Murdock A172.8FGVR Series Installation and operating instructions

A172.8 SeriesFGVR
Barrier Free, 14 Gage Stainless Steel, Enhanced
Vandal Resistance, Bi-Level, Wall Mounted Water Cooler
COMPLIES WITH
7020-928-001 Date: 06/01/2023 A
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
Murdock assumes no responsibility for use of void or
suspended data. © Copyright Murdock, City of
Industry, CA Member of Morris Group International.
Please visit www.murdockmfg.com for most
current specifications.
NOTES TO INSTALLER:
1. Please leave this documentation with the owner of the fixture when finished.
2. Please read this entire booklet before beginning the installation.
3. Check your installation for compliance with plumbing, electrical and other applicable codes.
4. IMPORTANT: Water supply to unit from RO Reverse Osmosis filtration systems will damage
fixture components and void product Warranty.
TECHNICAL ASSISTANCE TOLL FREE TELEPHONE NUMBER:
1.800.591.9360
Technical Assistance E-Mail: [email protected]
Federal
Public Law
111-380
(No Lead)
ANSI/ASHRAE 18
(220V Compressor Only)
NSF/ANSI/CAN 61
Member of 15125 Proctor Ave, City of Industry,
CA, 91746 U.S.A.
Phone [phone]
www.murdockmfg.com

IMPORTANT
This fixture is intended to dispense water that has been lowered in temperature, but otherwise remains
unchanged by the materials in the water cooler. It is common for electrical equipment to be grounded
to water lines either within a structure or away from it. Every attempt should be made to prevent this
kind of grounding from generating electrical feedback into the water cooler creating electrolysis.
Electrolysis will cause a metallic taste or cause water metal content to increase.
NOTICE
A dielectric coupling must be used to connect the water cooler to the water supply. A nonmetallic
coupler is furnished with this water cooler to meet this requirement.
ROUGHING-IN AND DIMENSIONAL DRAWING
Prior to roughing consult with local, state, and federal codes for proper mounting height.
A172408FGVR Wall Mounted Drinking Fountain
NOTES: Dimensions indicated * are for ADA frontal approach installation. Adjust vertical dimension * as required to comply with
federal, state, and local codes. For Child ADA compliant parallel approach, decrease spout height to 30” maximum above finished
floor. Provide clear floor space as required. Compliance is subject to the interpretation and requirements of the Local Code
Authority.
A172.8FGVR
Page 2 of 12
Revised: 06/01/2023 A
7020-928-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
GENERAL NOTES:
1. ALL DIMENSIONS ARE IN INCHES [MM]
2. ALLOW 4 INCHES [102 MM] MINIMUM CLEARANCE PER SIDE FOR VENTILATION
*3. DIMENSIONS SHOWN ARE FOR RECOMMENDED ADULT HEIGHT. ADJUST VERTICAL
DIMENSIONS AS NECESSARY TO COMPLY WITH FEDERAL, STATE, & LOCAL CODES
4. STOP VALVE, P-TRAP, & ELECTRICAL OUTLET NOT SUPPLIED
5. IMPORTANT: COOLERS MUST BE ATTACHED TO WALL WITH APPROPRIATE WALL ANCHOR SCREWS
A. 3/8" NCT SUPPLY INLET
B. WASTE OUTLET FOR 1-1/4" P-TRAP BY OTHERS
C. ELECTRICAL SERVICE ROUGH
D. Ø1/2" HANGER BRACKET PUNCHING, 3 PLACES FOR ANCHORING HARDWARE BY OTHERS
E. Ø5/16" PUNCHING, 2 PLACES FOR ANCHORING HARDWARE BY OTHERS
181
2"
*331
2"
13
8"
105
8"
TAILPIECE
*167
8"51
4"
*221
4"
21
4"
*25"
141
4"
5"
193
8"
77
8"
65
8"
AIR FLOW
*16"
185
8"
81
4"
371
8"
D
E
C
B
A
41
4"
71
2"
141
4"
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY DRINKING FOUNTAINS

