Mohawk TR-33 User manual

MADE IN THE U.S.A.
.
FOUR POST VEHICLE LIFT MANUAL
 INSTALLATION
 OPERATION
 MAINTENANCE
PARTS MANUAL
.
65 VROOMAN AVE.
P.O. BOX 110
AMSTERDAM, NY 12010
TOLL FREE : 1-800-833-2006
FAX : [phone]
LOCAL : 1-518-842-1431
Rev: 12-1-2015
File: TR-33-35-50-75-33WT-35WT-50WT-70WT
12-1-2015.doc
Part No. 601-800-311
READ MANUAL
THOROUGHLY BEFORE
INSTALLING,
OPERATING OR SERVICING
THIS LIFT !!
Deliver these instructions to lift
owner/user/employer along with
other instructional materials
furnished with this lift.
MODEL TR-33 & TR-33WT RATED 33,000 LB CAP.
MODEL TR-35 & TR-35WT RATED 35,000 LB CAP.
MODEL TR-50 & TR-50WT RATED 50,000 LB CAP.
MODEL TR-75 & TR-75WT RATED 75,000 LB CAP.
WARRANTY CARD
THANK YOU
FOR SENDING IN
YOUR
REGISTRATION
CARD.
MOHAWK SERVICE
DEPARTMENT

IMPORTANT SAFETY INSTRUCTIONS
When using your garage equipment, basic safety precautions should always be followed, including the
following:
1. Read this manual and review all illustrations of this manual thoroughly before attempting to install,
operate or maintain this lift.
2. Deliver these operation, inspection, and maintenance instructions to the lift owner/user/employer
along with the other instructional materials furnished with this lift.
3. Maintenance on this equipment is to be performed only by trained lift service personnel, and and
worn or broken parts are to be replaced only with genuine Mohawk brand supplied parts.
4. Care must be taken as burns can occur from touching hot parts.
5. Do not operate equipment with a damaged cord or if the equipment has been dropped or damaged -
until it has been examined by a qualified serviceman.
6. Do not let cord or hoses hang over edge of table, bench or counter or come in contact with hot
manifolds or moving fan blades.
7. If an extension cord is necessary, a cord with a current rating equal to or more than that of the
equipment should be used. Cords rated for less current than the equipment may overheat. Care
should be taken to arrange the cord so that it will not be tripped over or pulled.
8. Always unplug equipment from electrical outlet when not in use. Never use the cord to pull the plug
from the outlet. Grasp plug and pull to disconnect
9. To reduce the risk of fire, do not operate equipment in the vicinity of open containers of flammable
liquids (gasoline). WARNING: Risk of Explosion: This equipment has internal arcing and sparking
parts which should not be exposed to flammable vapors. This equipment is only suitable for
installation in a garage having sufficient air circulation to be considered a non-hazardous location.
10. Adequate ventilation should be provided when working on operating internal combustion engines.
11. Keep hair, loose clothing, fingers, and all parts of body away from moving parts.
12. To reduce the risk of electric shock, do not use on wet surfaces or expose to rain.
13. Use only as described in this manual. Use only manufacturer’s (Mohawk) recommended
attachments.
14. ALWAYS WEAR SAFETY GLASSES. Everyday eyeglasses only have impact resistant lenses,
they are NOT safety glasses.
SAVE THESE INSTRUCTIONS Rev (10/22/99)

3
MOHAWK MODEL TR-33/35/50/75/33WT/35WT/50WT/70WT
APPENDAGE:
(7/10/2012)
LIFT ENVIRONMENT:
Mohawk prohibits the outdoor installation of this standard lift, which is APPROVED FOR INDOOR USAGE ONLY,
in a normal garage type environment. Any concerns in applications that expose the lift to additional environmental
effects, such as paint booths, wash bays, outdoors, high or low temperatures, etc. must be addressed to our
engineering department, where provisions could/may be made to the lift to accommodate the area of use. Our
engineering department must be made aware in advance of these conditions and any additional code requirements that
must bemet.
Also, the foundation for which this lift must be installed on must comply to the minimum specifications as set forth in
this manual. Any drainage slopes in the bay where the lift is to be installed must be directed away from the posts to
prevent water accumulation at the post bases.
Standard foundation flooring and anchorage specifications are contained within this manual. For installation within a
seismic area, a qualified person must be consulted to address seismic loads and other local or state requirements.
ACCESSORIES:
All accessories (i.e. jacking beams, etc.) supplied with this lift are to be used on this lift only. Accessories
from other lifts are not acceptable and could result in injury to the user.
If attachments, accessories or configuration modifying components are used on this lift and, if they are not
certified for use on this lift, then the certification of this lift shall become null and void. Contact the
participant (.) for information pertaining to certified attachments, accessories or
configuration modifying components.
LOCKOUT/TAGOUT REQUIREMENTS:
The start switch provided with this unit must not be used as a primary disconnecting means. A separate
disconnecting means must be provided in accordance with all applicable codes. It is the responsibility of the
owner/user of this unit to provide a proper lockout/tagout device for this unit before or during installation in
conformance to ANSI Z244.1 and any local/state/national electrical codes and any OSHA regulations.
JACKING BEAMS:
Loading of the jacking beams or combinations of jacking beams above the rated capacity of the lift itself
could result in personal injury to the operator and/or damage to the lift and/or vehicle. The load rating of
any jacking beam or combination of jacking beams on this unit must not exceed the rated capacity of the
lift.

MOHAWK MODEL TR-33/35/50/75/33WT/35WT/50WT/70WT
4
HAVE A QUESTION?
Call your local
Mohawk distributor
For parts, service and technical support.
Distributor Place Card Here
Please have this unit’s model and serial number when calling for service.
Model Number ______________________
Serial Number ______________________
OR CONTACT:
.
65 Vrooman Ave.
P.O. Box 110
Amsterdam, NY 12010
Toll Free: 1-800-833-2006
Local: 1-518-842-1431
Fax: [phone]
Internet: www.MOHAWKLIFTS.com
E-Mail: [email protected]

