Murdock A172108F-UBL Installation and operating instructions

OR
Standard Configuration
Alternate Configuration
A172.8UBL Series
Refrigerated Universal Bi-Level
Barrier Free, Wall Mounted Water Cooler
A172108F-UBL / A172408F-UBL / A172108F-SO / A172408F-SO
TECHNICAL ASSISTANCE TOLL FREE TELEPHONE NUMBER:
1.800.591.9360
Technical Assistance Fax: [phone]
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
COMPLIES WITH
7020-905-001 Date: 07/18/18
Test rating conditions are
compliant with ARI 1010.
Federal
Public Law
111-380
(No Lead) Member of
MURDOCK
15125 Proctor Ave.
City of Industry, CA
91746 U.S.A.
Phone [phone]
626-336-4561
Fax [phone]
www.murdockmfg.com
NOTES TO INSTALLER:
1. Please leave this documentation with the owner of the fixture when finished.
2. Please read this entire booklet before beginning the installation.
3. Check your installation for compliance with plumbing, electrical and other applicable codes.
LIMITED WARRANTY - UNITED STATES & CANADA
Murdock warrants the compressor and hermetically sealed refrigeration system, including cooling coil assembly
when part of the hermetically sealed refrigeration system, to be free from defects in material and workmanship
under normal use for an additional four (4) years from the end of the one (1) year period described above.
This warranty does not cover installation or labor charges and does not apply to materials, which have been
damaged by other causes such as mishandling or improper care or abnormal use. The repair or replacement of the
defective materials shall constitute the sole remedy of the Buyer and the sole remedy of Murdock under this
warranty. Murdock shall not be liable under any circumstances for incidental, consequential or direct charges
caused by defects in the materials, or any delay in the repair or replacement thereof. This warranty is in lieu of all
other warranties expressed or implied. Product maintenance instructions are issued with each unit and disregard
or non-compliance with these instructions will constitute an abnormal use condition and void the warranty.
Stainless steel must be protected on job site during construction and must be properly maintained after the water
has been introduced into the water cooler or drinking fountain, or Murdock’s limited warranty is void.
LIMITED EXPORT WARRANTY - One year on parts only.
Murdock warrants that every cooler, bottle filling station, packaged water chiller, fountain and accessory to be free
from defects in material and workmanship under normal use for one (1) year from date of install or eighteen (18)
months after the date of shipment from the factory, whichever comes first.
Murdock assumes no responsibility for use of void or
suspended data. © Copyright Murdock, City of
Industry, CA Member of Morris Group International.
Please visit www.murdockmfg.com for most
current specifications.

1. Dimensions shown for ADA compliant installation. For Child ADA 2010 compliant parallel approach
installation, decrease height of * dimensions by 2-3/4".
2. Provide clear floor space as required. Adjust vertical dimensions as required to comply with federal,
state, and local codes.
See next page for alternative mounting of units, roughing-in and dimensional drawing.
NOTES:
A dielectric coupling must be used to connect the water cooler to the water supply . A nonmetallic
coupler is furnished with this water cooler to meet this requirement.
A172.8UBL SERIES REFRIGERATED BI-LEVEL WALL MOUNTED WATER COOLER
Note: there are no mounting changes to be made for -SO models.
This fixture is intended to dispense water that has been lowered in temperature, but otherwise remains
unchanged by the materials in the water cooler. It is common for electrical equipment to be grounded
to water lines either within a structure or away from it. Every attempt should be made to prevent this
kind of grounding from generating electrical feedback into the water cooler creating electrolysis.
Electrolysis will cause a metallic taste or cause water metal content to increase.
Prior to roughing consult with local, state, and federal codes for proper mounting height.
NOTICE
IMPORTANT
ROUGHING-IN AND DIMENSIONAL DRAWING
A. 3/8" NCT SUPPLY INLET
B. WASTE OUTLET FOR 1-1/4" P-TRAP BY OTHERS.
C. ELECTRICAL SERVICE ROUGH.
D. Ø3/8" HANGER BRACKET PUNCHING, 3 PLACES FOR ANCHORING HARDWARE BY OTHERS.
E. Ø1/4" PUNCHING, 2 PLACES FOR ANCHORING HARDWARE BY OTHERS.
AIR FLOW
11"
165
8"
201
2"
37
8"
131
2"
51
4"77
8"
181
2"
13
8"
6"
12"
TAIL
PIECE
*33"
71
4"
6"
21
4" 41 4"
D
E
A
B
C
65
8"
185
8"91
4"
*215
8"
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
A172.8UBL
Page 2 of 11
Revised: 07/18/18
7020-905-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

