Morris MMT-16224 User manual

MarboThermic Heater
Model: MMT-16224
User Manual

1
Contents
Safety Precautions & Important Safeguards
2-3
Specifications
4
Features
4
Remove Packing
4
Installation precautions
4
Unit Layout
5
Control Panel
6
Installation Kit
6
Installation instruction
7
Operation
7
Cleaning
8
Storage
8
Check the Heater before Repairing
8
Warning
9
Recycling
9
KEEP THESE INSTRUCTIONS

2
Safety precautions & Important Safeguards:
Please read all the instructions before using this heater.
 Don’t do any modification to the Heater.
 Children less than 3 years should be kept away unless
continuously supervised.
 Children aged from 3 years and less than 8 years shall only switch
on/off the appliance provided that it has been placed or installed in
its intended normal operating position and they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children aged from 3
years and less than 8 years shall not plug in, regulate and clean
the appliance or perform user maintenance.
 This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
 CAUTION: Some parts of this product can become very hot and
cause burns. Particular attention has to be given where children
and vulnerable people are present.
 Children should be supervised to ensure that they do not play with
the appliance.
 Do not use this heater in the immediate surroundings of a bath, a
shower or a swimming pool.
 WARNING: In order to avoid overheating, do not cover the
heater.
 The Heater must not be located immediate below a socket outlet.
 This Heater has hot and arcing or sparking parts inside. Please do
not place combustible or chemical items near the Heater.
 This Heater is not equipped with a device to control the room
temperature. Do not use this heater in small rooms, when they are
occupied by persons not capable of leaving the room on their own,
unless constant supervision is provided
 To avoid over-heating since a fire risk exists, do not cover the
Heater.

3
 To avoid burns, do not touch the hot surfaces of the heater when it
is in use.
 Do not use the Heater in outdoors.
 Do not insert or allow foreign objects to enter any ventilation or
exhaust opening as this may cause an electric shock or fire, or
damage the Heater.
 Always unplug the Heater when not in use. To disconnect the
Heater, remove the plug from the electrical outlet.
 Connect the Heater to properly grounded outlets only.
 Never use a damaged cord or plug. If the supply cord is damaged,
must be replaced by the manufacturer, an affiliate agent or a
qualified person in order to avoid hazard.
 Using an extension cord is not recommended as it may overheat
and cause a risk of fire. However, if an extension cord has to be
used, the conductor wire inside the cord must be at least 1.5mm²
and rate not less than 10Amp.
 Do not run cord under carpet and do not cover cord with throw rugs,
runners, or the like. Place the cord away from traffic area and
where it will not be tripped over.
 Use this Heater only as described in this manual. Any other use
not recommended by the manufacturer may cause fire, electric
shock, or injury to persons.
 If you are away for several hours, consider reducing the
temperature setting.
 If you have several appliances in one room, let them operate
simultaneously. In doing so you will obtain a more uniform
temperature without increasing your electricity consumption
 CAUTION: In order to avoid hazard due to inadvertent resetting of
the thermal cut-out, this appliance must not be supplied through an
external switching device, such as a timer, or connected to a circuit
that is regularly switched on and off by the utility.
 Only qualified service representative should perform repairing and
maintenance services.
 CAUTION: Must have a safety ground.

4
Specifications:
Voltage Rating
230V AC, 50Hz
Power Consumption (W)
1300W
Unit Size (cm)
40(L) × 66.5(H) x 25.5(W)
Unit Weight (kg)
10 kg
Features:
 Power switch with Indicator Light
 Adjustable Thermostat Control
 Built-in Safety thermal cut-off
 Built-in Tip-over switch
 Anti-Frost Function
 Cool Touch Handle
 Quiet
 No oil-leakage
 No dehumidifying
 Natural
 30% more infrared
Remove Packaging:
1. Take out the Heater from the gift box.
2. Remove the polyfoams and polybags.
3. Save the packaging to store the Heater while it is not being used.
Keep the original box! It can be used for storage in summer season.
Installation Precautions:
 Switch Off the power before installing Plug to electrical outlet.
 Keep combustible materials, such as drapery and other furnishings
at least 1 meter from the front and side of the heater.