5
MOHAWK MODEL TR-33/35/50/75/33WT/35WT/50WT/70WT
MOHAWK WARRANTIES
EFFECTIVE DATE: 12/1/2015*
READ THIS WARRANTY IN ITS ENTIRETY
GENERAL WARRANTY INFORMATION:
MOHAWK’S OBLIGATION UNDER THIS WARRANTY IS LIMITED TO REPAIRING OR REPLACING ANY PART OR PARTS
RETURNED TO THIS FACTORY, TRANSPORTATION CHARGES PREPAID BYCUSTOMER WITH AUTHORIZED RETURN
(RGA), WHICH PROVE UPON INSPECTION TO BE DEFECTIVE AND WHICH HAVE NOT BEEN MISUSED. DAMAGE OR
FAILURE TO ANYPARTDUE TO FREIGHT DAMAGE OR LACK OF REQUIRED REGULAR DOCUMENTED MAINTENANCE
IS NOT COVERED UNDER THIS WARRANTY. ALL WARRANTY CLAIMS MUST BE PERFORMED IN ACCORDANCE TO
MOHAWK’S WARRANTY PARTSRETURN POLICY (CONTACT MOHAWK’S SERVICE DEPARTMENT FOR MORE
INFORMATION).
THIS WARRANTY DOES NOT COVER MIS-DIAGNOSING OF UNIT OR PARTS RETURNED THAT ARE NON-DEFECTIVE.
THIS WARRANTY DOES NOT COVER ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES INCLUDING, BUT NOT LIMITED
TO, LOST REVENUES OR BUSINESS HARM. THIS EQUIPMENT HAS BEEN DESIGNED FOR USE IN NORMAL VEHICLE
MAINTENANCE APPLICATIONS. A SPECIFIC INDIVIDUAL WARRANTY MUST BE ISSUED FOR UNITS THAT DEVIATE
FROM INTENDED USAGE, SUCH AS HIGH CYCLE USAGE IN INDUSTRIAL APPLICATIONS, OR USAGE IN EXTREMELY
ABUSIVE ENVIRONMENTS. MOHAWK RESERVES THE RIGHT TO DECLINE RESPONSIBILITY WHEN REPAIRS OR
MODIFICATIONS HAVE BEEN MADE OR ATTEMPTED BY OTHERS WITHOUT WRITTEN AUTHORIZATION FROM
.. THIS WARRANTY DOES NOT COVER LABOR OR TRANSPORTATION. THIS WARRANTY DOES
NOT COVER DOWNTIME EXPENSES INCURRED WHEN UNIT IS IN REPAIR. THE LIFT MUST BE REGISTERED WITHIN 30
DAYS OF INSTALLATION BY MAILING SUPPLIED WARRANTY REGISTRATION CARD TO MOHAWK AND MUST BE
SIGNED BY ALICENSED ELECTRICIAN. THE MODEL NUMBER AND SERIAL NUMBER OF THE EQUIPMENT MUST BE
FURNISHED WITH ALL WARRANTY CLAIMS. THIS WARRANTY STATEMENT CONTAINS THE ENTIRE AGREEMENT
BETWEEN . AND THE PURCHASER UNLESS OTHERWISE SPECIFICALLY EXPRESSED IN WRITING.
THIS NON-TRANSFERABLE WARRANTY APPLIES TO THE ORIGINAL PURCHASER ONLY.
THIS WARRANTY DOES NOT COVER NORMAL SURFACE WEAR ITEMS, ITEMS SUBJECT TO ABRASION, OR ITEMS
USED IN A CORROSIVE ENVIRONMENT. SOME ITEMS ON LIFT ARE SUBJECT TO NORMAL “WEAR AND TEAR” AND ARE
NOT COVERED UNDER THIS WARRANTY.
STRUCTURAL AND MECHANICAL COMPONENTS (ALL LIFTS):
STRUCTURAL AND MECHANICAL COMPONENTS OF THIS UNIT ARE GUARANTEED FOR THE BELOW STATED TIME
FRAME, SPECIFIC TO MODEL LISTED, FROM THE DATE OF SHIPMENT FROMFACTORY, AGAINST DEFECTS IN
WORKMANSHIP AND/OR MATERIALS WHEN LIFT IS INSTALLED AND USED ACCORDING TO SPECIFICATIONS.
25-YEARS STRUCTURAL / 10 YEARS MECHANICAL: TWO-POST MODELS A-7, SYSTEM IA-10, LC-12, LMF-12,
TP-16, TP-18, TP-20, TP-26, TP-30. STRUCTURAL ITEMS COVERED INCLUDE LEG, CARRIAGE, SWING ARM AND
SLIDER WELDMENTS (EXCLUDING NORMAL WEAR AREAS AS STATED ABOVE). MECHANICAL ITEMS
COVERED INCLUDE ROLLER BEARINGS AND LIFTING CHAIN.
5-YEAR: MODELS TL-7.
3-YEAR: MODELS TR-19, TR-25, FL-25, TR-30, TR-33, TR-35, TR-50, TR-75, TR-110, TR-120, MP-SERIES LIFTS.
2-YEAR: MODELS PARALLELOGRAM SERIES LIFTS.
1-YEAR: MODELS TD-1000, TD-2000, CT-1000, USL-6000.
POWER UNIT (ALL LIFTS):
A
LL POWER UNIT COMPONENTS (MOTOR, PUMP AND RESERVOIR) ARE GUARANTEED FOR TWO YEARS FOR PARTS,
FROM THE DATE OF SHIPMENT FROM FACTORY, AGAINST DEFECTS IN WORKMANSHIP AND/OR MATERIALS WHEN
THE LIFT IS INSTALLED, WIRED BY A LICENSED ELECTRICIAN AND USED ACCORDING TO SPECIFICATIONS.
ELECTRICAL COMPONENTS (ALL LIFTS):
A
LL ELECTRICAL COMPONENTS (EXCLUDING MOTOR) ARE GUARANTEED FOR ONE YEAR FOR PARTS, FROM THE
DATE OF SHIPMENT FROM FACTORY, AGAINST DEFECTS IN WORKMANSHIP AND/OR MATERIALS WHEN THE LIFT IS
INSTALLED AND USED ACCORDING TO SPECIFICATIONS. SEE WARRANTY EXCEPTIONS SECTION FOR BATTERIES.
PNEUMATIC-AIR COMPONENTS (ALL LIFTS):
A
LL PNEUMATIC (AIR) COMPONENTS (I.E. AIR CYLINDERS AND POPPET AIR VALVES) ARE GUARANTEED FOR ONE
YEAR FOR PARTS, FROM THE DATE OF SHIPMENT FROM FACTORY, AGAINST DEFECTS IN WORKMANSHIP AND/OR
MATERIALS WHEN THE LIFT IS INSTALLED AND USED ACCORDING TO SPECIFICATIONS. COMPONENTS IN A
PNEUMATIC SYSTEM THAT ARE NOT PROPERLY REGULATED, LUBRICATED AND CONDITIONED WITH AN AIR DRYING
SYSTEM ARE NOT COVERED UNDER WARRANTY.
HYDRAULIC COMPONENTS (ALL LIFTS):
EXCLUDING CYLINDERS AND PUMPS (COVERED IN OTHER SECTIONS), ALL HYDRAULIC COMPONENTS (I.E. VALVES
A
ND FITTINGS) ARE GUARANTEED FOR ONE YEAR FOR PARTS, FROM THE DATE OF SHIPMENT FROM FACTORY,
A
GAINST DEFECTS IN WORKMANSHIP AND/OR MATERIALS WHEN THE LIFT IS INSTALLED AND USED ACCORDING TO
SPECIFICATIONS.

MOHAWK MODEL TR-33/35/50/75/33WT/35WT/50WT/70WT
6
HYDRAULIC CYLINDERS (MODEL SPECIFIC LIFTS):
THE FOLLOWING MODELS ARE GUARANTEED FOR 5 YEARS (PARTS ONLY), FROM DATE OF SHIPMENT FROM
FACTORY, FOR HYDRAULIC CYLINDERS, AGAINST DEFECTS IN WORKMANSHIP AND/OR MATERIALS WHEN THE
LIFT IS INSTALLED AND USED ACCORDING TO SPECIFICATIONS: TWO-POST MODELS A-7, SYSTEM IA-10, LC-12,
LMF-12, TP-16, TP-18, TP-20, TP-26, TP-30.
ALL OTHER MODELS ARE GUARANTEED FOR TWO YEARS (PARTS ONLY), FROM THE DATE OF SHIPMENT FROM
FACTORY, FOR HYDRAULIC CYLINDERS, AGAINST DEFECTS IN WORKMANSHIP AND/OR MATERIALS WHEN THE
LIFT IS INSTALLED AND USED ACCORDING TO SPECIFICATIONS (EXCLUDING USL-6000, WHICH IS ONE YEAR).
THE “EXTENDED LIFETIME CYLINDER SEAL WARRANTY” (BELOW) IS APPLICABLE TO THE FOLLOWING MOHAWK
LIFTS ONLY: TWO-POST MODELS A-7, SYSTEM IA-10, LC-12, LMF-12, TP-16, TP-18, TP-20, TP-26, TP-30. SEE
MOHAWK’S “EXTENDED LIFETIME CYLINDER SEAL WARRANTY” FOR SPECIFIC WARRANTY PROVISIONS FOR
HYDRAULIC CYLINDERS.
THE “EXTENDED LIFETIME CYLINDER SEAL WARRANTY” IS AS FOLLOWS:
AS THE ORIGINAL PURCHASER OF A MOHAWK LIFT MANUFACTURED BY . YOU ARE
ENTITLED TO AN EXTENDED CYLINDER SEAL WARRANTY.
MOHAWK’S OBLIGATION UNDER THIS WARRANTY IS LIMITED TO SUPPLYING MODEL SPECIFIC CYLINDER SEALS.
THE CUSTOMER IS RESPONSIBLE FOR SHIPPING AND HANDLING OF THE SEALS. MOHAWK IS NOT
RESPONSIBLE/LIABLE FOR THE REBUILD OF CYLINDERS BY OTHERS. THIS WARRANTY IS NON-TRANSFERABLE
AND RUNS TO THE ORIGINAL PURCHASER ONLY.
STANDARD OPTIONS (ALL LIFTS):
ALL STANDARD OPTIONS OF THIS UNIT ARE GUARANTEED FOR ONE YEAR FOR PARTS, FROM THE DATE OF
SHIPMENT FROM FACTORY, AGAINST DEFECTS IN WORKMANSHIP AND/OR MATERIALS WHEN LIFT IS INSTALLED
AND USED ACCORDING TO SPECIFICATIONS.
CUSTOM LIFTS AND CUSTOM OPTIONS:
ALL “CUSTOM” LIFTS AND/OR “CUSTOM” OPTIONS ARE GUARANTEED FOR ONE YEAR FOR PARTS, FROM THE
DATE OF SHIPMENT FROM FACTORY, AGAINST DEFECTS IN WORKMANSHIP AND/OR MATERIALS WHEN LIFT IS
INSTALLED AND USED ACCORDING TO SPECIFICATIONS.
WARRANTY EXCEPTIONS (ALL LIFTS):
ADJUSTMENTS: THIS WARRANTY DOES NOT COVER CASUAL AND ROUTINE ADJUSTMENTS SUCH AS, BUT NOT
LIMITED TO: FITTINGS, SENSORS AND SWITCHES, ANCHOR BOLT RE-TIGHTENING, OR ANY SHIMMING OR
ADJUSTMENTS REQUIRED DURING A PROPER AND PROFESSIONAL INSTALLATION BY A QUALIFIED INSTALLER.
MAINTENANCE AND INSPECTIONS: IF THIS UNIT IS NOT MAINTAINED AND INSPECTED IN ACCORDANCE TO THE
RELEVANT SECTIONS IN THE USERS MANUAL FOR THIS SPECIFIC MODEL, WARRANTY IS VOID. OSHA, ANSI AND
MOHAWK REQUIRE THAT RECORDS MUST BE MAINTAINED TO PROVE THAT INSPECTIONS AND MAINTENANCE
OF THIS UNIT HAVE BEEN ROUTINELY PERFORMED BY QUALIFIED INDIVIDUALS.
ABUSE: IF THIS UNIT IS FOUND TO BE OVERLOADED (PURPOSELY OR UNKNOWINGLY), USED IN A SITUATION
BEYOND ITS INTENDED FUNCTION, NOT MAINTAINED & INSPECTED REGULARLY, USED IN AN ABUSIVE
ENVIRONMENT OR BEYOND NORMAL SHOP USAGE, THIS WARRANTY IS VOID IN ITS ENTIRETY.
NON-EXISTENT PROBLEMS: FOR SERVICE VISITS, PART REPLACEMENTS, LABOR, ETC. FOR PARTS FOUND TO
BE NON-DEFECTIVE, OR FOR A UNIT DIS-FUNCTION THAT DOES NOT EXIST, IT IS THE LIFT OWNER THAT
REQUESTED THE SERVICE VISIT WHO BEARS THE RESPONSIBILITY OF ALL RELATED EXPENSES.
BATTERIES: ALL BATTERIES CARRY THE BATTERY MANUFACTURER’S WARRANTY. MAINTENANCE
REQUIREMENTS AND ABUSE PROVISIONS ARE AS STATED BY THE BATTERY MANUFACTURER. REFER TO
BATTERY MANUFACTURER’S WARRANTY.
SPECIAL/MODIFIED INSTALLATIONS: THIS WARRANTY DOES NOT COVER “NON-TRADITIONAL” INSTALLATIONS.
INSTALLATIONS ARE TO BE DONE ACCORDING TO SPECIFICATIONS, OR THE WARRANTY IS VOID.
WEARABLE COMPONENTS: SOME ITEMS ON LIFTS ARE SUBJECT TO NORMAL “WEAR AND TEAR” AND ARE NOT
COVERED UNDER THIS WARRANTY.
NON-VEHICLE / RE-PURPOSED LIFTS: THIS WARRANTY DOES NOT COVER LIFTS THAT ARE “RE-PURPOSED” TO
RAISE AND LOWER EQUIPMENT THAT ARE NOT CONSIDERED VEHICLES.
*THIS
WARRANTY SUPERSEDES ALL OTHER WARRANTY POLICIES PREVIOUSLY STATED AND IN ALL OTHER
MOHAWK PRODUCT SPECIFIC LITERATURE (MANUALS, BROCHURES, ETC.).
Rev 12/1/2015