10. Fixture operates within water pressure range of 20 to 105 psig. Acorn Engineering will not warranty fixtures
damaged when connected to supply lines with flow pressure lower than 20 psig or higher than 105 psig. A
pressure regulator must be furnished by others on supply line if inlet pressure is greater than 105 psig.
3. Water supply is 3/8” Outside Diameter copper tube. Waste is 1-1/4” Outside Diameter.
4. Completely flush supply lines of all foreign debris before connecting to fixture. Water cooler designed to not
affect taste, odor, color, or sediment. Optional water filter (Wf1) is available should any of these problems
arise from the water supply.
IMPORTANT:
1. Waste P-Trap, Water Supply Service Angle Stop Valve and 2” x 4” Electrical Plug-In Receptacle to be supplied
by others in accordance with local codes. A metallic p-trap (by others) must be used for the drain connection.
5. Do NOT solder copper tube when inserted into the coupler as damage to the o-ring will result.
6. All burrs must be removed from outside of cut tubes before inserting into coupler or other components.
7. Power supply must be identical in voltage, cycle and phase to that specified on the cooler data plate.
Electrical outlet and furnished power cord with plug must be used to supply power to fixture. Do NOT wire
compressor directly to the power supply.
9. Warranty is voided if installation is not made following current Acorn Engineering installation instructions and
if components are assembled to the fixture that is not approved by Acorn Engineering.
2. Provide 4” minimum clear space on fixture sides to allow for proper ventilation through cabinet louvers.
8. This unit must be grounded per the requirements of applicable electrical codes.
11. Due to cold waste water, Acorn Engineering recommends that p-trap supplied by installer be insulated to
prevent excessive condensation.
12. Per UPC 609.10- All building water supply systems in which quick acting valves are installed shall be provided
with devices to absorb the hammer caused by high pressure resulting from the quick closing of the valve.
These pressure-absorbing devices shall be approved mechanical devices. Water pressure-absorbing devices
will be installed as close as possible to the quick closing valve.
A172.8UBL SERIES REFRIGERATED BI-LEVEL WALL MOUNTED WATER COOLER
Note: there are no mounting changes to be made for -SO models.
13
8"
6" 12"
TAIL
PIECE
*33"
71
4"
A
6"
*155
8"
AIR FLOW
11"
165
8"
51
4"E
185
8"
201
2"
D
E
B
173
8"
C
61
2"65
8"Typ.
91
4"
63
8"
41
4"
77
8" Typ.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
A172.8UBL
Page 3 of 11
Revised: 07/18/18
7020-905-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
3/8" NCT SUPPLY INLET
WASTE OUTLET FOR 1-1/4" P-TRAP
ELECTRICAL SERVICE ROUGH.
Ø3/8" HANGER BRACKET PUNCHING, 3 PLACES FOR
ANCHORING HARDWARE BY OTHERS.
Ø5/16" PUNCHING, 2 PLACES FOR ANCHORING
HARDWARE BY OTHERS.
A.
B.
C.
D.
E.
BY OTHERS.
NOTES:

INSTALLATION:
Choose configuration; Remove and reinstall filler plate, item 23 and reverse drain assembly if
required for alternate mounting configuration.
4. Anchor the water coolers to the wall at the lower mounting points in each back panel. Shim lower mounting
points to level unit if necessary.
6. Thoroughly flush the 3/8” O.D. supply line and then connect water cooler to water supply angle stop valve (by
others) with supplied 3/8” O.D. copper tube.
2. Remove the bottom cover from the water cooler and set aside in a safe place. Save the screws in a secure
location for re-use in later stages of installation.
5. Outlet tube from evaporator has an in-line tee with a tube going to the refrigerated unit's valve and the "TEE"
not connected. Connect the loose supply tube from refrigerated unit to the "TEE".
7. Use supplied flexible hose and clamps to connect waste tailpiece from the upper unit to the waste tailpiece of
lower unit and then make up 1-1/4” O.D. p-trap waste connection. Waste p-trap by others.
1. Mount hanger bracket to wall horizontally level as shown in Roughing-In and Dimensional Drawing. Note:
Adjust height of bracket if bubbler outlet height is required to vary from that shown.
Hanger Bracket MUST be securely anchored to wall with fasteners sufficient to support 3 times the weight of
cooler. If wall can not provide adequate support, order and install optional fixture support carrier.
3. Hang the water coolers on the hanger brackets ensuring the bracket tabs engage AND seat in the slots in the
back of the water coolers. NOTE: Hanging of refrigerated unit first is recommended since it is the heavier of
the two. Verify water coolers are level, left to right AND front to back from bottom of unit. CAUTION: The
bubbler stream may be adversely affected if units are not square and level. Bottom of units and louvers
should be used as reference to verify unit is square and plumb.
STANDARD WASTE CONFIGURATION ALTERNATE WASTE CONFIGURATION
ITEM 23
FILLER PLATE
ITEM 23
FILLER PLATE
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
A172.8UBL
Page 4 of 11
Revised: 07/18/18
7020-905-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

START UP:
2. Air within the water cooler system or the structure supply piping will cause an irregular bubbler outlet stream
until purged out by incoming water. Covering the bubbler with a clean cup (or similar object) is recommended
when first activating water cooler to prevent excessive splashing. Depress the pushbutton until steady water
stream is achieved.
3. If water flow requires adjustment, insert a slotted narrow blade screwdriver through the hole centered on the
pushbutton to the flow regulator. Turning clockwise will increase flow and turning counterclockwise will
decrease flow.
1. Before connecting power supply and assembling bottom cover to water cooler, but after thoroughly flushing
the supply line and connecting it to the fixture, turn on building water supply and check all connections for
leaks.
4. Recheck all water and drain connections with water flowing through system.
5. With power still NOT connected, carefully manually rotate cooling fan to insure proper clearance and free fan
action.
6. Plug water cooler in to electrical outlet and make sure unit begins to function.
7. Assemble bottom cover to water cooler with screws furnished.
TROUBLE SHOOTING:
IMPORTANT: BEFORE MAKING ANY OF THE REPAIRS LISTED, MAKE SURE THE WATER COOLER IS
DISCONNECTED FROM THE ELECTRICAL SUPPLY AND THE WATER SUPPLY VALVE IS SHUT OFF.
IMPORTANT : ASSUREZ-VOUS QUE LA FONTAINE D'EAU POTABLE RÉFRIGÉRÉE SOIT
DÉBRANCHÉE DE LA PRISE DE COURANT MURALE ET QUE LE ROBINET D'ALIMENTATION
D'EAU SOIT FRMÉ AVANT D'EFFECTUER LES RÉPARATIONS NÉCESSAIRES.
1. Adjustments
a. Cartridge – The water flow can be adjusted through the pushbutton using a straight blade
screwdriver and turning clockwise to increase flow and counterclockwise to decrease flow.
b. Cold Water Thermostat – The water temperature can be adjusted using a slotted screwdriver
and turning clockwise to make colder and counterclockwise to make warmer.
c. Bubbler Stream – Bubbler can be rotated slightly to direct the stream backwards or forwards.
Adjust the stream to minimize splashing. Splashing may occur from bubbler stream if the unit
is not level. Shim lower mounting points, if necessary, to level cooler.
2. Compressor Does Not Run
a. Check the electrical receptacle for power and correct voltage. The incoming voltage
must be within 10% of the rated voltage on the serial nameplate.
b. The cold thermostat is accessible by removing the bottom access cover. If the cold
thermostat capillary bulb loses its charge or becomes kinked it will fail in the open position
causing a disruption of power to the compressor. Unplug the water cooler and using and
ohm meter check for continuity across the two electrical terminals on the thermostat. Install
a new thermostat if there is no continuity.
c. Check for loose wires within the compressor box. The incoming power leads must be
connected to the overload and relay.
d. If all components check positive for continuity then test the wiring harness plug for
continuity to see if there is a broken wire within the wiring harness insulation.
3. Compressor Runs – Water Is Warm
a. The most common cause for a water cooler to run without producing cold water is a loss
of refrigerant. The water cooler must be taken to a certified refrigerant technician for repairs.
b. Make sure the condenser fan motor is operative. The fan blade must turn freely to help
remove the heat of compression.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
A172.8UBL
Page 5 of 11
Revised: 07/18/18
7020-905-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

