Motorola MOTORAZR Ve CDMA User manual

motorola.com
MOTORAZR Ve
CDMA
English

1
HELLOMOTO
Introducing your new Motorola MOTO RAZR Ve CDMA wireless phone. Here’s a quick anatomy
lesson.
1
N
Mute Options
Left Soft Key Right Soft Key
Clear/Back Key
Volume Keys
Smart/
Speakerphone
Key
Turn on & off,
hang up, exit
menus.
Scroll up, down,
left, or right.
Make & answer
calls.
Skip back. Skip forward.Play/Pause
Music Player Controls

2
1
N
Message Contacts
MENU
Thu, Oct 23 12:45pm
1
N
OK
1. New Contact
2. Contact List
3. Groups
4. Speed Dials
CONTACTS
B
1
23
4
s
s
Press and hold the
Power Key for
a few seconds or
until th edisplay
lights up to turn on
your phone.
Press the navigation
key left/right to
highlight a menu
option, then down to
highlight a suboption.
Press the center
key to select.
S
P
Press the center
key to open
the Main Menu.
Home Screen Main Menu

3
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
Certain mobile phone features are dependent on the capabilities
and settings of your service provider’s network. Additionally,
certain features may not be activated by your service provider,
and/or the provider's network settings may limit the feature’s
functionality. Always contact your service provider about feature
availability and functionality. All features, functionality, and other
product specifications, as well as the information contained in this
user's guide are based upon the latest available information and
are believed to be accurate at the time of printing. Motorola
reserves the right to change or modify any information or
specifications without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US
Patent & Trademark Office. All other product or service names are
the property of their respective owners. Java and all other
Java-based marks are trademarks or registered trademarks of Sun
Microsystems, Inc. in the U.S. and other countries.
© Motorola, Inc., 2006.
Manual Number:

4
contents
contents
menu map . . . . . . . . . . . . 6
Use and Care . . . . . . . . . . 8
essentials . . . . . . . . . . . . . 9
about this guide. . . . . . . 9
battery . . . . . . . . . . . . . 10
turn it on & off . . . . . . . 12
make a call. . . . . . . . . . 12
answer a call . . . . . . . . 13
store a phone number . 13
call a stored phone
number . . . . . . . . . . . . 13
your phone number . . . 14
main attractions . . . . . . 15
get & play music . . . . . 15
record & play voice
records . . . . . . . . . . . . 19
record & play video
clips . . . . . . . . . . . . . . . 20
send a photo in a
message . . . . . . . . . . . 22
send a multimedia
(PIX/FLIX) message . . . 24
receive a multimedia
(PIX/FLIX) message . . . 26
download pictures . . . . 27
download V CAST
videos . . . . . . . . . . . . . 28
Bluetooth wireless . . . 28
memory card . . . . . . . . 33
cable connections . . . . 35
TTY operation . . . . . . . 36
phone updates. . . . . . . 37
basics . . . . . . . . . . . . . . . 38
home screen . . . . . . . . 38
text entry . . . . . . . . . . . 41
volume. . . . . . . . . . . . . 44
change sound
settings . . . . . . . . . . . . 45
external screen . . . . . . 46
handsfree speaker . . . . 46
standalone mode. . . . . 47
change codes &
passwords . . . . . . . . . . 48
lock/unlock side keys . . 48
lock & unlock phone . . 49
customize. . . . . . . . . . . . 50
sound settings . . . . . . . 50
get ringtones . . . . . . . . 52

contents
5
talking phone
settings. . . . . . . . . . . . 52
answer options. . . . . . 52
wallpaper . . . . . . . . . . 53
screen saver . . . . . . . . 53
backlight . . . . . . . . . . . 54
brightness. . . . . . . . . . 54
hide/show location
information . . . . . . . . . 54
AGPS limitations
& tips . . . . . . . . . . . . . 55
calls . . . . . . . . . . . . . . . . 57
redial a number. . . . . . 57
recent calls . . . . . . . . . 57
return unanswered
calls . . . . . . . . . . . . . . 58
attach number . . . . . . 59
speed dial . . . . . . . . . . 59
emergency calls . . . . . 60
AGPS during an
emergency call . . . . . . 60
voicemail . . . . . . . . . . 61
in-call options . . . . . . . 62
other features . . . . . . . . 63
advanced calling . . . . . 63
contacts . . . . . . . . . . . 64
messages . . . . . . . . . . 67
personalizing. . . . . . . . 69
call times & costs . . . . 73
handsfree . . . . . . . . . . 75
network . . . . . . . . . . . 75
personal organizer . . . 76
security. . . . . . . . . . . . 77
fun & games. . . . . . . . 77
service & repairs. . . . . . 79
Specific Absorption
Rate Data. . . . . . . . . . . . 80
Safety and General
Information . . . . . . . . . . 84
Motorola Limited
Warranty for the
United States and
Canada . . . . . . . . . . . . . 89
Hearing Aid
Compatibility with
Mobile Phones . . . . . . . 93
Information from the
World Health
Organization . . . . . . . . . 94
Smart Practices While
Driving . . . . . . . . . . . . . . 96
Index . . . . . . . . . . . . . . . 98

