Multay SV02 User manual

Thank you for buying our product
Large Extending Table ( SV02 )
Assembly Instruction
Step By Step Assembly Instructions
PRE-ASSEMBLY PREPARATION
1. Please check the pack contents before attempting to assemble this product.
A full checklist of components is given in this leaflet. If any components are missing,
please contact the retailer from whom you bought this product.
2. This product is VERY HEAVY, It should be assembled as near as possible to the
point of use. TAKE CARE WHEN LIFTING to avoid personal
injury and ( or ) damage to the product.
3. This product takes approximately 60 minutes to assemble with 3 people.
4. The fitting pack contains SMALL ITEMS which should be :
“KEPT AWAY FROM YOUNG CHILDREN“
5. Read this leaflet in full before commencing assembly.
6. You will require a 17 mm spanner (not supplied).
Page 1

HARDWARE IDENTIFICATION
ITEM DESCRIPTION Qty
A
B
C
Table Top
Leg
Extension Leaf
2
4
1
DNut, Washer, Bolt
8
EBag
2
(A) Table Top
(B) Leg
Large Extending Table ( SV )
Assembly Instruction
02
Page 2
( C ) Extension Leaf
( D ) Nut, Washer, Bolt

1. Step
Place protective cardboard or blankets on the floor ( make sure there is no debris )
and place the top of the table upside down as per the diagram below ( Fig.1 )
Fig.1 (Shows the table upside down on the floor ready for assembling)
Large Extending Table ( SV )
Assembly Instruction
02
Page 3
There are 4 x table leg marked clearly with white stickers ( 1, 2, 3 and 4 ). Underneath the
table, there are corresponding marks ( 1, 2, 3 and 4 ).
Fit the table leg ( 1 ) to underside corner of table marked ( 1 )
and do the same with leg ( 2 ) to underside corner of table ( 2 )
and do the same with leg ( 3 ) to underside corner of table ( 3 )
and do the same with leg ( 4 ) to underside corner of table ( 4 ).

Large Extending Table ( SV )
Assembly Instruction
02
Page 4
marks 1
marks 1
Fig.2 Shows the underside of the table with clear markings of 1 with 1, and 2 with 2 and
also show bolts, nut and washer.
Important Notice : Ensure the bolts are inserted as below
Tighten the bolts firmly ( make sure the washer is on the outside of the corner )

2. Step
Turn the table over. First onto one side then carefully using at least 2 men turn the table
into its final operating position. THIS PRODUCT IS HEAVY.
Finaly re - tighten the 8 nuts and bolts from underneath.
Fig. 4 Shows take out the extension leaves from storage location of the extension leaves.
Open the table mechanism and you will find 2 extension leaves. Remove them both from their bags carefully.
Place one or both of the extension into the table noting the positions of the locating tenons.
Push the main leaves back together ensuring the pins locate into the holes.
The assembly is now complete.
3. Step
Fig. 5 Shows the completed assembled table
Large Extending Table ( SV )
Assembly Instruction
02
Page 5
