Murdock BF1 Series Installation and operating instructions

1.800.591.9360
Technical Assistance Fax: [phone]
TECHNICAL ASSISTANCE TOLL FREE TELEPHONE NUMBER:
Date: 07/15/16
BF1 Series
Bottle Filler, Pushbutton Operated
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
NOTES TO INSTALLER:
1. Please leave this documentation with the owner of the fixture when finished.
2. Please read this entire booklet before beginning the installation.
3. Check your installation for compliance with plumbing, electrical and other applicable codes.
LIMITED WARRANTY - UNITED STATES & CANADA
Murdock warrants that its products are free from defects in material or workmanship under normal use and
service for a period of one year from date of original shipment or for 18 months after the date of shipment from the
factory, whichever comes first. Murdock’s liability under this warranty shall be discharged solely by replacement
or repair of defective material, provided Murdock is notified in writing within one year from date of shipment,
F.O.B. Industry, California.
This warranty does not cover installation or labor charges and does not apply to materials, which have been
damaged by other causes such as mishandling or improper care or abnormal use. The repair or replacement of the
defective materials shall constitute the sole remedy of the Buyer and the sole remedy of Murdock under this
warranty. Murdock shall not be liable under any circumstances for incidental, consequential or direct charges
caused by defects in the materials, or any delay in the repair or replacement thereof. This warranty is in lieu of all
other warranties expressed or implied. Product maintenance instructions are issued with each unit and disregard
or non-compliance with these instructions will constitute an abnormal use condition and void the warranty.
Stainless steel must be protected on job site during construction and must be properly maintained after the water
has been introduced into the water cooler or drinking fountain, or Murdock’s limited warranty is void.
LIMITED EXPORT WARRANTY - One year on parts only.
COMPLIES WITH
Member of
MURDOCK
15125 Proctor Ave.
City of Industry, CA
91746 U.S.A.
Phone [phone]
626-336-4561
Fax [phone]
Murdock assumes no responsibility for use of void or
suspended data. © Copyright Murdock, City of
Industry, CA Member of Morris Group International.
Please visit www.murdockmfg.com for most
current specifications.
7109-708-001
www.murdockmfg.com
WATER COOLERS

MCBF1 (Install/Maintenance Instructions)
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Page 2 of 10
CONTEMPORARY WATER COOLERS
Date: 04/03/18
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
7109-708-001
WATER COOLERS
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Please visit www.murdockmfg.com
for most current specifications.
PRIOR TO INSTALLATION
Important: Some options may slightly alter installation. To ensure proper installation review the manual thoroughly and verify
rough-ins before beginning any work. File this manual with the owner or maintenance personnel upon completion of installation
— Fixture mounting requirements: Industry standard wall construction, adequate to support the fixture and (installer provided) wall
anchors sufficient to secure the fixture.
— Fixture operates within water pressure range of 20 to 105 psig. Murdock will not warranty fixtures damaged when connected to
supply lines with flow pressure lower than 20 psig or higher than 105 psig.
— Per UPC 609.10- All building water supply systems in which quick acting valves are installed shall be provided with devices to
absorb the hammer caused by high pressure resulting from the quick closing of the valve. These pressure-absorbing devices
shall be approved mechanical devices. Water pressure-absorbing devices will be installed as close as possible to the quick
closing valve.
— Water supply inlet is 1/4” OD polyethylene tube.
— Completely flush supply of all foreign debris before connecting to fixture. Bottle filler is designed to provide trouble free drinking
water unaffected by fixture connection tubing and fittings and not cause problems with taste, odor, color or sediment.
INSTALLATION INSTRUCTIONS:
1. Remove drinking cooler access panel and shut off water supply, then actuate valve to relieve pressure.
2. Drill 1/2” dia. hole thru drinking cooler deck (where shown above). Deburr hole and install grommet provided.
Drilling Notes:
— Wear approved safety glasses when drilling.
— Prior to drilling stainless steel, adhere masking tape over drilling area to protect finish and provide
marking surface.
— Use a short, sharp high-speed drill bit and drill speed of 400-600 RPM; applying heavy pressure. Drill
must cut at all times. DO NOT allow drill bit to ride, this will cause work hardening and will make it
very difficult to drill or tap. Bibb washers, placed on drill shank will help to prevent marring the surface
after the drill has broke through.
3. Mark vertical (plumb) center line on the wall, at the center of the drinking cooler deck.
5"
(127)
2"
(51)
C
L
Ø1
2"

