Moulinex 043-2214-8 User manual

12-CUP FOOD PROCESSOR
043-2214-8
ROBOT CULINAIRE DE 12 TASSES
www.moulinex.ca
EN FR
USER GUIDE
GUIDE DE L’UTILISATEUR
If you have any questions or concerns please call our Moulinex
toll-free number at 1-888-670-6681.
Si vous avez des questions ou des préoccupations, veuillez
appeler notre numéro sans frais Moulinex au 1-888-670-6681.

contents
important safeguards
product diagram
operating your food processor
care and cleaning
recipes
04
06
09
17
19
importantes mises en garde
pièces et caractéristiques
fonctionnement du robot culinaire
entretien et nettoyage
recettes
24
26
29
37
39
contenu

4
EN
When using electrical appliances, basic safety precautions
should always be followed, including the following:
1. Read all instructions.
2. To protect against risk of electrical shock, DO NOT put base, cord,
or plug in water or other liquid.
3. Close supervision is necessary when any appliance is used by or
near children.
4. Turn unit off and unplug from outlet when not in use, before put
ting on or taking off parts, and before cleaning. To disconnect,
turn unit off, grasp plug, and pull out from wall outlet.
Never yank on cord.
5. Avoid contact with moving parts.
6. DO NOT operate any appliance with a damaged cord or plug or
after the appliance malfunctions or has been damaged in any
manner. Return the appliance to an authorized service facility for
examination, repair, or electrical/mechanical adjustment.
7. The use of attachments not recommended or sold by the appliance
manufacturer may cause fire, electric shock, or injury.
8. DO NOT use outdoors.
9. DO NOT let cord hang over the edge of a table or counter or touch
hot surfaces.
10. Keep hands and utensils away from moving blades or Discs while
the unit is processing food, to prevent the possibility of severe
personal injury or damage to the food processor. A scraper may be
used but must be used only when the food processor is not
IMPORTANT SAFEGUARDS

5
EN
running.
11. Blades are sharp. Handle carefully.
12. Be sure to insert or remove Multipurpose/Chopping blade and
Slice/Shred Disc by using hubs to avoid injury.
13. To avoid injury, never place Multipurpose/Chopping blade or Slice/
Shred Disc on Base without first putting Bowl properly in place.
Make sure motor, Disc, and/or Multipurpose/Chopping blade have
stopped completely before removing cover.
14. Be certain cover is securely locked in place before operating
appliance.
15. Never feed food into chute by hand. Always use Food Pusher.
16. DO NOT operate this appliance in the presence of explosive and/or
flammable fumes.
17. DO NOT attempt to defeat the cover interlock mechanism.
18. DO NOT use the food processor to process hot liquids
19. DO NOT leave the appliance unattended while it is running.
20. Keep fingers out of discharge opening.
21. This appliance has Overload Protection. When working for too
long, the motor will stop working automatically, protecting the
appliance from overheating by cooling it down. The appliance
will work again when the motor cools down for about 5 minutes.
22. This appliance is for Household Use Only.
Toll free number for Moulinex: 1-888-670-6681

6
EN PRODUCT DIAGRAM
Food chute
Small food pusher
Big food pusher
Bowl cover
Bowl
Base
1. Big food pusher
2. Small food pusher
3. Disc Stem
4. Thin Slice/Shred
5. Multipurpose/Chopping blade
6. Dough Blade
7. Spatula
1 2 3
4
5 6 7

7
EN
Control Panel
1. Pulse
2. On
3. Off
Pulse
Pulse button must be pressed and held for unit to
operate. When released, unit will stop. Use PULSE for short
processing tasks, such as chopping nuts, raw meats, or vegetables.
This lets you check processed results and control the size.
On
When this button is pressed, unit runs continuously until
OFF button is pressed.
Off
Processor should always be left in OFF position when unit is
not in use.
PREPARING TO USE YOUR FOOD PROCESSOR
BEFORE FIRST USE
 •Whenunpackingtheproductandremovingpackingmaterial,
handle the Multipurpose/Chopping blade, and Slice/Shred Disc
carefully; they are very sharp.
 •WashallpartsexcepttheBaseinhot,soapywater.Rinsethem
dry. These parts can also be placed in the dishwasher. Be sure
Pulse On Off

