LC6 / LC7
4
Monark Exercise AB
Monark has 100 years’ experience of bicycle production. The Monark tradition has yielded
know-how, experience, and a real feel for the product and quality. Since the early 1900s,
Monark’s cycles have been living proof of precision, reliability, strength and service. Those
are the reasons why we are now the world leader in cycle ergometers and the market leader
in Scandinavia in transport cycles.
We manufacture, develop and market ergometers and exercise bikes, transport bikes and
specialized bicycles. Our largest customer groups are within health care, sports medicine,
public authorities, industry and postal services.
For more information: http://www.monarkexercise.se

LC6 / LC7 5
Thank you for choosing a test cycle from Monark!
Ideal position is important for performance to reach its maximum. LC6/LC7 has a brand new frame
that is adjustable in all directions. The frame also allows the Q-factor to be reduced, which further
increases the possibilities for a perfect performance. The new setting options, along with an upgraded
braking system, make Monark's renowned bike even better.
LC6/LC7 gives the conditions; the rest is up to the rider.
In today's society we are used to customizing our machines and tools for our own needs. The
same applies to LC6/LC7. Through intelligent solutions parts can be customized according to user
requirements. LC6/LC7 is also prepared for additional equipment, channels behind the covers make it
easy to install different equipment for different needs. LC6/LC7 is a great bike as it is, with additional
equipment, it can be even better.
Force is a strong word which brings many associations. For us, force is interesting when it can be
measured and calibrated. For a brake-force to be correct, regardless of the system, it must be calibrated
and controlled. On LC6/LC7 the brake system and calibration have been updated so that it is safer
and more accurate. It is also quicker to adjust and has more options in that it is speed-independent,
but can be switched into constant braking force as an alternative.
Monark has always been known for the bikes measurement accuracy, now it's even better.

LC6 / LC7
6
Facts Technical data power adaptor, LC6 and LC7
Input voltage: 220-240 V AC; 650 mA; 50/60 Hz.
Output voltage: 24 V DC switching adapter alt. 18
V AC.
(Sweden, 18 V, Art. No: 9339-67, other countries
incl. USA, 24 V, Art. No: 9339-66)
Polarity: Optional AC
NOTE! The power adaptor must be CE-marked if
original adaptor is replaced.
Technical details
Length 1405-1630 mm
Width 640 mm
Height (max at display) LC6 1530 mm
LC7 1500 mm
Height (max at saddle) 1240 mm
Weight 77 kg
Weight flywheel 20 kg
Max user weight 180 kg
Painting Industrial powder coating
Rust protection Zinc-based basic powder
coating on exposed areas
Power output
Continuous (50-100 rpm) 4-700 W
Peak (at rpm) 1400 W (200 rpm)
Smallest increment 1 W
Features
VO• 2submax test
Training/test protocols (custom)•
HRC•
VO• 2controlled
External control via RS232 (USB with the includ-•
ed adaptor)
VO• 2max test
ECG worktest•
Included
Calibration weight 4 kg•
Chest belt Polar T34, 5 kHz•
Tool kit•
Power adaptor•
USB-Serial converter•
0-modem cable (RS232)•
Product Information
LC6 is delivered with a document•
holder.
LC7 is delivered with an integrated•
computer with 10" touch screen,
Windows, Bluetooth and WiFi.
NOTE!
Use of the product may involve considerable physical
stress. It is therefore recommended that people who
are not accustomed to cardiovascular exercise or
who do not feel completely healthy, should consult
a physician for advice.
Serial number
The serial number is placed according to Fig: Overview
at page 7.
NOTE! Before you start using the bike - remember to
remove the pendulum locking devices and protective
tape on the flywheel.
The bike can be used at maximum load
without any time limit.
PC software
(not LC7)
If you need a PC software to do exercise tests on the
bike, our software is available for free download from
our website: www.monarkexercise.se.

