Operator’s Manual
for Morse Double Can Tipper
Model 2-15
Manufactured 10/2006 to _______
Receiving Procedures
Every Morse product is inspected prior to shipping. However,
damage may be incurred during transit.
• Check for visible damage. If you choose to accept damaged
freight, always sign noting the damage on the BILL OF LADING.
• Document the damage and have the truck driver sign. We
recommend keeping a digital camera at your receiving dock for
this purpose.
• Open packages expeditiously to check the condition of the
goods. There is only a 24 hour window to notify the carrier of any
concealed damage.
• IMMEDIATELY REPORT ALL DAMAGE TO THE SHIPPING
COMPANY! Then you may contact Morse for assistance with
your freight claim.
• Morse Manufacturing will not be held responsible for any
damaged freight that is not signed for as damaged.
Delivery to non-business addresses without a loading dock result
in additional freight charges. Residential delivery fees, inside
delivery fees, re-delivery charges, and lift gate services will be
added by the truck line, and are non-negotiable.
Limited 2 Year Warranty
Morse drum handling equipment is guaranteed against defects in
workmanship or materials for TWO YEARS when used properly
within its rated capacity. Warranty does not cover wear from
normal use or damage from accident or abuse. Motors and
other purchased parts carry the warranties of their manufacturers.
For warranty claims, contact your Morse Dealer to obtain a
return authorization number, and for return freight advice. Return
freight must be prepaid.
In all instances, liability is limited to the purchase price paid or to
repairing or replacing the product. Customer assumes liability for
any modications, unauthorized repairs or parts substitution.
Safety Information
While Morse Manufacturing Co. equipment is engineered for safety
and e󰀩ciency, a high degree of responsibility must be placed upon
the machine operator to follow safe practices, based primarily on
common sense, upon which true safety depends.
Failure to follow the safety precautions in this manual can result in
personal injury or property damage. Observe the same precautions
as with similar machinery where carelessness in operating or
maintenance is hazardous to personnel. Carefully read the safety
precautions below and throughout this manual.
CONTENTS
Page
Receiving Procedures. . . . . . . . . . . . . . . . . 1
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Information. . . . . . . . . . . . . . . . . . . . . 1 - 2
Assembly Instructions. . . . . . . . . . . . . . . . . . . . . 3
Parts List and Diagram. . . . . . . . . . . . . . . . . . . . 3

The Specialist In Drum Handling Equipment
Model 2-15
Double Can Tipper
Morse Model 2-15 Double 5-Gallon Can Tipper
Made Oct. 2006 to present
morsedrum.com
Copyright 2019 - Morse Mfg. Co., Inc. Form PL2-15 (1006-____) (Updated 17 Jun, 2019 1:19 PM) 2
Safety Information (continued)
DANGER - Indicates a situation which, if not
avoided, will result in serious injury or death.
This signal word is limited to the most extreme
situations.
WARNING - Indicates a situation which, if not
avoided, could result in serious injury or death.
CAUTION - Indicates a situation which, if not
avoided, can result in damage to the machine.
WARNING - Do Not Modify the Unit - Un-
der no circumstances should any modi-
cations be made to the Morse machinery
without factory authorization. Any modica-
tions may void the warranty. This machine
was designed to perform a specic job and
alterations may result in injury to operator or
machine.
WARNING - No Loose Fitting Cloth-
ing - Wear close-tting clothing and safety
equipment appropriate to the job. Loose
tting clothing may become caught on the
machinery and cause severe personal
injury.
CAUTION - Wear Safety Shoes - Wear
safety shoes with non-slip soles and hard
toe protection.
WARNING: This product can expose
you to chemicals including barium
sulfate, cobalt, titanium dioxide, and
2-methylimidazole, which are known to
the State of California to cause cancer,
and bisphenol-A, which is known to
the State of California to cause birth
defects or other reproductive harm.
For more information go to
www.P65Warnings.ca.gov

The Specialist In Drum Handling Equipment
Model 2-15
Double 5-Gallon Can Tipper
Morse Model 2-15 Double 5-Gallon Can Tipper
Made Oct. 2006 to present
morsedrum.com
Copyright 2019 - Morse Mfg. Co., Inc. Form PL2-15 (1006-____) (Updated 17 Jun, 2019 1:19 PM) 3
ITEM QTY. PART # DESCRIPTION
1 2 1687-P CAN HOLDER ASM, 15
2 4 4234-P SHCS, 3/8-24 X 7/8
3 2 1686-P SCREW, 5/16-18 X 3/4 THUMB
4 2 4283-P CATCH ASM, 15 W/ SCREW
5 8 1518-P NUT, 1/4-20 NYLON LOCK
6 4 1517-P SCREW, 1/4-20 X 5/8 PAN HEAD
7 1 4323R-P SIDE BRACE, RIGHT, 2-15
8 4 1714-P HHCS, 1/4-20 X 3/4 GR2
9 1 4277-P BASE ASM, 15 SERIES
10 1 4281-P CENTER BRACE, 15
11 1 4323L-P SIDE BRACE, LEFT, 2-15
Assembly Instructions
1. Please unpack and identify the following parts:
2 - Can holders with catches
1 - Base
1 - Center brace
2 - Side braces (left and right)
4 - 1/4-20 x 5/8 Panhead screws
8 - 1/4-20 Two way lock nuts
4 - 1/4-20 x 3/4 Hex head cap screws
2. Spread base (item 9) open, hinging at riveted joints.
3. Align side braces (items 7 and 11) and center brace (item 10)
with center hole in base (item 9). Note: Ensure left and right side
braces are on correct sides with holes for lower can holder pivot
points 17-1/2” high.
4. Fasten braces to base using two 1/4-20 x 3/4 hex head cap
screws (item 8) and 1/4-20 lock nuts (item 5).
5. Attach center brace (item 10) to rear uprights of base (item 9)
with 1/4-20 x 5/8 panhead screws (item 6) and 1/4-20 lock nuts
(item 5).
6. Place bottom can holder between side braces as shown. Insert
1/4-20 x 3/4 hex head cap screws (item 8) from inside of loop
through holes in can holder ring, side braces and rear brace up-
rights. Thread 1/4-20 lock nuts (item 5) onto screws but do not
tighten completely. Nuts should be just loose enough to allow
can holder to pivot freely.
7. Place top can holder between side braces. Fasten with 1/4-20 x
5/8 panhead screws (item 6) and 1/4-20 lock nuts (item 5) allow-
ing can holder to pivot freely as on step 6.
8. Place a few drops of oil on pivot screws before using, and peri-
odically, to minimize wear.
