Motorola StarTAc 7760 User manual

1
Welcome
Thank you for choosing Motorola—a global leader in
communications technology.
All Motorola phones are designed and manufactured
in the United States to meet Motorola’s exacting specifications
and world-class quality standards. During development,
our laboratory testing team took the durable StarTAC
™
phone
through its paces. They cooked it, steamed it, shook it, shocked
it, dusted it, and dropped it—and the phone still worked! We are
confident that the one you purchased will meet your own exact-
ing standards.
Thank you for choosing Motorola, and by all means, enjoy your
StarTAC Model 7760 dual mode digital cellular phone!

2
Guide Overview
Okay, you’ve got a brand new phone
with a bunch of nifty features.
Now what?
Afraid you’ll press the wrong key?
Or forget a feature or two?
Don’t sweat it!
We’ve designed this guide to take you
step-by-step through each feature of
your new StarTAC
™
phone. We’ll show
you what key to press and what happens when you press it. Follow
along, chapter-by-chapter, and you’ll find it’s as easy as 1-2-3.
Here’s an idea of what you’ll learn in each chapter:
Getting Started
First things first. Turn to page 10, and we’ll explain what came
with your phone. Then, we’ll show you how to install and
charge your battery so that you can get started with “The Basics”
in the next section.
The Basics
What do all those buttons and lights mean? How do I make my
first phone call? In this section, we’ll answer those questions and
get you going with your StarTAC phone. Start learning “The
Basics” on page 22.

3
Guide Overview
Using Memory
Read “Using Memory,” beginning on page 36, and you’ll learn
how to make the most of your new phone’s built-in Phone Book.
You’ll save time with dialing shortcuts and memory tricks that
make it easy to place quick calls.
Using Messaging
Did you know that your StarTAC
™
phone supports optional
messaging services, like Caller ID
*
, which allows you to see
who’s calling before you answer? Your new phone can even
receive alphanumeric messages just like a pager and tell you
when you have Voice Mail*. Simply turn to page 48 to begin
“Using Messaging.”
The Works
When you’re ready to get into the more advanced features your
new phone has to offer, just turn to page 56 for “The Works.”
Learn about everything from navigating the menu system to elec-
tronically locking your phone.
So relax! Let us show you what your
StarTAC phone can do!
*Contact your Service Provider for availability.

4
Contents
Introduction
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Getting Started
Package Content Options . . . . . . . . . . . . . . . . . . . . . . 10
Introduction to Batteries. . . . . . . . . . . . . . . . . . . . . . . 12
Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . 14
Charging the Battery. . . . . . . . . . . . . . . . . . . . . . . . . . 16
Phone Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Using the Smart Button . . . . . . . . . . . . . . . . . . . . . . . 21
The Basics
Turning Your Phone On . . . . . . . . . . . . . . . . . . . . . . . 22
Reading the Indicators. . . . . . . . . . . . . . . . . . . . . . . . 24
Placing and Ending Calls. . . . . . . . . . . . . . . . . . . . . . 28
Receiving Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Redialing Numbers. . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Basic Tone Controls . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Your Phone & Its Shortcuts . . . . . . . . . . . . . . . . . . . . 34
Using Memory
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Making the Most of Memory . . . . . . . . . . . . . . . . . . . 37
Storing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Recalling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Pause Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Using Calling Cards . . . . . . . . . . . . . . . . . . . . . . . . . . 46

5
Contents
Using Messaging
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Receiving Messages . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Viewing Your Caller IDs . . . . . . . . . . . . . . . . . . . . . . . .50
Checking Your Voice Mail . . . . . . . . . . . . . . . . . . . . . .52
Reading Your Messages . . . . . . . . . . . . . . . . . . . . . . . .54
The Works
Introducing the Menu Features. . . . . . . . . . . . . . . . . .56
The Internal Phone Book . . . . . . . . . . . . . . . . . . . . . .58
Learn how to store and recall numbers
Using Call Timers . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Learn how to monitor the length of your calls
Setting Tone Controls. . . . . . . . . . . . . . . . . . . . . . . . . .72
Learn how to adjust your phone’s tone controls
Lock/Security Features. . . . . . . . . . . . . . . . . . . . . . . . .78
Learn how to control access to your phone
Phone Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
Learn how to personalize your phone’s operation
Reference Information
Accessory Options. . . . . . . . . . . . . . . . . . . . . . . . . . . .100
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114