5
6
10
7
5
4
3
14b
14a
1
13
12
11
9a
2
16
17
18
19
9b
15
9
8
LC6 / LC7 7
Fig: Overview
1) Knob for horizontal adjustment of saddle
2) Scale for horizontal adjustment of saddle
3) Knob for horizontal adjustment of handlebar and display
4) Scale for horizontal adjustment of handlebar
5) RPM meter
6) LC6 Document holder
7) LC7 Display with integrated computer
8) RS232 connection
9a) LED
9b) Power switch
10) Pulse receiver
11) Screw for adjustment Kp-scale
12) Kp-scale
13) Locking for front cover
14a) Power connection
14b) Locking for cable (power adaptor)
15) Serial number
16) Locking handle for height adjustment saddle
17) Scale for height adjustment saddle
18) Locking handle for height adjustment handlebar
19) Scale for height adjustment handlebar

1
4
3
2
LC6 / LC7
8
Settings
User settings
Crank Steel, 170 mm standard,
172,5 mm optional
Pedals 9/16”, SPD/LOOK compatible
Saddle Racing
Seat post Vertically: 530-940 mm
Horizontally: 200 mm
Handlebar Racing, Ø31,8 mm at clamp
Handlebar stem Vertically: 500-910 mm
Horizontally: 200 mm
Distance saddle - handlebar 140-840 mm
Cycle adjustments
Seat height should be adjusted to a comfortable
position. The appropriate height is to have the knee
slightly bent when the sole of the foot is centred over
the pedal axle with the pedal in the bottom position.
When adjusting the saddle height and vertical
position, loosen the respective locking handles. See
Fig: Overview at page 7.
The handlebar setting should be in a comfortable
position when cycling. During longer exercise sessions
it is recommended to occasionally change handlebar
position. The handlebar can be adjusted both
horizontally and vertically. This is done by loosening
the respective locking handles. See Fig: Overview at
page 7.
NOTE! Be sure that the stem and seat post are inserted
to at least 100 mm in the frame. This is marked with
“MAX” on the stem.
Initial operation
LC6 / LC7 is mechanically calibrated in the factory.
The user may wish to verify this by performing the
mechanical calibration of the pendulum weight. See
”Electronic calibration”.
Apply power to the test bike by first connecting the
cable from the power adaptor to the test bike at the
power connector (3) at the right side of the bike, see
Fig: Front cover right. Then plug the power adaptor
into the wall outlet. Turn on the power switch (2) and
a green LED (1) lights up.
The cable from the power adaptor can be locked
with the clamp (4) which is placed below the power
connection.
Perform the electrical calibration as specified in section
"Calibration Electronics”. Test by pedalling the bike.
If the bike is working properly, it is ready for use.
Fig: Front cover right
1) LED (voltage indicator)
2) Power switch
3) Power input
4) Locking for cable (power adaptor)

1
LC6 / LC7 9
Power on crank or ywheel
Monark bikes measure the effect of the flywheel, so it
will be a friction of 6-8% if you measure the impact
of the pedals (measure the effect of the crankshaft,
the difference is 4-5 %). These percentages will be
primarily due to friction in the chain, pedals and
bearings.
LC6 / LC7 is designed for fitness tests and is set for
power measurements on the flywheel. The bike can be
set to work with effect in the pedals / crankshaft (the
cycle constant).
Distance meter, miles
Energy kcal
Heart rate bpm
Force Newton (N), kp
Power Watts (W), kpm / min or
VO2ml/min/kg
Time min:sec
Weight kilogram (kg), pounds (lbs)
Measured quantities
The following units are normally used. Where multiple
units are specified, the user can select, see the software
documentation.
Control of the bike
LC6 / LC7 is built on a solid framework, a large
well-balanced flywheel, a brake belt and a pendulum
that measures the braking force. The pedals operate
around the brake wheel via a chain, while a stretch
mechanism tightens the brake belt to regulate the
braking force to affect the flywheel. This brake force
is given directly by the pendulum against the scale on
the right side of the bike.
The computer system consists of a main unit (built in
the bike) and a control unit (integrated computer on
the bike, PC, terminal or other external equipment).
The main unit reads pedal speed and braking force
and to determine the test subject's heart rate by a
chest belt, where applicable. In addition, the main
unit activates an actuator, which adjusts the brake belt
tension that regulates the braking force. This brake
force is varied automatically in relation to changes in
pedal speed, so that a constant power is maintained
The bike is as default rpm-independent.
For information about how respective control units
works, see respective sections.
The bike can be controlled externally by PC, terminal
or other external equipment.
Here are instructions for connection and options for
connection to external devices. If advanced technical
documentation / data protocol for system builders or
similar are required, contact Monark Exercise AB.
The control is performed over a serial line using ANSI/
ISO/ASCII format commands. Connector, a 9-pin
D-Sub (male) located below the RPM meter, see Fig:
Connector, is compatible with the RS232 standard.
The bike need not be switched off when connecting
external components, but it is recommended to pre-
vent transmission of incorrect data between devices
over the connection.
Be careful when connecting different types of external
equipment to prevent flash-over and subsequent
injury. The user must ensure that the correct cables are
used, otherwise you risk serious injury or equipment
damage.
Operating Instruction
Fig: Connection
1) RS232 connection