7. Water Drip Or Will Not Shut Off:
a. Remove Pushbutton Adjust flow regulator to the highest setting using a
flat head screwdriver and turning clockwise. Check if water drip continues, if it is no longer
dripping turn screwdriver counter-clockwise until you have desired flow rate. Assure that
retaining nut is tighten to valve assembly, 25 in-lb torque is required. If issue still continues after
adjusting flow and tightening retainer nut, replacement of the flow regulator cartridge will be
required.
4. Compressor Cycling On Overload Protector
a. A dirty condenser or a blocked fan will cause a high head pressure and frequent cycling of
the overload protector.
b. Check the incoming voltage to make sure it is within 10% of the serial nameplate rating.
c. A restriction or moisture in the system will also cause intermittent cycling. A certified
refrigeration mechanic should be contacted in this situation.
d. Change the overload or relay if defective.
3. Periodically remove access panels and clean out in-line strainer.
6. Restricted Or No Water Flow
a. Ensure water supply service stop valve is fully open.
b. Verify minimum 20 psig supply line flow pressure.
c. Check for twists or kinks in bubbler tubing.
d. Check the water inlet strainer. Sediment from the main supply can get trapped in the
screen along with installation materials such as pipe dope and flux. The screen should
be cleaned and checked on a regular basis and replace if needed.
NOTE: STRAINER SCREEN MUST BE IN PLACE FOR WATER TO FLOW.
e. The cartridge valve located in the water control assembly or bubbler can also become
clogged with foreign material. The cartridge valve can only be replaced and not repaired.
f. Check flow adjustment. See start up note #3.
g. The water cooler may also develop a freezing condition in which the water will become
frozen inside the evaporator coil. This indicates a refrigeration problem or thermostat
failure in which case the water cooler needs to be checked by a qualified technician.
5. Exterior panels can be cleaned using mild household detergents or warm, soapy water. Extra care must be
used cleaning chrome plated items and mirror finished stainless steel. They can scratch easily and should only
be cleaned using a clean, soft cloth and mild soap with water or a mild glass cleaner.
c. An incorrect refrigerant charge, restriction or defective compressor (not pumping) will also
cause the compressor to run without producing cold water. All these signs indicate a
problem within the refrigeration system and the water cooler must be checked by an
authorized service company.
5. Noisy Operation
a. Check to make sure the fan blade is rotating freely.
b. Make sure the water cooler is correctly mounted to the wall. Absence of the two lower
mounting bolts may cause excess noise and vibration.
c. Check the compressor mounting to make sure the pins and clips are not rattling. If the
compressor appears to be noisy internally, it must be replaced.
1. Motors have lifetime lubrication and do not require scheduled maintenance.
2. Excess dirt or poor ventilation will cause the compress` more frequently.
CLEANING & MAINTENANCE GUIDE:
4. Do NOT use harsh chemicals, abrasive or petroleum based cleaners. Use of these will void the Acorn warranty.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
A172.8UBL
Page 6 of 11
Revised: 07/18/18
7020-905-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