6
Safety Information
Exposure
to Radio
Frequency
Signals
Your wireless handheld portable telephone is a low power radio
transmitter and receiver. When it is ON, it receives and also sends out
radio frequency (RF) signals.
In August 1996, the Federal Communications Commissions (FCC)
adopted RF exposure guidelines with safety levels for hand-held
wireless phones. Those guidelines are consistent with the safety
standards previously set by both U.S. and international standards
bodies:
•
ANSI C95.1 (1992)
*
•
NCRP Report 86 (1986)*
•
ICNIRP (1996)*
Those standards were based on comprehensive and periodic evalua-
tions of the relevant scientific literature. For example, over 120 sci-
entists, engineers, and physicians from universities, government
health agencies, and industry reviewed the available body of
research to develop the ANSI Standard (C95.1).
The design of your phone complies with the FCC guidelines (and
those standards).
*American National Standards Institute; National Council on Radiation Protection and
Measurements; International Commission on Non-Ionizing Radiation Protection
Antenna
Care
Use only the supplied or an approved replacement antenna. Unau-
thorized antennas, modifications, or attachments could damage the
phone and may violate FCC regulations.
Phone
Operation
Normal Position:
Hold the phone as you would any other telephone, with the antenna
pointed up and over your shoulder.
Tips on Efficient Operation:
For your phone to operate most efficiently:
•
Extend your antenna fully.
•
Do not touch the antenna unnecessarily when the phone is in use.
Contact with the antenna affects call quality and may cause the
phone to operate at a higher power level than otherwise needed.

7
Safety Information
Batteries
Caution: All batteries can cause property damage, injury or burns if
a conductive material, such as jewelry, keys or beaded chains,
touches exposed terminals. The material may complete an electrical
circuit and become quite hot. To protect against such unwanted cur-
rent drain, exercise care in handling any charged battery, particu-
larly when placing it inside your pocket, purse or other container
with metal objects. When the battery is detached from the phone:
your battery is packed with a protective cover.; please use this cover
for storing your battery when not in use.
Driving
Check the laws and regulations on the use of wireless telephones in
the areas where you drive. Always obey them. Also, if using your
phone while driving, please:
• Give full attention to driving–driving safely is your first responsibility;
• Use hands-free operation, if available;
• Pull off the road and park before making or answering a call if
driving conditions so require.
Electronic
Devices
Most modern electronic equipment is shielded from RF signals.
However, certain electronic equipment may not be shielded against
the RF signals from your wireless phone.
Pacemakers
The Health Industry Manufacturers Association recommends that a min-
imum separation of six (6”) inches be maintained between a handheld
wireless phone and a pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent with the independent
research by and recommendations of Wireless Technology Research.
Persons with pacemakers:
•
Should ALWAYS keep the phone more than six inches from their
pacemaker when the phone is turned ON;
•
Should not carry the phone in a breast pocket;
•
Should use the ear opposite the pacemaker to minimize the poten-
tial for interference.
•
If you have any reason to suspect that interference is taking place,
turn your phone OFF immediately.

8
Safety Information
Hearing Aids
Some digital wireless phones may interfere with some hearing aids.
In the event of such interference, you may want to consult your
hearing aid manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult the manufac-
turer of your device to determine if they are adequately shielded
from external RF energy. Your physician may be able to assist you in
obtaining this information.
Turn your phone OFF in health care facilities when any regula-
tions posted in these areas instruct you to do so. Hospitals or
health care facilities may be using equipment that could be sen-
sitive to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately shielded
electronic systems in motor vehicles. Check with the manufacturer
or its representative regarding your vehicle. You should also consult
the manufacturer of any equipment that has been added to your
vehicle.
Posted Facilities
Turn your phone OFF in any facility where posted notices so require.
Aircraft
FCC regulations prohibit using your phone while in the air. Switch
OFF your phone before boarding an aircraft.

9
Safety Information
Blasting
Areas
To avoid interfering with blasting operations, turn your phone OFF
when in a “blasting area” or in areas posted: “Turn off two-way
radio.” Obey all signs and instructions.
Turn your phone OFF when in any area with a potentially explosive
atmosphere, and obey all signs and instructions. Sparks in such
Potentially
Explosive
Atmospheres
areas could cause an explosion or fire resulting in bodily injury or
even death.
Areas with a potentially explosive atmosphere are often, but not
always, clearly marked. They include fueling areas such as gasoline
stations; below deck on boats; fuel or chemical transfer or storage
facilities; areas where fuel odors are present, i.e. if a gas/propane
leak occurs in a car or home; areas where the air contains chemi-
cals or particles, such as grain, dust, or metal powders; and any
other area where you would normally be advised to turn off your
vehicle engine.
Vehicles
Equipped
with Air
Bags
An air bag inflates with great force. DO NOT place objects, including
both installed or portable wireless equipment, in the area over the
air bag or in the air bag deployment area. If in-vehicle wireless
equipment is improperly installed and the air bag inflates, serious
injury could result.
Equipment
Care
Your Motorola cellular radiotelephone is designed for excellent
durability under normal use conditions. Protect your cellular tele-
phone from water damage that could result from spills or excessive
exposure to rain. Never submerge your cellular phone.

