MP-Man MP-CS155 User manual

DIGITAL VIDEO / MUSIC PLAYER
MP3/WMA/AMV
USER MANUAL
MP-CS155
www.mpmaneurope.com
___________________________________________________________________
Before connecting, operating or adjusting this product please read these
instructions completely.

1
UP TILL 99 SONGS IN ONE DIRECTORY
YOUR MP-CS155 ACCEPTS
UPTILL 99 SONGS IN ONE DIRECTORY
IF YOU WANT MORE THEN 99 SONGS,
STORE THEM IN A NEW DIRECTORY
IN PLAY MODE, YOU CAN CHANGE THE DIRECTORY
IN THE MENU.
DON’T FORGET: MAXIMUM 99 SONGS IN EACH DIRECTORY

2
1.1The player characteristics
♠MP3 / WMA music format.
♠AMV movie format
♠JPEG picture format
♠65K full color display
♠Voice recorder
♠GUI (graphical user interfaces).
The box:
(1) MP3 player 1Pcs
(2) Stereo earphone 2Pcs
(3) CD ROM 1Pcs
(4) Quick guide 1Pcs
(5) USB cable 1Pcs
(6) Charger 1Pcs
PC needs
(1) Pentium 100 MHz or faster
(2) Windows 98/2000/ ME/XP
(3) USB port
(4) CD- ROM driver
(5) 15MB of free space on harddisk
(6) 32 MB RAM

3
1.2 The player appearance interface

4
1.3 Figure & Keys
1) Earphone jack,
2) USB Port
3) Power ON/OFF,
4) 65 K color display
5) Previous, Vol-
6) Next, Vol+
7) Menu
8) A-B recording
9) Play/pause
10) Microphone
1.4 Display
65000 colors OLED display
1.5Battery
The screen shows a battery indicator with nine levels.
The battery is full when the battery voltage is 1.5V.
The battery indicator will be empty when the battery is used up. At that time,
the player should be charged with an external charger(optional) or with
the USB connection on your PC

5
2 Operating instruction
2.1 Turning on/off the MP3 player
Slide ON/OFF switch to the right. The OLED display will light up.
Slide ON/OFF switch to the left. The MP3 player will shut off.
2.2 Main menu
Press the “Menu” button for several seconds, from any point in the menu,
and the player returns automatically back to the main menu.
Six options:
- 1) MUSIC
- 2) MOVIE
- 3) RECORD
- 4) VOICE
- 5) JPG VIEW
- 6) SETTING
You can switch between options by pushing “Next/Vol+” or “Prev/Vol-”
button. Then press shortly on the “Menu” button to
enter the submenu or to confirm a function.
2.3 Changing volume
First you enter any submenu (music, voice, movie), then press and hold “A-B” button
for several seconds until the volume indicator appears on the screen. Now adapt the
volume with the Vol-/Vol+ buttons.

6
2.4 MUSIC
Select “Music” mode in the main menu, by pressing once the “menu” button.
To enter any music submenu options press once the “menu button”
There are 2 different types of submenu
A/ In stop mode (not available in playback)
B/ In play mode (during playback)
2.4.1 In stop mode (not available during playback)
Press "Menu" button once to enter the music submenu.
Three options are available:
- Local Folder
- Delete
- Repeat
- Exit
Select and confirm your choice by pushing menu button.
2.4.1.1 Local folder (not available during playback)
Here you will be able to find the files stored in different folders.
On the root folder or in any other folder you have created in Windows.
To create new folders in Windows explorer when MP3 is connected.
Open “external drive”.
Create new folder
- Press "Menu" button to open Local folder
- Press “Next” or “Prev” button to select the catalog
- Press “Menu” button to confirm

7
2.4.1.2 Delete (not available during playback)
In the “delete fille submenu, by pressing once the “menu” button, you will get a list with
all songs available in the respective folder.
By pressing once again “menu” button, you will be able to access the following
- Exit
- Delete fill
- Delete all
2.4.1.3 Repeat
Normal All songs are played once
Repeat One Repeats the current song
Folder Plays all the music of a specific folder
Repeat Folder Repeats the music of a specific folder
Repeat All Repeats all the music.
Random Plays music at random.
Intro First 10 seconds of each song is played.

8
2.4.2 In play mode (available only during playback)
During playback, press "Menu "button to enter "Play submenu “:
Six options:
- Repeat
- Equalizer
- Tempo Rate
- Replay
- Replay times
- Replay gap
- Exit
Select and confirm your choice by pushing menu button.
2.4.2.1 Repeat
Normal All songs are played once
Repeat One Repeats the current song
Folder Plays all the music of a specific folder
Repeat Folder Repeats the music of a specific folder
Repeat All Repeats all the music.
Random Plays music at random.
Intro First 10 seconds of each song is played.
2.4.2.2 Equalizer
Seven options:
- Natural
- Rock

9
- Pop
- Classic
- Soft
- Jazz
- DBB
Select and confirm your choice by pushing menu button.
2.4.2.3 Tempo Rate
The music can be played faster or slower (only with MP3 files)
Change the rate by Pressing “Next/Vol+” or “Prev/Vol-” button .
Confirm your choice by pushing menu button.
2.4.2.4 Replay times
Here you are able to choose how many times (1-10) the A-B section
will be repeated.
2.4.2.5 Replay gap
Choose the time( 1-10 sec) between each A-B section.
2.4.2.4 Replay mode (available during playback)
A-B replay
When replay mode is selected, the A-B icon is visible .
Select the start point A (flashing) by pressing “Next/vol+” button.
Select the end point B(flashing) by press “Next/vol+” button .
The A-B section will be repeated continuously
Press “Menu” button to return to normal playback