MOHAWK MODEL TR-33/35/50/75/33WT/35WT/50WT/70WT
7
The Automotive Lift Institute (ALI) is a trade association comprised of US and Canadian manufacturers and certain national
distributors of automotive lifts. For almost 50 years, the ALI in cooperation with the American National Standards Institute
(ANSI) has continued to sponsor the national standard ANSI/ALI ALCTV:2011 "Safety Requirements for Construction, Testing,
and Validation for Automotive Lifts.”
The new "ALI/ETL Automotive Lift Certification Program" is based on ALI developed methods and criteria
for third party testing of automotive lifts to validate conformance with ANSI/ALI ALCTV:2011.
For automotive lifts to be certified, manufacturers must execute an agreement with the ALI and ETL /
Intertek Testing Services and must meet certain requirements:
Must be structurally tested in accordance with the test requirements as outlined in ANSI/ALI
ALCTV:2011.
All motor operated units must be listed by a nationally recognized testing laboratory (NRTL) in
accordance with ANSI/UL-201.
The manufacturer's production facility must meet quality control requirements as set forth in the ANSI
Z34.1-1987 and the ALI/ETL Automotive Lift Certification Program Procedural Guide.
All manufacturer-provided instructions, manuals, and operator safety documents, must meet the
requirements of the ANSI/ALI ALCTV:2011 and ANSI/UL-201.
Lifts meeting these rigid requirements may be listed in the directory of certified lifts and be labeled with the
"ALI/ETL certification mark" (Above on right), and, if applicable, the ETL listing mark to ANSI/UL-201.
Mohawk has been a long-standing member of ALI and most of Mohawk’s popular models are currently
listed and certified. Other Mohawk models are in various stages of testing. To obtain a complete and
current certification listing, contact . or visit www.mohawklifts.com or www.ali-
directory.org To obtain a copy of the current automotive lift standard, contact ALI or ANSI or visit
www.autolift.org
Some people purchase quality products and others do not. You are assured of quality when you purchase a
Mohawk product in compliance with the certification program.

MOHAWK MODEL TR-33/35/50/75/33WT/35WT/50WT/70WT
8
CONTENTS
TOPIC PAGE
INSTALLATION TEXT
GENERAL INFORMATION 9-12
APPENDAGES 13-14
PACKINGLIST 15
INSTALLATION INSTRUCTIONS 16-18
FINALCHECKOUT 19
LIFT LIMITATIONS 20
SAFETYTIPS 21
CONTROL PANEL FUNCTION DEFINITIONS 22-23
PRE OPERATION CHECK LIST 24
LIFTING PROCEDURES 24
MAINTENANCE PROCEDURES 25-26
TROUBLE SHOOTING CHART 27
ELECTRICAL INFORMATION 28
SERVICECHART 29
MAINTENANCECHART 29
FIGURES & DIAGRAMS
LIFTSETUPDIMENSIONS
DIAGONAL MEASUREMENT LAYOUT
WEJ-IT ANCHORS / NYLON LOCK NUT ASSEMBLY
CONTROL PANEL FUNCTIONS
POSTSHIMS
FLOOR SLOPE & SHIMMING GUIDELINES
TRACKAUTOLEVELSYSTEM
WHEELCHOCKPLACEMENT
ELECTRICAL / HYDRAULIC SCHEMATICS
HYDRAULIC SCHEMATIC 075-050-080
ELECTRICAL SCHEMATIC 075-050-093
BOXWIRINGDIAGRAM 075-050-094
PANEL WIRING DIAGRAM 075-050-091
PARTS (& ASSEMBLY) DRAWINGS
NEW SLAB RECOMMENDATIONS
SAFETY, CAUTION & WARNING DIAGRAMS
ALSO INCLUDED WITH MANUAL: SAFETY TIPS CARD
ALI LIFTING IT RIGHT MANUAL

MOHAWK MODEL TR-33/35/50/75/33WT/35WT/50WT/70WT
9
GENERAL INFORMATION
BEFORE INSTALLING A LIFT
 BEFORE INSTALLING A MOHAWK LIFT REVIEW THE FOLLOWING ITEMS . EACH REPAIR SHOP BAY IS
DIFFERENT. IN AN ATTEMPT TO PREVENT OVERSIGHTS, ALL OF THE FOLLOWING INFORMATION MUST
BE VERIFIED.
WHAT ARE THE LIFT SPECIFICATIONS ?
THE SPECIFICATIONS IN THIS MANUAL ARE FOR A
STANDARD LIFT. ANY SPECIAL FEATURES WILL
BE INDICATED ON THE LIFT VERIFICATION SHEET.
USE THE LIFT VERIFICATION SHEET AND THE TR
33/35/50/75 DIMENSIONAL CHART TO VERIFY THE
UNITS SPECIFICATIONS AND SET-UP DIMENSIONS.
OVERHEAD OBSTRUCTIONS:
THE AREA IN WHICH THE LIFT WILL BE LOCATED
SHALL BE FREE OF OBSTRUCTIONS. HEATERS,
BUILDING SUPPORTS, ELECTRICAL CONDUIT. ALL
OF THESE ITEMS ARE TO BE (20 FT) TWENTY FEET
ABOVE THE BAY FLOOR
CONCRETE FLOOR:
VISUALLY LOOK OVER THE BAY FLOOR. THE LIFT
CAN NOT BE INSTALLED ON EXPANSION SEAMS,
OR CONCRETE THAT IS CRACKED. THE LIFT
CANNOT BE EXPECTED TO BE STRUCTURALLY
SOUND ON DEFECTIVE CONCRETE.
TEST DRILL THE FLOOR:
TEST DRILL THE FLOOR TO VERIFY CONCRETE
THICKNESS. TEST DRILL EACH BAY WHEN MORE
THAN ONE LIFT IS BEING INSTALLED.
FLOOR REQUIREMENTS:
THIS INFORMATION IS IN THE GENERAL FLOOR
REQUIREMENTS.
POWER SUPPLY:
REFER TO THE LIFT VERIFICATION SHEET FOR
THE POWER SUPPLY SPECIFICATIONS.
BAY SIZE:
REFER TO THE LIFT VERIFICATION SHEET AND
THE DIMENSIONAL CHART.
SPECIFICATIONS:
REFERENCE ALL SPECIFICATIONS PRIOR TO
INSTALLING THE LIFT.
IMPORTANT
ALLINFORMATION,ILLUSTRATIONS,ANDSPECIFICATIONS IN THIS MANUAL ARE
SPECIFIC TO MOHAWK MODELS TR-33, TR-35, TR-50, TR-75. WE RESERVE THE RIGHT TO
MAKE CHANGES AT ANY TIME WITHOUT NOTICES.
ALWAYSREFERTOTHELIFTVERIFICATION SHEET AND THE TR 33/35/50/75
DIMENSIONAL CHART. SPECIFIC INFORMATION PERTAINING TO THIS LIFT IS FOUND ON
THESE PAGES.