MCBF1 (Install/Maintenance Instructions)
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Page 3 of 10
CONTEMPORARY WATER COOLERS
Date: 04/03/18
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
7109-708-001
WATER COOLERS
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Please visit www.murdockmfg.com
for most current specifications.
INSTALLATION INSTRUCTIONS CONTINUED:
C
L
3"
(76)
3"
(76) 3
8" (9.5) x 4 Mounting Anchors
(By Others)
103
8"
(262)
27
8"
(73)
Alignment
Notch
Horizontal Mounting
Channel
To Filler Tube
Valve Inlet
From Evaporator
Out Tee Fitting
Bottle Filler Mounting
Frame
Horizontal Mounting
Channel
Water Cooler
(Shown For Reference)
Air Line Inlet
Note: Housing not shown
for clarity
4. Carefully disassemble bottle filler. Remove the top, frame, horizontal mounting channels, and disconnect the PE tubing from
the fill tube. (see page 5)
5. Use the frame as template, align notches in the frame with the vertical center line, and with the frame sitting on the deck
NOTE: COOLER SHOULD BE LEVEL.
6. Mark four mounting holes.
7. Install the four wall anchors (by others).
8. Align mounting frame and horizontal mounting channels to the anchors (as shown) and attach to wall with mounting fasteners
(by others).
9. In drinking cooler access compartment, attach the “Y” strainer (provided) to existing 3/8” OD copper inlet tube and connect
outlet of “Y” strainer to existing 1/4” OD evaporator inlet tube. (see page 4).
10. *In drinking cooler access compartment, remove the 1/4” push-in fitting from evaporator outlet and replace it with 1/4” push-in
tee fitting. Reconnect the PE tube from the cartridge valve assembly to top of tee. (See page 4)
*See insert detail on page 4, for special installation instructions when installing on bi-level drinking fountains.
11. Remove the 18” piece of insulation from the 1/4” OD 30” PE tube. Pass the end of the 30” PE tube through the hole in the
deck of the drinking cooler. Reinstall 18” piece of insulation on to the 30” PE tube, under deck. Connect the 30” PE tube to
the side of the previously installed tee fitting, from step 10. (see page 4).
12. Reconnect 24” PE to fill tube.
13. To reassemble housing to mounting frame assembly, engage the left side of the housing behind the horizontal mounting
channels, then stretch the housing over the right end of the horizontal mounting channels, make sure that the rubber trim on
the housing is touching the water cooler deck. Secure the housing to the top channel, with #10-32 truss head screws
provided.
14. reassemble and install top with #8-32 truss head screws provided.
15. Turn on the water supply stop, test unit and check for leaks, then reinstall access panel.

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Page 4 of 10
CONTEMPORARY WATER COOLERS
Date: 04/03/18
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
7109-708-001
WATER COOLERS
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Please visit www.murdockmfg.com
for most current specifications.
MCBF1 (Install/Maintenance Instructions)
INSTALLATION INSTRUCTIONS CONTINUED:
WATER TUBING CONNECTIONS
To
cartridge
30" PE Tube to
valve inlet
From cold water tube
from evaporator
Cut tube
and
Install tee
Special Instructions
Bi-Level Drinking Fountains
ONLY INSERT DETAIL
When mounting bottle filler on unit with no
compressor, only.
NOTE: Insulation on all water tubes not shown (all PE
water tubes are insulated).
Fill Tube
Pushbutton Assembly
Valve Outlet Elblow
w/ Flow Control
Valve Inlet Fitting
Hole in Deck
Drinking Foutain
(Shown for Reference)
"Y" Strainer
Evaporator
30" Ø 1
4" PE Tubing
Evaporator Inlet
To Cartridge
Push-In Tee
Evaporator Outlet
3/8" OD Copper
inlet (by others)
1/4 x 3/8 Adapter
Pushbutton Air Line
1/4 Turn Shut-Off Valve

