User’s Guide
motorola W315
C
M
Y
CM
MY
CY
CMY
K
v527063.eps 2/12/2008 1:27:26 PMv527063.eps 2/12/2008 1:27:26 PM

1
HELLOMOTO
Introducing your new Motorola W315 CDMA wireless phone. Here’s a quick anatomy lesson.
Volume Keys
Charge
battery,
attach data
cable.
Connect
headphones.
Voice
Key
Smart/
Speakerphone
Key
Left Soft Key
Make &
answer calls.
Clear/Back Key
Turn on & off,
hang up, exit
menus.
Navigation Key
Scroll up, down,
left, or right.
Right Soft Key
Center
Key
Smart/
Speakerphone
Key
Microphone

2
Home Screen Main Menu
p
s
MESSAGE
t
1:51pm 05/24/08
n
t
SELECT EXIT
8
s
8
CONTACT
É
K
e
s
Recent Calls
h
Éwl
1
2
3
4
Press the
Center Key s
to select.
Press the
Center Key s
to open the
Main Menu .
Press and hold the
Power Key u for a
few seconds, or until
the screen lights up,
to turn on your
phone.
Press the Navigation Key
S
up, down, left or right to
highlight a menu feature.

3
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
Certain mobile phone features are dependent on the capabilities
and settings of your service provider’s network. Additionally,
certain features may not be activated by your service provider,
and/or the provider's network settings may limit the feature’s
functionality. Always contact your service provider about feature
availability and functionality. All features, functionality, and other
product specifications, as well as the information contained in this
user's guide are based upon the latest available information and
are believed to be accurate at the time of printing. Motorola
reserves the right to change or modify any information or
specifications without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US
Patent & Trademark Office. All other product or service names are
the property of their respective owners. Java and all other
Java-based marks are trademarks or registered trademarks of Sun
Microsystems, Inc. in the U.S. and other countries.
© 2008 Motorola, Inc. All rights reserved.
Software Copyright Notice
The Motorola products described in this manual may include
copyrighted Motorola and third-party software stored in
semiconductor memories or other media. Laws in the United
States and other countries preserve for Motorola and third-party
software providers certain exclusive rights for copyrighted
software, such as the exclusive rights to distribute or reproduce
the copyrighted software. Accordingly, any copyrighted software
contained in the Motorola products may not be modified,
reverse-engineered, distributed, or reproduced in any manner to
the extent allowed by law. Furthermore, the purchase of the
Motorola products shall not be deemed to grant either directly or
by implication, estoppel, or otherwise, any license under the
copyrights, patents, or patent applications of Motorola or any
third-party software provider, except for the normal, non-exclusive,
royalty-free license to use that arises by operation of law in the
sale of a product.
Manual Number: 6809502A05-B

4
contents
contents
menu map . . . . . . . . . . . . . . . . 6
essentials . . . . . . . . . . . . . . . . . 9
about this guide . . . . . . . . . . 9
battery. . . . . . . . . . . . . . . . . 10
turn it on & off . . . . . . . . . . 12
make a call . . . . . . . . . . . . . 13
answer a call. . . . . . . . . . . . 13
store a phone number . . . . 13
call a stored phone
number . . . . . . . . . . . . . . . . 13
your phone number . . . . . . 14
main attractions . . . . . . . . . . 15
send message . . . . . . . . . . 15
cable connections. . . . . . . . 17
TTY operation . . . . . . . . . . . 17
basics . . . . . . . . . . . . . . . . . . . 19
display . . . . . . . . . . . . . . . . . 19
text entry. . . . . . . . . . . . . . . 21
volume . . . . . . . . . . . . . . . . 23
Navigation Key . . . . . . . . . . 24
external screen . . . . . . . . . . 24
handsfree speaker. . . . . . . . 24
codes & passwords. . . . . . . 25
lock/unlock side keys . . . . . 25
lock & unlock phone . . . . . . 25
customize . . . . . . . . . . . . . . . . 27
ring style . . . . . . . . . . . . . . . 27
time & date . . . . . . . . . . . . . 28
wallpaper. . . . . . . . . . . . . . . 28
themes . . . . . . . . . . . . . . . . 29
screen appearance . . . . . . . 29
answer options . . . . . . . . . . 30
AGPS & your location . . . . . 30
AGPS limitations & tips . . . . 31
calls . . . . . . . . . . . . . . . . . . . . . 32
turn off a call alert . . . . . . . . 32
recent calls . . . . . . . . . . . . . 32
redial . . . . . . . . . . . . . . . . . . 33
return a call . . . . . . . . . . . . . 33
caller ID . . . . . . . . . . . . . . . . 34
emergency calls . . . . . . . . . 34
AGPS during an
emergency call . . . . . . . . . . 34
speed dial . . . . . . . . . . . . . . 35
voicemail . . . . . . . . . . . . . . . 36

