INSTRUKTION MANUAL
Monark model 915E
Monark ExerciseAB

3
CONTENTS
General 4
Generalaboutexercise 14-15
Brakebelt 10
Brakebelt -brake surface 11
Assemblyinstruction 5-6
Functions 12
Servicing 13
Careandmaintenance 14
Trainingtips 18
Flywheelbearing 14
Crankbearing 14
Chain 12
Warranty 4
Freewheel 13

4
CONGRATULATIONS
Congratulationsonacquiring your MonarkEnergy915
Wehopethat you get alotoutoftraining on this bicycle.
Training tipscanbefoundatthe end of this booklet.
Elderlypeopleandphysicallyweakpersonsshouldconsultadoctorbeforestartingtheirtraining.
GENERAL
Description
Monarkhasproduced test andtrainingbicycles for over40years.Yourbicyclehasbeen produced in
accordancewith thehighestqualityrequirements.
MonarkEnergy915isequipped with variable-speedbrake and rapidbrakein the samecontrollever.
Withasimplehandgripyoudecideyourselfwhatloadtoapply.Thebicyclehasaheavyflywheelwith
fixedrim,givingevenvelocity.Thisbicycleissuitableforallages.
Guarantee
Evenwithaqualityproducttherecanariseoccasionaldefectsinmaterialandmanufacturethat are
coveredbytheguarantee.Ifsuchadefectshouldoccurwithyourtraining bicycle you should, in
accordancewith the ConsumerPurchasesAct,contact the placeofpurchase.
Serial number
Whencontactingtheplaceofpurchaseormanufacturerthemodelnumberand serial number of the
bicycleshouldbegiven.
Themodelnumber is located onthesideof the bicycleandtheserialnumber under therearofthe
bicycle.
ASSEMBLY
Unpacking
Turnthe box according tothe instructions onthe
outside.Unpackall the parts fromthetransport
packingandremoveallthepackingonthe
bicycle.
Checkthat all thecomponents are present,as
listedbelow:
1 set Handlebars 1
Monkeywrench 1
Bicycle 1
Socket wrench 10-13 1
Seatwith seat post 1
TorquewrenchTX25 1+1
Staytube, front andrear 3
Thrustwasherforlocking knobs 1
Brakelever 3
O-ringsforthrustwashers 1
Speedindicatorwith attachment 1
Allenkey 3
Lockingknobs 1
Stop screw 1 pr
Pedals 1
Trainingprogramme 2
Toeclips 1

Fig4
Fig.1 Fig.2
Fig.3
5
Tillverkningsnummer
1. Assembly of rear stay tube
Tipthebicycleforward.Assembletherearstay
tubefrombeneath with twocoachbolts and two
nutsasinthefig.1.
NBUse the socketwrench provided when
carryingoutassembly.
2. Assembly of front stay tube
Tip thebicyclebackandassemble the front stay
tubefrom beneath asin the fig.2.Note that thetwo
M8-boltsarealready-fixedinthebicycle.Return
thebicycle touprightposition.
5. Assembly of seat and seat post
AssemblethrustwashersandO-rings in the seat
tubeand in the horizontalbar of theseatpost,
seefig.Then insert theseatpost into theseat
tubeon the frame.Push seatinto seat postand
securewithlockingknob. Here youcanadjust
thedistance to thehandlebars.Adjustthe seatto
asuitableheight.
NBTightenwellaftermakingadjustments.
O-ring
Seat post
Seatclamp
Lockingknob
Thrustwasher
Brake wheel
NBLiftthefrictionbandandremovethe
protectivetape on thebrake groovebefore use.It
ismostimportantthatthewholeoftheprotective
tapeisremoved. Remnants of protectivetape
canotherwiseleadtojerkingintheloading
device. Remove protective tape on the
brakegroovebefore using thebicycle.• The
userofthebicycleshould be fully informed as to
how the brake works. See fig. 4.