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Page 5 of 10
CONTEMPORARY WATER COOLERS
Date: 04/03/18
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
7109-708-001
WATER COOLERS
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Please visit www.murdockmfg.com
for most current specifications.
MCBF1 (Install/Maintenance Instructions)
RETRO-FIT INSTALL FOR EXISTING WATER COOLER FIXTURE:
PRESSURIZED SINGLE UNIT PIPE INSTALLATION (WITH -GF & -BF OPTIONS)
ITEM PART NUMBER DESCRIPTION QTY.
1 7012-055-000 FOAM INSULATION, PIPE, 3/8" ID x 1/4" THICK 5.5'
2 2169-000-000 TUBING, LLDPE, BLUE 1/4" OD 5'
17" Water Supply Tubing
13" Water Supply Tubing
1 2
To Bottle Filler or Glass Filler

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Page 6 of 10
CONTEMPORARY WATER COOLERS
Date: 04/03/18
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
7109-708-001
WATER COOLERS
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Please visit www.murdockmfg.com
for most current specifications.
MCBF1 (Install/Maintenance Instructions)
RETRO-FIT INSTALL FOR EXISTING WATER COOLER FIXTURE (NON-PRESSURIZED UNIT):
RE-PIPING FROM NON-PRESSURIZED TO PRESSURIZED (FOR -GF & -BF ONLY)
To re-pipe a single non-pressurized unit to pressurized, you will have to move the water supply tubing around, with “NO”
additional tubing needed. Before performing this task you MUST SHUT OFF THE WATER SUPPLY, and disconnect all supply
connections.
STEP 3:
From the outlet of the cartridge assembly, connect to
the bubbler.
STEP 1:
Starting with the supply line coming from the wall,
connect to the inlet of the evaporator assembly.
STEP 2:
From the outlet of the evaporator assembly, connect to
the inlet of the cartridge assembly.
Wall Supply Connection
17" Water Supply Tubing
Evaporator Inlet Connection
13" Water Supply Tubing
Bubbler Connection
Cartridge Assembly
Outlet Connection
Cartridge Assembly
Inlet Connection
Evaporator Outlet Connection
To Bottle Filler or Glass Filler
Add 1
4" Tee for Both BF or GF

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Page 7 of 10
CONTEMPORARY WATER COOLERS
Date: 04/03/18
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
7109-708-001
WATER COOLERS
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Please visit www.murdockmfg.com
for most current specifications.
MCBF1 (Install/Maintenance Instructions)
PUSH-IN FITTING INSTALLATION
NOTE: FITTINGS AND TUBE SHOULD BE KEPT
CLEAN, BAGGED AND UNDAMAGED PRIOR TO
INSTALLATION.
2. Pull on the fitted tubing to ensure it is secure. Tube
should not come free from the fitting. Water test the
connection assembly prior to leaving the site to ensure
there are no leaks.
DISCONNECTING THE TUBE:
To disconnect the tube from the fitting ensure that the
water line is depressurized. Push collet square towards
the push-in fitting body and hold. While holding the collet
in, pull on the PE tubing to remove from the push-in fitting.
TO CUT TUBE:
Cut to fit length of 1/4” PE tubing and remove any burrs
or sharp edges. Ensure that the outside diameter is free
from score marks. Tube ends should be square.
INSERTING THE TUBE:
1. Firmly and fully insert the tubing end into the push-in
fitting up to the tube stop located approximately ½”
deep.
COLLET
COLLET
O-RING
O-RING
TUBE STOP
COLLET
COLLET
COLLET

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Page 8 of 10
CONTEMPORARY WATER COOLERS
Date: 04/03/18
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
7109-708-001
WATER COOLERS
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Please visit www.murdockmfg.com
for most current specifications.
MCBF1 (Install/Maintenance Instructions)
START UP:
1. Air within the bottle filler system or the structure supply pipping will cause an irregular spout outlet stream until
purged out by incoming water. Hold cup (or similar object) directly below filler spout is recommended when first
activating bottle filler to prevent excessive splashing. Press and hold pushbutton until steady water stream is
achieved.
2. Using the same method, hold cup (or similar object) directly over bubbler(s) and active bubblers until air is purged
out and a steady stream is achieved.
OPERATING INSTRUCTIONS:
Hold container to be filled just below the filler tube in the center of the unit, then push pushbutton. When the container
is almost filled, release the pushbutton.
Push Button
Bottle Filler Label
Fill Spout