8
EN
to read this Use & Care Book, paying special attention to the
sections on “How to Use” and “Care and Cleaning” to learn the
correct methods for taking the unit apart and cleaning.
Note: DO NOT attempt to chop ice in this food processor; it will
damage container and dull the Multipurpose/Chopping blade. This
unit will not whip cream, beat egg whites to a desirable volume,
grind coffee beans or spices with high oil content, or slice or
shred hard-cooked eggs, marshmallows, or soft cheeses.
Important: For your protection, this unit has an interlock system.
The processor won’t operate unless the bowl is properly locked
onto base and cover is properly locked onto the bowl. Be sure to
attach the bowl to the base before attaching the food chute Lid
on the bowl. Lid should be in the lock position. DO NOT attempt
to operate the unit without the bowl lid, bowl and food chute Lid
being correctly in place. Be sure base is on a flat, dry and clean
surface before you begin processing.

9
EN
OPERATING YOUR FOOD PROCESSOR
HOW TO ASSEMBLE THE BOWL
Align the base and bowl as illustrated in Fig.
1, then turn the bowl counterclockwise until it
clicks into the base.
Note: There is only one position for the bowl to
lock onto the base. The food processor will not
operate unless the bowl is securely locked onto
the base.
HOW TO LOCK THE COVER
Open the food chute lid (see “How to open food
chute lid”). Place the cover onto the bowl, align
the mark on the cover, twist the cover counter-
clockwise towards until it clicks into the bowl,
as illustrated in the Fig. 2.
Note: When cover is locked into position, the
safety mechanism on the cover and bowl will
align. The food processor will not operate unless
the cover is securely locked onto the bowl.
Fig.1
Fig.2
Bowl
Base
Cover
Bowl

10
EN
THE IMPORTANCE OF BIG FOOD PUSHER
Put the big food pusher into the food chute. As
illustrated in Fig. 3.
Fig.3
When processing large food, the big food pusher
has to be pushed into the food chute. As
illustrated in Fig. 4.
Note: The food processor will not operate unless
the big food pusher is latched onto the food
chute.
Fig.4
When processing long and thin food, the big
food pusher has to be completely pushed into
the food chute before putting foods into food
chute. As illustrated in Fig. 5.
Note: The food processor will not operate unless
the big food pusher is latched onto the food
chute.
Fig.5

11
EN
HOW TO CHOP
Note: Make sure the unit is turned OFF and unplugged
before using. Process the food into 1 inch (2.5cm) pieces.
1. Lock the bowl onto base. (See “How to assemble the bowl ”.)
2. Grasp the Multipurpose/Chopping blade by its center shaft and
slide it down onto the center post. (Fig. 6)
3. Place food into bowl.
4. Lock cover onto bowl. (See “How to lock the cover”.)
5. Push the big food pusher into the food chute.
(See “The Importance of Big Food Pusher”)
6. Plug the cord into an electric outlet. .
7. Push the ON button to run constantly, or for better control over
consistency, push and hold PULSE button. When pulsing, hold
the PULSE position for about 2-3 seconds, check result, and
repeat for desired consistency.
8. When finished processing food, release from the PULSE position,
or if you were using continuous ON, press OFF, allow the chopping
Fig.6
Chopping
Blade

12
EN
blade to stop rotating.
Note: Before opening the Bowl Cover Assembly, press the OFF
Button and unplug the cord.
9. To remove bowl cover, unlock by turning clockwise until cover
unlatches, and lift off.
10. Take out food pusher, then twist the food chute/cover towards
“UNLOCK”to remove the cover.
11. Grasp the Chopping Blade by its shaft and remove. Unlock the
bowl by turning it clockwise towards the UNLOCK, and lift it off.
Empty the processed food.
CAUTION Chopping Blade is very sharp, must be
careful when handling.
HOW TO SLICE OR SHRED
CAUTION Make sure the unit is turned OFF and unplugged
before using. NEVER use your hand instead of Food Pusher to push food
directly. The use of heavy pressure will not speed up operation.
DO NOT use the processor continuously for more than 3 minutes at a
time. Please allow a rest period of 5 minutes between working cycles.
Fig.7
Disc