6
Fig.5
Fig.6
”R”höger
”L”vänster
3. Assembly of handlebar stem, bracket for
speed indicator and water bottle, and
brake lever attachment
Mountthepressurewasherfromtheinsideinthehole
onthefrontframe tube andfittheO-ring onto the
thrustwasherfromtheoutside.
Fitthe bracket withspeedindicator and waterbottle
ontothehandlebarstemtubetogetherwith the plastic
brakeleverattachment.Theninsertthehandlebarstem
intothefronttubeonthebicycleandscrewtightwith
thelockingknob.Seefig.
Thebracket for thespeed indicator andwater bottle
canbe secured atasuitable height withthestop screw.
6. Assembly of pedals
Thepedalsare marked R(right)andL (left) at
theend of thepedalaxle.
Assemblethetoe clip on eachpedalwiththe
accompanyingwashers,screwsandnuts.
Threadthestrapsthrough the holes inthepedals
andthroughtheholesinthetoeclips.
Fitthepedalmarked R on thebicycle’sright
side.Thepedalaxle is right-threaded and
shouldbe screwed ontothe crankin a
clockwisedirection.Tightenwell.
Fitthepedal marked Lon the bicycle’s left side.
Thepedalaxle is left-threaded andshouldbe
screwedontothe crank in ananti-clockwise
direction.Tightenwell.
NBAfter approx. 5hours cyclingor as soonas
playintheaxleattachmentisobserved,the
pedalsshouldbetightened.
Tåstöd=Toe clip
Fotrem = Toe strap
Vevarm=Crank
4. Assembly of brake lever
Passthebrake lever rodthroughthe hole inthe
plasticattachmentandthendownintotheholein
thebicycle,see fig.
Screwin the knobclockwise about10 turns. More
turnsgiveload on the brakewheel,which can be
adjustedwhencycling.

7
Fig.7
Valtwattalpåskalan för
60RPM(24km/h)
Valdhastighet o
verkligtwattal
Omvandlingstabellförwattvid olikahastigheter.
Whencyclingyousupply largeamountsofenergyforstorageinthe brake wheel.Abrake is putupon
thekineticenergybymeansof a frictionbandthatruns round thebrakegrooveof the brakewheel.A
changein braking effecttakesplaceeitherthroughchangingtherate ofpedallingorthroughincreasing
orreducingthetensionofthe friction band against the
brakewheel.
On account of the large amount of energy that
builds up in the brake wheel and as the brake wheel
has no freewheel (the pedals turn with the wheel) it
is most important that the user is fully aware of
how the brake functions and has the shoes properly
secured in the toe clip.
Seat
Adjustseattodesiredheightbyreleasingthelocking
knobontheseat post.Youhavetheright height when
youaresittingcomfortably with the sole of yourfoot
overthe pedal axleandthe pedal isinits lowest posi-
tion.Thenthe kneeshouldonlybeslightlybent.
To change thedistance between theseat and the
handlebars,releasethe locking knobandadjust to the
desiredposition.
To change theangleof the seatslackentheseat clamp
undertheseat.
NBTightenwellaftermakinganyadjustment.
BEFORE USE
Handlebars
Thehandlebarsshouldbeadjustedto give a comfortable cycling position.Adjust the height until a
comfortablecyclingpositionisobtained.Releasethelockingknobunderthehandlebarstoadjust
height.
Pedals
Afterabout5 hours cyclingorassoon as thereisanyplay the pedalsshouldbetightened. Thereafter
youshould check periodicallythattheyarestillproperlytightened. This isprincipallyforyourown
safety.Playcan also causedamage to thecrank.
Your shoesshouldbe securely fastenedintothe toe clip,asthe brake wheelhasno freewheel andthe
pedalsalwaysturnwiththebrakewheel’srotation.
• Checkthatthe pedals areproperlytightened.
• Whenusingthebicycle the shoes shouldbeproperlysecuredin the toe clips.

FITNESS COMPUTER
Specification
PULSE 50 - 199 slag/min.
PULSE-HI 50 - 199 slag/min
PULSE-LOW 30 - (HI-10) slag/min
SPEED 0 - 199 km/tim
TIMER(up) 0:00 - 99:59 min:sek
TIMER(down) 99:00 - 0:00 min:sek
CALORIES(up) 0 - 999 kcal
CALORIES(down) 999 -0 kcal
DISTANCE(up) 0.00 - 99.99 km
DISTANCE(down) 99.00 - 0,00 km
Powersupply 1.5 V x 2 R6
Storagetemperature -10ºC - 60ºC
Operationtemperature 0ºC - 50ºC
KEYSANDFUNCTIONS
MODEkey
Use"MODE"keyto set mode andcyclethroughthe display windows asbelow:
PULSE HI -- PULSE LOW --TIMER -- CALORIES -- DISTANCE
SETkey
Press"SET" key toset desired value.Ifyou hold/press thiskey for twoseconds or more,
youcanadvancethe function valueatafaster rate.
RESETkey
Apressonthe key willclearthe values separatelyforTIME, DISTTANCE,CALORIES (kcal) and
HI/LOWpulselimitindividually.
Ifyouhold down the buttonformorethan two secondsatnormaldisplay,allvalues except upper and
lowerpulselimitwillbesettozeroat the same time.
8

