Motorola DSP56824ADM User manual

Motorola, Incorporated
Semiconductor Products Sector
6501 William Cannon Drive West
Austin TX 78735-8598
DSP56824ADM User’s Manual
Order this document by
DSP56824ADMUM/D
Rev. 1.1, 3/1999

©MOTOROLA INC., 1998. All rights reserved.
This document contains information on a new product. Specifications and information herein are subject to change
without notice.
Motorola reserves the right to make changes without further notice to any products herein to improve
reliability, function, or design. Motorola does not assume any liability arising out of the application or use
of any product or circuit described herein; neither does it convey any license under its patent rights nor the
rights of others. Motorola products are not designed, intended, or authorized for use as components in
systems intended for surgical implant into the body, or other application in which the failure of the
Motorola product could create a situation where personal injury or death may occur. Should Buyer
purchase or use Motorola products for any such unintended or unauthorized application, Buyer shall
indemnify and hold Motorola and its officers, employees, subsidiaries, affiliates, and distributors harmless
against all claims, costs, damages, and expenses, and reasonable attorney fees arising out of, directly or
indirectly, any claim of personal injury or death associated with such unintended or unauthorized use,
even if such claim alleges that Motorola was negligent regarding the design or manufacture of the part.
Motorola and are registered trademarks of Motorola, Inc. Motorola, Inc. is an Equal
Opportunity/Affirmative Action Employer
OnCE and Mfax are trademarks of Motorola, Inc.
This manual is one of a set of three documents. You need the following manuals to have
complete product information: the family manual, the user’s manual, and the technical data.

MOTOROLA DSP56824ADMUM/AD iii
TABLE OF CONTENTS
SECTION 1 QUICK START GUIDE. . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.1 DSP56824ADM OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.2 REQUIRED USER-SUPPLIED EQUIPMENT . . . . . . . . . . . . . . 1-3
1.3 INSTALLATION PROCEDURE . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
1.3.1 Preparing the DSP56824ADM. . . . . . . . . . . . . . . . . . . . . . . . 1-4
1.3.2 Installing the Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
1.3.3 Installing the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
1.3.4 Testing the DSP56824ADM Installation . . . . . . . . . . . . . . . . 1-7
SECTION 2 DSP56824ADM TECHNICAL SUMMARY. . . . . . . . . . 2-1
2.1 DSP56824ADM DESCRIPTION AND FEATURES . . . . . . . . . . 2-3
2.2 DSP56824 DESCRIPTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.3 MEMORY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.3.1 Fast Static RAM (FSRAM). . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
2.3.2 Non-Volatile Static RAM (NVSRAM) . . . . . . . . . . . . . . . . . . . 2-6
2.4 VOICE CODEC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
2.5 OTHER DSP56824ADM FEATURES . . . . . . . . . . . . . . . . . . . . 2-6
2.5.1 Clock Oscillator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2.5.2 LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2.5.3 Pushbutton Switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2.5.4 Test Points. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2.6 JUMPER CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2.6.1 Clock Input Selection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
2.6.2 User Clock Oscillator VCC Setting . . . . . . . . . . . . . . . . . . . . . 2-8
2.6.3 Operating Mode Selection. . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
2.6.4 Program Memory Configuration. . . . . . . . . . . . . . . . . . . . . . . 2-9
2.6.5 Data Memory Configuration. . . . . . . . . . . . . . . . . . . . . . . . . 2-12
2.6.6 Codec Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
2.6.6.1 Codec Enabling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
2.6.6.2 Codec Input Connector Signal Selection . . . . . . . . . . . . 2-13
2.6.6.3 Codec Output Connector Signal Selection . . . . . . . . . . . 2-14
2.6.6.4 Codec Output Load Selection. . . . . . . . . . . . . . . . . . . . . 2-14

