Motorola PEBL U6 User manual

MOTOMANUALMOTOMANUAL

1
HELLOMOTO
Introducing your new Motorola PEBL U6 GSM wireless
phone. Here’s a quick anatomy lesson.
Battery Charge &
Bluetooth ®
Indicator Light
Accessory
Connector Port
Insert charger &
phone accessories.
Handsfree Speaker
(on back of phone)
Camera Lens
External Display
See incoming call
information.

2
check it out!
check it out!
Your phone is designed for convenient, single-handed
use. To open your phone:
1Grip
phone firmly, with
tip of index finger at
upper left corner of
phone (see arrow).
2Place thumb on upper
right corner of flip (see
arrow) and
slide flip
down toward you.
(You’ll see a space
open up underneath
the hinge).
3 Release thumb to
let flip glide open.

3
check it out!
Please Note: Your phone’s flip and keypad
area contain exposed magnets, which may
cause damage to credit cards, magnetic ID
cards, and other magnetically encoded
materials. Don’t place these or other items
that are sensitive to magnetic fields near the
exposed magnets. For example, do not place
your phone in the same pocket as your credit
card or hotel key.
Left Soft Key
Navigate menus.Open menus.
Select menu
items.
Volume Keys
Open browser
Smart Key
Voice Key
Voice dial phone
numbers, open
applications, create
voice records.
Right Soft Key
Turn on & off,
hang up, exit
menus.
Make & answer
calls.
Send a message.

4
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States for hearing impaired)
1-800-461-4575 (Canada)
Certain mobile phone features are dependent on the capabilities and
settings of your service provider’s network. Additionally, certain features
may not be activated by your service provider, and/or the provider’s
network settings may limit the feature’s functionality. Always contact your
service provider about feature availability and functionality. All features,
functionality, and other product specifications, as well as the information
contained in this user’s guide are based upon the latest available
information and are believed to be accurate at the time of printing.
Motorola reserves the right to change or modify any information or
specifications without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US Patent &
Trademark Office. The Bluetooth trademarks are owned by their proprietor
and used by Motorola, Inc. under license.Java and all other Java-based
marks are trademarks or registered trademarks of Sun Microsystems, Inc.
in the U.S. and other countries. All other product or service names are the
property of their respective owners.
© Motorola, Inc., 2005.
Caution: Changes or modifications made in the radio phone, not expressly
approved by Motorola, will void the user’s authority to operate the
equipment.
Manual Number: 6809495A87-A

5
contents
contents
check it out! . . . . . . . . . . 2
menu map . . . . . . . . . . . . 7
essentials . . . . . . . . . . . . 9
about this guide . . . . . . 9
SIM card . . . . . . . . . . . 10
battery. . . . . . . . . . . . . 10
turn it on & off. . . . . . . 13
make a call . . . . . . . . . 13
answer a call. . . . . . . . 13
your phone number . . 14
main attractions . . . . . . 15
voice commands. . . . . 15
video clips. . . . . . . . . . 17
photos. . . . . . . . . . . . . 20
Bluetooth® wireless. . 22
basics. . . . . . . . . . . . . . . 26
display. . . . . . . . . . . . . 26
menus. . . . . . . . . . . . . 30
text entry . . . . . . . . . . 32
volume . . . . . . . . . . . . 36
navigation key . . . . . . . 36
smart key . . . . . . . . . . 37
external display . . . . . . 37
handsfree speaker . . . 38
codes & passwords . . 39
lock & unlock phone . . 39
customize . . . . . . . . . . . 40
ring style. . . . . . . . . . . 40
time & date. . . . . . . . . 41
wallpaper . . . . . . . . . . 41
screen saver . . . . . . . . 42
themes . . . . . . . . . . . . 42
display appearance . . . 43
answer options . . . . . . 44
calls . . . . . . . . . . . . . . . . 45
turn off a call alert. . . . 45
recent calls . . . . . . . . . 45
redial. . . . . . . . . . . . . . 46
return a call . . . . . . . . . 47
notepad. . . . . . . . . . . . 47
hold or mute a call . . . 47
call waiting . . . . . . . . . 48
caller ID. . . . . . . . . . . . 48
emergency calls . . . . . 49
international calls . . . . 49
1-touch dial . . . . . . . . . 49
voicemail. . . . . . . . . . . 50
other features . . . . . . . . 51
advanced calling . . . . . 51
phonebook . . . . . . . . . 53
messages . . . . . . . . . . 59
instant messaging . . . 61
personalize . . . . . . . . . 62

