MP10 3D Printer
P/N 34437
User's Manual

2
CONTENTS
SAFETY WARNINGS AND GUIDELINES.......................................................................................................................................3
INTRODUCTION................................................................................................................................................................................................4
FEATURES..............................................................................................................................................................................................................4
CUSTOMER SERVICE....................................................................................................................................................................................5
PACKAGE CONTENTS.................................................................................................................................................................................5
PRODUCT OVERVIEW.................................................................................................................................................................................6
INSTALLATION..................................................................................................................................................................................................8
SETUP........................................................................................................................................................................................................................9
AUTO LEVELING ............................................................................................................................................................................................13
GLOBAL Z OFFSET LIVE LEVEL.........................................................................................................................................................14
WI-FI SETUP.......................................................................................................................................................................................................14
SOFTWARE INSTALLATION AND SETUP..................................................................................................................................15
Installing Cura ...........................................................................................................................................................................................15
Repetier-Host............................................................................................................................................................................................19
TECHNICAL SUPPORT..............................................................................................................................................................................20
REGULATORY COMPLIANCE..............................................................................................................................................................21
Notice for FCC ..........................................................................................................................................................................................21
EU Declaration of Conformity ...................................................................................................................................................22
WEEE Information ................................................................................................................................................................................22
Safety Notice............................................................................................................................................................................................23

3
SAFETY WARNINGS AND GUIDELINES
Be careful not to damage the PC paper on the build plate.
Take care to avoid touching hot parts, including heat blocks, extruder nozzle,
extruded filament, and the heated build plate.
Do not wear gloves when operating or repairing to avoid entanglement.
Keep the printer and all accessories out of reach of children.
Do not remove or disconnect the USB cable when printing from a computer.
Do not pull or twist the black cable at any time.
Do not force or tear anything during unpacking and setup. This may cause damage
to the printer and/or its accessories.
Do not reach inside the printer during operation.
Always allow the printer and extruded filament to cool before reaching inside.
Ensure that the printer is turned off and unplugged from its power source before
making repairs or performing service.
Do not install this device on an unstable surface where it could fall and cause either
personal injury or damage to the device and/or other equipment.
Do not subject the product to extreme force, shock, or fluctuations in temperature
or humidity.
This device is intended for indoor use only.
Do not expose this device to water or moisture of any kind. Do not place drinks or
other containers with moisture on or near the device. If moisture does get in or on
the device, immediately unplug it from the power outlet and allow it to fully dry
before reapplying power.
Do not touch the device, the power cord, or any other connected cables with wet
hands.
Use only in a well-ventilated area. Do not use in close, confined spaces.

4
Prior to operation, check the unit and power cord for physical damage. Do not use if
physical damage has occurred.
Before plugging the unit into a power outlet, ensure that the outlet provides the
same type and level of power required by the device.
Unplug this device from the power source when not in use.
Take care to prevent damage to the power cord. Do not allow it to become
crimped, pinched, walked on, or become tangled with other cords. Ensure that the
power cord does not present a tripping hazard.
Never unplug the unit by pulling on the power cord. Always grasp the connector
head or adapter body.
INTRODUCTION
Thank you for purchasing this 3D printer from Monoprice! This printer features a single
extruder, which is capable of printing in PLA, ABS, and other materials. You can print from a
Windows® or Mac® PC using a USB connection or can print from 3D model files stored on a
memory card, without the need for a PC connection of any kind. This printer is easy to
setup and easy to use following the instructions in this manual.
FEATURES
Single extrusion print head
Can print PLA, ABS, Wood, Copper Fill, Steel Fill, Bronze Fill, and other materials
Open frame design for ease of use and maintenance
Includes a memory card with Cura, Repetier-Host, and a sample 3D model

5
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to ensuring that your ordering,
purchasing, and delivery experience is second to none. If you have any problem with your
order, please give us an opportunity to make it right. You can contact a Monoprice
Customer Service representative through the Live Chat link on our website
www.monoprice.com or via email at [email protected]. Check the website for
support times and links.
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed
below. If anything is missing or damaged, please contact Monoprice Customer Service for a
replacement.
1x 3D printer
1x Filament rack
1x Plastic scraper
1x USB cable
1x Memory card
4x Hex wrench (2mm, 2.5mm, 3mm, 4mm)
5x M5x20 screw
13x M4x6 screw
1x Open-end wrench (8mm)
1x AC power cord
1x User's manual

6
PRODUCT OVERVIEW
1. Extruder
2. LCD touch screen
3. Micro USB and microSD™ ports
4. Power switch
5. AC power connector

7
6. Filament holder
7. Feed mechanism

8
INSTALLATION
1. Use the included 4mm hex wrench and 8x M4x6 screws (4x on each side), to attach
the vertical part of the frame to the horizontal part of the frame.