MOHAWK MODEL TR-33/35/50/75/33WT/35WT/50WT/70WT
10
GENERAL INFORMATION CONTINUED
RECOMMENDED TOOL LIST
SIZE / QTY TOOL USED FOR
3/4 IN WRENCH / SOCKET HYDRAULIC HOSES
11 / 16 IN WRENCH / SOCKET HYDRAULIC FITTINGS
5 / 8 IN WRENCH / SOCKET HYDRAULIC FITTINGS
1-1/16 IN WRENCH / SOCKET RAMP / CROSSRAIL
1-1/8 IN WRENCH / SOCKET RAMP / CROSSRAIL / WEJ-IT ANCHORS
1-1/4 IN WRENCH / SOCKET CHAIN CONNECTORS
1 SET ALLEN WRENCHES AS REQUIRED
1 PLIERS / NEEDLE NOSE CHAIN MASTER LINKS
1 RATCHET AS REQUIRED
50 FT MEASURING TAPE SITE LAYOUT
1 CHALK LINE SITE LAYOUT ( BLUE / YELLOW CHALK )
4 FT BUBBLE LEVEL VERIFY LEVEL ASSEMBLY
25 FT FISH TAPE PULLING CHAINS
1 HAMMER AS REQUIRED
8 FT STEP LADDER ASSEMBLE ELEVATED ITEMS
4 4 X 4 X 24 IN DUNNAGE SUPPORT TRACKS OFF FLOOR
1 PRY BAR ADJUST HEAVY ITEMS
50 / 100 FT LEAD CORD OPERATE ELECTRICAL TOOLS
3/4 IN MASONRY DRILL BIT DRILL ANCHOR HOLES
1 IMPACT DRILL DRILL ANCHOR HOLES
1 FORK TRUCK (6000 LBS. MIN
CAP.)
ERECT / MOVE HEAVY COMPONENTS
WARNING
BEFORE DRILLING THE MOUNTING HOLES
REFERENCE ANCHOR INSTALLATION
INFO IN FIGURE SECTION FOR DRILLING
AND WEJ-IT WARNINGS AND INSTALLATION
INSTRUCTIONS.
 CHECK THE DIMENSIONS OF THE POST AT THE
BOTTOM FROM THE FACE OF POST ONE TO
THE FACE OF POST NUMBER TWO.
 CHECK THE DIMENSIONS OF THE POST AT THE
BOTTOM FROM THE FACE OF POST THREE TO
THE FACE OF POST NUMBER FOUR
USEASHARPDRILLBITASNOTTODRILLAN
UNDERSIZED HOLE. DRILL THE HOLE EQUAL
TO THE LENGTH OF THE WEJ-IT ANCHOR..
BLOW OUT THE HOLE WITH SHOP AIR, OR
VACUUM. INSERT THE ANCHOR SO THAT THE
WASHER RESTS AGAINST THE POST FOOTING.
WHEN THE LEVEL HAS BEEN VERIFIED,
TIGHTEN THE NUT AS STATED FOR ANCHOR
SPECIFICATIONS.
 MAKE SURE THE CONCRETE IS SOLID WHEN
DRILLING. CRACKS AND EXPANSION SEAMS
REDUCE THE EFFECTIVENESS OF THE WEJ-IT
ANCHOR. NEVER INSTALL THE ANCHOR
UNDER THESE CONDITIONS.
 NEVER USE AN IMPACT TOOL TO TIGHTEN
THE WEJ-IT ANCHORS. USE A TORQUE
WRENCH ONLY.
 AFTER DRILLING EACH HOLE, VACUUM
CLEAN AND INSERT THE WEJ-IT ANCHOR.
ONLY AFTER VERIFYING A SQUARE LEVEL
UNIT, CAN THE UNIT BE SECURELY MOUNTED
TO THE SHOP FLOOR.
USING THE HOLES AT THE BASE OF EACH
POST AS A GUIDE, DRILL THE FOUR
MOUNTING HOLES FOR THE ANCHORS.

MOHAWK MODEL TR-33/35/50/75/33WT/35WT/50WT/70WT
11
GENERAL INFORMATION CONTINUED
FLOOR REQUIREMENTS
MODEL MINIMUM
THICKNESS
MINIMUM
COMPRESSIVE
STRENGTH
MINIMUM
AGING
TR-33 / 35 / 50 / 75 6 INCHES 4000 P.S.I. 28 DAYS
NOTE
CONSULT WITH A BUILDING ARCHITECT FOR SPECIFIC INFORMATION ON THE INSTALLATION SIGHT
DO NOT INSTALL ANY MOHAWK LIFT ON ANY
OTHER SURFACE OTHER THAN CONCRETE
CONFORMING TO THE MINIMUM TENSILE
STRENGTH, MINIMUM AGING, AND THE MINIMUM
THICKNESS STATED ABOVE.
DO NOT INSTALL ANY MOHAWK LIFT ON
EXPANSION SEAMS OR ON CRACKED, OR
DEFECTIVE CONCRETE.
DO NOT INSTALL ANY MOHAWK LIFT ON
SECONDARY FLOOR LEVELS OR ON ANY
GROUND WITH A BASEMENT BENEATH WITHOUT
WRITTEN AUTHORIZATION FROM THE BUILDING
ARCHITECT.
NEVER, NEVER HAND MIX YOUR OWN
CONCRETE.
IF FOR ANY REASON A NEW CONCRETE SLAB
SECTION IS REQUIRED, FOLLOW THE
INSTRUCTIONS FOR THE FLOOR MODIFICATION
DATA.
FLOOR MODIFICATION DATA
MODEL FOOTING
THICKNESS
FOUR PADS
WIDTH X LENGTH
VOLUME
TR-33 / 35 / 50 / 75 12 INCHES 6 FT X 6 FT 5.4 CUBIC YARDS
NOTE
FOUR FOOTINGS 6 FT X 6 FT X 12 IN DEEP MAY BE USED. FIGURE 1
IF, FOR ANY REASON, A NEW CONCRETE SLAB
SECTION IS REQUIRED, MINIMUM THICKNESS,
COMPRESSIVE STRENGTH, AND PROPER AGING IS
MANDATORY.
CERTIFIED STRENGTH DOCUMENTATION SHOULD
BE OBTAINED FROM THE FIRM WHO SUPPLIES THE
CONCRETE MIXTURE AT THE TIME OF THE POUR.
NEVER, NEVER HAND MIX YOUR OWN
CONCRETE.
FOR TYPICAL SLAB DRAWING AND DETAILED
REQUIREMENTS CONTACT:
.

MOHAWK MODEL TR-33/35/50/75/33WT/35WT/50WT/70WT
12
GENERAL INFORMATION CONTINUED
TR-SERIES STANDARD LIFT SPECIFICATIONS
LIFT MODEL MAX CAPACITY WORKING PRESSURE RELIEF PRESSURE
TR-33 & 33WT 33,000 LB 2,000 PSI 2,300 PSI
TR-35 & 35WT 35,000 LB 2,000 PSI 2,300 PSI
TR-50 & 50WT 50,000 LB 2,400 PSI 2,650 PSI
TR-70WT 70,000 LB 3,000 PSI 3,200 PSI
TR-75 75,000 LB 3,000 PSI 3,200 PSI
LIFTING SPEED ( UP CYCLE ) APPROX. 1 MINUTES - 40 SECONDS (100 SECONDS)
LIFTING HEIGHT ( STROKE ) 5 FEET 60 INCHES
OVERALL WIDTH ( W/O CONSOLE ) 14 FT. 5 IN. 173 IN.
OVERALL LENGTH (FOR 25’ STD TRACKS) 41 FT. 4 - 1/8 IN. 495 - 1/8 IN.
TRACK WIDTH 2 FT. 24 IN.
CLEARANCE BETWEEN POST ( WIDTH ) 11 FT. 10 IN 142 IN.
MAXIMUM WHEEL BASE (FOR 25’ TRKS) 27 FT. 324 IN.
SHIPPING WEIGHT 17,000 LBS.
POWER UNIT SPECIFICATIONS
MONARCH MODEL T-12-30-0-20-01-1-070000-00-0-0
MOTOR VOLTAGE 208-230 VAC 460 VAC
MOTOR HORSE POWER 10 HP 10 HP
MOTOR FULL LOAD AMPS 40 AMP 20 AMP
MOTOR PHASE THREE PHASE
MOTOR CYCLE / HERTZ 60 HZ
MOTOR SPEED ( RPM ) 1800 RPM
PUMP FLOW ( GPM) 8.8 GPM
RESERVOIR CAPACITY ( GALLONS ) 30 U.S. GALLON
POWER UNIT HORIZONTAL
HYDRAULIC FLUID MEDIUM DEXRON III ATF
FILTER 10 MICRON – SPIN ON
CIRCUIT BREAKER PER N.E.C. / LOCAL CODE
SUGGESTED MINIMUM BAY SIZE
WIDTH DEPTH HEIGHT
18 FEET 45 FEET 20 FEET
NOTE
THE PLACEMENT OF THE UNIT IS DETERMINED BY THE TYPE / LENGTH, WIDTH, HEIGHT OF VEHICLE BEING
SERVICED. ALLOW AMPLE ROOM ( THREE TO FOUR FEET ) FOR WALKWAYS ETC.
ANCHOR / WEJ-IT
LENGTH DIAMETER DRILL SIZE
MINIMUM
DRILL SIZE
MAXIMUM
TORQUE
FOOT POUNDS
5 INCHES 3/4 INCH 0.775 0.787 See Diagram
WARNING
NEVER USE AN IMPACT TOOL TO TIGHTEN THE WEJ-IT ANCHOR.

