Mohawk V-085-C-X User manual

IMPORTANT SAFETY INSTRUCTIONS
(SAVE THESE INSTRUCTIONS)
OPERATION AND MAINTENANCE MANUAL
Mohawk Lifts, LLC.
P.O. Box 11065 Vrooman Ave
Amsterdam, NY 12010
[phone](518) 842-1431
FAX: [phone]
www.mohawklifts.com
[e-mail]
“Before proceeding with installation, operating, servicing,
or maintain the lift, the user must read the manual carefully...”
X=23, 26, 30, 33, 36, 48
Noiselevels 70dB(A)

MV-C00000920 MOHAWK V-C SERIES: VERTICAL RISE DRIVE-ON MANUAL 85,000 - 99,000 LB MODEL
1-1
INDEX....................ENGLISH
IMPORTANT SAFETY INSTRUCTIONS............................................1-1
1. GENERAL INFORMATION...........................................1-1
1.1. MARKING DATA.............................................................................1-1
1.2. ASSISTANCE..................................................................................1-1
1.3. INTELLECTUAL AND INDUSTRIAL PROPERTY..........................1-1
1.4. DESCRIPTION OF PERSONNEL ..................................................1-1
2. DESCRIPTION OF THE MACHINE................................2-1
2.1. EXPECTED USE.............................................................................2-1
2.2. TECHNICAL DATA .........................................................................2-1
2.3. NOMENCLATURE ..........................................................................2-1
2.4. OVERALL DIMENSIONS................................................................2-3
2.5. LOADING CONDITIONS.................................................................2-4
2.6. JACKING BEAM..............................................................................2-2
3. SAFETY.......................................................................3-1
3.1. GENERAL SAFETY REGULATIONS.............................................3-1
3.2. PRECAUTION.................................................................................3-2
3.3. OWNER/EMPLOYER RESPONSIBILITIES ...................................3-3
3.4. IMPROPER USE.............................................................................3-4
3.5. SAFETY DEVICE FEATURES........................................................3-5
3.6. RESIDUAL RISKS...........................................................................3-6
3.7. STICKERS AND PLATES...............................................................3-7
4. INSTALLATION.............................................................4-1
4.1. TRANSPORT AND HANDLING......................................................4-1
4.2. INSTALLATION...............................................................................4-3
4.2.1. Installation sequence...................................................4-3
4.3. PLACE OF INSTALLATION............................................................4-4
4.4. CONNECTING THE LIFT................................................................4-5
4.5. CONNECTING THE LIFT’S COMMANDS......................................4-5
4.5.1. Hydraulic connections..................................................4-5
4.5.2. Pneumatic connection................................................. 4-7
4.5.3. Electric connection...................................................... 4-8
4.6. FILLING OF THE CIRCUIT MASTER-SLAVE..............................4-11
4.7. LIFT POSITION.............................................................................4-12
4.8. EXTENSIONS INSTALLATION (IF PRESENT)............................4-13
4.9. CHECK..........................................................................................4-14
4.10. ANCHORAGE CAPSULE INSTALLATION...................................4-15
4.11. CHECKS BEFORE USE...............................................................4-16
4.12. FINAL TESTING............................................................................4-17
4.13. LIFT OPERATIONAL TEST..........................................................4-17
4.13.1. Lift Operation..............................................................4-17
4.13.2. Caution.......................................................................4-17
4.13.3. To Load a Typical Vehicle..........................................4-17
4.13.4. To Raise the Lift.........................................................4-17
4.13.5. To Lower the Lift.........................................................4-17
5. USE............................................................................... 5-1
5.1. OPERATION COMMANDS.............................................................5-1
6. MAINTENANCE ........................................................... 6-1
6.1. ORDINARY/EXTRAORDINARY MAINTENANCE..........................6-1
6.2. TABLE ADJUSTMENT PROCEDURES .........................................6-3
6.2.1. Maximum pressure valve calibration............................ 6-3
6.2.2. Photocell ..................................................................... 6-4
6.2.3. Parachute valve........................................................... 6-5
6.2.4. Platforms levelling....................................................... 6-6
6.2.5. Unblocking safety locks............................................... 6-7
6.2.6. Bleeding air from the volumetric circuit........................ 6-7
6.3. EMERGENCY MANUAL LOWERING ............................................6-8
6.4. ABNORMAL OPERATION..............................................................6-9
6.5. . LIFT LOCKOUT/TAGOUT PROCEDURE ..................................6-10
7. ACCESSORIES.......................................................................... 7-1

