Overview
The MC-7400 box computer is powered by the 6th generation Intel Core™
i processor, delivering a full range of I/O connectivity, including serial
ports, Gigabit Ethernet ports, NMEA 0183 ports, USB 2.0/3.0 ports, and a
Mini PCI slot for storage expansion. The MC-7400 is designed to provide
outstanding PC performance, bringing a new level of flexibility and control
to marine applications.
Package Checklist
Before installing the MC-7400, verify that the package contains the
following items:
•MC-7400 embedded computer
•Terminal block to power jack converter
•Wall-mounting kit
•Quick installation guide (printed)
•Documentation
•Warranty card
Please notify your sales representative if any of the above items are
missing or damaged.
MC-7410 AC Model Panel Layout
MC-7410 DC Model Panel Layout

- 3 -
MC-7420 AC Model Panel Layout
MC-7420 DC Model Panel Layout
LED Indicators
The following table describes the LED indicators located on the front panel
of the MC-7400:
Real-time Clock
The embedded computer’s real-time clock is powered by a lithium battery.
We strongly recommend that you do NOT replace the lithium battery
yourself. If the battery needs to be changed, contact the Moxa RMA
service team at http://www.moxa.com/rma/about_rma.aspx.

- 4 -
ATTENTION
Used batteries are env
ironmentally hazardous; dispo
se of them
in the proper manner.
WARNING
There is a risk of explosion if the wrong type of battery is used. To
avoid this potential danger,
be sure to use the correct type of
battery.
Contact the Moxa RMA service team if you have any
questions about replacing your battery.
LED Name
Status
Description
Power
Green
Power is on and computer is functioning
normally
Off Power is off
Storage
Yellow Blinking: Data transmission
Off No data transmission.
Tx 1/2/3/4
Green
Blinking: Data is being transmitted.
Off
No connection
Rx 1/2/3/4
Yellow
Blinking: Data is being transmitted.
Off
No connection
Installing the MC-7400
Wall Mounting
The MC-7400 can be installed on a wall by using the wall-mounting kit.
STEP 1: Use eight screws for each bracket and attach the brackets to the
rear of the MC-7400.

- 5 -
STEP 2: Use two screws (Ø3.7 mm, 60 mm in length) per side to attach
the MC-7400 to a wall or cabinet.
Connector Description
Power Connector
The MC-7400 comes with a 100 to 240 VAC power
input or a 24 VDC power input (via the terminal
block). If power is supplied properly, the Power
LED will light up.
NOTE
The DC model should be suppli
ed by a UL-listed power source,
whose
output meets the ES1 standard and is rated at 24 VDC,
4.06
A (min.) If you need further assistance selecting a power
source, contact a Moxa representative.
Grounding the MC-7400
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from the
grounding screw (M6) to the grounding surface prior to connecting the
power as shown in the illustrations below:
NOTE
A 4 mm2conductor must be used when the connection to the
external grounding screw is utilized. The heat sink is grounded to
the chassis by an internal screw.

- 6 -
Ethernet Ports
The 10/100/1000 Mbps Ethernet ports use RJ45 connectors.
Pin
10/100 Mbps
1000 Mbps
1
ETx+
TRD(0)+
2
ETx-
TRD(0)-
3
ERx+
TRD(1)+
4
–
TRD(2)+
5
–
TRD(2)-
6
ERx-
TRD(1)-
7
–
TRD(3)+
8
–
TRD(3)-
Serial Ports
The serial ports use DB9 connectors. Each port can be configured by
software for RS-232, RS-422, or RS-485 port. The pin assignments for
the ports are shown in the following table:
Pin RS-232 RS-422
RS-485
(4-wire)
RS-485
(2-wire)
1
DCD
TxDA(-)
TxDA(-)
–
2
RxD
TxDB(+)
TxDB(+)
–
3
TxD
RxDB(+)
RxDB(+)
DataB(+)
4
DTR
RxDA(-)
RxDA(-)
DataA(-)
5
GND
GND
GND
GND
6
DSR
–
–
–
7
RTS
–
–
–
8
CTS
–
–
–
Display Outputs
For connecting display monitors, the MC-7400 comes with 1 DisplayPort,
1 DVI-I interface, and 1 DVI-D interface. The DisplayPort supports a
maximum resolution of 4096 x 2304 @ 60 Hz and the DVI interface
supports a maximum resolution of 1920 x 1200 @ 60 Hz.
Removable Storage Tray
The MC-7400 computer has two removable SSD trays on the front panel.
The default boot priority is the SSD 1 slot first.
NMEA 0183 Ports (MC-7420)
By default, the MC-7420 comes with 4 NMEA 0183 ports. You can expand
it to 8 NMEA 0183 ports. See the following figure for the NMEA pin outs.
Digital Input/Output Channels (MC-7420)
The MC-7400 comes with 4 digital input and 4 digital output channels. The
interface could be expanded to 8 digital input and 8 digital output
channels. You can connect to the input/output channels using the
terminal blocks included in the package. See the following figure for the
pin assignments.

- 7 -
Power ON/OFF Switch
The MC-7400 comes with a power ON/OFF switch on the front panel. You
can use the 2-pin terminal block on the power ON/OFF switch to boot up
a computer installed inside a marine console.
USB Hosts
The MC-7400 has five USB 2.0 and four SuperSpeed USB 3.0 type A ports
and support xHCI/ EHCI mode for full high-speed bandwidth. The USB
ports support peripherals like keyboards, mice, and other devices such as
portable HDDs or DVD-ROMs.
Audio Interface
The MC-7400 comes with an audio line-out, and a microphone input,
allowing users to connect a speaker system, an earphone, or a
microphone.