PRIOR TO INSTALLATION:
Important: some options may slightly alter installation. To ensure proper installation review the manual
thoroughly and verify rough-ins before beginning work. File this manual wit the owner or maintenance
personnel upon completion of installation.
— Fixture mounting requirements: industry standard wall construction, adequate to support the fixture and
installer provided wall anchors sufficient to secure the fixture.
— Receptacle(s) must be wired to a GFCI protected circuit. Fixture must be earth grounded per NEC
(National Electric Code).
— Inspect fixture an all parts from damages and all parts are bolted on.
IMPORTANT:
1. Waste P-Trap, Water Supply Service Angle Stop Valve and 2” x 4” Electrical Plug-In Receptacle to be
supplied by others in accordance with local codes. A metallic p-trap (by others) must be used for the
drain connection.
2. Provide 4” minimum clear space on fixture sides to allow for proper ventilation through cabinet louvers.
3. Water supply is 3/8” Outer Diameter copper tube. Waste is 1-1/4” Outer Diameter.
4. Completely flush supply lines of all foreign debris before connecting to fixture. Water cooler is designed
to not cause problems with taste, odor, color, or sediment. Optional water filter (Wf1) is available should
any of these problems arise from the water supply.
5. Do NOT solder tubes inserted into the coupler as damage to the o-ring may result.
6. All burrs must be removed from outside of cut tubes before inserting into coupler or other components.
7. Power supply must be identical in voltage, cycle and phase to that specified on the cooler data plate.
Electrical outlet and furnished power cord with plug must be used to supply power to fixture. Do NOT
wire compressor directly to the power supply.
A172.8FGVR
Page 3 of 12
Revised: 06/01/2023 A
7020-928-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
181
2"
*257
8"
51
4"
*311
4"
61
2"
*25"
141
4"
77
8"
65
8"
AIR FLOW
*16"
185
8"
371
8"
D
E
C
A
*331
2"
13
8"
105
8"
TAILPIECE
5"
193
8"
81
4"
71
2"
B
41
4"
141
4"
A172408FGVR Wall Mounted Drinking Fountain- Reverse Bi-Level
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY DRINKING FOUNTAINS

8. This unit must be grounded per the requirements of applicable electrical codes.
9. Warranty is voided if installation is not made following current Acorn Engineering installation instructions
and if components are assembled to the fixture that is not approved by Acorn Engineering.
10. Fixture is to operate within a water pressure range of 20 PSIG (138 kPa) to 105 PSIG (724 kPa).
Warranty is void if the unit is allowed to operate outside the range of 20 PSIG (138 kPa) to 105 PSIG
(724 kPa). Consult with UPC and local codes for maximum allowable water pressures.
11. Due to cold waste water, Acorn Engineering recommends that p-trap supplied by installer be insulated to
prevent excessive condensation.
12. Per UPC 609.10- All building water supply systems in which quick acting valves are installed shall be
provided with devices to absorb the hammer caused by high pressure resulting from the quick closing of
the valve. These pressure-absorbing devices shall be approved mechanical devices. Water pressure-
absorbing devices will be installed as close as possible to the quick closing valve.
INSTALLATION:
1. Mount hanger bracket to wall horizontally level as shown in Roughing-In and Dimensional Drawing.
Note: Adjust height of bracket if bubbler outlet height is required to vary from that shown. Hanger
Bracket MUST be securely anchored to wall with fasteners sufficient to support 3 times weight of cooler.
If wall can not provide adequate support, order and install optional fixture support carrier.
2. Remove the bottom cover from the water cooler and set aside in a safe place. Save the screws in a
secure location for re-use in later stages of installation.
3. Hang the water cooler on the hanger bracket, ensuring the bracket tabs engage AND seat in the slots in
the back of the water cooler. Verify water cooler is level, left to right AND front to back from bottom of
unit. NOTE: The bubbler stream may be adversely affected if unit is not square and level. Bottom of unit
and louvers should be used as reference to verify unit is square and plumb.
4. Anchor water cooler to wall at other mounting points in base. Shim lower rear mounting points to level
unit if necessary.
5. Thoroughly flush the 3/8” O.D. supply line and then connect water cooler to water supply angle stop
valve (by others) with supplied 3/8” O.D. copper tube.
6. Make up 1-1/4” O.D. p-trap (by others) waste connection.
START UP:
1. Do not connect electrical power to unit: With Bottom Cover removed, turn on fixture water supply and
check all connections for leaks.
2. Air within the Water Cooler system or the structure supply piping will cause an irregular Bubbler outlet
stream until purged out by incoming water. Thoroughly flush and purge air from supply line by
depressing the Pushbutton or activating infrared sensor, until steady water stream is achieved.
3. If water flow requires adjustment, insert a slotted narrow blade screwdriver through the hole centered on
the pushbutton to the flow regulator. Turning clockwise will increase flow and turning counterclockwise
will decrease flow.
4. Recheck all water and drain connections with water flowing through system.
5. With power still NOT connected, carefully manually rotate cooling fan to insure proper clearance and
free fan action.
6. Plug Water Cooler into Electrical Outlet and make sure unit begins to function. IMPORTANT: After turning
power on to initiate cooler and cool down, immediately purge (chiller) water by operating unit continuously for
approx. 1 minute.
IMPORTANT! Thoroughly, inspect all unit connections for water leaks.
7. Assemble bottom cover to water cooler with screws furnished.
A172.8FGVR
Page 4 of 12
Revised: 06/01/2023 A
7020-928-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY DRINKING FOUNTAINS

