Multay Montego MG01 User manual

PRE-ASSEMBLY PREPARATION
1.Please check the pack contents before attempting to assemble this product.
A full checklist of components is given in this leaflet. If any components are missing, please contact
the retailer from whom you bought this product.
2.This product is Heavy, it should be assembled as near as possible to the point of use.
TAKE CARE WHEN LIFTING to avoid personal injury and (or) damage to the product.
3.This product takes approximately 45 minutes to assemble with 2 people.
4.This product already contains fitting which should be :
“ KEPT AWAY FROM YOUNG CHILDREN “
5.Read this leaflet in full before commencing assembly.
Step By Step Assembly Instructions
Page 1
Montego Bed
MG01
Assembly Instruction

Page 2
(A) Headboard
HARDWARE IDENTIFICATION
ITEM DESCRIPTION Q ty
A
B
C
HEADBOARD
FOOTBOARD
SIDE RAILS
1
2
1
DSLATS ( Assembled )
2
ESLATS SUPPORT / CENTRE RAIL
1
FBOLT CONNECTING RAIL (Embedded in side rail)
8
(B) Footboard
( C ) Side Rail
(D) Slats
(E) Slats Support
( C ) Side Rail
Montego Bed
MG01
Assembly Instruction

1. HEADBOARD AND SIDE RAIL ASSEMBLY
1. “Left / Right” marked on headboard must be matched with “Left/Right” marked
on each side rail.
2. Remove bolt connecting rail from the Side Rail by hand
3. Screw the eight threaded bolt into the Headboard and Footboard then tighten by hand.
4. Locating the Side Rails onto the threaded bolt protruding from the Headboard,
Locating round washer and nut onto the threaded bolt and secure by hand first,
Tighten evenly using spanner (not provided)
Note :
- It’s required one person to hold
the headboard while the other
attaches the side rail.
- This bed needs both side rails attaching
to the headboard first.
# Step 1
Page 3
(A) Headboard
( C ) Side Rail
Special
round washer
Spanner
Nut
Montego Bed
MG01
Assembly Instruction

3. Once step 1 and step 2 are complete, side rail should be level with both the headboard and footboard.
The bolt can be screwed well.
2. FOOTBOARD AND SIDE RAIL ASSEMBLY
1. “Left / Right” marked on footboard must be matched with “Left/Right” marked
on each side rail.
2. Locating the Side Rails onto the threaded bolt protruding from the Footboard,
Locating round washer and nut onto the threaded bolt and secure by hand first,
Tighten evenly using spanner (not provided)
# Step 2
Page 4
(B) Footboard
( C ) Side Rail
Montego Bed
MG01
Assembly Instruction

3. CENTRE RAIL ASSEMBLY
Page 5
- Insert the Centre legs into Centre Rail
- Locate the Centre Rail into the wooden brackets
Centre Rail
Slat Support
Centre Leg
( Turn clockwise to tighten )
DONE !
4. SLAT ASSEMBLY
- Insert the Slat into Centre Rail.
Centre Rail
(E) Slats Support