3
2
1
LC6 / LC7
10
Meter instructions
Keys and functions
MODE key
Use MODE key to shift between the functions to set
TIME and TOTAL COUNT.
SET key
Pressing this key will make it possible to set TIME
and TOTAL COUNT. If you hold down this key for
two seconds you can advance the function value at a
faster rate.
Programming exercise time:
Push the MODE key until TIME flashes. Then use
SET to set the desired time. Each press of SET will
advance time by one minute. When the pedals are
rotated the countdown of time will start automatically
and count down to 0:00 and a beep will be heard for
five seconds.
Programming TOTAL COUNT:
Push the MODE key until TOTAL COUNT flashes.
Then use SET to set the desired value. Each press
of the SET will increase the value by 10. When the
pedals are rotated the countdown of number of turns
automatically start and count down to 0 and a beep
will be heard for five seconds.
RESET key
The RESET key will clear the values for TIME and
TOTAL COUNT individually.
NOTE!
Display will return to normal when not pressed•
any key for five seconds, or trainer is not used.
The meter starts automatically when a key is•
pushed, or if the bike is used and the meter gets
an indication of pedal movement.
Auto shut off function when not pressed any key•
or device not used for four minutes.
Do not expose the meter to direct sunlight or extremely
high temperature. Do not use any dissolvents when
cleaning. Use only dry cloth. For surface disinfection,
see the section "Regular service and maintenance".
Display
Pedal revolution
(RPM)
0 - 250 rev./min.
TOTAL COUNT 9999 Total number of
turns
TIME 0:00-99:59 min:sec
Batteries: 1.5 V x 2, R6 (AA)
Storing temperature: -10º C - +60º C
Operating temperature: 0º C - +50º C
Battery replacement
The batteries can be accessed from the back of the
RPM meter (2). Loosen the meter using the two
screws (1) on the back of the meter, under the meter
bracket.
Open the battery cover (3) and replace the batteries,
see Fig: Battery cover. Replace the meter and secure
it using the two screws.
Fig: Battery replacement
1) Screws
2) RPM meter
3) Battery cover

1
5
4
3
2
LC6 / LC7 11
Setting command type (PC or ECG device)
Check that the brake belt is loose around the flywheel,
see Fig: Control loose brake belt. If the brake belt is
tight loosen it by moving the pendulum pointer to
4 kp and the servo releases the brake belt tension.
To be sure that indicator positions are correct, do a
calibration. See section "Calibration".
Turn off the power by turning the power switch1.
(2), see Fig: Power switch. Disconnect the cable
from any connected external device.
Adjust the scale mechanically so that 0-index on2.
the scale and indicator are in line. See section
"Zero adjustment of meter panel".
Move the indicator to 6 kp and hold it there.3.
Turn on the power again. The green LED (1) is lit4.
when power is connected to the bike.
Hold the pendulum pointer at 6 kp until two5.
beeps are heard.
Move the pendulum pointer to6.
0 kp = mode for PC, terminal or some PC-
based external device.
1 kp = mode for ECG Siemens Megacart.
2 kp = mode for other ECG devices, alt 1.
3 kp = mode for other ECG devices, alt 2.
7. Keep at the selected position until two signals can
be heard. Then release the pointer to 0. The system
will now restart in the selected mode.
Alt. 1: ECG, Ergoline compatible command set,
requested load value.
Alt. 2: ECG, Ergoline compatible command set,
current load value.
Connection to controller
Fig: Control loose brake belt
Fig: Power switch
1) LED
2) Power switch
3) 6 kp