TROUBLE SHOOTING:
IMPORTANT: BEFORE MAKING ANY OF THE REPAIRS LISTED, MAKE SURE THE WATER
COOLER IS DISCONNECTED FROM THE ELECTRICAL SUPPLY AND THE WATER SUPPLY VALVE
IS SHUT OFF.
IMPORTANT : ASSUREZ-VOUS QUE LA FONTAINE D'EAU POTABLE RÉFRIGÉRÉE SOIT
DÉBRANCHÉE DE LA PRISE DE COURANT MURALE ET QUE LE ROBINET D'ALIMENTATION
D'EAU SOIT FRMÉ AVANT D'EFFECTUER LES RÉPARATIONS NÉCESSAIRES.
1. Adjustments:
a. Cartridge – The water flow can be adjusted using a slotted narrow blade Screwdriver and
turning clockwise to increase flow and counterclockwise to decrease flow.
b. Bubbler Stream – Bubbler can be rotated slightly to direct the stream backwards or
forwards. Adjust the stream to minimize splashing. Splashing may occur from Bubbler
stream if the unit is not level. Shim lower mounting points, if necessary, to level Water Cooler.
c. Cold Water Thermostat – IMPORTANT: Thermostat is Factory pre-set. Thermostat settings
should never be field adjusted since damage to fixture may occur, voiding product Warranty.
2. Compressor Does Not Run
a. Check the electrical receptacle for power and correct voltage. The incoming voltage must be
within 10% of the rated voltage on the serial nameplate.
b. The cold thermostat is accessible by removing the bottom access cover. If the cold
thermostat capillary bulb loses its charge or becomes kinked it will fail in the open position
causing a disruption of power to the compressor. Unplug the water cooler and using an
ohm meter check for continuity across the two electrical terminals on the thermostat. Install a
new thermostat if there is no continuity.
c. Check for loose wires within the compressor box. The incoming power leads must be
connected to the overload and relay.
d. If all components check positive for continuity then test the wiring harness plug for
continuity to see if there is a broken wire within the wiring harness insulation.
3. Compressor Runs – Water Is Warm
a. The most common cause for a water cooler to run without producing cold water is a
loss of refrigerant. The water cooler must be taken to a certified refrigerant technician
for repairs.
b. Make sure the condenser fan motor is operative. The fan blade must turn freely to help
remove the heat of compression.
c. An incorrect refrigerant charge, restriction or defective compressor (not pumping) will
also cause the compressor to run without producing cold water. All these signs indicate
a problem within the refrigeration system and the water cooler must be checked by an
authorized service company.
4. Compressor Cycling On Overload Protector
a. A dirty condenser or a blocked fan will cause a high head pressure and frequent cycling
of the overload protector.
b. Check the incoming voltage to make sure it is within 10% of the serial nameplate rating.
c. A restriction or moisture in the system will also cause intermittent cycling. A certified
refrigeration mechanic should be contacted in this situation.
d. Change the overload or relay if defective.
A172.8FGVR
Page 5 of 12
Revised: 06/01/2023 A
7020-928-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY DRINKING FOUNTAINS