iv DSP56824ADMUM/AD MOTOROLA
2.6.7 RS-232 Serial Communication Configuration . . . . . . . . . . . 2-14
2.6.8 PB14 Indicator LED Configuration . . . . . . . . . . . . . . . . . . . 2-15
2.6.9 Power Input Selection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
2.6.10 Reset Control Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
2.6.11 PB15 Pull Up/Pull Down Selection . . . . . . . . . . . . . . . . . . . 2-16
2.7 DSP56824ADM CONNECTOR DESCRIPTIONS. . . . . . . . . . 2-17
2.7.1 Expansion Connector 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
2.7.2 Expansion Connector 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19
2.7.3 JTAG/OnCE Connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
2.7.4 Codec Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-22
2.7.5 RS-232 Serial Communication Interface Connector. . . . . . 2-23
2.7.6 Power Source Connector . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
APPENDIX A DSP56824ADM SCHEMATICS . . . . . . . . . . . . . . . . . A-1
APPENDIX B DSP56824ADM BILL OF MATERIALS . . . . . . . . . . . B-1
B.1 ELECTRICAL PARTS LIST. . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
B.2 HARDWARE PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-6

MOTOROLA DSP56824ADMUser’sManual v
LIST OF FIGURES
Figure 1-1 DSP56824ADM Quick Jumper Reference . . . . . . . . . . . . . . . . . . . . 1-5
Figure 1-2 Application Development. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Figure 2-1 DSP56824ADM Functional Block Diagram. . . . . . . . . . . . . . . . . . . . 2-5
Figure 2-2 RS-232 Serial Communication Options. . . . . . . . . . . . . . . . . . . . . . 2-15

vi DSP56824ADM User’sManual MOTOROLA

MOTOROLA DSP56824ADMUser’sManual vii
LIST OF TABLES
Table 1-1 DSP56824ADM Default Jumper Options . . . . . . . . . . . . . . . . . . . . 1-5
Table 2-1 Clock Source Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Table 2-2 Oscillator VCC Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Table 2-3 Operating Mode Selection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Table 2-4 Program Memory Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Table 2-5 Data Memory Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
Table 2-6 Codec Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
Table 2-7 Codec Input Signal Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
Table 2-8 Codec Output Signal Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Table 2-9 Codec Output Selection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Table 2-10 Serial Communication Configuration. . . . . . . . . . . . . . . . . . . . . . . . 2-15
Table 2-11 PB14 LED Drive Selection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
Table 2-12 Power Input Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
Table 2-13 RESET Selection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
Table 2-14 PB15 Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
Table 2-15 DSP56824ADM Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
Table 2-16 DSP56824ADM J1 Bus Connector Description . . . . . . . . . . . . . . . 2-18
Table 2-17 DSP56824ADM J2 Bus Connector Description . . . . . . . . . . . . . . . 2-19
Table 2-18 DSP56824ADM J3 JTAG/OnCE Description . . . . . . . . . . . . . . . . . 2-21

viii DSP56824ADM User’sManual MOTOROLA
Table 2-19 DSP56824ADM J4 Line In Description . . . . . . . . . . . . . . . . . . . . . .2-22
Table 2-20 DSP56824ADM J5 Line Out Description . . . . . . . . . . . . . . . . . . . . .2-22
Table 2-21 DSP56824ADM Serial Connector Description. . . . . . . . . . . . . . . . .2-23
Table 2-22 DSP56824ADM J7 Power Source Connector Description. . . . . . . .2-23

MOTOROLA DSP56824ADMUser’sManual 1-1
SECTION 1
QUICK START GUIDE

1-2 DSP56824ADM User’sManual MOTOROLA
Quick Start Guide
1.1 DSP56824ADM OVERVIEW. . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.2 REQUIRED USER-SUPPLIED EQUIPMENT . . . . . . . . . . . . . . 1-3
1.3 INSTALLATION PROCEDURE. . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Quick Start Guide
DSP56824ADM Overview
MOTOROLA DSP56824ADMUser’sManual 1-3
1.1 DSP56824ADM OVERVIEW
The DSP56824 Application Development Module (DSP56824ADM) was designed to
operate with the Motorola Application Development System (ADS). Use of the
DSP56824ADM with the Motorola ADS facilitates development, debug, and test of
complex software applications and hardware products designed for the DSP56824.
Detailed information about the Motorola ADS is provided in the Motorola ADS User’s
Manual (order # DSPADSUM/AD).
Subsection 1.2 of this document gives a summary description of the equipment required
to use the module with the Motorola ADS.
Subsection 1.3 describes installation instructions, including the following:
• Preparing the module for installation
• Installing the module
• Installing the software
• Testing the installation
Note: Detailed information about the design and operation of the DSP56824ADM is
provided in this manual in Section 2 and Appendices A and B.
1.2 REQUIRED USER-SUPPLIED EQUIPMENT
For use with the Motorola ADS (and the appropriate interface card), the user must
supply one of the following host computer systems:
• PC-compatible computer (486 class or higher) with the following:
– MS-DOS version 6.0 or later, Windows 3.1 or later, or Windows 95
– 8 Mbytes RAM
– One open 16-bit ISA expansion slot
– One bank of free I/O addresses in the range of $100–$102, $200–202, or
$300–$303
– CD-ROM drive
– Hard drive with 4 Mbytes of free disk space
–Mouse