MOHAWK MODEL TR-33/35/50/75/33WT/35WT/50WT/70WT
13
APPENDAGES
RECOMMENDATIONS BY THE INDIVIDUAL USER
OR USING ORIGINATION FOR IMPROVING THIS
PUBLICATION OR ANY ASPECT OF THE PRODUCT
ARE ENCOURAGED AND SHOULD BE FORWARDED
IN WRITING TO :
.
PRODUCT IMPROVEMENTS
P.O.. BOX 110AMSTERDAM, NY, 12010
THIS IS NOT A VEHICLE LIFTING PROCEDURE
MANUAL AND NO ATTEMPT IS MADE OR IMPLIED
HEREIN TO INSTRUCT THE USER IN LIFTING
METHODS PARTICULARLY TO THE INDIVIDUAL
APPLICATION OF THE EQUIPMENT DESCRIBED IN
THIS MANUAL. RATHER, THE CONTENTS OF THIS
MANUAL ARE INTENDED AS A BASE LINE FOR
OPERATION, MAINTENANCE, TROUBLE
SHOOTING, AND PARTS LISTING OF THE UNIT AS
IT STANDS ALONE AND AS IT IS INTENDED AND
ANTICIPATED TO BE USED IN CONJUNCTION WITH
OTHER EQUIPMENT.
PROPER APPLICATION OF THE EQUIPMENT
DESCRIBED HEREIN IS LIMITED TO THE
PARAMETERS DETAILED IN THE SPECIFICATIONS
AND THE USES SET FORTH IN THE DESCRIPTIVE
PASSAGES. ANY OTHER PROPOSED APPLICATION
OF THIS EQUIPMENT SHOULD BE DOCUMENTED
AND SUBMITTED IN WRITING TO :
.
FOR EXAMINATION. THE USER ASSUMES FULL
RESPONSIBILITY FOR ANY EQUIPMENT DAMAGE,
PERSONAL INJURY, OR ALTERATION OF THE
EQUIPMENT DESCRIBED IN THIS MANUAL OR ANY
SUBSEQUENT DAMAGES.
DO NOT WELD, APPLY HEAT, OR MODIFY THIS
EQUIPMENT IN ANY MANNER WITHOUT WRITTEN
AUTHORIZATION FROM :
.
CERTAIN ALLOY OR HEAT-TREATED
COMPONENTS MAY BE DISTORTED OR
WEAKENED, RESULTING IN AN UNSAFE
CONDITION.   . IS NOT
RESPONSIBLE FOR DISTORTIONS WHICH
RESULT FROM WELDING ON THIS EQUIPMENT
AFTER MANUFACTURING IS COMPLETED.
UNAUTHORIZED WELDING, APPLICATION OF
HEAT, OR MODIFICATION OF THIS EQUIPMENT
VOIDS ANY AND / OR ALL APPLICABLE
WARRANTIES COVERING THIS EQUIPMENT.
ALL WARRANTIES APPLICABLE TO THIS
EQUIPMENT ARE CONTINGENT ON STRICT
ADHERENCE TO THE MAINTENANCE SCHEDULES
AND PROCEDURES IN THIS MANUAL.
KEEP ALL SHIELDS AND GUARDS IN PLACE.
INSURE ALL SAFETY MECHANISMS ARE
OPERABLE. KEEP HANDS, FEET, AND CLOTHING
AWAY FROM POWER-DRIVEN AND MOVING
PARTS.
THIS EQUIPMENT MUST BE INSTALLED ON A
LEVEL CONCRETE FLOOR WITH A MINIMUM
THICKNESS OF FIVE INCHES. THE CONCRETE
MUST BE AGED AT LEAST TWENTY EIGHT DAYS
PRIOR TO INSTALLATION AND HAVE A MINIMUM
TENSILE STRENGTH OF FOUR THOUSAND P.S.I..
WARNING
DO NOT INSTALL THIS UNIT IN A PIT OR
DEPRESSION DUE TO FIRE OR EXPLOSION RISK
IMPORTANT
DO NOT INSTALL THIS UNIT ON ANY ASPHALT
SURFACE.
DO NOT INSTALL THIS UNIT ON ANY SURFACE
OTHER THAN CONCRETE CONFORMING TO THE
MINIMUM SPECIFICATIONS STATED IN THE
GENERAL FLOOR REQUIREMENTS.
DO NOT INSTALL THIS UNIT ON EXPANSION
SEAMS OR ON CRACKED, DEFECTIVE CONCRETE.
CHECK WITH BUILDING ARCHITECT.
DO NOT INSTALL THIS UNIT ON A SECOND FLOOR
OR ANY GROUND FLOOR WITH A BASEMENT
BENEATH WITHOUT WRITTEN AUTHORIZATION
FROM THE BUILDING ARCHITECT.

MOHAWK MODEL TR-33/35/50/75/33WT/35WT/50WT/70WT
14
APPENDAGES
INSTALL THIS EQUIPMENT ON
CONCRETE ONLY
IF, FOR ANY REASON, A NEW CONCRETE SLAB
SECTION IS REQUIRED, THE MINIMUM
THICKNESS, STRENGTH, AND AGING ARE
MANDATORY. FOR YOUR PROTECTION, CERTIFIED
STRENGTH DOCUMENTATION SHOULD BE
OBTAINED FROM THE FIRM WHO SUPPLIES THE
CONCRETE MIXTURE AT THE TIME OF THE POUR.
SPECIAL CONSIDERATION SHOULD BE MADE TO
THE JOINING OF THE EXISTING FLOOR AND THE
NEW SECTION BEING ADDED. CHECK WITH
BUILDING ARCHITECT. THE SUGGESTED SIZE OF
THE NEW CONCRETE SLAB SECTION IS IN THE,
GENERAL FLOOR REQUIREMENTS. AND / OR THE
FLOOR MODIFICATION DATA SHEET.
IMPORTANT NOTE
A LEVEL FLOOR IS SUGGESTED FOR A PROPER
INSTALLATION SITE AND WILL ENSURE LEVEL
LIFTING. IF A FLOOR IS OF QUESTIONABLE SLOPE,
CONSIDER A SURVEY OF THE SIGHT AND / OR THE
POSSIBILITY OF POURING A NEW LEVEL
CONCRETE SLAB SECTION. SIMPLY STATED, FOR
OPTIMUM LEVEL LIFTING, THE EQUIPMENT, AT
BEST, CAN LIFT ONLY AS LEVEL AS THE FLOOR
ON WHICH IT IS LOCATED... AND SHOULD NOT BE
EXPECTED TO COMPENSATE FOR DRASTIC FLOOR
SLOPE DIFFERENCES.
CAUTION
THE EQUIPMENT DESCRIBED IN THIS MANUAL
COULD BE POTENTIALLY DANGEROUS IF
IMPROPERLY OR CARELESSLY OPERATED. FOR
THE PROTECTION OF ALL PERSONS AND
EQUIPMENT, ONLY COMPETENTLY TRAINED
OPERATORS WHO ARE CRITICALLY AWARE OF
THE PROPER OPERATING PROCEDURES,
POTENTIAL DANGERS, AND SPECIFIC
APPLICATION OF THIS EQUIPMENT SHOULD BE
ALLOWED TO TOUCH THE CONTROLS AT ANY
TIME.
SAFE OPERATION OF THIS EQUIPMENT IS
DEPENDENT ON USE IN COMPLIANCE WITH THE
OPERATION PROCEDURES OUTLINED IN THIS
MANUAL ALONG WITH THE MAINTENANCE AND
INSPECTION PROCEDURES WITH CONSIDERATION
OF PREVAILING CONDITIONS.
THE EQUIPMENT DESCRIBED IN THIS MANUAL IS
NEITHER DESIGNED NOR INTENDED FOR ANY
APPLICATION ALONE OR IN CONJUNCTION WITH
ANY OTHER EQUIPMENT THAT INVOLVES THE
LIFTING OR MOVING OF PERSONS.
ALWAYS CONSULT THE VEHICLE LIFTING GUIDE
FOR THE PROPER LIFTING POINTS ON ANY
VEHICLE. THESE GUIDES ARE AVAILABLE FROM
THE VEHICLE MANUFACTURERS.
AFTER LIFTING THE VEHICLE TO THE DESIRED
HEIGHT, ALWAYS LOWER THE UNIT ONTO THE
MECHANICAL SAFETIES. THE FORMING OF GOOD
OPERATIONAL WORK HABITS WILL ELIMINATE
OVERSIGHTS IN THE USE OF PROVIDED SAFETY
DEVICES.
WARNING:
ALL ACCESSORIES (I.E. LIFTING PADS, HEIGHT
ADAPTORS, JACKING BEAMS, ETC.) SUPPLIED
WITH THIS LIFT ARE TO BE USED ON THIS LIFT
ONLY. ACCESSORIES FROM OTHER LIFTS ARE NOT
ACCEPTABLE AND COULD RESULT IN INJURY TO
THE USER.
WARNING:
LOADING OF THE JACKING BEAMS OR
COMBINATION OF JACKING BEAMS ABOVE THE
RATED CAPACITY OF THE LIFT ITSELF COULD
RESULT IN PERSONAL INJURY TO THE OPERATOR
AND/OR DAMAGE TO THE LIFT AND/OR VEHICLE.
THE LOAD RATING OF ANY JACKING BEAM OR
COMBINATION OF JACKING BEAMS ON THIS UNIT
MUST NOT EXCEED THE RATED CAPACITY OF THE
LIFT.