5. Noisy Operation
a. Check to make sure the fan blade is rotating freely.
b. Make sure the water cooler is correctly mounted to the wall. Absence of the two lower
mounting bolts may cause excess noise and vibration.
c. Check the compressor mounting to make sure the pins and clips are not rattling. If the
compressor appears to be noisy internally, it must be replaced.
6. Restricted Or No Water Flow
a. Ensure water supply service stop valve is fully open.
b. Verify minimum 20 psig supply line flow pressure.
c. Check for twists or kinks in bubbler tubing.
d. Check the water inlet strainer. Sediment from the main supply can get trapped in the
screen along with installation materials such as pipe dope and flux. The screen should
be cleaned and checked on a regular basis and replace if needed.
NOTE: STRAINER SCREEN MUST BE IN PLACE FOR WATER TO FLOW.
e. The cartridge valve located in the water control assembly or bubbler can also become
clogged with foreign material. The cartridge valve can only be replaced and not
repaired.
f. Check flow adjustment. See start up note #3.
g. The water cooler may develop a freezing condition in which the water will become
frozen inside the evaporator coil. This indicates a refrigeration problem or thermostat
failure. Disconnect the electrical power and have the unit checked by a qualified technician.
7. Water Drip Or Will Not Shut Off:
a. Remove Pushbutton. Adjust flow regulator to the highest setting using a
flat head screwdriver and turning clockwise. Check if water drip continues, if it is no longer
dripping turn screwdriver counter-clockwise until you have desired flow rate. Assure that
retaining nut is tighten to valve assembly, 25 in-lb torque is required. If issue still continues after
adjusting flow and tightening retainer nut, replacement of the flow regulator cartridge will be
required in the center or two holes in convolution of the water diaphragm.
Remove and clean.
CLEANING & MAINTENANCE GUIDE:
1. Motors have lifetime lubrication and do not require scheduled maintenance.
2. Excess dirt or poor ventilation will cause the compressor overload protector to turn the compressor
off and it will cycle on and off with no cold water coming out of bubbler. Periodically clean with
vacuum cleaner, air hose or brush the condenser fins and cabinet ventilation louvers. In
environments where dirt and dust is more prevalent, clean more frequently.
3. Periodically remove access panels and clean out in-line strainer.
4. Do NOT use harsh chemicals, abrasive or petroleum based cleaners. Use of these will void the
Murdock warranty.
5. Exterior panels can be cleaned using mild household detergents or warm, soapy water. Extra care
must be used cleaning chrome plated items and mirror finished stainless steel. They can scratch
easily and should only be cleaned using a clean, soft cloth and mild soap with water or a mild glass
cleaner.
A172.8FGVR
Page 6 of 12
Revised: 06/01/2023 A
7020-928-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY DRINKING FOUNTAINS

A172.8FGVR
Page 7 of 12
v
7020-928-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CARTRIDGE REPLACEMENT/ STRAINER MAINTENANCE
Note: Use the -VR maintenance tool to perform the following:
1. Strainer plug 3 must be removed before cartridge replacement and strainer
maintenance (no need to turn the water off at the angle stop). Some residual water will drain
during plug removal.
2. Clean strainer 4 as needed using clean water.
3. Cartridge replacement - Rotate and remove -VR pushbutton escutcheon 6 to release pushbutton 7
and springs 9 10 to access cartridge.
4. Remove cartridge retaining nut 11 . Remove and replace cartridge 2 . When replacing cartridge be
sure to align the inlet and outlet ports on the cartridge with the ports in the valve body.
5. Install item 11 using maintenance tool 5 (Be careful not to over tighten)
6. Install button assembly items 6 7 8 9 10 using maintenance tool 5 . Insure springs are fully
seated onto button.
7. Reinstall strainer 4 and plug 3 using maintenance tool 5 .
NOTE: STRAINER FILTER SCREEN
MUST BE IN PLACE FOR
WATER TO FLOW.
5
6
9
8
10
7
ITEM PART NUMBER DESCRIPTION
1 7003-095-001 VALVE ASSEMBLY
2 7000-060-000 FLOW REGULATOR CARTRIDGE (0.5 GPM)
3 7003-097-001 O-RING &STRAINER PLUG
4 7003-864-000 STRAINER FILTER SCREEN
5 7003-194-199 (-VR) MAINTENANCE TOOL
6 7003-197-199 (-VR) PUSHBUTTON ESCUTCHEON, CHROME
7 7003-196-199 (-VR) PUSHBUTTON, CHROME
87003-192-199 (-VR) PUSHBUTTON SPRING SPACER
9 7003-195-000 (-VR) PUSHBUTTON OVERTRAVEL SPRING
10 7003-193-000 (-VR) PUSHBUTTON RETURN SPRING
11 7000-052-000 RETAINING NUT
2
4
3
1
5
11
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY DRINKING FOUNTAINS