1
LC6 / LC7
12
Connection to PC
To connect a PC to the bike, use a 0-modem cable
(RS232) with 9-pin D-sub connector (female) at both
ends. If no serial port is available on the computer,
use a USB-serial adaptor (included) for connection to
the USB port.
Before installing the Monark Software for your
ergometer, you must take the following steps.
Locate the USB adaptor.1.
Inside the USB adaptor packaging, there is a mini-2.
CD.
Insert the mini-CD into the CD-ROM drive and3.
install the driver software. If there is no CD drive
on your computer, driver software is available for
download from the website (http:www.vscom.de/
USB-CD).
Finalize the driver software installation by4.
inserting the USB adaptor.
Install Monark software (can be downloaded5.
from our website: www.monarkexercise.se).
Connect the USB Adaptor to the Serial Cable and6.
proceed with testing.
Tocontrolthebikeusethecomputerprogram"Monark
939 E Analysis Software" which is available for free
download from our website: www.monarkexercise.se.
The software is the same for the models 831 E, 839
E, 939 E and LC6 / LC7. Other external PC software
that are compatible with the bike can also be used.
Terminal Mode PC
A variety of settings can be made from the software.
For more information about this see the software's
help file.
Settings can also be made directly from the PC through
the terminal mode, see the Technichal Manual which
is available from Monark Exercise AB.
Fig: Connection
1) RS232 connection
When power is turned on to the bike it will beep, and
from the number of beeps the command type can be
determined.
Command type 0: A long beep.•
Command type 1: A long beep followed by a•
short beep.
Command type 2: A long beep followed by two•
short beeps.
Command type 3: A long beep followed by three•
short beeps.
What command type (cmd type) is set?

1
LC6 / LC7 13
Management of connections
Display with integrated computer on the bike (LC7)
Make sure the power adaptor is connected to the bike
Make sure the USB cable is plugged into the bike
computer and the computer has power (needed if the
computer's internal battery is drained). The computer
can be powered from the bike power adaptor. Set
the bike power switch to "on" and then start the
computer.
Now you can start the computer software in the
computer. If you get a message that the connection
can not be obtained probably the wrong COM port
is registered in the software, see the manual to the
software.
Connecting an external computer (LC7)
Make sure the power adaptor is connected to the bike
Set the bike power switch to "off" and then remove
the USB cable from the bike computer.
NOTE! Det är viktigt att USB-kabeln är urtagen ur
It is important that the USB cable is disconnected from
the bike computer, otherwise there may be a conflict
between the external computer and the display with
integrated computer.
Insert the supplied RS232 cable to the RS232
connector (1) below the RPM meter. At the other end
of the RS232 cable, connect the USB serial adaptor.
Connect the USB connector into an available port
on the external computer. Set the bike power switch
to "on" and then start the software in the external
computer.
If you need a pc software to do exercise tests on the
bike, our software is available for free download from
our website: www.monarkexercise.se.
If you connect an external computer with an RS232
port you can connect the RS232 cable directly into
the serial port and do not need to use the USB serial
adaptor.
Connecting external equipment directly to the RS232
connector (LC6 / LC7)
Make sure the power adaptor is connected to the bike
Set the bike power switch to "off" then remove the
USB cable from the bike computer.
NOTE! NOTE! It is important that the USB cable is
disconnected from the bike computer. Otherwise there
may be a conflict between the external computer and
the display with integrated computer.
Insert the supplied RS232 cable to the RS232
connector below the RPM meter. Connect the other
end of the RS232 cable to the external equipment.
Set the bike power switch to "on" and then start the
external equipment.
Fig: Connection
1) RS232 connection