MOHAWK MODEL TR-33/35/50/75/33WT/35WT/50WT/70WT
15
TR-SERIES STANDARD PACKING LIST
PACKED QTY PART NUMBER DESCRIPTION
2EAZZ1070-A-005LEG/POSTASSEMBLY(POST#1&4)
2EAZZ1070-A-004LEG/POSTASSEMBLY(POST#3&2)
2 050-010-008 CROSS RAIL
1 075-010-005 MAINSIDE TRACK ASSEMBLY (25’ STANDARD)
1 050-011-013 OFF SIDE TRACK ASSEMBLY (25’ STANDARD)
2075-050-004DRIVEONRAMPASSEMBLY
2 075-050-003 WHEEL STOP ASSEMBLY
1 ZZ1070-A-008 CONTROL CONSOLE ASSEMBLY
1FILEMAN1312PARTSBOX#1
1FILEMAN1313PARTSBOX#2
1FILEMAN1312 PARTSBOX#1
1 075-050-021 MANUAL / INSTALL-OPER-MAINT ( TR-SERIES )
4 600-930-001 WHEEL CHOCKS
2050-000-179TRACKSTOPS(BOTTOM)
2 050-000-157 TRACK STOPS ( TOP )
6 075-010-008 HYDRAULIC HOSE ASSEMBLIES
1 601-800-070 WARRANTY REGISTRATION CARD PACKAGE
1FILEMAN1313 PARTSBOX#2
6 050-000-032 TUBING ASSEMBLY
6 035-001-006 TUBING ASSEMBLY CLUSTER ( W/T-FITTING )
1 050-010-016 SMALL PARTS BAG
6 601-630-002 SPRAY PAINT ( YELLOW )
6601-630-001SPRAYPAINT(RED)
16 600-670-002WEJ-ITANCHOR(3/4X5)
32 600-640-024 BOLT, 3/4 X 2-1/2 IN
16 6000640-028 BOLT, 3/4 X 3-1/2 IN
48 600-690-003 NUT 3/4 NF NLN
4 050-000-160 CARRIAGE COVER PLATE
2 050-010-115 CROSSRAIL LINE COVER ( LEFT )
2050-010-116CROSSRAILLINECOVER(RIGHT)
1 050-010-016 SMALL PARTS BAG
10 600-740-003SHIM,1/4INBLACK
10 600-740-002SHIM,1/8INRED
10 600-740-001SHIM,1/16INBLUE
1 601-610-002 THREAD SEALING COMPOUND
2600-640-012BOLT5/16X3/4IN
4600-710-012WASHER,FLAT7/8IN
4 600-690-010 NUT 7/8 NF NLN
4 600-870-005 SNAP RING
4 600-870-004 SNAP RING
12 600-640-069 BOLT, 3/8-16 NC x 1 ¾LG
24 600-710-009 WASHER, FLAT, 3/8
12 600-680-012 NUT, PLAIN, 3/8-16 NC
12 600-720-011 WASHER, LOCK, 3/8
3 601-140-022 HOSE SUPPORT CLAMP
PACKED BY:

MOHAWK MODEL TR-33/35/50/75/33WT/35WT/50WT/70WT
16
INSTALLATION INSTRUCTIONS
IMPORTANT
READ THIS MANUAL IN ITS ENTIRETY. BE FAMILIAR WITH PART NAMES AND HAVE A GOOD
UNDERSTANDING OF HOW THIS UNIT IS TO BE ASSEMBLED AND OF HOW INDIVIDUAL PARTS OPERATE.
REFER TO ANSI/ALI ALIS, SAFETY REQUIREMENTS FOR INSTALLATION AND SERVICE OF AUTOMOTIVE
LIFTS.
IMPORTANT
 INSTALL THE UNIT AS INDICATED ON THE
LIFT VERIFICATION SHEET. YOU CANNOT
REVERSE THE TRACK ONLY. THE UNIT CAN
ONLY BE ROTATED IN ITS ENTIRETY.
 THE UNIT WILL NOT BE SECURELY MOUNTED
TO THE FLOOR UNTIL THE UNIT HAS BEEN
CYCLED AND OPERATES SMOOTHLY. USE
EXTREME CAUTION AS NOT TO DISRUPT THE
STABILITY OF THE UP-RIGHT POST. FAILURE
TO DO SO COULD RESULT IN PERSONAL
INJURY.
TO BEGIN
USE THE PACKING LIST IN THIS MANUAL AND
VERIFY ALL SUPPLIED PARTS. IF MISSING PARTS
ARE NOTED, THEY CAN BE OBTAINED BY
CALLING 1-800-833-2006 OR BY CONTACTING
YOUR LOCAL MOHAWK DISTRIBUTOR.
USING A CHALK LINE, LAYOUT THE FLOOR
DIMENSIONS WHERE THE UNIT IS TO BE
LOCATED.
NOTE
THE CARRIAGES AND CROSS RAILS ARE
MATCHED DRILLED ONE, TWO, THREE, AND FOUR.
THESE ARE REFERENCE MARKS ON THE TOP OF
THE CROSS RAIL AND THE TOP PLATE ON THE
ADJOINING CARRIAGE.
ALIGN POST ONE AND TWO INTO PLACE ON THE
CHALK LINE LAYOUT.
NOTE
POSTTWOISTOBESETONEFOOTOUTAWAY
FROM POST ONE. UNTIL THE CROSS RAIL
CHAINS HAVE BEEN ROUTED THROUGH THE
CARRIAGES.
 VERIFY THAT THE THREE INTERNAL
HYDRAULIC LINES IN BOTH CROSS RAILS ARE
TIGHT BEFORE ASSEMBLY.
WARNING
 INSURE ALL HYDRAULIC LINE CONNECTIONS
ARE LOCATED TO THE INSIDE OF THE UNIT
SET THE CROSSRAIL MARKED ONE AND TWO INTO
PLACE BETWEEN POST ONE AND TWO IN THE
CORRESPONDING ORIENTATION.
USING THE FISH TAPE ROUTE THE TWO
EQUALIZING CHAINS THROUGH THE CROSS RAIL
AND CARRIAGES. LAY THE EXCESS CHAIN ONTO
THE CROSS RAIL.
WARNING
 DO NOT CROSS OR TWIST THE EQUALIZING
CHAINS WHEN FISHING THEM THROUGH THE
CROSS RAIL. ALWAYS VERIFY THIS USING A
DROP LIGHT OR FLASH LIGHT. FAILURE TO DO
SO COULD RESULT IN PERSONAL INJURY.