1-4 DSP56824ADM User’sManual MOTOROLA
Quick Start Guide
Installation Procedure
• Hewlett Packard HP7xx Workstation running HPUX Version 9.x (Version 10.x is
not supported), one open EISA expansion slot, CD-ROM drive, and a mouse
• Sun Microsystems Sun 4 Workstation running Sun Operating System Release
4.1.1 or later (or Solaris Release 2.5 or later), one open SBus expansion slot, a
CD-ROM drive, and a mouse
1.3 INSTALLATION PROCEDURE
Installation requires four basic steps:
1. Preparing the DSP56824ADM board
2. Installing the module
3. Installing the software
4. Testing the installation
1.3.1 Preparing the DSP56824ADM
Locate the jumper blocks JG1–JG17 on the DSP56824ADM board, as shown in Figure 1-1.
Table 1-1 describes the jumper group settings for use with the Motorola ADS. Read the
CAUTION
Because all electronic components are sensitive to the effects of
electrostatic discharge (ESD) damage, correct procedures should be
used when handling all components in this kit and inside the
supporting personal computer. Use the following procedures to
minimize the likelihood of damage due to ESD:
– Always handle all static-sensitive components only in a protected area,
preferably a lab with conductive (anti-static) flooring and bench surfaces.
– Always use grounded wrist straps when handling sensitive components.
– Never remove components from anti-static packaging until required for
installation.
– Always transport sensitive components in anti-static packaging.

Quick Start Guide
Installation Procedure
MOTOROLA DSP56824ADMUser’sManual 1-5
technical summary in Section 2 of this manual for additional information about the
DSP56824ADM board and its components.
Figure 1-1 DSP56824ADM Quick Jumper Reference
Table 1-1 DSP56824ADM Default Jumper Options
Jumper
Group Comment Jumpers
Connections
JG1 Selects oscillator (U14) for clock input 1–2
JG2 Selects Mode 2 operation upon exit from reset 1–2
JG3 Selects Program memory with external Non-Volatile Static RAM
(NVSRAM) 5–6
JG4 Selects Data memory 1–2, 3–4
JG5 Selects on-board codec 1–2, 3–4,
5–6, 7–8
JG6 Reserved NC
JG7 Selects serial port connection to DSP 3–5, 4–6
JG8 Selects codec High Bandpass mode 2–3
1
2
3
4
CLK SEL
JG1
JG10
3
4
1
2
JG2
MODESEL
7
8
1
2
JG5
1
JG9 3
CLK VCC SEL
AA1651
5
6
1
2
JG3
5
6
1
2
JG4
JG6
JG13
JG12 JG15 JG17
5
6
1
2
JG7
1
JG8 3
7
8
1
2
JG14
JG16
1
JG11 3
SER SEL

1-6 DSP56824ADM User’sManual MOTOROLA
Quick Start Guide
Installation Procedure
1.3.2 Installing the Module
Figure 1-2 shows the interconnection diagram for connecting the PC to the
DSP56824ADM board. Using the instructions in the ADS User’s Manual, connect the
Command Converter to the DSP56824ADM board. Power for the DSP56824ADM is
supplied from an external 9–12 VDC power supply.
JG9 Selects 8-pin oscillator VCC = +5 V 2–3
JG10 Selects high input frequencies NC
JG11 Selects codec output to 1.7 V peak @ 300Ω1–2
JG12 Selects PB14 Light-Emitting Diode (LED) 1–2
JG13 Selects external NVSRAM 32K ×16 1–2
JG14 Power in to 3.3 V and 5 V regulators 3–4, 5–6, 7–8
JG15 Enable on-board reset logic 1–2
JG16 Codec input mono NC
JG17 Codec output mono on both channels (left and right) 1–2
Figure 1-2 Application Development
Table 1-1 DSP56824ADM Default Jumper Options (Continued)
Motorola DSP
37-pin
Host-Bus
Interface Card
Host Computer
Command
Interface
Cable
14-pin
Ribbon
Cable
Converter
DSP56824ADM AA1551
Power
Supply

