Motorola i2000 User manual

Motorola
TM
iDEN
®
Digital Multi-Service
i 2000 User’s Guide
Draft Two
5/6/99 FCC ID: AZ489FT5794

i
Contents
CONTENTS
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Setting Up Your i 2000 for Use . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Features of Your i 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Inserting the SIM Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Charging and Attaching the Battery . . . . . . . . . . . . . . . . . . . . . . . .5
Turning On Your i 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
SIM Card PIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Entering the PIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Unblocking the PIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Changing the PIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Disabling the PIN Requirement . . . . . . . . . . . . . . . . . . . . . . .8
Enabling the PIN Requirement . . . . . . . . . . . . . . . . . . . . . . . .9
Display Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
About Modes and Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
About Modes and Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Setting the Time and Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Changing the Display Language . . . . . . . . . . . . . . . . . . . . . . . . .13
Making Phone Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
International Phone Calls . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Inserting Pauses into Phone Numbers . . . . . . . . . . . . . . . . . .15
Using Other Dialing Methods . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Emergency Dial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Automatic Redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Last Number Redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Turbo Dial® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Hands-Free Speakerphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Receiving a Phone Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Missed Call Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
What Is My Phone Number? . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
VibraCall™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Selecting VibraCall for All Incoming Calls and Messages .20
Selecting VibraCall for Individual Services . . . . . . . . . . . . .20
Setting the Ringer Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Selecting a Ring Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Call Forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Unconditional Call Forwarding . . . . . . . . . . . . . . . . . . . . . .22
Conditional Call Forwarding . . . . . . . . . . . . . . . . . . . . . . . .23
Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Call Hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
3-Way Calling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

ii
i2000 User’s Guide
Call Barring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Barring Incoming Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Barring Outgoing Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Viewing Call Barring Status . . . . . . . . . . . . . . . . . . . . . . . . .26
Changing Your Call Barring Passcode . . . . . . . . . . . . . . . . .27
Alternate Phone Line (iDEN Only) . . . . . . . . . . . . . . . . . . . . . . .28
Setting the Active Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Receiving a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Receiving a Call on Your Alternate Line . . . . . . . . . . . . . . .29
Phone Only Mode (iDEN Only) . . . . . . . . . . . . . . . . . . . . . . . . . .29
Traveling between Systems . . . . . . . . . . . . . . . . . . . . . . 31
Searching for a Network . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Storing Your Preferred List of Networks . . . . . . . . . . . . . . .32
Creating, Editing, and Using Stored Lists . . . . . . . . . . . . . . . . . .33
Combined Phone Number and Private ID List . . . . . . . . . . .33
Last 10 Calls Received and Sent Lists . . . . . . . . . . . . . . . . .36
Quickstore of Phone Numbers . . . . . . . . . . . . . . . . . . . . . . .37
Making Private Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Receiving a Private Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Private/Group Mode Speaker . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Call Alert™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Sending a Call Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Receiving a Call Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Call Alert Queuing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Clearing or Queueing a Call Alert . . . . . . . . . . . . . . . . . . . .41
Responding to a Queued Call Alert . . . . . . . . . . . . . . . . . . .41
Quickstore of Private IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Storing Your Private ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Making Group Calls (Iden only) . . . . . . . . . . . . . . . . . 43
Receiving a Group Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Adding and Storing a Talkgroup . . . . . . . . . . . . . . . . . . . . . . . . .44
Area Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Private/Group Mode Speaker . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Using Mail Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Voice Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Message Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Saving and Erasing Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Auto Call Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Mail Memory Full . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

iii
Contents
Setting Programming Menus . . . . . . . . . . . . . . . . . . . . 48
About Status Messages . . . . . . . . . . . . . . . . . . . . . . . . . 53
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Charging the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Battery Operating Instructions . . . . . . . . . . . . . . . . . . . . . . .55
Travel Charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Using the Travel Charger . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Travel Charger Operating Specifications . . . . . . . . . . . . . . .56
Vehicular Battery Charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Using the Vehicular Battery Charger . . . . . . . . . . . . . . . . . .57
Removing the Vehicular Battery Charger . . . . . . . . . . . . . . .57
Vehicular Battery Charger Operating Specifications . . . . . .57
Desktop Dual-Pocket Charger . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Charging a Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Audio Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Using the Audio Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Attaching/Detaching the Earpiece Microphone . . . . . . . . . .59
Removing the Audio Adapter . . . . . . . . . . . . . . . . . . . . . . .59
FortheSafeandEfficientOperationofYourRadio,ObservetheseGuidelines:
60
Exposure To Radio Frequency Energy . . . . . . . . . . . . . . . . . . . .60
Safety and General Information . . . . . . . . . . . . . . . . . . 60
Interference to Medical and Personal Electronic Devices . . . . . .61
Pacemakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Hearing Aids . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Other Medical Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Interference to Other Electronic Devices . . . . . . . . . . . . . . .62
Safety and General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Use While Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
OPERATIONAL
WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Potentially Explosive Atmospheres . . . . . . . . . . . . . . . . . . .63
Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Blasting Caps and Areas . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
For Vehicles Equipped with an Air Bag . . . . . . . . . . . . . . . .63
OPERATIONAL CAUTIONS . . . . . . . . . . . . . . . . . . . 64

iv
i2000 User’s Guide
Damaged Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Cleaning Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Antenna Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Accessory Safety Information . . . . . . . . . . . . . . . . . . . . 65
Owner’s Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Private Number Directory . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Talkgroup Directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68

v
i2000 User’s Guide
Patent and Trademark Information
This product is protected under one or more of the following patents:
4817157, 4896361, 4857928, 5041793, 5060294, 5066923, 5134718, 5140156,
5239963, 5257411, 5287387, 5265219, 5289504, 5316168, 5317247, 5338396,
5389927, 5406588, 5424921, 5457376, 5460906, 5551063, 5557079, 5596487,
5615412, 5638403, 5559468, 5469465, 5170413, 5140615, 5519730, 5241544,
5584059, 5574992, 5396656, 5487091, 5533004, 5299199, 5343499, 5369501,
5509031, 5515379, 5528723, 5598417, 5066923, 5241650, 5278833, 5359696,
5548631, 5410632, 5440582, 5457735, 5457818, 5471670, 5477550, 5481537,
5566181, 5229767, 5208804, 5295140, 5381449, 5440590, 5467398, 5490230,
5620242, 5623523, 5655913, 5715240, 5771440, 5854578, 5675281
Additional patents are pending.
, Motorola, iDEN, Turbo Dial, VibraCall, Call Alert, and Message Mail are
trademarks or registered trademarks of Motorola, Inc.
®Reg. U.S. Pat. & Tm. Off.
All other trademarks mentioned in this manual are trademarks of their respective
companies.
© Copyright 1999, Motorola, Inc. All rights reserved.
Important!
Be sure to read “Safety and General Information” on page 60
before using your i1000 plus .

1
Getting Started
GETTING STARTED
ongratulations on purchasing your Motorola iDEN i 2000 multi-
service, digital, portable global phone. The use of two state-of-
the-art technologies, iDEN and GSM (Global System for Mobile
communications), provides worldwide services to keep you in constant
touch with your business and personal contacts wherever you travel.
A removable Subscriber Identity Module (SIM) card holds all your
personal information, including secure Personal Identification Numbers
(PINs), names, and phone numbers. Just as you protect your credit and
bank cards with PINs, you can safeguard your SIM card with a PIN.
Exciting new features include a vibration-only key, call barring, and a
missed-call indicator to help provide efficient operation of your i 2000.
And, new ease-of-dialing features, such as Turbo Dial and the Last Ten
Received and Sent lists, as well as stored names and numbers, help you
to quickly make and return phone calls.
Your i 2000 offers:
•
Phone Mode - for cellular phone operation. See page 15.
• Private Mode - for two-way radio use to talk with one person in
your iDEN service area. See page 39.
• Group Mode - for two-way radio use to talk with several people in
your iDEN service area. See page 43.
• Messaging Services - for message and voice mail. See page 45.
Setting Up Your i 2000 for Use
Before you can use your new i 2000, you’ll need to:
1. Insert the SIM card—see page 4.
2. Attach the battery—see page 5.
3. Turn on your i 2000—see page 6.
4. Optional: Enter a PIN for your SIM card—see page 7.
NOTE
• Some features of your i 2000 are available only in the
iDEN service area, and are indicated as such in this
guide.
• This guide describes the features of the
i 2000 as
they were set up by Motorola. However, your carrier
or your organization may have changed or added
features.For morinformation, check with your carrier
or your organization.
C