MOHAWK MODEL TR-33/35/50/75/33WT/35WT/50WT/70WT
17
INSTALLATION INSTRUCTIONS
ALIGN THE CROSS RAIL MOUNTING HOLES WITH
THE MOUNTING HOLES ON THE CARRIAGE ON
POST NUMBER ONE. WHEN THE CROSS RAIL IS IN
PLACE, INSERT AND HAND TIGHTEN THE EIGHT
3/4 - 16 NF X 2 - 1/2 IN BOLT AND 3/4 - 16 NF NYLON
LOCK NUT.
ALIGN THE CROSS RAIL MOUNTING HOLES WITH
THE MOUNTING HOLES ON THE CARRIAGE ON
POST NUMBER TWO. WHEN THE CROSS RAIL IS IN
PLACE, INSERT AND HAND TIGHTEN THE EIGHT
3/4 - 16 NF X 2 - 1/2 IN BOLT AND 3/4 - 16 NF NYLON
LOCK NUT.
FULLY TIGHTEN THE SIXTEEN CROSS RAIL
MOUNTING BOLTS TO 420 FOOT POUNDS.
CONNECT THE TWO EQUALIZING CHAINS TO THE
TOP OF POST ONE AND TWO.
TIGHTEN THE NYLON LOCK NUT SO THAT THE
THREADS OF THE CHAIN CONNECTOR PROTRUDE
PAST THE NYLON BY AT LEAST THREE THREADS.
PLACE THE MAIN AND OFF SIDE TRACK INTO
POSITION ON THE CROSS RAIL. ELEVATE THE
TRACKS OFF OF THE CROSS RAIL USING THE
4 X 4 X 12 IN DUNNAGE.
NOTE
 THE MAIN SIDE TRACK IS TO BE LOCATED ON
THE SIDE WITH THE CONTROL CONSOLE.
REFERENCE LIFT VERIFICATION SHEET
ALIGN POST THREE AND FOUR INTO PLACE ON
THE CHALK LINE LAYOUT.
POST THREE IS TO BE SET ONE FOOT OUT AWAY
FROM POST FOUR UNTIL THE CROSS RAIL CHAINS
HAVE BEEN ROUTED THROUGH THE CARRIAGES.
SET THE CROSS RAIL MARKED THREE AND FOUR
INTO PLACE BETWEEN POST THREE AND FOUR IN
THE CORRESPONDING ORIENTATION.
USING THE FISH TAPE ROUTE THE TWO
EQUALIZING CHAINS THROUGH THE CROSS RAIL.
AND CARRIAGES. LAY THE EXCESS CHAIN ONTO
THE CROSS RAIL.
WARNING
 DO NOT CROSS OR TWIST THE EQUALIZING
CHAINS WHEN FISHING THEM THROUGH THE
CROSS RAIL. ALWAYS VERIFY THIS USING A
DROP OR FLASH LIGHT. FAILURE TO DO SO
COULD RESULT IN PERSONAL INJURY.
ALIGN THE CROSS RAIL MOUNTING HOLES WITH
THE MOUNTING HOLES ON THE CARRIAGE ON
POST NUMBER THREE. WHEN THE CROSS RAIL IS
IN PLACE, INSERT AND HAND TIGHTEN THE EIGHT
3/4 - 16 NF X 2 - 1/2 IN BOLT AND
3/4 - 16 NF NYLON LOCK NUT.
ALIGN THE CROSS RAIL MOUNTING HOLES WITH
THE MOUNTING HOLES ON THE CARRIAGE ON
POST NUMBER FOUR. WHEN THE CROSS RAIL IS IN
PLACE, INSERT AND HAND TIGHTEN THE EIGHT
3/4 - 16 NF X 2 - 1/2 IN BOLT AND 3/4 - 16 NF NYLON
LOCK NUT.
FULLY TIGHTEN THE SIXTEEN CROSS RAIL
MOUNTING BOLTS TO 420 FOOT POUNDS.
CONNECT THE TWO EQUALIZING CHAINS TO THE
TOP OF POST THREE AND FOUR.
TIGHTEN THE NYLON LOCK NUT SO THAT THE
THREADS OF THE CHAIN CONNECTOR PROTRUDE
PAST THE NYLON BY AT LEAST THREE THREADS.

MOHAWK MODEL TR-33/35/50/75/33WT/35WT/50WT/70WT
18
INSTALLATION INSTRUCTIONS
ASSEMBLE THE TWELVE HYDRAULIC LINE
ASSEMBLIES MARKED ONE, TWO, THREE, AND
FOUR ONTO THE CARRIAGE AND TRACKS. DO NOT
CROSS THREAD OR OVER TIGHTEN THE
CONNECTORS.
ASSEMBLE THE SIX 40.50 IN HYDRAULIC HOSES
TO THE FORE AND AFT END OF THE UNIT.
(CONNECTIONS ON THE MAIN SIDE TRACK .FROM
THE CARRIAGE TO THE CROSS RAIL )
MOVE THE CONTROL CONSOLE INTO PLACE
BESIDE THE MAIN SIDE TRACK. ( CENTERED,
APPROXIMATELY FOUR FOOT FROM THE TRACK )
ASSEMBLE THE FOUR HYDRAULIC HOSE
ASSEMBLIES FROM THE CONTROL CONSOLE TO
THE MAIN SIDE TRACK.
ASSEMBLE THE HUBBLE PLUG FROM THE
CONTROL CONSOLE TO THE SELF LEVELING
DEVICE.
IMPORTANT
 AT THIS TIME HAVE A QUALIFIED LICENSED
ELECTRICIAN CONNECT THE POWER SUPPLY
TO THE CONTROL CONSOLE.
IMPORTANT
USING THE TEXT AND DIAGRAM, FAMILIARIZE
YOURSELF WITH THE CONTROL CONSOLE
FUNCTIONS.
PRE-STARTUP
 INSURE ALL HYDRAULIC CONNECTIONS ARE
PROPERLY TIGHTENED.
 PLACE THE AUTO / MANUAL SWITCH ON THE
CONTROL PANEL CONSOLE TO THE MANUAL
POSITION.
PLACETHEHIGH/LOWSWITCHONTHE
CONTROL PANEL CONSOLE TO THE LOW
POSITION.
 VERIFY THE MOTOR ROTATION.
 ENSURE ALL DEBRIS AND PERSONAL HAVE
BEEN REMOVED FROM THE LIFTING AREA..
 PLACE THE POWER UNIT STARTER SWITCH ON
THE CONTROL PANEL TO THE ON POSITION.
OBSERVE THE POWER INDICATOR LIGHT.
FOLLOWING THE PROCEDURES FOR RAISING AND
LOWERING THE UNIT, RAISE THE UNIT
APPROXIMATELY ONE FOOT. INSURE THAT THE
TRACKS HAVE SEATED THEMSELVES INTO THE
ALIGNMENT TABS ON THE CROSS RAIL ADJUST AS
NEEDED.
CYCLE THE UNIT TWO TO THREE TIMES. OBSERVE
EVEN AND SMOOTH OPERATION USE THE
PROVIDED SHIMS TO LEVEL POST ONE, TWO,
THREE, AND FOUR.
ASSEMBLE THE TWO TRACK STOPS TO THE FORE
END OF THE MAIN AND OFF SIDE TRACK USING
THE EIGHT 3/4 - 16 NF X 3 - 1/2 IN BOLTS AND 3/4 -
16 NF NYLON LOCK NUTS.
CHECK ALL HYDRAULIC FITTINGS FOR LEAKS.
TIGHTEN AS REQUIRED.
SNAP INTO PLACE THE FOUR CARRIAGE ACCESS
COVER PLATES ONTO THE CARRIAGES
ASSEMBLE THE FOUR HYDRAULIC LINE COVER
PLATES ONTO THE CROSS RAIL USING THE
TWELVE HEX HEAD 5/16 - 24 NF X 5/8 IN SELF
TAPPING BOLTS.
FOLLOWING THE INSTRUCTIONS FOR RAISING
AND LOWERING THE UNIT, AGAIN CYCLE THE
UNIT. AFTER RAISING THE UNIT FULLY LOWER
THE UNIT.
WITH THE UNIT FULLY LOWERED, ADJUST ALL
FOUR EQUALIZING CHAINS TO REMOVE ANY
REMAINING SLACK. ALL FOUR CHAINS ARE TO BE
TAUT.

