multicomp pro MP700006 User manual

1
Model: MP700006
Wire Tracker Probe with Tone Generator

2
Please read these instructions carefully before use and retain for future reference.
Warning: Do not connect to circuits carrying AC voltage in tone or polarity modes.
• The maximum voltage allowed across the leads is 60V DC in tone and polarity
modes.
Warning: Do not connect to circuits carrying AC or DC voltage in continuity test modes.
• Check the test leads, probes and case insulation before using. If you nd any
breakage or abnormality, or you consider the device is broken, stop using the
device immediately.
• Do not touch the metal probe tips when making connections.
• Do not use this meter in thunderstorm conditions.
• Replace the batteries as soon as the low battery indicator appears on the display.
• Remove dead batteries from the meter or if it is not going to be used for a long
time.
• Never mix old and new batteries together, or different types of batteries.
• Never dispose of batteries in a re, or attempt to recharge ordinary batteries.
• Do not use the meter with the battery or back cover open.
• Before replacing the battery, turn off the meter and disconnect all the test probes.
• To prolong battery life turn off the meter after use.
WHAT’S INCLUDED
• Digital Tone Generator.
• Probe.
• User manual.
• 9V battery x 2off.
IMPORTANT SAFETY INFORMATION
OVERVIEW
Probe
1. Signal probe
2. Volume/sensitivity slider
3. Power LED
4. Test button
Tone Generator
1. Tone/Power/Continuity switch
2. Tone LED
3. Power LED
4. Continuity LED
5. Modular RJ11 connector
6. Test leads

3
FUNCTIONS
Tracing Cables
• On the Tone Generator set the function switch to TONE position.
• The TONE and POWER LEDs will illuminate.
• Connect the red test lead to the wire in the cable you wish to trace and connect
the black lead to ground.
• If the cable is shielded connect the black lead to the shield.
• Point the probe tip to the cable and
press the TEST button.
• The POWER LED on the probe will
illuminate.
• Adjust the volume/sensitivity slider
so the output is easily audible.
• The volume will be loudest when
the probe tip is close to the wire
connected to the tone generator.
Tracing Pairs
• On the Tone Generator set the function switch to TONE position.
• The TONE and POWER LEDs will illuminate.
• Connect the red test lead to one wire of the cable and connect the black lead to
the other wire of the pair being
traced within the cable.
• Point the probe tip to the cable
and press the TEST button.
• The POWER LED on the probe
will illuminate.
• Adjust the volume/sensitivity slider
so the output is easily audible.
• The volume will be loudest when
the probe tip is close to the wires
connected to the tone generator.
Indicating Line Conditions (Checking Polarity)
• On the Tone Generator set the function switch to POWER position.
• Connect the red test lead to one wire and the black lead to the other wire of the
telephone line being tested.
• If the CONTINUITY LED turns green
a normal working line with correct
polarity is indicated.
• If the TONE LED turns red, incorrect
polarity is indicated.
• If the CONTINUITY LED turns dark
green, a faulty or off-hook line with
correct polarity is indicated.
• If the TONE LED turns dark red, a
faulty or off-hook line with incorrect
polarity is indicated.

4
Continuity Test
• Connect the red test lead to one wire and the black lead to the other wire of the
telephone line being tested.
• On the Tone Generator put the function switch to CONTINUITY position.
• If the CONTINUITY LED turns green
if there is an electrical path between
the connection points.
• The tester indicates continuity up to
10kΩ.
• The LED is brighter on low resistance
and less bright on higher resistance.
Supplying Talk Power
• Insert the RJ11 plug into the telephone socket and put the function switch to
CONTINUITY mode to supply talk power.
Note: the tone generator has an RJ11 phone plug which can be used instead of the
clip test leads when the pair of wires being tested is terminated in an RJ11 jack. This
can be used in any operating mode.
SPECIFICATIONS
BATTERY REPLACEMENT
Warning: Only replace the battery after the test leads are Disconnected and the
power is turned off.
To replace the battery:
• Remove the battery cover and replace batteries with 1 x 9V type battery keeping
the polarity correct. Replace the battery cover.
• Clean the meters with a clean, soft cloth.
• Do not use any chemicals, abrasives or solvents that could damage the meter.
CLEANING
INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF
ELECTRICAL & ELECTRONIC EQUIPMENT
These symbols indicate that separate collection of Waste Electrical and Electronic Equipment
(WEEE) or waste batteries is required. Do not dispose of these items with general household
waste. Separate for the treatment, recovery and recycling of the materials used. Waste batteries
can be returned to any waste battery recycling point which are provided by most battery retailers.
Contact your local authority for details of the battery and WEEE recycling schemes available in
your area. Made in China. LS12 2QQ
Man Rev 1.0
Tone Generator Probe
Output Power/Voltage 10mW (into 600Ω)/8VDC -
Output freq @ Warble rate Alternating 1.25/1.4kHz @ 6Hz -
Over voltage protection 60VDC -
Operating temperature 0o~40oC (storage: -10oC~50oC) 0o~40oC (storage: -10oC~50oC)
Dimensions 74 x 68 x 28mm 208 x 47 x 33mm
Weight 150g 130g
Input impedance - >100MΩ
