Multay BUTTERFLY LEAF NGR11 User manual

Thank you for buying our product
Step By Step Assembly Instructions
PRE-ASSEMBLY PREPARATION
1. Please check the pack contents before attempting to assemble this product.
A full checklist of components is given in this leaflet. If any components are missing,
please contact the retailer from whom you bought this product.
2. This product is VERY HEAVY, It should be assembled as near as possible to the
point of use. TAKE CARE WHEN LIFTING to avoid personal
injury and ( or ) damage to the product.
3. This product takes approximately 60 minutes to assemble with 3 people.
4. The fitting pack contains SMALL ITEMS which should be :
“KEPT AWAY FROM YOUNG CHILDREN“
5. Read this leaflet in full before commencing assembly.
6. You will require a 12 mm spanner (not supplied).
Page 1
WARNING: MUST LIFT HERE
BUTTERFLY LEAF DINING TABLE
( NGR11 )
Assembly Instruction

HARDWARE IDENTIFICATION
ITEM DESCRIPTION Qty
A
B
Table Top
Pedestal Leg
1
2
1
D
Leg Support
Page 2
C
Washer, Bolt
16
(B) Pedestal Leg
(C) Leg Support
(A) Top Table
BUTTERFLY LEAF DINING TABLE
( NGR11 )
Assembly Instruction

protector sheet
Step 1
Place protective cardboard or blankets on the floor (make sure there is no debris)
and place the top of the table upside down as per the diagram below (Fig.1)
Unlock the mechanism, Fig.1 (Shows the table upside down on the floor ready for assembling)
Page 3
lock
Fig.2 Fig.3
locked mechanism
Fig.1
BUTTERFLY LEAF DINING TABLE
( NGR11 )
Assembly Instruction

Step 2
Page 4
There are 2 x table leg marked clearly with white stickers ( 1 and 2 ). Underneath the
table, there are corresponding marks ( 1 and 2 ).
Fit the table leg ( 1 ) to underside Left of table marked ( 1 )
and do the same with leg ( 2 ) to underside Right of table ( 2 ).
Important Notice : Ensure the bolts are inserted as below
Fig.4
1
2
BUTTERFLY LEAF DINING TABLE
( NGR11 )
Assembly Instruction

Page 5
Fig.5 Shows the underside of the table with clear markings of 1 with 1, and 2 with 2,
also show bolts and washer.
Fig.6 Tighten the bolts firmly ( make sure used the washer )
Fig.5
Fig. 7 Shows the completed assembled leg table
Fig.7
Fig.6
tighten
the bolt
tighten
the bolt
tighten
the bolt
BUTTERFLY LEAF DINING TABLE
( NGR11 )
Assembly Instruction

Step 3
Turn the table over. First on to one side then carefully using at least 2 men turn the table
into its final operating position. THIS PRODUCT IS HEAVY.
Page 6
IMPORTAN NOTICE:
PLEASE ENSURE THAT TABLE IS LIFTED
AND TURNED BY HOLDING ON TO FRAME, NOT THE TABLE TOP PANEL ONLY
Fig.7
Fig.8
Finally re - tighten the 8 bolts from underneath.
TABLE MUST BE LIFTED
BY THE FRAME
DO NOT LIFT TABLE
FROM BY TOP TABLE ONLY
BUTTERFLY LEAF DINING TABLE
( NGR11 )
Assembly Instruction

Step 4 - (1 Leaf Open)
Page 7
Unlock and open the table mechanism and you will find 2 extension leaves.
Place one of the extension into the table noting the positions of the locating tenons.
Push the main leaves back together ensuring the pins locate into the holes.
Fig.9
2 Extension Leaves
Fig.11
1 Leaf Open
Fig.10
BUTTERFLY LEAF DINING TABLE
( NGR11 )
Assembly Instruction

Step 5 - (2 Leaf Open)
Page 8
Open the table mechanism and you will find 1 extension leave.
Place the extension into the table noting the positions of the locating tenons.
Push the main leaves back together ensuring the pins locate into the holes.
Fig.12
Fig.14
2 Leaf Open
Fig.13