MV-C00000920 MOHAWK V-C SERIES: VERTICAL RISE DRIVE-ON MANUAL 85,000 - 99,000 LB MODEL
1-1
READ ALL INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
When using your garage equipment, basic safety precautions should always be followed, including the following:
1. Read all instructions.
2. Care must be taken as burns can occur from touching hot parts.
3. Do not operate equipment with a damaged cord or if the equipment has been dropped or damaged until it has been examined by a qualified service
person.
4. Do not let a cord hang over the edge of the table, bench, or counter or come in contact with hot manifolds or moving fan blades.
5. If an extension cord is necessary, a cord with a current rating equal to ormore than that of the equipment should be used. Cords rated for less
current than the equipment may overheat. Care should be taken to arrange the cord so that it will not be tripped over or pulled.
6. Always unplug equipment from electrical outlet when not in use. Never use the cord to pull the plug from the outlet. Grasp plug and pull to
disconnect.
7. Let equipment cool completely before putting away. Loop cord loosely around equipment when storing.
8. To reduce the risk of fire, do not operate equipment in the vicinity of open containers of flammable liquids (gasoline).
9. Adequate ventilation should be provided when working on operating internal combustion engines.
10. Keep hair, loose clothing, fingers, and all parts of body away from moving parts.
11. To reduce the risk of electric shock, do not use on wet surfaces or expose to rain.
12. Use only as described in this manual. Use only manufacturer's recommended attachments.
13. ALWAYS WEAR SAFETY GLASSES. Everyday eyeglasses only have impact resistant lenses, they are not safety glasses.
14. To reduce the risk of injury, close supervision is necessary when this product will be used around children. (Pertains to cabinets only.)
15. To reduce the risk of injury, never overload the drawers or shelves. Refer to loading instructions.
16. To reduce the risk of electric shock or fire, never overload receptacles. Refer to markings for the proper load on receptacles.
SAVE THESE INSTRUCTIONS

MV-C00000920 MOHAWK V-C SERIES: VERTICAL RISE DRIVE-ON MANUAL 85,000 - 99,000 LB MODEL
1-1
1. GENERAL INFORMATION
1.1. Marking data
Table identification plate:
1.2. Assistance
Please use the following contact details for assistance requests :
Mohawk Lifts, LLC.
Phone: [phone] x 3000
Email: [e-mail]
1.3. Intellectual and industrial property
Designed & manufactured by O.ME.R. and patented worldwide.
1.4. Description of personnel
TERMS AND DEFINITIONS
SPECIALISED TECHNICIAN/EMPLOYER:
the person(s) appointed to:
oinstall,
oset up,
oadjust
operform maintenance on,
oclean,
orepair
otransport the lift.
operform certain maintenance operations that require
specific preparation and expertise in the mechanics,
electrical, electronic, oil-hydraulic and pneumatic fields.
The specialised technician is aware of any risks present on the machine
and the procedures to be followed to avoid damage to his/herself or others
during such maintenance operations.
EXPOSED PERSON: any person wholly or partly in a hazardous area.
HAZARDOUS OR RISKY AREA: any area inside and/or close to a
machine in whose presence an exposed person constitutes a risk for
his/her health and safety.
USER/OWNER: anyone who buys or possesses the lift in any way (on
loan, hire, lease, etc.), with the intention of using it as indicated by the
manufacturer.
MAINTENANCE: all activities, which shall be done to keep the system
in efficiency and in good condition.
DPI: (PPE) Personal protection equipment.