13
EN
PROCESS LARGE FOOD
1. Lock the bowl onto base. (see “How to assemble the bowl”.)
2. Slide the disc stem down onto the center post of the base, then
grasp the slice/shred disc (CAUTIONIt’s very sharp! Be
careful when handling!), with the desired side facing up for
either slicing or shredding, push it down onto the disc stem (Fig.7).
3. Lock cover onto bowl.
4. Fill the food chute with large food such as potatoes, chunks of
cabbage, green peppers, and whole tomatos (Fig. 8). Push the
big food pusher into the Food Chute, making sure the big food
pusher latched into the food chute. (See “The Importance of Big
Food Pusher”).
5. Plug the cord into an electrical outlet.
Fig.8
Large foods

14
EN
Fig.9
6. Firmly press on the ON speed button, then press down lightly but f
irmly on food pusher. (Fig. 9)
7. When food chute is empty, press OFF and allow the disc to stop
rotating.
CAUTION Before opening the Bowl Cover Assembly,
turn the unit OFF and unplug
TO PROCESS LONG AND THIN FOODT
1. Lock the bowl onto base. (See “How to assemble the bowl”.)
Fig.10
Disc

15
EN
2. Slide the disc stem down onto the center post of the base, then
grasp the slice/shred disc (CAUTION It’s very sharp! Be
careful when handling!), with the desired side facing up for either
slicing or shredding, push it down onto the disc stem (Fig.10).
3. Lock cover onto bowl. (See “How to lock the Cover”.)
4. Push the big food pusher into the food chute.
(See “The Importance of Big Food Pusher”)
Fig.11
5. Fill the big food pusher/food chute with long and thin food such
as potatoes, pepperoni, carrots, and celery. (Fig.11)
6. Firmly press on the ON speed button, then press down lightly but
firmly on food pusher.
7. When finishing processing, press OFF, allow the disc to stop
rotating, and twist the food chute/cover towards UNLOCK to
remove the cover.
Push
Thin foods

16
EN
USING THE DOUGH BLADE
1. The dough blade can mix and knead dough in a fraction of the
time it takes to do it by hand.
2. Typical bread dough is made with a flour mixture that contains at
least 50% white flour. It is uniformly soft, pliable and slightly
sticky when properly kneaded. Properly kneaded bread dough
doesn’t adhere to the inside of the work bowl.
3. Typical sweet dough contains a higher proportion of sugar, butter
and/or eggs than typical bread dough. It is rich and sticky, and
will adhere to the inside of the work bowl. It requires less
kneading after the ingredients are mixed.
DO NOT try to use the food processor to knead dough that is too
stiff to knead comfortably by hand.
PROCESSING HOT FOODS
Hot foods under than 80°C can be processed in the bowl. Anything
over this temperature is too hot and should not be processed with this
unit.
CAUTION DO NOT use the food processor to process hot
liquids kneading after the ingredients are mixed.

17
EN
CARE AND CLEANING
NOTE: DO NOT attempt to sharpen the cutting edges of the Multi-
purpose/Chopping blade or the reversible disc. They are permanently
sharpened at the factory and will be ruined by attempted sharpening.
1. Before cleaning, be sure the unit is switched off and the cord is
unplugged.
2. Whenever possible, rinse parts immediately after processing for
easy cleanup.
3. Wipe the base, control knob, and feet with a damp cloth and dry
thoroughly. Stubborn spots can be removed by rubbing with a
damp cloth and a mild, non-abrasive cleaner. DO NOT immerse the
base in liquid.
4. All removable parts can be washed by hand or placed on the top
rack of a dishwasher.
If washing by hand, wash in hot, sudsy water, rinse, and dry
thoroughly. If necessary, use a small nylon bristle brush to
thoroughly clean the bowl and food chute/cover. This type of
brush will also help prevent cutting yourself on the Multipurpose/
Chopping blade and slice/shred disc.
If washing in a dishwasher, place removable parts on the top rack
only-not in or near the utensil basket.
5. DO NOT use rough scouring pads or cleansers on any plastic or
metal parts.
6. DO NOT fill the bowl with boiling water or place any of the parts in
boiling water. Some foods, such as carrots, may temporarily stain the
bowl. To remove stains, make a paste of 2 tablespoons (30ml) baking

18
EN
soda and 1 tablespoon (15ml) warm water. Apply the paste to the
stains and rub with a cloth. Rinse in sudsy water and dry.
Any other service should be performed by an authorized service
representative.

19
EN
RECIPES

20
EN