6
contents
call times & costs . . . 64
handsfree . . . . . . . . . 66
data & fax calls . . . . . 67
network. . . . . . . . . . . 68
personal organizer . . . 68
security . . . . . . . . . . . 70
fun & games . . . . . . . 71
service and repairs . . . 73
SAR Data . . . . . . . . . . . 74
WHO Information . . . . 76
index . . . . . . . . . . . . . . 77

7
menu map
menu map
main menu
Voice Notes
s Recent Calls
• Received Calls
• Dialed Calls
• Notepad
•CallTimes
• Call Cost *
Get More
•MyAlbum
• My Journal
• My Email
•Games
• HiFi Ringers
• Wallpapers
ã IM *
•OfflineConvs.
• Saved Convs.
• Offline Settings
•Help
e Messages
• Create Message
• Message Inbox
•Voicemail
•QuickNotes
•PictureMsgTemplate
•Drafts
•Outbox
• Browser Msgs
• Info Services *
h Fun & Apps
• Video Camera
• Pictures
• Videos
• Sounds
• Themes
•Camera
•Games&Apps
Help
n Phonebook
w Settings
• (see next page)
This is the standard main
menu layout.
Your phone’s
menu may be a little
different.
* optional features

8
menu map
settings menu
l Personalize
• Home Screen
•MainMenu
• Voice Dial Setup
•Skin
• Greeting
• Wallpaper
• Screen Saver
t Ring Styles
•Style
•style Detail
L Connection
• Bluetooth Link
H Call Forward
•VoiceCalls
• Fax Calls
• Data Calls
• Cancel All
• Forward Status
U In-Call Setup
• Dialing Prefix *
• In-Call Timer
• Call Cost Setup *
• My Caller ID
• Answer Options
• Call Waiting
Z Initial Setup
• Time and Date
• 1-Touch Dial
• Display Timeout
• Backlight
• TTY Setup *
•Scroll
• Language
• Brightness
• External Display
•DTMF
• Master Reset
•MasterClear
É Tools
• SIM Apps *
• Calculator
• Datebook
• Shortcuts
•AlarmClock
• Dialing Services
m Phone Status
•MyTel.Number
• Credit Info/Available *
• Active Line *
•BatteryMeter
• Voice Dial Languages
• Software Update *
• Other Information
S Headset
• Auto Answer
• Voice Dial
J Car Settings
• Auto Answer
• Auto Handsfree
• Power-Off Delay
• Charger Time
j Network
•NewNetwork
•NetworkSetup
•AvailableNetworks
• Network Jingle
• Call Drop Tone
u Security
• Phone Lock
• Lock Application
• Fixed Dial
• SIM PIN
•NewPasswords
• Certificate Mgmt
c Java Settings
• Java System
• Delete All Apps
• App Vibration
• App Volume
• App Priority *
• App Backlight
• Set Standby App *
• DNS IP *
* optional features

9
essentials
essentials
about this guide
This guide shows how to locate a menu feature as follows:
Find it: Press a > Recent Calls > Dialed Calls
This example shows that, from the home screen, you press
a to open the menu, highlight and select sRecent Calls , then
highlight and select
Dialed Calls .
Press
S to scroll to and highlight a menu feature. Press s
or the
SELECT key to select the highlighted menu feature.
symbols
This means a feature is network/subscription
dependent and may not be available in all areas.
Contact your service provider for more information.
This means a feature requires an optional accessory.
CAUTION: Before using the phone for the
first time, read the
Important Safety and
Legal Information included in the
gray-edged pages at the back of this guide.
032257o

10
essentials
SIM card
Yo u r Subscriber Identity Module (SIM) card contains personal
information like your phone number and phonebook entries.
Caution: Don’t bend or scratch your SIM card. Keep it away
from static electricity, water, and dirt.
Slide the SIM card under the retention tabs and into the card
slot as shown:
battery
battery tips
Battery life depends on the network, signal strength,
temperature, features, and accessories you use.
• Always use Motorola Original batteries and
chargers. The warranty does not cover
damage caused by non-Motorola batteries
and/or chargers.
• New batteries or batteries stored for a long time may
take more time to charge.
1. 2.

11
essentials
• When charging your battery, keep it near room
temperature.
• When storing your battery, keep it uncharged in a cool,
dark, dry place.
• Never expose batteries to temperatures below -10°C
(14°F) or above 45°C (113°F). Always take your phone
with you when you leave your vehicle.
• It is normal for batteries to gradually wear down and
require longer charging times. If you notice a change in
your battery life, it is probably time to purchase a new
battery.
Contact your local recycling center for proper battery
disposal.
Warning: Never dispose of batteries in a fire because they
may explode.
Before using your phone, read the battery safety information
in the “Safety and General Information” section included in
this guide.
battery installation
1. 2.

