USE A
LIGHT LUBRICANT (WD-40 OR EQUIVALENT) REINSTALL.
DO NOT USE GREASE.

PERFORM THE DAILY, WEEKLY, AND MONTHLY
MAINTENANCE PROCEDURES.
PART REPLACEMENT NOTES

REPLACE ALL WORN OR BROKEN PARTS WITH GENUINE
LIFT MANUFACTURER SUPPLIED PARTS (FROM MOHAWK
RESOURCES LTD. ONLY)
ALL REPLACEMENTS OF PARTS ARE TO BE PERFORMED BY
TRAINED LIFT SERVICE PERSONNEL ONLY.
UPON PART REPLACEMENT, LIFT MUST PASS A FULL LIFT
INSPECTION AS DEEMED SUITABLE BY TRAINED LIFT
SERVICE PERSONNEL.

MOHAWK MODEL ML-220
HYDRAULIC SAFETY CHECKS / TROUBLE SHOOTING
WARNING: NEVER ATTEMPT TO LOOSEN HYDRAULIC FITTINGS, OR OVERRIDE SAFETY
DEVICES IN AN ATTEMPT TO CORRECT A PROBLEM. ALL TESTS ARE TO BE PERFORMED
WITH NO VEHICLE.
NOTE: THE HYDRAULIC SAFETY CHECK IS TO BE PERFORMED WITH NO VEHICLE ON THE
UNIT. THE HYDRAULIC SYSTEM CHECKS WILL DETECT INTERNAL HYDRAULIC LEAKS.
CONTACT YOUR LOCAL MOHAWK DISTRIBUTOR OR THE MOHAWK FACTORY SERVICE
DEPARTMENT IF A CHECK SHOULD FAIL.
MAINSIDE SAFETY CHECK:
1. RAISE THE UNIT APPROXIMATELY 3 FEET
2. DISENGAGE THE OFFSIDE MECHANICAL SAFETY
3. LOWER THE UNIT ONTO THE MAINSIDE MECHANICAL
SAFETY
4. WHILE CONTINUING TO HOLD DOWN THE POWER UNIT
LOWERING HANDLE, OBSERVE THE OFFSIDE
CARRIAGE FOR MOVEMENT. THE UNIT HAS CHECK
OUT OK IF THERE IS NO MOVEMENT (OFFSIDE
CARRIAGE DOES NOT CONTINUE TO LOWER)
OFFSIDE SAFETY CHECK:
1. RAISE THE UNIT APPROXIMATELY 3 FEET
2. DISENGAGE THE MAINSIDE MECHANICAL SAFETY
3. LOWER THE UNIT ONTO THE OFFSIDE MECHANICAL
SAFETY
4. WHILE CONTINUING TO HOLD DOWN THE POWER UNIT
LOWERING HANDLE, OBSERVE THE MAINSIDE
CARRIAGE FOR MOVEMENT. THE UNIT HAS CHECK
OUT OK IF THERE IS NO MOVEMENT (MAINSIDE
CARRIAGE DOES NOT CONTINUE TO LOWER)
OFFSIDE CYLINDER / DIVERTER VALVE CHECK:
(TO BE PERFORMED WHEN OFFSIDE CYLINDER DRIFTS
DOWN)
1. RAISE THE UNIT APPROXIMATELY 3 FEET
2. DISENGAGE BOTH MECHANICAL SAFETIES
3. REMOVE THE BLEED LINE FROM THE TOP OF THE
OFFSIDE CYLINDER AND CAP USING MOHAWK PN #601-
420-001.
4. IF THE OFFSIDE CYLINDER NO LONGER DRIFTS DOWN,
THEN THE OFFSIDE CYLINDER WILL NEED TO BE
SERVICED.
5. IF THE OFFSIDE CYLINDER CONTINUES TO DRIFT
DOWN, THEN THE DIVERTER PULL VALVE WILL NEED
TO BE SERVICED.
MAINSIDE CYLINDER PISTON CHECK:
(THIS CHECK IS TO BE PERFORMED AFTER ALL THE OTHER
HYDRAULIC SAFETY CHECKS HAVE BEEN PERFORMED)
1. RAISE A VEHICLE SO THAT ALL FOUR TIRES ARE OFF
THE FLOOR.
2. MEASURE AND RECORD THE CARRIAGE HEIGHTS ON
THE MAINSIDE AND OFFSIDE.
3. CYCLE THE LIFT UP AND DOWN FOUR TIMES WITHOUT
GOING TO FULL HEIGHT OR LETTING THE VEHICLE
TIRES CONTACT THE FLOOR.
4. LOWER THE UNIT, STOPPING WHEN THE TIRES ARE AT
THE APPROXIMATE HEIGHT AT THE BEGINNING.
5. MEASURE MAINSIDE AND OFFSIDE CARRIAGE
HEIGHTS AGAIN.
6. THE CHECK HAS FAILED IF THE MEASUREMENTS
CHANGE MORE THAN ¼INCH.