9
PROGRAMMINGEXERCISETIME:
Press"MODE"key to advancetothetime window,then use "SET"keytoenter your desiredtime.
EachpressoftheSETkey will advance timeby oneminute.
PROGRAMMINGTARGETTRIP:
Press"MODE" key toadvanceto the distancewindow,
thenuse"SET" key to enteryourdesiredtarget trip
distance.Eachpressof the SETwilladvancedistanceby
0.5 km.
PROGRAMMINGCALORIES:
Press"MODE"key to advanceto the calories window,
thenuse"SET"key to enteryourdesiredcaloriesburned.
Eachpress of theSETwill advance caloriesby10 Kcal.
PROGRAMMINGHIGHANDLOWPULSERATE LIMIT:
Press"MODE"key to advanceto the pulse window, then
use"SET"keytoenter your desired highandlow
pulserate/heratratelimit.EachpressoftheSET will advance
5bpm.Ifyourheartrateisabove the high pulse limit youprogrammed,
thecomputerwill generate abeepingtowarn you tostop
exercise.Incontrast,if your pulse rateislowerthanyour
desiredlowpulseratelimit,thebuzzerwillalsobeep to
remindyouto continue your exercise.
PROGRAMMINGTIMER
Usethe MODE keytoadvance tothetimer function. Thenuse the SETkeyto adjust todesired time.
EverypushontheSETkeywillincreasethetimebyoneminute.
PROGRAMMINGCALORIES
Usethe MODE key to advanceto the KCALfunction. Thenuse the SETkey to adjustto desired
amount.Everypushonthe key will increase the value by one minute.
PROGRAMMINGDISTANCE
Usethe MODEkey to advanceto theDISTANCE function. Then usethe SETkey to adjust todesired
distance.Everypushon the key willincreasethedistanceby one km.
NOTE: Whenno key hasbeenpressed for 5secondsthe display willreturn to normal.
Thecomputerstarts automatically whenoneofthe keys ispressedormeter get speedindication-is
pedalled.
Innormaldisplay,pleasemakesure the ♥-symbol appears on thedisplaybeforemeasuring your pulse
rate. The ♥-symbol will automaticallydisappear to savepowerwhen nokeyhas been pressedor no
signalhasbeenreceicedfor30secondsormore.By pressing "SET" or "RESET" the.symbol will turn
onagain.

Fig.10
Justermutter
Tension device
Skarvbygel
Justerskruv
10
Fig.9
JointbracketScrew
REPLACEMENT OF
BRAKE BELT
Removethe instrumentcoverassembledwith
twoscrews. Seefig. ?.
Removeleft sidecahincoverbydisassembling
theconnectingplate at the downsideofthe
covers. Removethe screwon the upperside.
Movetheciver backwards andremoveitfrom
thebike.
Adjustthetension device so thatthereis no
tensionleftin the brake belt.Loosenthescrew
underthe joint bracket.See fig. ??.Loosenthe
screwfasteningthebelt in thewattscale.See
fig.??.
Replacethe brake beltand assemble thethe
otherparts in reverseorder according to
above.Notehow it isassembled.The new belt
mustbeassembledin the same way, see fig.
??.
Note:Toobig a playin thebearingof thewatt
scalemaycauseanunevan operation of the
loaddevice.Thenut for the wattscalebearing
boltshouldthenbetightened.See fig.??. Make
surethatitisnottightened too much as itmay
thenoperate ina bad way.
CALIBRATION
Adjustthehandwheelfor the tension
screwsotrhat there is notensionleft
inthebrake belt.
Fastena 4kg weight (our part no.
9000-211) at the joint bracket. See
fig.??.
Whencorrectly set theweight-4 kp
-will beread on thescale forwatts
- 60 RPM. See fig. ??.
Shouldtherebeadeviation,
dismantlethe chain guard.Seefig.
??.
Adjusttothe correct positionby
meansoftheadjustingscrewand
lockingnut.Seefig.??.