10
Getting Started
Package Content Options
The StarTAC
™
phone comes equipped with a standard battery
and an AC adapter to get you up and running. A whole new line
of accessory options, now smaller and lighter than ever,
can customize your wireless package for maximum perfor-
mance and portability.
66
99
33
55
88
00
22
44
77
11
lock
vib
batt
menu
mute
RCL STO CLR
SEND
FCN END
tuv
jkl mno
wxyz
pqrs
ghi
def
opr
abc
Digital
07/07/98
Slim Main Battery with
Battery Cover
Standard Main Battery
with Battery Cover
StarTAC Model 7760 Dual Mode Phone
Standard Auxiliary Battery
with Battery Cover Slim Auxiliary Battery
with Battery Cover

11
Getting Started
Package Content Options
Your phone and accessories may not look exactly as pictured above.
Holster
Cigarette Lighter Adapter
AC Adapter Headset
Desktop Charger

12
Introduction to Batteries
Battery Covers
Your phone’s batteries are shipped in an uncharged state with
protective covers on them. You should save these covers to store
and carry batteries when they are not in use. The cover prevents
objects from touching the battery terminals, thereby reducing
the risk of injury or damage from a short circuit.
To begin using your phone, just slip a battery out of its protective
cover, install and charge the battery.
Removing the Main Battery Cover
Attaching the Main Battery Cover
1. Press In
Latch
Press in the release latch.
2. Remove
Battery
Rotate the batter upward and lift it out of the
cover.
1. Lower
Side
Lower the side, opposite the release latch,
into the cover.
2. Click
Latch
Drop the side with the release latch down
until the latch clicks.
Release Latch
1.
2.
1.
2.

13
Getting Started
Introduction to Batteries
Removing the Auxiliary Battery Cover
Attaching the Auxiliary Battery Cover
1. Dislodge
Cover
Hold the auxiliary battery securely with one
hand. With your other hand’s thumb, push up
on the bottom of the cover.
2. Remove
Battery
Continue to push up until the cover slides free
of the pins on the bottom of the battery, then
swing the cover outward.
1. Insert
Point
Slide the cover’s narrow end into the small
grooved hook on the top of the auxiliary battery.
2. Secure
Cover
Push the cover firmly so the base slides past
the pins on the auxiliary battery, then release.
1.
2.
1.
2.
Hook
Pins

14
Installing the Battery
Main Battery Installation
The main battery fits into the top of your phone like a ski boot
fits into a ski.
Main Battery Removal
To remove a battery:
1. Insert
Toe
Place the battery’s “toe” into the compart-
ment as shown.
2. Snap
Heel
Press its “heel” down until you hear it click
into place.
1. Turn OFF
Phone
If you don’t have another battery attached,
press ¡to turn your phone OFF.
2. Remove
Battery
Pull the release latch back toward the battery
and lift the battery out.
1.
2.
Tip:
If you have a
charged auxil-
iary battery
attached to your
phone, you can
remove and
change your
main battery at
any time – even
during a call.
Release Latch

15
Getting Started
Installing the Battery
Auxiliary Battery Installation
The auxiliary battery clips onto the back of your phone.
Auxiliary Battery Removal
To remove the auxiliary battery:
1. Place
Hook
Place the hook located on the narrow end of
the battery into the slot on the back of the
phone.
2. Pull Batt
Down
Pull the battery down and slide the battery
pegs over the bottom of the phone.
3. Release
Battery
Once the battery clears the bottom of the
phone, release it. Make sure that the pegs fit
securely into place.
1. Pull Batt
Down
Pull the battery down until the pegs come
free, then pull the base away from the phone.
2. Remove
Battery
Lift the battery’s hook out of the slot on the
back of the phone.
2.
1.
3.
Tip:
If you have a
charged main
battery
attached to
your phone,
youcanremove
and change
your auxiliary
battery at any
time – even
durin
g
a call.
1.
2.