contents
5
other features. . . . . . . . . . . . . 37
advanced calling . . . . . . . . . 37
contacts. . . . . . . . . . . . . . . . 39
messages . . . . . . . . . . . . . . 41
personalize . . . . . . . . . . . . . 43
call times. . . . . . . . . . . . . . . 45
handsfree . . . . . . . . . . . . . . 46
data & fax calls . . . . . . . . . . 47
network. . . . . . . . . . . . . . . . 47
personal organizer . . . . . . . . 47
security . . . . . . . . . . . . . . . . 49
fun & games . . . . . . . . . . . . 49
service & repairs . . . . . . . . . . 50
Industry Canada Notice
to Users . . . . . . . . . . . . . . . . . 58
FCC Notice to Users . . . . . . . 58
Motorola Limited Warranty
for the United States
and Canada. . . . . . . . . . . . . . . 59
Hearing Aid Compatibility
with Mobile Phones. . . . . . . . 63
Information from the World
Health Organization. . . . . . . . 64
Product Registration . . . . . . . 64
Export Law Assurances . . . . . 64
Caring for the Environment
by Recycling . . . . . . . . . . . . . . 65
California Perchlorate Label. . . 65
Privacy and Data Security . . . 66
Smart Practices
While Driving . . . . . . . . . . . . . 67
index . . . . . . . . . . . . . . . . . . . . 69

6
menu map
menu map
main menu
e Messaging
•Voicemail
• New TXT Msg
• Inbox
• Drafts
•Saved
•QuickNotes
• Sent
• Settings
t Alert Styles
•Style
•Style Detail
• Sounds
8 Calendar
n Contacts
s Recent Calls
• Received
• Dialed
• Missed Calls
•ViewTimers
• Notepad
h Gallery
• Pictures
• Sounds
É To o l s
•Calculator
•Alarm
•VoiceMemo
•Games
w Settings
• (see next page)
l Phone Info
• My Number
• NAM Setting
• Battery Meter
• Other Information
This is the standard main menu layout. Your
phone’s menu may be a little different.

menu map
7
settings menu
Personalize
• Main Menu
• Scroll Keys
• Color Style
• Greeting
• Banner
• Flip Tone
• Wallpaper
• Themes
• Speed Dial
Initial Setup
• Speakerphone
• Time and Date
• Auto PIN Dial
• Auto Redial
• Backlight
• Animation
• Language
• SubLCD
• Brightness
• Contrast
• TTY Setup
•DTMF
• Master Reset
• Master Clear
• Icon Glossary
In-Call Setup
• In-Call Timer
• Answer Options
Phone Info
• My Number
• NAM Setting
• Battery Meter
• Other Information
Security
• Phone Lock
• Lock Side Keys
• Lock Application
• Restrict Calls
•NewPasswords
Location
• Location On
• 911 Only
Network
• Current Network
• Analog Only
• Set Mode
• Service Tone
• Call Drop Tone
More
• Car Settings
• Headset

8
Use and Care
Use and Care
Use and Care
To care for your Motorola phone, please keep it away from:
liquids of any kinddustand dirt
Don’t expose your phone to water, rain,
extreme humidity, sweat, or other moisture. If
it does get wet, don’t try to accelerate drying
with the use of an oven or dryer, as this may
damage the phone.
Don’t expose your phone to dust, dirt, sand,
food, or other inappropriate materials.
extreme heat or cold cleaning solutions
Avoid temperatures below 0°C/32°F or
above 45°C/113°F. To clean your phone, use only a dry soft cloth. Don’t use alcohol or other cleaning solutions.
microwaves the ground
Don’t try to dry your phone in a microwave
oven. Don’t drop your phone.