5
Unit Layout:
Front
Rear
Side
Feet
Control Box
Handle
Front Net
Air Outlet

6
Control Panel
Installation Kit:
Carefully unpack the components and check that no damage occurred
during transportation. If any damage is apparent or any component is
missing, please contact the dealer immediately.
1.
Feet
2pcs
2.
Screw
4pcs
Temperature Control
Knob
Power Switch
Anti-Frost Position
Max temperature Position
Min temperature Position
1
2
Heating Indicator Light
Comfortable Zone

7
Installation instruction:
Fix two feet on the bottom of the heater by screws.
Operation:
Please read all the instructions before using this heater.
1. Ensure that the Temperature Control Knob is at “Max” position.
Also, make sure the power switch is at “OFF” position. Plug the
power cord into a suitable electrical outlet.
2. Switch “ON” the heater.
3. Then adjust the temperature control knob to set the room
temperature. According to the personal needs, you can turn the
temperature control knob in a clock-wise or anti-clockwise direction
to increase or decrease the room temperature.
4. When the room temperature reaches the pre-set temperature the
power will cut out and the heating indicators light will be “OFF” at
the same time. The power will resume when the room temperature
drops at least 3ºC lower than the pre-set temperature.
5. “” Anti-Frost mode: It will keep the surrounding temperature
above freezing point to avoid the pipe breakage by ice.

8
Cleaning:
1. Please switch off the heater, unplug the power cord and allow the
heater to cool down before cleaning.
2. Do not immerse the power cord and plug or the heater into water
or other liquid. Do not pour water or other liquid over the heater.
3. Use a vacuum cleaner to remove dust and lint from the metal grid
of the heater.
4. Wipe the heater with a dry cloth to remove dust and a damp cloth
(not wet) to clean the stains.
5. Do not use detergents, abrasive cleaning powder or polish of any
kind on the body of the heater, as these can damage the finish.
Storage:
Store the heater in a cool dry place when not in use. To prevent dust
and dirt getting into the heater, use the original box to repack the unit.
Check the heater before repairing:
Heater not Warm or not Operating:
1. Check if the electrical supply in the house or the main fuse is
working or not?
2. Check if the power cord is plugged into an electrical outlet or not?
3. Check if the heater is switched on or not?
4. Check if the room temperature is under thermostat setting
temperature or not?
5. Check if any objects are covering the unit or not?
If the heater is still not operation after these checking, please contact
the manufacturer service agent. All repairs must be referred to
authorized personnel from authorized retailer.
Important: Any tampering with the appliance will invalidate the
warranty. Repairs carried out improperly and by unqualified persons
may have serious consequences for the user.

9
WARNING:
 Please do not attempt to repair the heater, as it is potentially
hazardous and will void the heater’s warranty. Only authorized
personnel may repair the heater.
 Plastic bags are not toys. Keep them away from infants and
children as they represent risk of suffocation and other hazards.
NOTICE ABOUT RECYCLING
Your product is designed and manufactured with high quality materials and
components which can be recycled and reused.
This symbol means that electrical and electronic equipment, at their
end-of-life,
should be disposed of separately from your household waste. Please
dispose of this equipment at your local community waste collection/
recycling centre.
In the European Union there are separate collection systems for used electrical and
electronic products.
Please help us to conserve the environment we live in!
DECLARATION OF CONFORMITY
Herewith, Amiridis-Savvidis S.A. states that this product, complies with the requirements of
below directives:
EMC-Directive: 14 / 30 / EU
Low Voltage Directive: 14/ 35 / EU
CE Marking: 93 / 68 / EEC
RoHS Directive: 11 / 65 / EU
The detailed declaration of conformity can be found at www.morris.gr
Exclusive importer in Greece:
Amiridis – Savvidis S.A.
87A, 17th Noemvriou str, P.C. 55534
Thessaloniki – Greece
T: [phone] | F: [phone]
www.amiridis-savvidis.gr