1
23
1
LC6 / LC7
14
Checking the pulse function
This bike does not have a meter that shows the heart
rate. However, the heart rate is displayed in the
computer software or other external equipment.
While the patient rests, with the chest belt on, compare
heart rate in the software with the manually taken
pulse. If it does not correspond, check the chest belt
contact area and moisten if necessary the electrode
surfaces with water. Electrodes on the back of the
chest belt. If this fails, call customer service.
The following procedure ensures that the bike works
for daily use.
Check the pulse function, see section.•
Check the brake force, see section.•
Test by pedalling and check that a reasonable•
rpm is obtained - verify by a clock. Feel if the
pedals move smoothly. Listen for unusual sounds.
Remedy if necessary.
Adjust the handlebar and saddle and make sure•
they are securely attached and that the adjustment
is working properly.
Make sure the support legs are in position by•
rocking the bike. Tighten if necessary.
If something unusual is found during the daily
inspection that you cannot resolve, please call
customer service.
Fig: Placement of the chest belt
Validation Validation of force
Start the PC software (it is available for free download
from our web site: www.monarkexercise.se) and
select a test programme from the menu "Test". In the
dialogue box that opens is a box showing the braking
force in Newton, see Fig: Force and HR display. You
do not have to press "Start" (1) to get the heart rate
showed (2), but you must press "Start" to show the
force (3).
With the pendulum pointer at 0, the display should1.
read "00N".
Move the pendulum pointer to 4 kp and the display2.
should now show "39N".
If the braking force is not displayed correctly, an
electronic calibration must be done. See section
"Calibration electronics".
NOTE!
After this verification, the brake belt will be loose,
which means that it takes about 15 seconds before the
regulating device has tense the brake belt to normal
again (5 N).
Fig: Force and HR display
1) Start
2) Heart rate display
3) Force in software (manual test)
Fig: Electrodes on the back of the chest belt (1)

4 kg
1
3
4
2
1
2
3
1
2
3
LC6 / LC7 15
Zero adjustment of scale
Check that 0-index (3) on the scale (2) is in line with
the pendulum pointer when the bike is at a stand
still and the brake belt is loose. If not, an adjustment
must be done. Loosen the screw and adjust the scale.
Tighten the screw (1) after adjustment. See Fig:
Adjustment scale.
Calibration
All LC6 / LC7 are calibrated in the factory, but a
calibration of the pendulum can still be done to verify
this. If so, please do the following.
Open the front cover. Check that the brake belt (3) is
loose. If not, move the pendulum to 4 kp and hold it
there a while to loosen it. Unhook the brake belt from
the spring. Check that scale 0-index is in line with
the pointer. Adjust if necessary, see section "Zero
adjustment of scale".
Calibration weight 4 kg (Art. No: 9000-211) is
hooked on the spring.
NOTE!
The flywheel must be completely stopped before the
weight is hung on!
This weight (4 kg) can, when properly adjusted, be
read at the corresponding point on the scale. If there is
a deviation, adjust the pointer to the correct position
by adjusting the weight (2) inside the pendulum. To
change the adjustment weight loosen the adjustment
screw (1). If the pointer shows too low, the internal
weight must be moved upwards. If the pointer shows
too high, the adjustment weight is moved down.
This process is repeated until pointer is in the correct
position. Hook the brake belt in the spring and close
the front cover.
Check the calibration of the pendulum weight once a
year or when needed.
Fig: Calibration
1) Kp-scale
2) Pointer
3) Spring
4) Calibration weight 4 kg
Fig: Pendulum
1) Adjustment screw
2) Adjustment weight
3) Brake belt
Fig: Adjusting scale
1) Screw
2) Scale (Kp-scale)
3) 0-index