6
menu map
menu map
main menu
B GET IT NOW*
• Get Tunes & Tones
• Get PIX & FLIX
• Get Fun & Games
• Get News & Info
•GetGoing
• Get Extras
C MESSAGING
•NewMsg
• Inbox
• Sent
•Drafts
•Voicemail
• E-mail*
• Mobile IM*
•Chat*
n CONTACTS
• New Contact
• Contact List
• Groups
• Speed Dials
A RECENT CALLS
•Missed
• Received
• Dialed
•All
•ViewTimers
D SETTINGS & TOOLS
• (see next page)
* optional features
This is the standard main menu layout. Your
phone’s menu may be a little different.

menu map
7
settings menu
My Account
Tools
• Voice Commands
• Calendar
•AlarmClock
• World Clock
• Notepad
•Calculator
Sound Settings
• Master Volume
• Call Sounds
• Alert Sounds
• Keypad Volume
• Service Alerts
•PowerOn/Off
• Alarm Sounds
• Talking Phone
Display Settings
• Banner
• Backlight
• Brightness
• Wallpaper
• Screensaver
• Display Themes
Phone Settings
• Standalone Mode
• Shortcut Key
• Language
•Location
• Security
• System Select
•NAMSelect
• Master Clear
• Master Reset
Call Settings
• Answer Options
• Auto Retry
• TTY Mode
• One Touch Dial
•VoicePrivacy
• Data Settings
• DTMF Tones
Bluetooth
• Add New Device
Memory
• Save Options
• Phone Memory
•CardMemory
Phone Info
• My Number
•SWVersion
• Icon Glossary
• Software Update

8
Use and Care
Use and Care
Use and Care
To care for your Motorola phone, please keep it away from:
liquids of any kind dust and dirt
Don’t expose your phone to water, rain,
extreme humidity, sweat, or other moisture.
Don’t expose your phone to dust, dirt, sand,
food, or other inappropriate materials.
extreme heat or cold cleaning solutions
Avoid temperatures below -10°C/14°F or
above 45°C/113°F.
To clean your phone, use only a dry soft cloth.
Don’t use alcohol or other cleaning solutions.
microwaves the ground
Don’t try to dry your phone in a microwave
oven.
Don’t drop your phone.

9
essentials
essentials
about this guide
This guide shows how to locate a menu
feature as follows:
Find it: Press MENU ( s ) &ARECENT CALLS
%Dialed
This means that, from the home screen:
1 Press the center key s to open the
menu.
2 Press the navigation key S left or right to
scroll to
ARECENT CALLS , and press the
center key
s to select it.
3 Press the navigation key S down to
scroll to
Dialed , and press the
center key
s to select it.
CAUTION: Before using the
phone for the first time, read the
Important Safety and Legal
Information
included in the gray-
edged pages at the back of this
guide.
symbols
This means a feature is
network/subscription dependent
and may not be available in all areas.
Contact your service provider for
more information.

10
essentials
battery
battery installation
battery charging
New batteries are
not fully charged.
Plug the battery
charger into your
phone and an
electrical outlet. Your
phone might take
several seconds to start charging the battery.
This means a feature requires an
optional accessory.
1
symbols 2
3

11
essentials
Your phone displays Charge Complete when
finished.
Tip: Relax, you can’t overcharge your battery.
It will perform best after you fully charge and
discharge it a few times.
Note: When the battery is charging, the
phone automatically changes to the audible
Master Volume setting, regardless of what
ringstyle you have set. The phone changes
back to your selected ringstyle when you
disconnect the charger.
You can charge your battery by
connecting a cable from your
phone’s mini-USB port to a USB
port on a computer. Both your
phone and the computer must be turned on,
and your computer must have the correct
software drivers installed. Cables and
software drivers are available in Motorola
Original data kits, sold separately.
battery tips
Battery life depends on the network, signal
strength, temperature, features, and
accessories you use.
• Always use Motorola
Original batteries and
chargers. The warranty does
not cover damage caused by
non-Motorola batteries and/or chargers.
• New batteries or batteries stored for a
long time may take more time to
charge.
• When charging your battery, keep it
near room temperature.
When storing your battery, keep it
uncharged in a cool, dark, dry place.
• Never expose batteries to
temperatures below -10°C (14°F) or
above 45°C (113°F). Always take your

12
essentials
phone with you when you leave your
vehicle.
• It is normal for batteries to gradually
wear down and require longer charging
times. If you notice a change in your
battery life, it is probably time to
purchase a new battery.
Contact your local recycling center for
proper battery disposal.
Warning: Never dispose of batteries in a fire
because they may explode.
Before using your phone, read the battery
safety information in the “Safety and General
Information” section included in this guide.
turn it on & off
1 Open your phone.
2 Press and hold O for
a few seconds or until
the display turns on.
The phone may
require several seconds to turn on. If
prompted, enter your four-digit unlock
code (the last four digits of your phone
number) and press
OK to unlock the
phone.
To turn off your phone, press and hold
O for
a few seconds.
make a call
Enter a phone number and press N to make
a call.
To “hang up,” close the flip or press
O .
032375o