9
essentials
essentials
about this guide
This guide shows how to locate a menu feature as
follows:
Find it: s > h Gallery > Pictures
This means that, from the home screen:
1 Press the Center Key s to open the menu.
2 Press the Navigation Key S to scroll to
h Gallery , and press the Center Key s to select
it.
3 Press the Navigation Key S to scroll to Pictures ,
and press the Center Key
s to select it.
CAUTION: Before using the
phone for the first time, read the
Important Safety and Legal
Information
included in the gray-
edged pages at the back of this
guide.
symbols
This means a feature is
network/subscription dependent and may
not be available in all areas. Contact your
service provider for more information.
This means a feature requires an optional
accessory.

10
essentials
battery
Battery Use & Battery Safety
• Motorola recommends you always use
Motorola-branded batteries and chargers.
The warranty does not cover damage caused
by non-Motorola batteries and/or chargers.
Caution: Use of an unqualified battery or
charger may present a risk of fire, explosion,
leakage, or other hazard. Improper battery
use, or use of a damaged battery, may result
in a fire, explosion, or other hazard.
• Battery usage by children should be
supervised.
• Important: Motorola mobile devices are
designed to work best with qualified batteries.
If you see a message on your display such as
Invalid Battery or Unable to Charge , take the following
steps:
• Remove the battery and inspect it to
confirm that it bears a Motorola “Original
Equipment” hologram;
• If there is no hologram, the battery is not
a qualified battery;
• If there is a hologram, replace the battery
and retry charging it;
• If the message remains, contact a
Motorola Authorized Service Center.
• New batteries or batteries stored for a long
time may take more time to charge.
• Charging precautions: When charging your
battery, keep it near room temperature. Never
expose batteries to temperatures below 0°C
(32°F) or above 45°C (113°F) when charging.
Always take your mobile device with you
when you leave your vehicle.

11
essentials
• When storing your battery, keep it in a cool,
dry place.
• It is normal over time for battery life to
decrease, and for the battery to exhibit shorter
runtime between charges or require more
frequent or longer charging times.
• Avoid damage to battery and mobile
device.
Do not disassemble, open, crush,
bend, deform, puncture, shred, or submerge
the battery or mobile device. Avoid dropping
the battery or mobile device, especially on a
hard surface. If your battery or mobile device
has been subjected to such damage, take it to
a Motorola Authorized Service Center before
using. Do
not attempt to dry it with an
appliance or heat source, such as a hair dryer
or microwave oven.
• Use care when handling a charged
battery
—particularly when placing it inside a
pocket, purse, or other container with metal
objects. Contact with metal objects (such as
jewelry, keys, beaded chains) could complete
an electrical circuit (short circuit), causing the
battery to become very hot, which could
cause damage or injury.
Promptly dispose of used batteries in
accordance with local regulations. Contact
your local recycling center for proper battery
disposal.
Warning: Never dispose of batteries in a fire because
they may explode.

12
essentials
battery installation
battery charging
New batteries are
not fully charged.
Plug the battery
charger into your
phone and an
electrical outlet.
Your phone might take several seconds to start
charging the battery. Your display shows
Charge Complete
when finished.
Tip: Relax, you can’t overcharge your battery. It will
perform best after you fully charge and discharge it a
few times.
turn it on & off
To turn on your phone, press
and hold
O for a few
seconds or until the display
turns on. If prompted, enter
your four-digit unlock code.
To turn off your phone, press and hold
O for two
seconds.
12
3

13
essentials
make a call
Enter a phone number and press N to make a call.
To “hang up,” close the flip or press
O .
answer a call
When your phone rings and/or vibrates, just open the
flip or press
N to answer.
To “hang up,” close the flip or press
O .
store a phone number
You can store a phone number in Contacts :
1 Enter a phone number in the home screen.
2 Press Store .
3 Select Create New Contact , if necessary.
4 Enter a name and other details for the phone
number. To select a highlighted item, press the
Center Key
s .
5 Press Done to store the number.
To edit or delete a
Contacts entry, see page 39.
To store an email address:
Find it: s > n Contacts > [Create New Contact]
>
Email Address
Enter the new contact’s name and email address
information.
call a stored phone
number
Find it: s > n Contacts
1 Scroll to the Contacts entry.