LC6 / LC7
16
The following steps show how electronics are
calibrated against the pendulum.
Open the front cover.1.
Check that the brake belt is loose on the flywheel,2.
see Fig: Control loose brake belt. If not, move
the pendulum pointer to 4 kp and hold it there
for a few seconds. Move the pendulum pointer
to 0 again, and check again that the brake belt is
loose.
Adjust the scale, see "Zero adjustment of scale,"3.
so that the pendulum pointer is pointing at the
0-index of the scale, see Fig: Zero position.
Turn off the power to the bike and move the4.
pendulum pointer to 4 kp, as shown in Fig: 4 kp.
Hold the pendulum pointer at 4 kp and turn the5.
power on the bike again and wait for a beep.
Move the pendulum pointer to 0, see Fig: 0 kp.
Wait for a beep.
Move the pendulum pointer to 2 kp, see6. Fig: 2 kp.
Wait for a beep.
Move the pendulum pointer to 4 kp, see7. Fig: 4 kp.
Wait for a beep.
Move the pendulum pointer to 6 kp, see8. Fig:
6 kp. Wait for two beeps. Move the pendulum to
0 again.
The calibration is complete. Close the front cover.
Electronic calibration - with the pendulum
Calibration electronics
Usually it is not necessary to recalibrate the cycle
electronically, but it should be done after each service,
change of electronic part, movement, if you adjusted
the 0-index, or after you have programmed the
"Reset" by default settings.
The calibration coefficient calculated by the computer
is stored in main memory. No matter when the power
is turned on, the last stored calibration will be placed
in main memory. New calibration automatically
replaces the old.
A check of the electronic calibration can be done in
the computer programme, see section "Validation of
force". NOTE!
The pendulum must be kept still at the different
positions. This is done by pressing down the pointer
into the groove on the scale at each kp value.
Calibration
LC6 / LC7 has a mechanical brake and pendulum
weight, making performance validation a simple
procedure. Calibration is necessary so that the
electronic and the mechanical parts of the cycle
conform. The work carried out on the bike is a
result of the braking force (pendulum mode) and the
number of pedal revolutions (= distance). The effect
is then counted out by dividing the work done by the
time it took to accomplish it. Validation includes both
mechanical and electronic procedures. For detailed
information, see the computer programme's user
manual. If the bike fails to pass any section of the
validation, proceed to the calibration and/or service
menu.
After any repair or service, a "Daily Check" should
be done.
It is also possible to calibrate from the software. See
the menu "Monark Ergomedic" - Check calibra-
tion..." in the computer software.

LC6 / LC7 17
Fig: Control loose brake belt Fig: Zero position
Fig: 2 kp. Fig: 4 kp.
Fig: 6 kp. Fig: 0 kp.

LC6 / LC7
18
Testing with LC6 / LC7
The versatility of the LC6 / LC7 enables it to be utilized
in a variety of testing environments. The precision
and reproducibility of the test values obtained with
the bike, along with the uncomplicated way to set up
the tests, means the bike can be used in clinical work
tests, in occupational health services for the fitness
tests as well as fitness centers, schools, sports clubs
and the like.
In general, one should note that stresses on the tested
person can become quite severe, whether in a clinical
work test or a simple fitness test in physical activity
contexts. As a precaution, it may be advisable, prior
to beginning an exercise protocol, that each subject
consults with a physician.
Before testing, the operator should review the entire
protocol operation with the test person, explaining
the work which will be required and the duration of
the procedure. One should also agree on how the test
person shall give signs of any fatigue, chest pain or
other abnormal physical reactions.
The test person should not engage in heavy physical
activity for several hours prior to testing to establish
maximum oxygen consumption. In addition, all
testing and exercise protocols should be performed
a reasonable time after meals. The test person should
also refrain from smoking within an hour of the
testing period.
The tested person shall also have the appropriate
clothing for a work test. Training suit or loose-
fitting clothing is best. More detailed instructions
are rarely needed, regarding the ride, but it may
still be appropriate for the test leader to give some
advice on pedalling, saddle height and position of
the handlebars. It should be comfortable to ride. The
appropriate height of the saddle is when the knee is
slightly bent when the sole of the foot is centred over
the pedal axle with the pedal in the bottom position.
Let the test subject try to ride with low workload and
see how it feels to hold a steady rpm.
Finally, the chest belt shall be put on, see Fig: Placement
heart rate belt in section "Heart Rate (telemetry)" for
correct placement. Check for a minute that a proper
heart rate is displayed. The baseline heart rate may
also be of assistance in determining the nervousness
of the test subject. It may be appropriate to let the test
person rest long enough before the test so a more or
less stable resting heart rate can be read.
Power calculation
1 rpm = that a point on the flywheel moves 6 meters
per minute.
50 rpm = 300 m
2 kp force makes 2 x 300 = 600 kpm/min
100 rpm= 600 m
1 kp force makes 1 x 600 = 600 kpm/min
Exact calculation:
Watts = rpm x kp x 0.98065
"Rule of thumb" calculation:
Watts = rpm x kp
(2% error, but may be good enough in many cases)