MV-C00000920 MOHAWK V-C SERIES: VERTICAL RISE DRIVE-ON MANUAL 85,000 - 99,000 LB MODEL
2-1
2. DESCRIPTION OF THE MACHINE
Addressees:
-USER/OWNER;
-SPECIALISED TECHNICIAN/EMPLOYER.
2.1. Expected use
The function of the vehicle lift is to lift motorized vehicles, which have the
distribution of the loading according standard in force.
The vehicle movement has to be done with lift closed.
The accessories indicated in the relating chapter can be used.
2.2. Technical data
LIFT
CAPACITY
V-085-C
Lb
85,000
V-090-C
Lb
90,000
V-095-C
Lb
95,000
V-099-C
Lb
99,000
JACKING BEAM CAPACITY
Lb
35,000
MOTOR POWER
KW
7,5
HP
10
ELECTRIC POWER SUPPLY
V
220-240
THREE-
PHASE
440-480
Hz
60
V
A
Hz
TOTAL ABSORBED CURRENT MAX
200-208
33
60
230-240
29
400
17
460-480
15
550-575
13
PNEUMATIC POWER SUPPLY
bar
8
Filtered and
lubricated
psi
116
MAXIMUM
PRESSURE
OF
HYDRAULIC
POWER
SUPPLY
V-085-C
psi
3360
V-090-C
psi
3560
V-095-C
psi
3770
V-099-C
psi
3920
QUANTITY OF OIL
LT
40
UPSTROKE/DOWNSTROKE
TIME
S
100/100
MIN/MAX OPERATING
TEMPERATURE
°C
-10° +40
SOUND EMISSION LEVEL
db(A)
< 80
INSTALLATION
INDOOR
Outdoor installation is prohibited
NOTE :
A qualified person should be consulted to address seismic loads and other
local or state requirements.
2.3. Nomenclature
MODELS LEGEND :
N
STANDALONE VERSION (SMOOTH TRAVEL)
I
RECESS-MOUNTED VERSION

MV-C00000920 MOHAWK V-C SERIES: VERTICAL RISE DRIVE-ON MANUAL 85,000 - 99,000 LB MODEL
2-2
N°
DESCRIPTION
1
Platform
2
Lower leg
3
Upper lever
4
Tension rod
5
Hydraulic cylinder (main lift)
6
Base plate
7
Wheel stop
8
Access ramps
9
Electrical Controls
10
Hydraulic Pump
11
Flow divider
12
Protective floor pipe covers
13
Ramp cover plate
12
1
2
3
4
5
6
7
9
10
11
8
13

MV-C00000920 MOHAWK V-C SERIES: VERTICAL RISE DRIVE-ON MANUAL 85,000 - 99,000 LB MODEL
2-3
2.4. Overall dimensions
BOLTED EXTENSION MAY BE APPLIED TO THE 11 m PLATFORM UP TO 14,5 m.

MV-C00000920 MOHAWK V-C SERIES: VERTICAL RISE DRIVE-ON MANUAL 85,000 - 99,000 LB MODEL
2-4
2.5. Loading conditions
The maximum lift capacity is valid when the load is equally distributed
along the platform as shown in the label here below reported.
V-085-C
V-090-C
Capacity 85,000 lb
Capacity 90,000 lb
V-095-C
V-099-C
Capacity 50,000 lb
Capacity 64,000 lb
In case of an asymmetric loading distribution, the lifting capacity depends
on:
The maximum lifting capacity according the lift type
The vehicle position along the platform
The load distribution between the truck axles
The wheel base
The loading capacity of the table is calculated by assuming a load of
distribution of 33% and 67% between the truck axles.
Note: In case of a shorter wheel base than the indicated ones or
a difference axle load ratio contact your dealer to verify the real
loading capacity.