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Page 9 of 10
CONTEMPORARY WATER COOLERS
Date: 04/03/18
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
7109-708-001
WATER COOLERS
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Please visit www.murdockmfg.com
for most current specifications.
MCBF1 (Install/Maintenance Instructions)
TROUBLE SHOOTING:.
1. RESTRICTED OR NO WATER FLOW
a. Ensure Water Supply service stop valve is fully open.
b. Verify minimum 20 psig supply line flow pressure.
c. Check for twist or kinks in spout tubing.
d. Check the water inlet “Y’’ strainer. Sediment from the main supply can get trapped in the screen along with
installation materials such as pipe dope and flux. The screen should be cleaned and checked on a regular
basis and replace if needed.
e. Flow control in solenoid valve outlet elbow clogged remove & clean.
f. The water cooler may also develop a freezing condition in which the water will become frozen inside the
evaporator coil. This indicates a refrigeration problem or thermostat failure in which case the water cooler
needs to be checked by a qualified technician.
CLEANING & MAINTENANCE GUIDE:
1. To remove water spots or rust spots, stainless steel cleaner/polish on a cloth is recommended.
2. If there are stubborn spots or if you wish to treat a scratch, synthetic abrasive general purpose pads such as
scotch brite are recommended.
3. Apply stainless steel cleaner/polish to the synthetic abrasive pads and carefully rub the panel with the grain.
4. DO NOT use harsh chemicals, abrasive or petroleum based cleaners. Use of these will void the Murdock
warranty. DO NOT use abrasives on powder coated units.
5. Stainless steel should be kept clean at all times. If a coating of stainless steel cleaner/ polish is maintained,
stainless steel surfaces will retain their new, clean, polished appearance indefinitely. Use clean mild soapy
water for powder coated units.
6. Periodically remove access panel of cooler and clean out inline “Y’’ strainer.

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Page 10 of 10
CONTEMPORARY WATER COOLERS
Date: 04/03/18
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
7109-708-001
WATER COOLERS
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Please visit www.murdockmfg.com
for most current specifications.
MCBF1 (Install/Maintenance Instructions)
BOTTLE FILLER PARTS
BREAKDOWN
ITEM #
PART NUMBER DESCRIPTION ITEM # PART NUMBER DESCRIPTION
1 7014-004-199 Bottle Filler Top 12 7014-010-199 Bottle Filler Trim (Right)
2 7000-415-000 Self-Retaining J-Nut, SS 13 7013-210-001 1/4" "Y" Strainer, Bottle Filler
3 7014-007-001 Channel and Valve Assembly 14 7013-020-000 5/8" OD Grom m et
4 0316-018-00 10-32 Stn Stl Nut Retainer 15 1895-710-000 1/4" Push-in Union Tee
5 7013-027-002 Air-Control Valve As sem bly 16 7014-006-199 Bottle Filler Frame
6 2150-002-199 1/8" x 10" O.D. Clear PE Tubing 17 0112-021-000 #10-32 x 1/2" S/S Hex Btn Hd Screw
7 2169-000-000 1/4" OD LLDPE Tubing, Blue 18 7013-008-199 Bottle Filler Channel
8 2566-160-001 Pushbutton Assem bly 19 1895-123-000 1/4" x 3/8" OD Push-In Tube Union
9 0279-002-000 #8-32 Socket Cap Btn Hd Screw 20 7012-055-000 Foam Insulation
10 7014-000-003 Bottle Filler Sub Assembly 21 7000-420-000 1/4 Turn Shut-Off Valve
11 7014-009-199 Bottle Filler Trim (Left) 22 7014-005-199 Bottle Filler Top Bracket
13
3
4
8
9
20
14
20
15 19
12
7
19
18
17
9
16
2
6
5
20
11
10
7
30"
12"
18"
24"
21
1
22