16
Charging the Battery
Using the Internal Rapid Charger
Believe it or not, there’s a battery charger built right into your
phone! It’s called the internal charger and it’s a quick and easy
way to charge your phone’s battery. To make use of the internal
charger, all you need is one of the three available adapters,
either a standard AC adapter, a rapid rate AC adapter, or a ciga-
rette lighter adapter.
Keep in mind: When the internal charger is in use and the
phone is ON, you can still place and receive calls. Just remember,
talking on the phone requires energy, so your phone may not
charge while the call is in progress.
Keep in mind: In some cars, the ignition must be ON to use
the cigarette lighter.
1. Attach
Adapter
to Phone
Plug the AC or cigarette lighter adapter into the
accessory connector on the bottom of your
phone as shown, with the release tab facing up.
2. Plug In
Adapter
Plug the adapter into the appropriate power
source.
PUSH
00
77
RCL STO CLR
SEND
FCN END
p
opr

17
Getting Started
Charging the Battery
The Battery Indicator
In the upper right corner of your phone’s display, there is a bat-
tery indicator filled with three segments. The more segments
you see, the greater the charge.
•The border of the battery icon will flash during charging.
•When both batteries are fully charged, the battery icon will
stop flashing and become solid.
Expert Performance ( E•P™) Charging System
Your phone uses the Motorola E•P Charging System. This innova-
tive technology allows your phone to communicate with the battery
and tailor the charging cycle to get the best performance possible.
When you power up the phone or install a new battery, you may
see: Invalid Battery. This means your phone can’t com-
municate with the attached battery. Check the label on the bat-
tery–if it isn’t a Motorola original, the battery may not have the
appropriate circuitry to communicate with the phone. Other-
wise, try removing and attaching the battery again.
We recommend that you use Motorola original batteries and
accessories and that you store your batteries in the protective
cover when not in use.
Battery Storage and Disposal
To prolong the life of your batteries, avoid exposing them to
temperatures below -10°C (14°F) or above 45°C (113°F). As a
good rule of thumb, always take your phone with you when you
leave your car.
To dispose of batteries, check with your local recycling center for
a battery recycler near you. Never dispose of batteries in fire.
Caution: To prevent injuries or burns, do not allow metal
objects to contact or short circuit the battery terminals.

18
Charging the Battery
Using the Desktop Charger
The desktop charger’s front pocket can charge batteries while
they are attached to your phone, and the rear pocket can charge
batteries separately.
If you have a desktop charger:
1. Attach
Adapter
Plug the AC adapter into the back of the charger,
with the release tab facing up.
2. Plug In
Adapter
Plug the other end of the AC adapter into a
wall socket.
3. Insert
Phone
Insert the phone into the front pocket with a
main and/or auxiliary battery attached.
&Insert
Battery
If you like, insert a main or auxiliary battery
into the rear pocket.
PUSH
Front Pocket
Rear Pocket

19
Getting Started
Charging the Battery
Desktop Charger Indicators
The three LED indicators on the left front of the desktop charger
let you know the current state of any charging batteries. The first
light provides information on the main battery attached to the
phone, the second on the attached auxiliary battery, and the third
provides information on any battery loaded in the rear pocket.
•Red means the battery is charging.
•Flashing yellow means the battery is waiting to be charged.
•Green means the battery is charged within 90% of its capacity
and can be used. An additional hour of charging will bring
your battery up to 100% capacity.
•Flashing red means the battery is damaged and can’t be
charged.
Desktop Charger Charging Times
The time it takes for your battery to obtain a full charge is
affected by a variety of factors, including:
•Temperature Batteries should be at or near room
temperature when charging. To prolong battery life
and charge capacity, avoid exposing your batteries to
temperatures below -10°C (14°F) or above 45°C (113°F).
As a good rule of thumb, always take your phone with
you when you leave your car.
•Inactivity New batteries, or batteries that have been stored
for long periods of time, may not rapid charge properly. In
these instances, the battery requires an overnight charge.
•Extended Usage Over extended periods of time, batteries
gradually wear down and require longer charging times.
This is normal. If you’ve been charging your batteryregularly
and notice a decrease in talk-time or an increase in charging
time, then it’s probably time to purchase a new battery.
Tip:
When you
charge the
main and an
auxiliary bat-
tery, the main
battery will be
charged first.

20
Phone Overview
Function Keys
¡Turns the phone ON and OFF.
øOpens messaging menus.
ƒActs as a “shift” key to access the secondary functions of
other keys.
‰Recalls phone numbers from memory.
¬Stores phone numbers into memory.
ÇClears characters from the screen.
ºEnds phone calls and exits the menu.
æPlaces or answers calls.
«and » can be used to scroll through memory entries
and menu features.
Alphanumeric Display Displays your input from the keypad,
information recalled from memory, and other messages.
Microphone Positioned for convenient conversation.
Retractable Antenna Extend for best performance.
Earpiece Ultra-compact phone speaker.
Headset Jack Provides the connection for an optional headset.
Accessory Connector Provides the connection for an exter-
nal power supply.
Volume Keys Represented in this manual by qq
qq and ZZ ZZ,these
keys adjust keypad, earpiece, and ringer volume. They also scroll
up and down through memory locations and menu features.