MV-C00000920 MOHAWK V-C SERIES: VERTICAL RISE DRIVE-ON MANUAL 85,000 - 99,000 LB MODEL
2-2
2.6. Jacking beam
The machine can be arranged for so that auxiliary jacking beam can be used for lifting.
The jacking beam slide on rails welded to the platform.
NOTE: The lift allows the installation of 1 jacking beam.
The maximum load of the jacking beam can lift is
35000 lbs
See certified model

MV-C00000920 MOHAWK V-C SERIES: VERTICAL RISE DRIVE-ON MANUAL 85,000 - 99,000 LB MODEL
3-1
3. SAFETY
Addressees:
-USER/OWNER;
-SPECIALISED TECHNICIAN/EMPLOYER.
3.1. General safety regulations
For quick reference by operator, this manual must:
be kept in a well known, easily accessible place
be kept in good condition
Before proceeding with installation and use of the
machine, the user must read the manual carefully,
especially the safety rules.
“Before proceeding with installation, operating, servicing, or
maintain the lift, the user must read the manual carefully...”
The machine should be used by authorised, trained personnel only.
The user (owner and/or employee) must make sure that the fitter has
provided:
all accessories
the spares provided with the lift
this operation and maintenance manual
Use as described in this manual only.
Always use the accessories recommended by the manufacturer.
Mohawk Lifts LLC. declines all responsibility for non-compliance with
the indications given in this manual.
The main safety rules are shown below:
Read all instructions carefully
Put the main switch to the zero position when the
machine is not in use. Never pull the electric cable to
remove the plug from the socket.
To reduce the risk of fires, avoid using the lift close to
open drums of inflammable liquid (such as gas oil)
and/or in explosive environments.
Make sure the work area is adequately aired when
using internal combustion engines.
Avoid contact between parts of the body and/or
clothing and moving parts.

MV-C00000920 MOHAWK V-C SERIES: VERTICAL RISE DRIVE-ON MANUAL 85,000 - 99,000 LB MODEL
3-2
3.2. Precaution
When loading the lift never exceed the capacity shown on
the ID plate on the lift.
Never lift people.
Any modifications to the lift must be authorised by the
manufacturer.
The equipment must be used by specifically trained and
authorised personnel only.
Do not tamper with the lift's upstroke and downstroke.
Always check the stability of hoisted vehicle.
In case of “recess-mounted version” before
carring out the final lowering with bypass key,
please ensure you that all personell are clear of
the lift.
Do not use the lift in the event of hindrances to
operation or hazardous conditions.
Check the lift carefully after long periods of
inactivity before putting it back into service.
The lift comes complete with an instruction manual
warning labels designed to last.
Ask the manufacturer for a replacement
immediately if damaged or destroyed.
MOHAWK LIFTS declines responsibility for any
inconvenience deriving from non-compliance with
the instructions for use.
The operator in order to lift the vehicle in a proper
way has to :
-Follow the instructions of the ALI/SM
Lifting It Right
-Refer to SAE J 2184 for the vehicle
lifting points

MV-C00000920 MOHAWK V-C SERIES: VERTICAL RISE DRIVE-ON MANUAL 85,000 - 99,000 LB MODEL
3-3
3.3. Owner/Employer Responsibilities
The owner/employer:
Shall ensure that lift operators are qualified and that they are trained in
the safe use and operation of the lift using the manufacturer’s operating
instructions; ALI/SM, “Lifting It Right” safety manual; ALI/ST, “Safety
Tips” card; ANSI/ALI ALOIM, Standard for Automotive Lifts – Safety
Requirements for Operation, Inspection and Maintenance; ALI/WL
Series, ALI Uniform Warning Label Decals/Placards; and in the case of
frame engaging lifts, ALI/LP-Guide, “Quick Reference Guide – Vehicle
Lifting Points for Frame Engaging Lifts”.
Shall establish procedures to periodically inspect the lift in accordance
with the lift manufacturer’s instructions or ANSI/ALI ALOIM, Standard for
Automotive Lifts –Safety Requirements for Operation, Inspection and
Maintenance; and the employer shall ensure that lift inspectors are
qualified and that they are adequately trained in the inspection of the lift.
Shall establish procedures to periodically maintain the lift in accordance
with the lift manufacturer’s instructions or ANSI/ALI ALOIM, Standard for
Automotive Lifts –Safety Requirements for Operation, Inspection and
Maintenance; and the employer shall ensure that lift maintenance
personnel are qualified and that they are adequately trained in the
maintenance of the lift.
Shall maintain the periodic inspection and maintenance records
recommended by the manufacturer or ANSI/ALI ALOIM, Standard for
Automotive Lifts –Safety Requirements for Operation, Inspection and
Maintenance.
Shall display the lift manufacturer’s operating instructions; ALI/SM, “Lifting
It Right” safety manual; ALI/ST, “Safety Tips” card; ANSI/ALI ALOIM,
Standard for Automotive Lifts –Safety Requirements for Operation,
Inspection and Maintenance; ALI/WL Series, ALI Uniform Warning Label
Decals/Placards; and in the case of frame engaging lifts, ALI/LP-Guide,
“Quick Reference Guide – Vehicle Lifting Points for Frame Engaging
Lifts”; in a conspicuous location in the lift area convenient to the operator.
Shall review and understand the proper requirements outlined in
ANSI/ALI ALIS, Safety Requirements for Installation and Service of
Automotive Lifts.

