Murdock H2O To Go BF15 Series Installation and operating instructions

COMPLIES WITH
Member of
TECHNICAL ASSISTANCE TOLL FREE TELEPHONE NUMBER:
1.800.591.9360
Technical Assistance Fax: [phone]
LIMITED WARRANTY - UNITED STATES & CANADA
This warranty does not cover installation or labor charges and does not apply to materials, which have been
damaged by other causes such as mishandling or improper care or abnormal use. The repair or replacement of
the defective materials shall constitute the sole remedy of the Buyer and the sole remedy of Murdock under this
warranty. Murdock shall not be liable under any circumstances for incidental, consequential or direct charges
caused by defects in the materials, or any delay in the repair or replacement thereof. This warranty is in lieu of
all other warranties expressed or implied. Product maintenance instructions are issued with each unit and
disregard or non-compliance with these instructions will constitute an abnormal use condition and void the
warranty. Stainless steel must be protected on jobsite during construction and must be properly maintained
after the water has been introduced into the water cooler or drinking fountain, or Murdock’s limited warranty is
void.
Murdock warrants that its products are free from defects in material or workmanship under normal use and
service for a period of one year from date of shipment from the factory. Murdocks’s liability under this warranty
shall be discharged solely by repair or replacement of defective material, provided Murdock is notified in writing
within the time periods described above.
NOTES TO INSTALLER:
1. Please leave this documentation with the owner of the fixture when finished.
2. Please read this entire booklet before beginning the installation.
3. Check your installation for compliance with plumbing, electrical and other applicable codes.
LIMITED EXPORT WARRANTY - One year on parts only.
Murdock™ assumes no responsibility for use
of void or superseded data. © Copyright
Murdock Mfg., City of Industry, CA Member of
Morris Group International. Please visit
www.murdockmfg.com for most current
specifications.
7020-957-001 Date: 08/02/19
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Surface Mounted Bottle Fillers
BF15 & BF16 Series
Surface Mount Bottle Fillers
MURDOCK
15125 Proctor Ave.
City of Industry, CA
91746 U.S.A.
Phone [phone]
626-336-4561
Fax [phone]
www.murdockmfg.com
Federal
Public Law
111-380
(No Lead)
BF15 Series BF16 Series

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
7020-957-001 Revised: 08/02/19
Page 2 of 13
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Surface Mounted Bottle Fillers
— Fixture operates within water pressure range of 20 to 105 PSIG. Murdock will not warranty fixtures damaged when connected
to supply lines with flow pressure lower than 20 PSIG or higher than 105 PSIG.
— Fixture mounting requirements: Industry standard wall construction, adequate to support the fixture and (installer provided) wall
anchors sufficient to secure the fixture.
— Per UPC 609.10- All building water supply systems in which quick acting valves are installed shall be provided with devices to
absorb the hammer caused by high pressure resulting from the quick closing of the valve. These pressure-absorbing devices
shall be approved mechanical devices. Water pressure-absorbing devices will be installed as close as possible to the quick
closing valve.
— Electrical Receptacle(s) must be wired to a GFCI protected circuit. Fixture must be earth grounded per N.E.C. (National
Electrical Code).
Important: Some options may slightly alter installation. To ensure proper installation, review the manual thoroughly and verify
rough-ins before beginning any work. File this Manual with the owner or maintenance personnel upon completion of installation.
— Completely flush supply of all foreign debris before connecting to fixture. Bottle Filler is designed to provide trouble- free
drinking water unaffected by fixture connection tubing and fittings and not cause problems with taste, odor, color or sediment.
PRIOR TO INSTALLATION
— Water supply inlet is 3/8” O.D. Copper Tube.
Prior to roughing in, consult with local, state, and federal codes for proper mounting height.
DIMENSIONAL DRAWING
BF15/16 Surface Mounted Bottle Filler
OPTIONAL -BCD BOTTLE
COUNTER AND FILTER
REPLACEMENT DISPLAY
291
2"
[749]
181
4"
[464]
73
8"
(187)
121
8"
[308]
125
8"
[321]
47
8"
[124]
GENERAL OTES:
1. ALL DIMENSIONS ARE IN INCHES (MM)
LED LIGHTING
WITH -BCD OPTION
ONLY
51
8"
341
2"
[876]
A.F.F.