9
2. Use the included 2.5mm hex wrench and 4x M5x20 screws to secure the vertical
frame to the horizontal frame from the bottom.
3. Use the included 2.5mm hex wrench to loosen the screw marked with the red circle.
Remove the screw rod, then re-tighten the screw.
4. Use the included 3mm hex wrench to loosen the screw on the top side.
5. Insert the screw rod into the hole on top of the printer, then tighten the screw from
step 4.
6. Use the included 2.5mm hex wrench and 2x M4x6 screws to attach the LCD module
to the printer, then insert the plug into the back of the LCD module.
7. Use the included 2.5mm hex wrench and 2x M4x6 screws to attach the filament
holder to the frame.
SETUP
Warning! Take care not to remove or damage the printing surface on the build platform.
This paper is essential to ensure the 3D model properly adheres to the build platform
during printing. If this tape becomes damaged or wears out, replace it with painter's tape,
Kapton® tape, or ordinary masking tape.
Perform the following steps to prepare the printer for use.
1. Put the printer on a flat, stable surface with plenty of ventilation and a nearby AC
power outlet.
2. Ensure that the Power Switch is in the OFF position. Plug the included AC Power
Cord into the AC Power Connector jack on the right side of the printer, then plug
the other end into a nearby AC power outlet. Flip the Power Switch to the ON
position.
3. Insert the included memory card into the slot on the right side of the LCD module.

10
4. Touch the Preheat button on the Main Menu.
5. Touch the Nozzle button, then set the temperature of the nozzle to your target
value, which depends on the type of filament you are using.
6. Touch the Bed button, then the temperature to the target temperature for your
filament type.
7. Touch Start Preheat. The printer will start preheating the nozzle and heated print
bed to the target values. The option on the screen will change to read Stop Preheat
and the Extruder and Platform buttons will read the actual temperatures.
8. While the printer is heating, open your filament. Using a pair of scissors or side
cutters, diagonally snip the end of the filament to make a point, as shown in the
images below. Place the filament reel on the filament rack.
9. Touch the Back button on the Preheat Menu to return to the Main Menu, then
touch the Move button on the Main Menu to enter the Move Menu. Touch the
button on the Z column to raise the extruder above the build platform.

11
10. While squeezing the lever on the Feed
Mechanism, insert the filament and push it into
opening. Keep pushing until you feel resistance as
it hits the extruder. Release the lever on the Feed
Mechanism.
11. Touch the button in the E column on the
Move Menu to feed the filament into the extruder. Continue touching the button
until several centimeters of filament have been extruded.
12. Use the included plastic scraper to clean the extruded filament from the nozzle and
the build platform.
13. Touch the button on the Move Menu to return to the Main Menu.
14. Touch the Print button on the Main Menu. The printer will read the contents of the
memory card and display them on screen. Touch the cat.gcode entry to start
printing the model.

12
15. After the first layer has been printed, touch the Pause or Cancel button to stop
printing.
16. Compare the first layer with the images in the table below to determine whether
the build platform needs to be leveled or not. If it does need adjustment, touch the
Cancel button, then perform the steps in the AUTO LEVELING section.
Wrong
The nozzle is too far from the
platform. This can result in the
extruded material not sticking to the
build platform.
Correct
The nozzle is at the correct height
above the platform.
Wrong
The nozzle is too close to the
platform. This can result in damage to
the nozzle and build platform.