Quick Start Guide
Installation Procedure
MOTOROLA DSP56824ADMUser’sManual 1-7
1.3.3 Installing the Software
Refer to the Motorola Application Development System User’s Manual for detailed
instructions about installation and use of the ADS software.
1.3.4 Testing the DSP56824ADM Installation
Refer to the Motorola Application Development System User’s Manual for detailed
information regarding evaluation and testing of an installed ADS system.

1-8 DSP56824ADM User’s Manual MOTOROLA
Quick Start Guide
Installation Procedure

MOTOROLA DSP56824ADMUser’sManual 2-1
SECTION 2
DSP56824ADM TECHNICAL SUMMARY

2-2 DSP56824ADM User’s Manual MOTOROLA
DSP56824ADM Technical Summary
2.1 DSP56824ADM DESCRIPTION AND FEATURES. . . . . . . . . . 2-3
2.2 DSP56824 DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.3 MEMORY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.4 VOICE CODEC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
2.5 OTHER DSP56824ADM FEATURES . . . . . . . . . . . . . . . . . . . . 2-6
2.6 JUMPER CONFIGURATION. . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2.7 DSP56824ADM CONNECTOR DESCRIPTIONS. . . . . . . . . . 2-17

DSP56824ADM Technical Summary
DSP56824ADM Description and Features
MOTOROLA DSP56824ADMUser’sManual 2-3
2.1 DSP56824ADM DESCRIPTION AND FEATURES
The DSP56824ADM is designed as a versatile Digital Signal Processor (DSP)
development card that can be used with the Motorola Applications Development
System (ADS) and can also be plugged into other cards to permit special user
configurations. Two 70-pin connectors, J1 and J2, located on the bottom of the Printed
Circuit Board (PCB), allow access to all the DSP signals, including VDD (3.3 V) and
VSS (GND). An overview description of the DSP56824ADM is also provided in the
DSP56824ADM Product Information (DSP56824ADMP/D) included with this kit. The
main features of the DSP56824ADM include the following:
• DSP56824 16-bit DSP
• External Fast Static RAM (FSRAM) memory
– 64K ×16 program memory
– 64K ×16 data memory
• 32K ×16 External Non-Volatile Static RAM (NVSRAM) memory
• 13-bit linear codec with voice input and output jacks
• Socketed on-board 10-MHz oscillator for DSP system clock
• Manual DSP reset button S1
• Manual interrupt button S2 for IRQA
• Light Emitting Diode (LED) power indicator (LED1)
• LED for user debug operations (LED2)
• Two on-board 70-pin expansion connectors
• Joint Test Action Group (JTAG) port connector for Motorola’s ADS that provides
an enhanced development environment including a high-speed data transfer port
to a host PC ISA bus
2.2 DSP56824 DESCRIPTION
A full description of the DSP56824, including functionality and user information, is
provided in the following documents included as a part of this kit (either as printed
copies or on the documentation CD-ROM):

2-4 DSP56824ADM User’s Manual MOTOROLA
DSP56824ADM Technical Summary
Memory
• DSP56824 Technical Data (DSP56824/D):Provides features list and
specifications including signal descriptions, dc power requirements, ac timing
requirements, and available packaging
• DSP56824 User’s Manual (DSP56824UM/AD): Provides an overview description
of the DSP and detailed information about the on-chip components including the
memory and I/O maps, peripheral functionality, and control and status register
descriptions for each subsystem
• DSP56800 Family Manual (DSP56800FM/AD): Provides a detailed description of
the core processor including internal status and control registers and a detailed
description of the family instruction set
Refer to these documents for detailed information about chip functionality and
operation.
2.3 MEMORY
The DSP56824ADM uses the following memory external to the DSP56824:
• 64K ×16-bit FSRAM for external program memory
• 64K ×16-bit FSRAM for external data memory
• 32K ×16-bit NVSRAM program memory
Figure 2-1 shows a functional block diagram of the DSP56824ADM including the
memory devices.