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
7020-957-001 Revised: 08/02/19
Page 3 of 13
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Surface Mounted Bottle Fillers
INSTALLATION INSTRUCTIONS:
Place unit onto a horizontal surface. Unscrew Top Screws with 1/8"
Allen Wrench (not included) and place in a secure location for later
use. Open unit by swinging Mounting Panel down.
1#10-32 x 1" Allen Button Head Screw
1
Bottle Filler Housing
2
Mounting Panel
3
Remove Bottle Filler Housing from unit by removing one Screw from
the Hinge and sliding the Bottle Filler Housing out. Set aside for later
use in the Manual.
Mounting Panel
2
#10-32 x 3/4" Phillips Round Head Screw
3
Bottle Filler Housing
1
2
Finished Wall
1
Mounting Panel
2
Anchoring Hardware, by others
3
1
2
3
2
11
2
3
Locate and attach Mounting Panel to finished wall. Secure Mounting
Panel with Anchoring Hardware, provided by installer. See step four
for rough-in layout.
3
1
2
2
3

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
7020-957-001 Revised: 08/02/19
Page 4 of 13
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Surface Mounted Bottle Fillers
INSTALLATION INSTRUCTIONS CONTINUED:
Provide wall openings as indicated in rough-in detail provided, ensuring to block out the electrical service rough and Waste
outlet for 1-1/2" P-Trap. Use Mounting Panel as template.
General Notes:
1. Dimension indicated with (*) is for 34-1/2" deck
height. Adjust accordingly for preferred deck
height.
2. Anchoring is required for holes marked with
(X). Auxiliary holes available if required.
4
2
C
L
*241
4"
TYP.
A.F.F.
12"
TYP.
91
2"
TYP.
47
8"
TYP.
33
4"
TYP.
7"
*261
4"
A.F.F.
61
4"
31
2"
4"
*277
8"
A.F.F.
3
1
4
5
110VAC Electrical Duplex1
2
3
4
5
3/8" NCT Supply Inlet
Waste Outlet for 1-1/2" P-Trap
Mounting Panel
Ø1/4" Holes, for Anchoring
Hardware, by others
341
2"
Deck Height Notch
A.F.F.
Receptacle, by others
X X X
X X X
*291
8"
A.F.F.
181
4"
291
2"
6 Housing, Shown for Ref.
6

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Surface Mounted Bottle Fillers
7020-957-001 Revised: 08/02/19
Page 5 of 13
INSTALLATION INSTRUCTIONS CONTINUED:
With the Mounting Panel secured to finished wall, install P-Trap Waste
Outlet. P-Trap must not extend more than 4-1/4" from finished wall. Mounting Panel
1
P-Trap
2
Drain Tray
3
Connect 3/8" O.D. "Y" Strainer to main water supply. Recommend
using angle stop for easy maintenance. Angle stop must not extend
more than 3-1/2" from finished wall.
Angle Stop Recommended,
2
"Y" Strainer
3
Mounting Panel
1
Re-mount Bottle Filler Housing by reversing steps taken in Step 2.
Bottle Filler Housing
1
Mounting Panel
2
#10-32 x 3/4" Phillips Round Head screw
3
by others
41
4"
Max
Top View
31
2"
Max

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Surface Mounted Bottle Fillers
7020-957-001 Revised: 08/02/19
Page 6 of 13
INSTALLATION INSTRUCTIONS CONTINUED: (BF15)
Mounting Panel
1
Bottle Filler Housing
2
Mounting Panel
1
Bottle Filler Housing
2
1/8" O.D. Polyethylene Air Line
3
Valve Water Supply Outlet Elbow
3
Bottle Filler Water Supply Inlet Tubing
4
1
2
4
3
Valve Air Line Inlet
4
Plastic Cable Holder
5
With Bottle Filler Housing secured to unit, connect water supply line.
Keep supply line within plastic cable holders to prevent supply line
from getting pinched or damaged. If Fixture is BF16, see steps 8B-9B.
8A
9A With Water Supply Line properly secured, connect 1/8" O.D.
Polyethylene Air Line to valve. Keep Air Line within the plastic cable
holders to prevent supply line from getting pinched or damaged.
Turn on water and check for Leaks throughout the system.
1
2
51/4"
Min.
4
3
Plastic Cable Holder
5
5