12
essentials
battery charging
New batteries are not fully
charged. Open the
protective cover and plug
the travel charger into your
phone as shown. Plug the
other end into an electrical
outlet. The battery charge
indicator light shows when the battery is charging. Your
display shows
Charge Complete when finished.
Tip: Relax, you can’t overcharge your battery. It will perform
best after you fully charge and discharge it a few times.
Note: You can charge your battery by connecting a
cable from your phone’s mini-USB port to a USB
port on a computer. Both your phone and the
computer must be turned on, and your computer
must have the correct software drivers installed. Cables and
software drivers are available in Motorola Original data kits,
sold separately.
3.

13
essentials
turn it on & off
Caution: On power up, the phone may prompt you to enter
your SIM card PIN code to unlock the SIM card. If you enter
an incorrect PIN code three times in a row, your SIM card is
disabled and your display shows
SIM Blocked . Contact your
service provider.
To turn on your phone, press and hold
u for a few seconds or until the
display turns on. If prompted, enter
your six-digit SIM card PIN code and/or
four-digit unlock code.
To turn off your phone, press and hold
u for two seconds.
make a call
Enter a phone number and press U to make a call.
To “hang up,” close the flip or press
u .
Note: Closing the flip doesn’t end a call when the handsfree
speaker is turned on (see page 38).
answer a call
When your phone rings and/or vibrates, just open the flip or
press
U to answer.
To “hang up,” close the flip or press
u .
Note: Closing the flip doesn’t end a call when the handsfree
speaker is turned on (see page 38).

14
essentials
your phone number
From the home screen, press a# to see your number.
Tip: Want to see your phone number while you’re on a call?
Press
a > My Tel. Numbers .
To store or edit your name and phone number on your
SIM card, press the
EDIT key while showing your
number. If you don’t know your phone number, contact your
service provider.

15
main attractions
main attractions
You can do much more with your phone than make and
receive calls!
voice commands
You can use voice commands to make calls, and to open and
use some phone applications.
Note: Not all phone languages support voice recognition and
voice commands.
open applications
To open the Camera or Voicemail applications, Redial (dialed calls
list), or
Received Calls list:
1 Press and release the voice key.
Your phone prompts you to say a command.
2 Say one of the following commands:
“Camera,” “Voicemail,” “Redial” (dialed calls list), or
“Received Calls”
Your phone opens the application.
make a call
You can use voice commands to make a call:

16
main attractions
• Use name dial to dial a phonebook entry by speaking
the entry’s name.
• Use digit dial to dial any phone number by speaking
its digits.
Tip: Speak numbers at a normal speed and volume,
pronouncing each digit distinctly. Avoid pausing between
digits.
1 Press and release the voice key.
Your phone prompts you to say a command.
2 Say “Name Dial” or “Digit Dial.”
3 When prompted, say the name of the phonebook entry
or speak the digits in the phone number.
If your phone recognizes the name or number, it makes
the call.
Notes:
•
Your phone may prompt you to repeat a name or
number. If the name/number isn’t valid, the phone
doesn’t make the call.
• If the phone does not recognize the name or number,
the display shows a list of names/numbers, asks, “Did
you say ...,” and highlights the first item in the list. Say
“Yes” to call the highlighted number, or “No” to go to
the next list item.
To select the name or number manually, scroll to the
name/number on the list and press the
SELECT key.

17
main attractions
• You can improve voice dial operations by training the
phone to recognize your voice. Press
a > Settings
>
Personalize > Voice Dial Setup > Adapt Digits .
video clips
record a video clip
Find it: Press a > Fun & Apps > Videos > [New Video]
The display shows the active viewfinder image.
Note: You can zoom only before you start recording.
1 Point the camera lens at the video subject.
2 Press the CAPTURE key to begin video recording.
3 Press the STOP key to stop video recording.
BACK CAPTURE
Return to previous
screen.
Press
S up or
down to zoom in
or out.
Press
a to open Videos Menu .
Video Clips
Remaining
Start video
capture.
VIDEO
CLIP
AREA
Video Viewfinder
26 Remaining

18
main attractions
• To delete the video clip and return to the active
viewfinder, press the
DISCARD key.
• To store the video clip, press the STORE key.
Your storage options are
Send in Message or Store Only .
play a video clip
Find it: Press a > Fun & Apps > Videos > video clip
The display shows the video clip in the playback screen.
video settings
During video recording or playback, press a to open the
Videos Menu :
options
Go To Videos See video clips stored on your phone.
VIDEO
CLIP
AREA
BACK DETAILS
Press S up or
down to pause or
play video clip.
Press
S left or
right to skip to
previous or next
video clip.
Timer indicates %
played.
See video clip
information.
Return to previous
screen. Press
a to open Videos Menu .
Video Clip Name
00:07/00:12