OPTIONAL -WF1 WATER FILTER
See the following page for models with -WF1 Water Filter (A172.8-FG-VR-WF1)
A172.8FGVR
Page 8 of 12
Revised: 06/01/2023 A
7020-928-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
ITEM PART NUMBER DESCRIPTION
1 7012-311-000 WF1 Filter 1500 Gal
2 1895-709-000 Elbow , Push in, 1/4" O.D. x 1/4" Stem
3 2169-000-000 1/4" O.D. LLDPE Tubing, Blue
4 7012-055-000 Foam Pipe Insullation
5 7003-670-001 Filter Assembly, FG
FILTER MOUNTING
DETAIL
LINE TO DRINKING
FOUNTAIN INLET
INSTALLED
FILTER DETAIL
NOTES:
1.) CUT AND DEBURR
WATER LINE TUBING
AS REQUIRED
2.) ENSURE TUBING END
IS NOT DEFORMED
BEFORE INSERTING IN
"Y" STRAINER
3.) CUT INSULATION AS
REQUIRED TO COVER
WATER TUBING
INSTALL TUBING
PROVIDED WITH
FILTER SUB-ASSEMBLY
REMOVE TUBING FROM
"Y" STRAINER & INSTALL
TO OUTLET OF FILTER
"Y" STRAINER
IN
OUT
TO DRINKING
FOUNTAIN INLET
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY DRINKING FOUNTAINS

OPTIONAL -WF1 WATER FILTER
See the following page for models with -WF1
Water Filter (A172-FG-VR-WF1)
FILTER CARTRIDGE REPLACEMENT:
1. Remove access panel, this allows access to the filter
and the water inlet valve (provided by others). Turn
valve knob 1/4 turn clockwise to close.
2. Slowly lift water filter from the water filter bracket
assembly.
3. With the water filter removed from the bracket
assembly, hold the cap firmly. Turn the
replaceable cartridge filter counterclockwise to
remove.
4. Remove and replace the cartridge turning clockwise
to secure.
5. Re-insert the water filter into the water filter bracket
assembly.
6. Turn water inlet 1/4 turn knob 1/4 turn
counterclockwise to open and test for leaks and
proper operation before closing access panel.
A172.8FGVR
Page 9 of 12
v
7020-928-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
ACCESS PANEL
WATER INLET
VALVE OPEN
WATER INLET
VALVE CLOSED
REPLACEMENT
CARTRIDGE
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY DRINKING FOUNTAINS

PUSH-IN FITTING INSTALLATION
NOTE: FITTINGS AND TUBE SHOULD BE KEPT
CLEAN, BAGGED AND UNDAMAGED PRIOR TO
INSTALLATION.
2. Pull on the fitted tubing to ensure it is secure. Tube
should not come free from the fitting. Water test the
connection assembly prior to leaving the site to ensure
there are no leaks.
DISCONNECTING THE TUBE:
To disconnect the tube from the fitting ensure that the
water line is depressurized. Push collet square towards
the push-in fitting body and hold. While holding the collet
in, pull on the PE tubing to remove from the push-in fitting.
TO CUT TUBE:
Cut to fit length of 1/4” PE tubing and remove any burrs
or sharp edges. Ensure that the outside diameter is free
from score marks. Tube ends should be square.
INSERTING THE TUBE:
1. Firmly and fully insert the tubing end into the push-in
fitting up to the tube stop located approximately ½”
deep.
COLLET
COLLET
O-RING
O-RING
TUBE STOP
COLLET
COLLET
COLLET
A172.8FGVR
Page 10 of 12
Revised: 06/01/2023 A
7020-928-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY DRINKING FOUNTAINS