13
essentials
Tip: Closing the flip also ends the call, unless
you are using the speakerphone feature (see
page 46).
answer a call
When your phone rings and/or vibrates, just
open the flip or press
N to answer.
To “hang up,” press
O .
Tip: Closing the flip also ends the call, unless
you are using the speakerphone feature (see
page 46).
store a phone number
You can store a phone number in Contacts :
1 Enter a phone number in the home
screen.
2 Press the Store key.
Select
New Contact , if necessary.
3 Enter a name and other details for the
phone number. To select a highlighted
item, press the center key
s .
4 Press the Done key to store the number.
To edit or delete a
Contacts entry, see page 64.
call a stored phone
number
Find it: Press MENU ( s ) &nCONTACTS
1 Scroll to the Contacts entry.
Shortcut: In Contacts , press keypad keys to
enter the first letters of an entry you want.
You can also press
* and # to see the
entries you use frequently, or entries in
other categories.
2 Press N to call the entry.

14
essentials
your phone number
Press B # .
Tip: Want to see your phone number while
you’re on a call? Press
Options , then select
My Number .

15
main attractions
main attractions
You can do much more with your phone than
make and receive calls!
get & play music
Use the Get Tunes & Tones menu to:
• get new tunes and tones
• record new sounds
• set tunes and tones as your ringtone
• access music files
download V CAST music
You can download music from the
V CAST Music catalog and store it in your
phone’s memory or on an optional memory
card.
Find it: Press MENU ( s ) &BGET IT NOW
%Get Tunes & Tones
1 Scroll to Get V CAST Music and press OK ( s )
to open the V CAST music catalog.
2 Browse or search the catalog to find the
songs you want.
3 When the desired song is highlighted,
select
Preview to preview the song or Buy to
purchase it.
4 When your phone shows song details and
price, press
BUY ( s ) to confirm your
selection.

16
main attractions
5 When you see a confirmation that your
purchase was successful and your music
is available for download, press
OK ( s ) to
continue, or choose to download at a later
time.
6 When prompted to select a storage
location, scroll to
Phone Memory or Memory Card
and press the center key
s to begin
downloading.
Your phone displays a status indicator.
After downloading, you must wait for the
phone to acquire the content license.
7 Press OK ( s ) when the download is
complete.
8 Press Play to play the downloaded song
immediately.
or
Press Library to go to the Music Library (see
next section).
or
Press OK ( s ) to return to the previously
viewed music catalog.
manage music
Go to the Music Library to sort your music or
create playlists.
Find it: Press MENU ( s ) &BGET IT NOW
%Get Tunes & Tones
Scroll to Manage Music and press OK ( s ).
The
Music Library includes these options:
option
Genres View songs grouped into folders
by music type such as Folk, Rock,
or Country.
Artists View songs grouped into folders
by names of artists.

17
main attractions
create a playlist
Find it: Press MENU ( s ) &BGETITNOW
%Get Tunes & Tones
1 Scroll to Manage Music and press OK ( s ).
2 Scroll to Playlists and press OK ( s ).
3 If playlists already exist, press Options. Then
select
Create playlist and select OK ( s ).
or
If no playlists exist, press Create . Then
enter a title for the playlist in the text box
and press
OK ( s ).
4 Press B to return to the Music Library
menu.
5 Select Genres , Artists , Albums , or Songs .
6 Scroll to a desired song and press Options .
7 Scroll to and select Add to Playlist .
8 Scroll to the desired playlist and press
ADD ( s ).
9 Repeat steps 3 through 6 to add more
songs.
10 Press P to return to the main menu.
Albums View songs grouped into folders
by album title.
Note: Even if you have only one
song from an album, you will see
a folder for that album.
Playlists View playlists that you have
created.
Inbox View alert notifications received
when new music from a selected
artist is available for download.
Play All Play all songs in list order.
Shuffle Resort a playlist order.
option

18
main attractions
play music
Use the MusicPlayer to play music files that
you download from the V CAST Music catalog
(see page 15).
Find it: Press MENU ( s ) &BGETITNOW
%Get Tunes & Tones
1 Scroll to My Music and press OK ( s ).
The MusicPlayer opens and displays a list
of music files on phone memory and the
microSD® (TransFlash) memory card.
2 Scroll to a desired song and press
PLAY ( s ) to play the song. (The song
plays only once.
or
Select Playlist to see a list of your playlists.
or
Press the Options key to open the Options
menu (see the table following these
steps).
3 If you select a playlist or Play All Songs , press
S right during a song to advance to the
next song in the current playlist. Press
S
left tp skip back to the previous song.
Press the
Options key while a song is
playing to access these functions:
Note: Any music currently playing is
stopped when you press
Options .
Play All —Play all songs in the playlist.
Shuffle —Play songs from the playlist in
random order.
Get V CAST Music —Connect to the V CAST
music catalog to download more songs.