MV-C00000920 MOHAWK V-C SERIES: VERTICAL RISE DRIVE-ON MANUAL 85,000 - 99,000 LB MODEL
3-4
3.4. IMPROPER USE
NEVER remove the wheel stop (A)
and the union platform (B).
They prevent the vehicle from
coming off the platform.
NEVER lift vehicles using equipment other than that envisaged by the manufacturer.
NEVER lift vehicles that are only partially on the lift.
A
B

MV-C00000920 MOHAWK V-C SERIES: VERTICAL RISE DRIVE-ON MANUAL 85,000 - 99,000 LB MODEL
3-5
3.5. Safety device features
SAFETY DEVICE
COMPOSED OF
POSITION
IN THE EVENT OF ...
EFFECT ON MAIN LIFT
MECHANICAL
ANTI-FALL
DEVICE
Rack jack
On each hydraulic
cylinder of the lift.
Leakage on the hydraulic
circuit or breakage of a
component
Accidental descent is blocked with a maximum displacement of
4 inch.
ANTI-SHEARING
DEVICE
Limit switch and
buzzer
On the master cylinder
in the control unit.
Descent on last stretch
Platform descent stops at 19.6 inches off the ground
To complete descent:
turn the PEFT key switch.
Hold down the Down Button PD 1.
Final descent is confirmed by the buzzer.
PLATFORM
ALIGNMENT
CONTROL
DEVICE
Photocell and
reflectors
Each end of the
platforms
Maximum misalignment of 2
inches between the platforms
of the main or auxiliary lift.
The lift stops moving.
HYDRAULIC
FAILURE DEVICE
Velocity fuse
On each hydraulic
cylinder of the lift and on
MASTER cylinder
supply.
Breakage of hoses.
The valve blocks descent when the speed reaches a value
preset by the Manufacturer.
WHEEL STOP
DEVICES
Wheel chock and
ramp cover plate
Front and rear in both lift
platforms.
-
They prevent the vehicle from coming off the platforms.
SIGNALS
Stickers and plates
See paragraph:
Stickers and plates
-
Draw attention to residual risks and precautions for use.

MV-C00000920 MOHAWK V-C SERIES: VERTICAL RISE DRIVE-ON MANUAL 85,000 - 99,000 LB MODEL
3-6
3.6. Residual risks
HAZARD
WHO
CONDITION
RISK
PIPE BREAKING
Maintenance
technician
MAINTENANCE
Contact with squirts of pressurised oil
AIR ELIMINATION FROM
CYLINDERS
PIPES LOOSENING
ELECTRIC SHOCK
Maintenance
technician
MAINTENANCE
Contact with live components
SHEARING
Maintenance
technician
MAINTENANCE
Shearing of hands and feet with lift is in movement.
TIPPING OVER OF THE
LOAD
Maintenance
technician
MAINTENANCE
During manual lowering, check that the load moves
smoothly, without being thrown out of balance.
Operate the valves so that the bridge is realigned step by
step.
REDUCED VISIBILITY
Operator
OPERATING
Possible third-party damage