14
essentials
Shortcut: In Contacts , press keypad keys to enter
the first letters of an entry you want. You can also
press
* and # to see the entries you use
frequently, or entries in other categories.
2 Press N to call the entry.
your phone number
Find it: s > w Settings > Phone Info > My Number
Tip: Want to see your phone number while you’re on
a call? Press
Options > My Number .

15
main attractions
main attractions
You can do much more with your phone than make
and receive calls!
send message
Find it: s > e Messaging > New TXT Msg
1 Scroll to the name of a Contacts entry and press the
Center Key
s .
or
Scroll to [New Phone Number] or [New Email Address] and
press the Center Key
s to enter a new phone
number or email address.
2 Press NEXT to go to the Create screen.
3 Enter the text of the message.
Press
OPTIONS to display a list of message options
(see the table following these steps).
4 When you finish entering the message, press the
Center Key
s .
Your phone displays the
Send screen, with the Call
entry area highlighted.
5 To change the callback number, type a new
number, then press
OK when finished.
6 Scroll to the Priority entry area, then scroll left or
right to select
Normal or Urgent .
7 Scroll to the Receipt entry area, then scroll left or
right to select
Yes or No .
8 Press SEND to send the message.
or

16
main attractions
Select OPTIONS to see details about the message,
schedule the message to be sent later, or save
the message to the
Drafts folder.
Press
OPTIONS from the Create screen to display the
following selections:
options
PREVIOUS Go to the contact selection
screen.
Insert Enter Quick Notes, Pictures, or Sounds.
Entry Mode
Set the current entry mode (see
page 21).
Entry Setup Specify the default primary and
secondary entry modes (see
page 21).
Cut Cut message text:
Select
Cut , scroll to highlight the
message text you wish to cut,
then press the Center Key
s .
Copy Copy message text:
Select
Copy , scroll to highlight the
message text you wish to copy,
then press the Center Key
s .
Paste Paste cut or copied text into the
message, at the cursor location.
Format Text Format message text that
you enter:
Underline , Bold , Italic ,
Color , Align .
options

17
main attractions
cable connections
Your phone has a
mini-USB port so
you can connect it to a
computer.
If you use a USB cable
connection:
• Make sure to connect the phone to a
high-power USB port on your computer (not a
low-power one such as the USB port on your
keyboard or bus-powered USB hub). Typically,
USB high-power ports are located directly on
your computer.
Note: If you connect your phone to a
low-power USB port, the computer may not
recognize your phone.
• Make sure both your phone and the computer
are turned on.
TTY operation
You can use an optional TTY device with your phone to
send and receive calls. You must plug the TTY device
into the phone’s headset connector and set the phone
to operate in one of three TTY modes.
Note: Use a TSB-121 compliant cable (provided by the
TTY manufacturer) to connect the TTY device to your
phone.
Note: Set the phone to level 4 (middle setting) for
proper operation. If you experience a high number of
incorrect characters, adjust the volume as needed to
minimize the error rate.
Note: For optimal performance, your phone should be
at least 12 inches (30 centimeters) from the TTY
device. Placing the phone too close to the TTY device
may cause high error rates.

18
main attractions
set TTY mode
ù When you set your phone to a TTY mode, it
operates in that mode whenever the TTY device is
connected:
Find it: s > w Settings > Initial Setup > TTY Setup
TTY Setup
can include these options:
When your phone is in a TTY mode, your phone
displays the international TTY mode, the international
TTY symbol, and the mode setting during an active
TTY call.
return to voice mode
To return to standard voice mode, select Voice from the
TTY Setup menu.
option
Voice Return to standard voice mode.
TTY Transmit and receive TTY characters.
VCO Receive TTY characters but transmit by
speaking into microphone.
HCO Transmit TTY characters but receive by
listening to earpiece.