1
LC6 / LC7 19
Test person enforcement
The bike performs automated tests virtually by itself,
requiring minimal intervention by the test operator.
This allows the operator to pay careful attention to
the test person without distraction. The response to
the exercise protocol can be accurately estimated and
appropriate action taken to assist the test person, if
necessary. Some programmes have sections where
the test person may develop significant physical
activity. The effect on the test person should not be
underestimated.
During the test it is important to observe the test
person's appearance and heart rate. The testing should
be stopped immediately if the test person reports chest
pain, difficulty in breathing, etc. A system of prompt
medical attention should be set up prior to testing, in
case of emergency.
The test person may also have difficulty in keeping a
steady pedalling speed. This is of minor importance
(except in cases where the program assumes a constant
braking force, since the effect is automatically adjusted
to the correct value as long as the pedal speed is at least
35 revolutions / min (rpm)). However, it is important
to consider what each test documentation says about
the pedal speed.
Heart Rate (telemetry)
A person's heart rate can be measured with a chest
belt that senses the electronic output of the heart. The
chest belt is standard equipment.
The bike does not have a meter that shows the heart
rate, however, the HR is displayed in the computer
programme or in other externally connected devices.
Fuss-free HR measurement requires that the belt is
correctly placed. When it is correctly fitted the logo
on the belt will be central and readable, outward
and upright, by another person. Before putting on
the belt, clean the skin where the belt is to be placed.
The chest belt should be secured at a comfortable
tension around the mid section, just below the breast
muscle, see Fig: Placement of the chest belt. Moisten
the electrodes before use, see Fig: Electrodes on the
back of the chest belt. To make contact with the HR
receiver on the bike, the distance should not be more
than 100 cm / 39 1/3". It is especially important when
first used to identify the chest belt with the sensor, by
standing close to get the HR (maximum 60 cm). This
relates especially to the Polar heart rate belt.
NOTE! Electromagnetic waves can interfere with the
telemetry system. Cellular phones are not allowed to
be used near the bike during test.
In case of problems, turn off WiFi, Bluetooth and
similar on computers nearby (including the display
with integrated computer on LC7).
Fig: Placement of the chest belt Fig: Electrodes on the back of the chest belt (1)

LC6 / LC7
20
Fitness Rating Index - Males
Maximum Oxygen Consumption ml/kg/min
Fitness Rating Index - Females
Maximum Oxygen Consumption ml/kg/min
Rating Rating
-36 yrs 36-45
yrs
45- yrs -36 yrs 36-45
yrs
45- yrs
Excellent 54 53 43 Excellent 55 49 46
Good 49 45 38 Good 45 43 38
Above aver-
age
46 39 34 Above aver-
age
39 37 32
Average 36 33 30 Average 34 33 27
Below aver-
age
32 29 27 Below aver-
age
30 29 24
Fair 28 25 24 Fair 26 26 20
Poor 24 23 20 Poor 20 22 18
See also table 7 in “ Work tests with the Bicycle Ergometer“ by P O Astrand.
Reviewing results
The maximum oxygen uptake is a
standard measure of the condition of the heart- and
lung-functions. Dependent on the linear relationship
between work and oxygen uptake and between work
and heart rate, the heart rate response to work may
be used to estimate the oxygen consumption. If the
maximum heart rate is considered, the maximum
oxygen consumption may be determined.
The YMCA and Åstrand protocols estimate
the maximum oxygen consumption, based on a
submaximal workload while all others report the
oxygen consumption required by the final workload.
The Bruce and Naughton protocols require that the
test subject exercise at a workload level for a minimum
of one minute to establish the oxygen consumption.
If less than one minute is observed, the previous
workload value is used.
The estimated maximum oxygen consumption
derived from some of the ergometer tests is subject
to the error of the “age related predicted maximum
heart rate“. Although there is a definite and linear
relationship between work and oxygen uptake, there
are some differences in actual oxygen uptake based
on individual work efficiency. Test persons who are
less familiar with bike exercise and those individuals
who are less fit, are more likely be less efficient than
those who ride bikes frequently.
It should be noted that these results are estimates or
predictions of maximal response and have a greater
chance of being in error than if the individual were
tested to their actual maximum value. Interpretation
should therefore be made more carefully with an
understanding of the possibility of errors in the
methodology.
A relative fitness index can be obtained from the
following tables:
