Motorola Moto Q Moto Q Cellular Telephone and PDA User manual

1.
2.
Getting Started
Battery Installation
Battery life depends on the network, signal
strength, display usage, accumulated data
service usage, and accessories used.
1. 2.
3. a.
b. 4.
3. 4.

Getting Started
Battery Charging
• To charge the phone, connect
the phone’s power supply
to the phone’s mini-USB port
and plug into a wall outlet.
• New batteries are not
fully charged
• Battery life depends on the
network, signal strength,
temperature, features, and
accessories.
The phone will show Charge Complete when finished
The phone can charge via a mini USB cable from
the phone to the computer USB port. However,
charge times vary for each computer manufacture.
Please contact the computer manufacture for the
USB charge rate.
NOTE: If battery has been completely drained, it
can not charge via the USB cable plugged into the
computer.
Memory Card
To Install Memory Card
• Open memory slot cover. Place finger nail on
bottom ridge of infrared port and lift rubber cover
from the memory slot.
• Insert memory card into exposed memory slot.
• Place memory card cover back in place and push
to close.
NOTE: If you install the memory card when the
phone is turned on, you might have to turn the
phone off and on again before you try to use the
card. Do not remove the memory card while the
phone is using or writing files on it.

Navigate
Right Soft key
Center Key -
Selects menu
items
Left Soft Key
Phone
Make and
Answer Calls
(send key)
Turn on and
off and End
Calls
Back Key
Home Key
Alt Key
Message Key Space Key
Microphone
Caps Key
Enter Key
Camera Key
Voice Key
Undo/Back
Key
Thumb
Wheel

Opening Programs
• Press Start to access the list of programs the
phone has to offer
Locking Phone
• Press and hold the Home key > Device lock
• Enter and confirm a password
• Press Done
Only numbers can be stored as
a password
Locking Keypad
• Press and hold the Home key > Key lock
Thumb Wheel
• Use the thumb wheel to scroll through menu
items and lists.
• Press the thumb wheel to select the
highlighted items in a list or menu
Turning Phone On
• Press and hold the Power Key
Ofor 3-4 seconds to turn
phone on
NOTE: Allow 40-50 seconds before the Home
Screen appears.
Turning Power Off
• Press and hold the End key for 3-4 seconds to
turn phone off
Making a Call
• From the home screen, enter a phone number
and press Nto make a call
Answering a Call
• Press Nto answer a call
• Press Oto end the call
Setting Date and Time
• Press
Start > Settings > Clock and Alarm >
Date and Time
Basics
TIP

Changing between Uppercase, Lowercase,
and Caps Lock
• The phone has a Qwerty keypad similar to a
computer
• Press the Caps key to change between
uppercase, lower case, and caps lock within a
text input mode
Hands Free Speaker
• During a call, press the voice key to turn
the speakerphone on.
Adding a Phonebook Entry
Press
Start > Contacts > New
• Enter First Name and press Navigation key down
• Enter Last Name and press Navigation key down
• Enter Work, Mobile, Home, and E-mail
information. Also, you can assign Ringer and
Picture Caller ID to contact
Basics
Editing a Phonebook Entry
Press Start > Contacts > Contact Name >
Menu > Edit
Changing a RingerTone
Press
Start > Settings > Sounds
• On Ring tone, press Navigation key sleft or
right to hear ringers
• Press Done to save the sound selected
Adjust Ringer Volume When Phone Rings
• From the
Home screen > Profile > Menu
> Edit
• Scroll down to Ring volume and adjust by
using the right/left keys

Synchronization
Two main ways to synchronize the Q phone.
It can by synchronized Over the Air (OTA), or
via a PC with a cable connection.
Synchronization the phone via OTA
NOTE: You can synchronize your Motorola Q
with your company’s Microsoft Exchange Server.
Contact your system administrator for the required
e-mail set-up information, or see the Motorola Q
Support site. www.motorola.com/support/Q/
Once you have verified the correct settings
with the IT Department. You can Synchronize
the phone either Over the Air (OTA) or with a
cable connection.
• Press
Start > ActiveSync
®
> Sync
NOTE: If you are out of network coverage, and the
Moto Q tries to synchronize three times according
to the schedule it is on, and it can not find a network,
the synchronization settings automatically will
revert to manual synchronization.
Synchronization
Changing a Wallpaper
Set a photo, picture, or animation as a wallpaper
(background) image
Press
Start > Settings > Home Screen >
Background image
• On Background image - press Navigation key
sleft or right to select image
• Press Done when finished
Personalization

Synchronization
To set the synchronization schedule back to the
desired frequency, you need to change this under
‘Schedule’ in ActiveSync
For additional information on troubleshooting for
Activesync, please go to www.motorola.com/support/q
Synch with a Computer
Installing and Setting up ActiveSync
®
To synchronize information on the phone with a
PC, you must install Microsoft ActiveSync®4.1
or above software on the computer.
• If you do not have a CD-ROM, download the
latest ActiveSync®software from the
Microsoft Window Mobile website:
http://microsoft.com/windowsmobile
1. Install ActiveSync ®on the PC
2. After setup is complete, connect the phone
to the PC. The Synch Setup Wizard
automatically starts.
3. Follow the on screen instruction to complete
the wizard
• When finished, ActiveSync ®starts to
synchronize automatically with the phone.
Once synchronization completes, disconnect
the phone from the computer.
Synchronization the phone and PC via a
cable connection
• Once ActiveSync®is installed on the PC,
connect the phone to the computer and sync.
• Turn the phone on
• Connect the phone to the PC using a USB
cable
• Open the ActiveSync®icon on the PC
OTA Synchronization Troubleshooting
If you are not receiving e-mails, you will need
to verify e-mail set-up, wireless network,
and/or e-mail platform settings. See the
Motorola Q support site for more information.
www.motorola.com/support/Q/

• Select Attempt to obtain e-mail settings from
the Internet and select Next
NOTE: If the account is sets up successfully,
you will be prompted to send and receive
e-mail. If not, you must click Next and see
the next section.
NOTE: For more information about e-mail
setup, visit www.motorola.com/support/Q/
Setting up Hotmail
Follow the next steps if you use the Hotmail or
MSN e-mail service.
Press
Start > Pocket MSN
• Select MSN Hotmail
• In E-mail address, enter the e-mail address
for the account
• In Password, enter the password for the
account
• Select
Next > Menu > Send and Receive
Setting Up E-mail
• There are a few ways to set up e-mail to
the phone
Consumer E-mail (Hotmail, Yahoo, etc)
Corporate E-mail
Carrier Hosted E-mail
Consumer E-mail
Automatic E-mail Setup
• If you have Hotmail or Pocket MSN account
see Setting up Hotmail
Some e-mail providers allow for automatic
e-mail set up.
Press
Start > Messaging > Outlook E-mail
Select Menu > Options > New Account
• In Your name, enter the display name for
e-mail messages
• In E-mail address, enter the e-mail address
for this account
Email

From the Home screen, press Start >
Messaging > Outlook E-mail > [e-mail account]
To return to the message list, press the
Back key <
Corporate E-mail (make title in Italic)
You can set up e-mail with your company’s
Microsoft Exchange Server. Contact your system
administrator for the required e-mail set-up
information, or see the Motorola Q support site.
www.motorola.com/support/Q
Carrier Hosted E-mail
Please contact your operator, or access their
website in order to get information about their
hosted email solution, and it’s compatibility with
Windows Mobile(add trademark symbol -r) 5.0
enabled devices.
TIP
Manual e-mail accounts settings
If you tried to automatically set up the account
and were prompted for detailed e-mail settings,
call your e-mail (internet) service provider for
information like: Domain, Server type, (POP3
or IMAP4), Account name, Incoming mail
server, Secure Sockets Layer, connections
requirements, and Outgoing mail server.
Press
Start > Messaging > Outlook E-mail
Select Menu > Options > New Account
• In Your name, enter your display name for
e-mail messages
• In E-mail address, enter the e-mail address
for the account
• Select Next
• Enter the information from the e-mail service
provider > Finish
Email

Connect with Bluetooth®
Headset
• The headset must be charged for two hours
prior to starting
• The headset must be paired with the phone
before it can be used. Please see the
Bluetooth Pairing Instructions that came with
the headset
• Bluetooth must be turned On in the phone
Please See Following Steps
Turning Bluetooth Power On
Press Start > Bluetooth > Bluetooth Manager
> Settings > Status > Bluetooth On
Receiving and Reading Messages
When a message is received, the phone plays
an alert and displays New Message with a
message indicator such as R.
To Read E-mail
To open the next message in the list form
within an open message, press the Navigation
key sto the right; to open the previous
message in the list, press the Navigation key
sto the left.
Create and Send E-mail
Press
Start > Messaging > Outlook > E-mail >
E-mail Account > New
• In To, Cc, and/or Bcc, enter e-mail address or
addresses. Insert a semicolon (;) between
multiple addresses
• Enter a subject in the Subject field
• Use the keypad to compose a message
• Press Send
Email

Messaging
Sending a Message
• Press
Start > Messaging > Text Message > New
• Enter the phone number and press the down
arrow on the Navigation key s
•
Type in message > Send
Taking and Sending a Picture
• Press the Camera key e
• Point the camera lens at photo subject
• Press the Camera key eto take photo
• The picture is automatically saved and
displays in view finder
• Press Menu to see the picture options
• Select Delete to delete picture
• Select Send to send photo in a Message,
Outlook E-mail, or Multimedia Message
Pair with Headset
Before trying to pair the phone with a Bluetooth
headset, make sure the phone’s Bluetooth power
is on and the Bluetooth headset is on and in
pairing/bonding mode. Please refer to the instruc-
tions that was included with the Bluetooth headset
for information about pairing or bonding mode.
Press
Start > Bluetooth > Bluetooth Manager >
Hands-free
• The phone searches for the device
• Select the device in which to pair the phone
• When prompted press the Yes or OK key to
pair with the device
• If necessary, enter the device pass key (0000)
> Done
When successfully paired, the Bluetooth
indicator shows in display
NOTE: More then one Bluetooth headset can
be paired with the phone. However, only one
headset can have an active connection to the
phone at any time.
Connect with Bluetooth®

Recording Videos
• Press
the Camera key e > Menu > Video
• Press the Camera key eor the center
select key sto begin recording a video
• Press Stop to end recording
• Or press Pause to pause recording and
Resume to continue
To View Stored Videos
NOTE: Videos are automatically stored in
the phone. To view: Press Start > Pictures
and Videos Select the video to view and
press Play
Messaging Media Player
Media®Player
Use Windows Media®Player 10.0 Mobile for
Smartphone to play digital audio and video files
that can be stored on the phone
Press
Start > Windows Media
• To play or pause a music or video file, press
Enter
• To skip to the previous or next file, press the
Navigation key sleft or right
• To increase or decrease the volume, press
the Navigation key sup or down

Media Player
Download and copy Media files
You can copy or download media files from the
computer or internet onto the phone
Copy files from the computer
NOTE: Activesync must be installed on the
computer
Connect the phone to the PC
• On the PC, copy the files you want to transfer
to the phone
• In ActiveSync on the PC, click Explore and
double-click My Windows Mobile device
• Double-click Application Data
• Double-click Home, and paste that image into
the folder
• Resynch the phone and computer and then
view the picture or video from Start >
Pictures & Videos or File Manager
Download files
To download files from the Internet to the
phone
• From the Home screen, press
Start >
Internet Explorer
Open a web page
• Highlight the files, press the Select key >
Store
• To view the picture or video from Start >
Pictures & Videos or File Manager

Travel Charger
Vehicle Power Adapter
miniSD™Memory Card
Carrying Case
One Touch Stereo
Headset
RAZRWIRE™Bluetooth®
Eyewear
Bluetooth®
Headset H3
Accessories
Bluetooth®Headset
H700
Desktop Charger
Bluetooth®Wireless
Car Kit IHF1000
Bluetooth®Stereo
Headset HT820

No liability for certain damages. Except as prohibited by law, Microsoft shall have no
liability for any indirect, special, consequential or incidental damages arising from or
in connection with the use or performance of the software. This limitation shall apply
even if any remedy fails of its essential purpose. Screen images have been simulated.
*The features detailed here may be a network, subscription and SIM card or service
MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark
Office. All other product or service names are the property of their respective owners.
Windows, Windows Mobile and the Windows Flag logo are trademarks or registered
trademarks of Microsoft Corporation in the United States and/or other countries.
© Motorola, Inc. 2006.