2. Clean strainer as needed using clean water.
3. Cartridge replacement - insert diamond end of the universal tool into push button, rotate 90 degrees
and pull firmly to remove the button. Remove cartridge retaining nut . Remove and replace cartridge.
When replacing cartridge be sure to align the inlet and outlet ports on the cartridge with the ports in
the valve body.
— NOTE: STRAINER SCREEN MUST BE IN PLACE FOR WATER TO FLOW.
1. Strainer plug must be removed before cartridge replacement and strainer
maintenance (no need to turn the water off at the angle stop). Some residual water will drain
during plug removal.
Note: Use the universal maintenance tool to perform the following:
CARTRIDGE REPLACEMENT/ STRAINER MAINTENANCE
2
4
3
1
5
ITEM PART NUMBER DESCRIPTION
5 7003-830-000 UNIVERSAL MAINTANANCE TOOL
4 7003-864-000 STRAINER FILTER SCREEN
3 7003-097-001 O-RING &STRAINER PLUG
2 7000-060-000 FLOW REGULATOR CARTRIDGE(05 GPMG)
1 7003-095-001 VALVE ASSEMBLY
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
A172.8UBL
Page 7 of 11
Revised: 07/18/18
7020-905-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

PUSH-IN FITTING INSTALLATION
NOTE: FITTINGS AND TUBE SHOULD BE KEPT
CLEAN, BAGGED AND UNDAMAGED PRIOR TO
INSTALLATION.
2. Pull on the fitted tubing to ensure it is secure. Tube
should not come free from the fitting. Water test the
connection assembly prior to leaving the site to ensure
there are no leaks.
DISCONNECTING THE TUBE:
To disconnect the tube from the fitting ensure that the
water line is depressurized. Push collet square towards
the push-in fitting body and hold. While holding the collet
in, pull on the PE tubing to remove from the push-in fitting.
TO CUT TUBE:
Cut to fit length of 1/4” PE tubing and remove any burrs
or sharp edges. Ensure that the outside diameter is free
from score marks. Tube ends should be square.
INSERTING THE TUBE:
1. Firmly and fully insert the tubing end into the push-in
fitting up to the tube stop located approximately ½”
deep.
COLLET
COLLET
O-RING
O-RING
TUBE STOP
COLLET
COLLET
COLLET
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
A172.8UBL
Page 8 of 11
Revised: 07/18/18
7020-905-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

Standard A172.8UBL series refrigerated ADA cooler shown. All 1/4" O.D. Plastic tubing 15 must be
insulated with 16 foam insulation.
Universal Maintenance Tool
-Button Removal
-Cartridge Retaining Nut
Push-in Fittings
-Strainer Plug
-Removal of P.E. Tubing from
32
NOTE:
29 Flow Restrictor Only Available
With Low Flow Bubbler.
1
2
3
11
5
6
5
9
4
8
8
7
10 12 13
16
14
15
27"
27
24
17
17
1615
34"
25
26
23
22 21
19
18
20
33
15 16
15"
29
28
31
30
32
11
15 16
15"
29
31
30
28
NOTE: See page 11 for table of part numbers corresponding to
drawing below.
WATER COOLER PARTS BREAKDOWN DRAWING:
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
A172.8UBL
Page 9 of 11
Revised: 07/18/18
7020-905-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

Repairs must be made with Acorn Engineering parts only. Please order through your local representative or
distributor. The phone number to locate your local representative is 1.800.591.9360.
1
2
3
11
5
6
5
9
4
8
8
7
10 12 13
16
14
15
27"
27
24
17
17
1615
34"
25
26
23
22 21
19
18
20
33
15 16
15"
29
28
31
30
32
28
29
34 38
39
41
40
39
37
38
35
36
38
43 42
39
44
11
15 16
15"
NOTE:
29 Flow Restrictor Only Available
With Low Flow Bubbler.
-Strainer Plug
-Removal of P.E. Tubing from
Universal Maintenance Tool
-Cartridge Retaining Nut
Push-in Fittings
-Button Removal
32
SENSOR OPERATED WATER COOLER PARTS BREAKDOWN DRAWING:
NOTE: See page 11 for table of part numbers corresponding to drawing below.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
A172.8UBL
Page 10 of 11
Revised: 07/18/18
7020-905-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