MOHAWK MODEL TR-33/35/50/75/33WT/35WT/50WT/70WT
19
LIFT FINAL CHECKOUT (AFTER INSTALLATION):
REV (4/4/2011)
THIS PROCEDURE OUTLINES THE FINAL CHECKS TO MAKE AFTER INITIAL INSTALLATION OF THE LIFT UNIT.
REPEAT THIS PROCEDURE IF THE LIFT IS RELOCATED.
AFTER THE LIFT IS FULLY ASSEMBLED, RAISE THE LIFT EMPTY A FEW TIMES TO VERIFY:
PROPER SYNCHRONIZATION OF TRACKS AND CROSSRAILS
UNIT IS RAISING SMOOTHLY (AIR IS BLEED FROM HYDRAULIC SYSTEM - SEE BLEEDING PROCEDURE FOR MORE DETAILS)
NO LEAKS PRESENT AT ANY FITTING JUNCTIONS
LOCKS ARE ENGAGING ON ALL POSTS SIMULTANEOUSLY AS LIFT IS RAISING (MAKE ADJUSTMENTS AS NEEDED)
LOCKS ARE DIS-ENGAGING ON ALL POSTS WHEN LOCK RELEASE BUTTON DEPRESSED.
LOCKS ARE RE-ENGAGING AFTER DIS-ENGAGED.
LIFT IS NOT DRIFTING DOWN WHEN RAISED (RAISE LIFT, THEN STOP, AND VERIFY DRIFT DOWN OF CYLINDERS)
NO VIBRATIONS FROM LOOSE CLAMPING, ETC.
ONCE THIS IS COMPLETE, LOCATE A REPRESENTATIVE VEHICLE INTO THE LIFTING AREA. USE A VEHICLE THAT WEIGHS AT LEAST 50
PERCENT OF THE CAPACITY OF THE LIFT.
OBSERVING LIFTING PROCEDURES CONTAINED IN THIS MANUAL TO POSITION THE VEHICLE ONTO THE LIFT.
RAISE LIFT APPROXIMATELY 1 FOOT. VERIFTY THE FOLLOWING:
PROPER SYNCHRONIZATION OF TRACKS AND CROSSRAILS
NO LOOSENING OF REAR ANCHOR BOLTS IN BASE PLATES AT FLOOR (LOOK FOR GAP BETWEEN FLOOR AND BASES)
UNIT IS RAISING SMOOTHLY (AIR IS BLEED FROM HYDRAULIC SYSTEM - SEE BLEEDING PROCEDURE FOR MORE DETAILS)
NO LEAKS PRESENT AT ANY FITTING JUNCTIONS
LOCKS ARE ENGAGING ON ALL POSTS SIMULTANEOUSLY AS LIFT IS RAISING (SOME VARIANCE EXPECTED)
LIFT IS NOT DRIFTING DOWN WHEN RAISED (RAISE LIFT, THEN STOP, AND VERIFY DRIFT DOWN OF CYLINDERS)
NO VIBRATIONS FROM LOOSE CLAMPING, ETC.
PRESS LOCK RELEASE AND LOWER UNIT. VERIFY THE FOLLOWING:
PROPER SYNCHRONIZATION OF TRACKS AND CROSSRAILS
UNIT IS LOWERING SMOOTHLY (AIR IS BLEED FROM HYDRAULIC SYSTEM - SEE BLEEDING PROCEDURE FOR MORE DETAILS)
NO LEAKS PRESENT AT ANY FITTING JUNCTIONS
NO VIBRATIONS FROM LOOSE CLAMPING, ETC.
LOCKS ARE NOT RE-ENGAGING WHILE LOWERING
RAISE LIFT TO FULL STROKE. VERIFY THE FOLLOWING:
PROPER SYNCHRONIZATION OF TRACKS AND CROSSRAILS
NO LOOSENING OF REAR ANCHOR BOLTS IN BASE PLATES AT FLOOR (LOOK FOR GAP BETWEEN FLOOR AND BASES)
UNIT IS RAISING SMOOTHLY (AIR IS BLEED FROM HYDRAULIC SYSTEM - SEE BLEEDING PROCEDURE FOR MORE DETAILS)
NO LEAKS PRESENT AT ANY FITTING JUNCTIONS
LOCKS ARE ENGAGING ON ALL POSTS SIMULTANEOUSLY AS LIFT IS RAISING (SOME VARIANCE EXPECTED)
LIFT IS NOT DRIFTING DOWN WHEN RAISED (RAISE LIFT, THEN STOP, AND VERIFY DRIFT DOWN OF CYLINDERS)
NO VIBRATIONS FROM LOOSE CLAMPING, ETC.
LOWER LIFT ONTO LOCKS. VERIFY THE FOLLOWING:
ALL LOCKS ARE ENGAGING UPON DESCENT
PROPER SYNCHRONIZATION OF TRACKS
RAISE LIFT 3 INCHES, THEN RELEASE LOCKS AND LOWER VEHICLE TO FLOOR. VERIFY THE FOLLOWING:
PROPER SYNCHRONIZATION OF TRACKS AND CROSSRAILS.
UNIT IS RAISING & LOWERING SMOOTHLY (AIR IS BLEED FROM HYDRAULIC SYSTEM - SEE BLEEDING PROCEDURE FOR MORE
DETAILS)
NO LEAKS PRESENT AT ANY FITTING JUNCTIONS
NO VIBRATIONS FROM LOOSE CLAMPING, ETC.
LOCKS ARE NOT RE-ENGAGING WHILE LOWERING
NO LOOSENING OF REAR ANCHOR BOLTS IN BASE PLATES AT FLOOR (LOOK FOR GAP BETWEEN FLOOR AND BASES)
ENSURE THAT ALL MANUALS AND OTHER INSTRUCTIONAL MATERIALS ARE DELIVERED TO OWNER/USER/EMPLOYER.
ENSURE THAT USERS ARE INSTRUCTED IN THE SAFE AND PROPER USER OF THE LIFT.
THIS ENDS THE FINAL CHECKOUT OF LIFT.

MOHAWK MODEL TR-33/35/50/75/33WT/35WT/50WT/70WT
20
4-POST LIMITATIONS:
REV (4/4/2011)
4-POST LIMITATIONS:
ALL MOHAWK 4-POST LIFTS ARE FOR INDOOR USE UNLESS SPECIFICALLY QUALIFIED AND
MODIFIED FOR A CUSTOM ENVIRONMENT.
ALL MOHAWK 4-POST LIFTS MUST ACCOMPLISH THREE MAIN CRITERIA IN ORDER TO LIFT
A VEHICLE SAFELY:
1. PROPER CAPACITY. ALL 4-POST RUNWAY LIFTS ARE DESIGNED TO LIFT STANDARD
VEHICLES WITHIN THEIR RATED CAPACITY WITHIN THE CAPACITY OF THE LIFT
RATING. ANY VEHICLES EXCEEDING THE CAPACITY MUST NOT BE RAISED.
2. PROPER CENTER OF GRAVITY PLACEMENT OF VEHICLE ON LIFT ENSURE THAT
THE CENTER OF GRAVITY OF THE VEHICLE LIES CENTERED ALONG THE LENGTH OF
THE TRACKS. WITH RESPECT TO HEAVY ENDED VEHICLES SUCH AS FORK TRUCKS,
DELIVERY VANS, PICKUP TRUCKS, ETC, THE VEHICLE MAY NEED TO BE POSITIONED
FORWARD OR REARWARD TO CENTER THE LOAD ON THE TRACKS. ALSO, THE
VEHICLE SHOULD BE CENTERED SIDE TO SIDE ON THE LIFT TRACKS AS WELL.
3. PROPER CHOCKING OF TIRES. USE CHOCKS SUPPLIED, AND CHOCK TIRES ON
BOTH TRACKS.
SPECIAL SAFETY PRECAUTIONS MUST BE OBSERVED IN APPLICATIONS INVOLVING VERY
LONG AND VERY SHORT WHEELBASE VEHICLES. THE WHEEL BASE RANGE ON VERY LONG
VEHICLE MAY NOT ALLOW FOR PROPER POSITIONING OF TIRES ON TRACKS TO GET THE
CENTER OF GRAVITY OF THE VEHICLES CENTERED WITH THE CENTER OF THE TRACK
LENGTH. SHORT WHEEL BASE VEHICLES MAY OVERLOAD THE CENTRAL LENGTH OF THE
TRACKS. AS A RULE OF THUMB, ALL MOHAWK 4-POST RUNWAY LIFTS ARE DESIGNED TO
ACCOMMODATE WHEEL BASES THAT ARE ~3 FEET SHORTER THAN THE LENGTH OF THE
TRACKS (MORE IF VEHICLES ARE FAIRLY EVENLY LOADED FRONT TO REAR) AND WHEEL
BASES AS SHORT AS 10 FEET (LESS IF VEHICLES ARE LIGHTER). REFER TO VEHICLE
MANUFACTURER GUIDELINES FOR PROPER LIFTING TECHNIQUES.
PRIOR TO LIFTING LOW PROFILE VEHICLES, RAMPS SHOULD BE CHECKED TO ENSURE
PROPER CLEARANCE FOR ENTRY AND BREAK OVER OF THE VEHICLE UNDERCARRIAGE.
(IE. STRETCHED LIMOS.). LONGER RAMPS MAY BE REQUIRED.
THIS LIFT IS NOT INTENDED, NOR DESIGNED, TO LIFT VEHICLE BY ONLY THE FRONT OR
ONLY THE BACK ENDS.
THIS LIFT IS NOT INTENDED TO BE DRIVEN ON TO OR OFF OF, UNLESS WHEN IT IS FULLY
LOWERED.
(THIS IS NOT AN ELEVATOR LIFT).
THIS LIFT IS NOT INTENDED FOR THE LIFTING OF PEOPLE.
CARE MUST BE OBSERVED WHEN REMOVING ANY HEAVY COMPONENTS FROM A VEHICLE
AND THEREBY DRASTICALLY SHIFTING THE VEHICLE CENTER OF GRAVITY (I.E. ENGINE
REMOVAL, TRANSMISSION REMOVAL, ETC.). THE USE OF JACK STANDS AT THE FRONT
AND REAR ENDS OF THE VEHICLE IS HIGHLY RECOMMENDED WHEN PERFORMING THIS
TYPE OF WORK.