2
i2000 UserÕs Guide
Features ofYour i 2000
NOTE
Before you use your i 2000 for the first time,
remove the plastic lens protector from the
display.
1. Antenna
12. Option Keys
8. On/Off Key
16. Speaker Key
4. Push-To-Talk
(PTT) Button
3. Volume
Control
Buttons
15. Alphanumeric
Keypad
6. Mode Key
7. LED
14. Menu Key
2. Earpiece
11. Alphanumeric
Display
5. Scroll Key
13. Send/End Key
10. Microphone
17. Accessory
Connector
9. Vibe-all Key

3
Getting Started
1. Antenna Extend for optimal signal.
2. Earpiece Listen to calls when the speakerphone is
off.
3. VolumeControl
Buttons Press to adjust volume levels in Phone, Private, and Group modes. In mail menus,
press to scroll forward and backward.
4. Push-To-Talk
(PTT) Button Transmit a Private or Group Call, or a Call Alert. Press and hold to talk; release to
listen.
(iDEN use only)
5. Scroll Key Press the left side to scroll backward or
the right side to scroll forward through
menu options and lists.When entering
text, press to erase text or add a space.
6. Mode Key Press to change modes.
(iDEN use only)
7. LED (Light
EmittingDiode) Check the phone’s status. See Table 1 on page 6 for more information.
8. On/Off Button Press and hold to turn your
i 2000 on or off.
9. Vibe-All Key Press to silence or turn on the ringer tone.
1 0 . Microphone Use to speak during calls.
11. Alphanumeric
Display View up to four lines (up to 12 characters per line) or six lines (up to 16 characters
per line) on the display.
12. Option Keys Press the right or left option key to select
the menu option that appears directly
above the key.
13. Send/End Key Press to answer an incoming Phone call.
After entering a phone number, press to
dial the call or to redial the entered phone
number. Press to end Phone calls.
14. Menu Key Press to scroll through menu options.
15. Alphanumeric
Keypad Enter telephone numbers, Private call IDs, and alphanumeric characters.
16. Speaker Key Press to switch between the earpiece and
speaker during Private and Group calls.
(iDEN use only)
17. Accessory
Connector Use to connect accessories or the battery charger.

4
i2000 UserÕs Guide
Inserting the SIM Card
The SIM card contains all your stored names, numbers, and PINs after
you enter them in your i 2000.You can make a phone call only when the
SIM card is properly placed in the phone.
Important! Insert and remove your SIM card with care so that you do
not lose it.
To insert the SIM card:
1. If your i 2000 is on, press and hold the On/Off button until
you see the message “Powering Off”.
2. If the battery is attached,
remove it. For information,
see “Detaching the Battery”
on page 5.
3. Turn the phone over so that
the antenna is at the upper
left corner.
4. Slide the latch to the left
position and open the SIM
card holder.
5. If you have a full-size SIM
card, gently punch out the
mini SIM card.
6. Position the cut corner of the
SIM card as illustrated and
slide the card into the holder.
7. Close the card holder and
slide the latch to the right.
8. Now, you can attach the
battery. See “Attaching the
Battery” on page 5.
NOTE
Depending on the network that you are on, you
may be able to make an emergency call without
a SIM card.
Latch
Latch
SIM card
holder
SIM
card