13
AUTO LEVELING
If the gap between the nozzle and the build platform is not correct, use the Auto Level
function to adjust the gap. You will want to perform Auto Leveling before using the printer
for the first time or after it is moved.
Note that the Auto Level function will determine the local offsets for each location on a
5"x5" grid. It will not set the global Z offset for the bed distance. This is set by tuning the
offset during the print or in the menu starting the auto level function. See the GLOBAL Z
OFFSET LIVE LEVEL section below for details.
1. With the printer powered on and the Main Menu displayed, touch the Move button
on the Main Menu, then touch the Tune button on the Move Menu to enter the Set
Offset Menu.
2. Touch the Auto Leveling button. The printer will move the extruder to different
points and measure the distance from the nozzle to the print bed to determine the
proper local offset at each point. Note that this function only works with a metal
print bed or plate.
3. If you want to adjust the global offset, touch the CLOSE or FAR buttons. Note that
the global offset must be less than 0.

14
4. Once the gap is where you want it, touch the button to save the data and exit
the menu.
GLOBAL Z OFFSET LIVE LEVEL
While printing is in progress, you can adjust the global Z offset. To do this, touch the Tune
button on the print screen, then touch the CLOSE button to decrease the gap between the
nozzle and the print bed or the FAR button to increase it.
WI-FI SETUP
You can connect the printer wirelessly to a 2.4GHz Wi-Fi® network to print models from
your Android™ phone or tablet. Perform the following steps to setup the Wi-Fi connection
for your device.
1. Download the free MP 3D Printer WiFi Connect app from the Google Play Store.
2. Disconnect the USB cable from the printer. You cannot use USB and Wi-Fi
connections at the same time.
3. Power on the printer.
4. Start the MP 3D Printer WiFi Connect app.
5. The SSID of your Wi-Fi network should be displayed on screen. If a different SSID is
displayed, open your device's Wi-Fi settings and select the appropriate Wi-Fi
network.
6. Enter your wireless password.

15
7. Press and hold the Move button on the Main Menu for 3 seconds. Release the
button when Smart config started is displayed on screen.
8. Press the Connect to WiFi button on your mobile device. The connection will be
completed within 10 ~ 60 seconds, the message MP10 is now connected to Wi-Fi
will be displayed on your device's screen, and the IP address will be displayed at the
top of the printer's LCD screen.
Note that you may have difficulty connecting to the Wi-Fi® network if you have a 2.4GHz
and 5GHz network with the same SSID. Try changing the SSID of the 5GHz network if this
occurs. For best results, move the printer to a location closer to the Wi-Fi router or access
point.
SOFTWARE INSTALLATION AND SETUP
As you've seen, you can print a model directly from a gcode file on a microSD™card and
this is the preferred method, as it does not require a continuous connection to your
computer. You can download gcode files to the microSD card and print them without
having to build any model files.
However, you can create your own gcode files using an open source program, such as Cura
or Repetier-Host, which are pre-installed on the microSD card that comes with the printer.
These programs use 3D models (typically .STL or .OBJ files) and, using machine specific
information, generate a gcode file with detailed instructions for the printer to create the
selected model. We recommend you start with Cura, since it includes a Slicing Engine.
Installing Cura
1. Use a card reader to read the contents on the included microSD™card. Locate and
double-click the Cura_3.3.1.exe file to start the setup program.

16
2. Click the Next button on the Welcome screen, then click the I Agree button on the
License Agreement screen.
3. Use the file browser to select an install directory or accept the default directory
(recommended). Click the Next button to continue.

17
4. Ensure that all boxes are checked, then click Install to continue.
5. Click Finish to complete the installation and launch the Cura program.
6. Click Printer > Printer > Add Printer...

18
7. Click the Other option, then choose the Monoprice MP10 entry. Click the Add
Printer button to continue.
8. The Machine Settings screen will be displayed. Click the Close button to finish the
Cura installation.

19
Repetier-Host
You can also install Repetier-Host from the file on the included microSD™ card. The
screenshots below show the proper Repetier-Host settings to use for this printer.

20
TECHNICAL SUPPORT
Monoprice is pleased to provide free, live, online technical support to assist you with any
questions you may have about installation, setup, troubleshooting, or product
recommendations. If you ever need assistance with your new product, please come online
to talk to one of our friendly and knowledgeable Tech Support Associates. Technical
support is available through the online chat button on our website www.monoprice.com
or through email by sending a message to [email protected]. Check the website for
support times and links.