Standard A171.8 series refrigerated ADA cooler shown. All 1/4" O.D. Plastic tubing 30 must be
insulated with 31 foam insulation.
NOTE: See next page for table of part numbers corresponding to drawing above.
COOLER PARTS BREAKDOWN
A172.8FGVR
Page 11 of 12
Revised: 06/01/2023 A
7020-928-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Universal Maintenance Tool
-Button Removal
-Cartridge Retaining Nut
-Strainer Plug
-Removal of P.E. Tubing from
Push-in Fittings
32
12
24
23
22
35
36
34
37
38
39
38
34
33 13
41
40
42
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY DRINKING FOUNTAINS

Repairs must be made with Acorn Engineering parts only. Please order through your local representative
or distributor. The phone number to locate your local representative is 1.800.591.9360.
COOLER PARTS BREAKDOWN TABLE
NOTE: See previous page for fixture drawing corresponding to table of parts below.
ITEM # PART NUMBER DESCRIPTION
1 7003-201-000 CONDENSER
2 7003-634-199 FG-VR SUPPORT STRUT
3 7003-355-000 FAN BLADE
7003-302-001 FAN MOTOR
7012-062-000 FAN MOTOR - 220V
5 7003-250-000 COLD CONTROL
7012-801-000 COMPRESSOR
7012-030-001 COMPRESSOR - 220V
7012-802-000 START RELAY
7012-031-000 START RELAY - 220
7012-803-000 START CAPACITOR
7012-032-000 START CAPACITOR - 220
9 7012-050-000 FILTER / DRYER
10 7003-115-001 EVAPORATOR ASSEMBLY
11 0112-002-000 CENTER REJECT ALLEN BUTTON HEAD SCREW
12 7003-681-199 FG-VR STAINLESS STEEL KNEE PANEL
13 7003-095-001 VALVE ASSEMBLY
14 7000-012-001 STAINLESS STEEL BUBBLER ASSEMBLY
15 0152-006-000 CENTER REJECT ALLEN FLAT HEAD SCREW
16 7012-803-000 FG-VR HANGER BRACKET
17 7003-681-299 ACCESS PLATE, -VR AUTO-STOP
18 7000-006-000 FLAT DRAIN ADAPTER GASKET
19 7000-005-199 DRAIN ADAPTER
20 7000-019-001 WASTE TAILPIECE ASSEMBLY
21 7003-073-000 1-1/4" x 1-1/2" COMPRESSION 45? ELBOW
22 1758-043-299 1-1/2" O.D. x 3" LONG DRAIN TUBE
23 7003-072-000 1-1/2" x 1-1/2" COMPRESSION 45
?
ELBOW
24 1758-043-199 1-1/2" O.D. x 15" LONG WASTE ARM
25 7000-032-001 1-1/4" x 1-3/4" LONG DRAIN TUBE ASSEMBLY
26 7003-070-000 1-1/2" COMPRESSION TEE
27 7000-032-299 1-1/4" O.D. BRASS WASTE TAILPIECE
28 7003-300-005 BACK PANEL ASSEMBLY
29 7003-604-002 ACCESS PANEL
30 2169-000-000 1/4" O.D. TUBING
31 7012-055-000 TUBE INSULATION
32 7003-194-199 (-VR) MAINTENANCE TOOL
33 7003-198-199 (-VR) PUSHBUTTON MOUNTING SLEEVE
34 0124-055-000 #8x3/4 PHILLIPS ROUND HEAD SS SM SCREW
35 7003-199-000 AUTO-STOP CONDENSATION GASKET, UPPER
36 7003-200-000 AUTO-STOP CONDENSATION GASKET, LOWER
37 7003-193-000 (-VR) PUSHBUTTON RETURN SPRING
38 0161-062-000 #6-32 x 1/2" S/S PHIL FLAT HD SCREW
39 7003-195-000 (-VR) PUSHBUTTON OVERTRAVEL SPRING
40 7003-196-199 (-VR) PUSHBUTTON, CHROME
41 7003-197-199 (-VR) PUSHBUTTON ESCUTCHEON, CHROME
42 7003-192-199 (-VR) PUSHBUTTON SPRING SPACER
4
6
7
8
A172.8FGVR
Page 12 of 12
Revised: 06/01/2023 A
7020-928-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY DRINKING FOUNTAINS