Repairs must be made with Acorn Engineering parts only. Please order through your local representative or
distributor. The phone number to locate your local representative is 1.800.591.9360.
COOLER PARTS BREAKDOWN TABLE
NOTE: See previous page for fixture drawing corresponding to table of parts below.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
A172.8UBL
Page 11 of 11
Revised: 07/18/18
7020-905-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
ITEM #
PART NUMBER DESCRIPTION
1 0124-032-000 #8 x 3/4" LG PHIL FLAT HD SELF TAPPING SCREW
7003-001-199 BASIN TOP
7003-161-199 BF12 BASIN TOP WITH LESS HOLE FOR BF11/12
7003-161-299 BF12 BASIN TOP WITH HOLE FOR BF11/12
3 0124-056-000 #8 x 3/8" LONG PHILLIP HEAD SHEET METAL SCREW
7000-099-002 LOW-FLOW FLEXIBLE BUBBLER ASSEMBLY
7000-012-001 STAINLESS STEEL BUBBLER ASSEMBLY
5 7000-006-000 FLAT DRAIN GASKET
6 7003-182-000 DRAIN TAIL PIECE (SHORT)
7 7003-183-199 DRAIN HOSE
8 7003-184-000 7/8" SPRING HOSE CLAMP
9 7003-181-000 DRAIN TAIL PIECE (LONG)
7003-819-020 FILLER PLATE - GRANITE
7003-825-199 FILLER PLATE - STAINLESS STEEL
11 7003-014-199 HANGER BRACKET
12 0124-050-000 #8 x 3/8" LONG PHILLIPS PAN HEAD SCREW
13 1895-123-000 1/4" OD x 3/8" OD PUSH-IN CONNECTION
14 7003-115-001 EVAPORATOR ASSEMBLY
15 2169-000-000 1/4" OD TUBING
16 7012-055-000 TUBE INSLULATION
17 7003-003-199 BACK PANEL
7003-302-000 FAN MOTOR
7012-062-001 FAN MOTOR - 220V
19 7003-350-000 FAN BLADE
20 7003-201-000 CONDENSER
7012-801-000 COMPRESSOR
7012-030-001 COMPRESSOR - 220V
7012-802-000 START RELAY
7012-031-000 START RELAY - 220V
7012-803-000 START CAPACITOR
7012-032-000 START CAPACITOR - 220V
24 7003-250-000 COLD CONTROL
7003-817-020 LEFT CABINET - GRANITE
7003-823-299 LEFT CABINET - STAINLESS STEEL
7003-818-020 RIGHT CABINET - GRANITE
7003-824-299 RIGHT CABINET - STAINLESS STEEL
27 7003-007-199 SUPPORT STRUT
7003-816-020 APRON ASSEMBLY - GRANITE
7003-826-001 APRON ASSEMBLY - STAINLESS STEEL
7003-029-020 SENSOR OP APRON ASSEMBLY - GRANITE
7003-029-005 SENSOR OP APRON ASSEMBLY - STAINLESS STEEL
29 7003-093-001 FLOW RESTRICTOR - LOW-FLOW BUBBLER ONLY
30 7003-095-001 VALVE ASSEMBLY
31 7003-099-000 PUSH BUTTON
32 7003-830-000 UNIVERSAL MAINTENANCE TOOL
33 0124-031-000 #8 x 3/8 LNG SLOTTED HEX WASHER HD SCREW
34 7001-200-001 SOLENOID/VALVE MOUNTING ASSEMBLY
35 7003-027-199 SENSOR BRACKET, SENSOR OP
36 2562-369-001 9VDC SENSOR
37 7001-202-199 SENSOR SPACER
38 0308-009-000 #8-32 NYLON INSERT LOCKNUT
39 0331-023-000 #8 S/S FLAT WASHER
40 0711-407-199 POWER SUPPLY , 240VDC
41 7003-028-199 TRANSFORMER BRACKET
42 7000-059-199 1-1/4" - 18 NORMALLY OPEN VALVE CAP
43 7003-023-199 CARTRIDGE MTG BRACKET, SENSOR OP
44 7000-050-001 VALVE CARTRIDGE ASSEMBLY
2
4
25
26
28
22
10
18
21
23