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Surface Mounted Bottle Fillers
7020-957-001 Revised: 08/02/19
Page 7 of 13
INSTALLATION INSTRUCTIONS CONTINUED: (BF16)
With Bottle Filler Housing secured to unit, connect water supply line
and electrical wiring as shown below. Keep supply line and wiring
within plastic cable holders to prevent supply line and wiring from
getting pinched or damaged. If fixture is BF15, see steps 8A-8B.
Mounting Panel
1
Bottle Filler Housing
2
Solenoid Valve Electrical Wiring
3
Plug-in power supply, turn on water and check for leaks
throughout the system.
Mounting Panel
1
Bottle Filler Housing
2
Power Supply
3
Bottle Counter Display / Sensor Wiring
4
Solenoid Valve Water Supply Outlet Elbow
5
Bottle Filler Water Supply Inlet Tubing
6
1
2
3
46
5
110VAC Duplex Receptacle
4
3
4
2
1
Plastic Cable Holder
7
7
8B
9B

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Surface Mounted Bottle Fillers
7020-957-001 Revised: 08/02/19
Page 8 of 13
INSTALLATION INSTRUCTIONS CONTINUED:
With fixture tested, hook Lanyard from Bottle Filler Housing to
Mounting Panel and tighten Screw.
10 Bottle Filler Housing
1
Lanyard
2
Mounting Panel
3
#10-32 x 1" Allen Button Head Screw
2
Bottle Filler Housing
3
Bottle Filler Assembly
1
1
Lift up from Fill Spout area to close the unit by swinging Bottle Filler
Housing up and secure with Screws from step 1. Do not force closed.
Address any interference if necessary. Do not over-tighten.
11
To open unit for maintenance purposes, remove Top Screws. Lift
Bottle Filler Housing up from Fill Spout area then pull away from wall.
12
3
2
2
4Lanyard Mounting Screw
4
1
Mounting Panel
4
#10-32 x 1" Allen Button Head Screw
2
Bottle Filler Housing
3
Bottle Filler Assembly
1
Mounting Panel
4
4
3
2
4
3
2
1

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Surface Mounted Bottle Fillers
7020-957-001 Revised: 08/02/19
Page 9 of 13
2. Connect the Sensor Wires to either the Solenoid Valve or -BCD Bottle Counter Display (if equipped).
ELECTRICAL INSTALLATION:
1A. Plug-In Operation: Plug transformer provided into GFCI protected electrical service, used by the Bottle Filler.
START UP:
NOTE: PLUG-IN POWER IS A STANDARD FEATURE FOR BF16.
BOTTLE COUNTER ADJUSTING & RESETTING INSTRUCTIONS:
1. Air within the Bottle Filler System or the structure supply piping will cause an irregular Spout outlet stream until
purged out by incoming water. Hold cup (or similar object) directly below Filler Spout is recommended when first
activating Bottle Filler to prevent excessive splashing. Activate sensor until steady water stream is achieved.
NOTE: Bottle Counter Has Multiple Functions
Reset/ Mode Button
• Counts refilled bottles
• Adjustable for units with and without Filters
• “REPLACEMENT FILTER” alert function
• Alert reset, when Filter is replaced
Description
Illuminated LCD Display counts bottles and has a Filter replacement alert function.
OPERATING INSTRUCTIONS:
Bottle Counting Function
The software applies a flow volume of approximately 16.9 fl oz (volume in standard size plastic water bottle) to
each bottle counted. If the flow volume is less than 16.9 fl oz, there will be no count but the volume will
accumulate, so that part way through the next cycle the total bottle count will change.
Position container to be filled directly in front of the Sensor and centered under the Filler Spout. Water flow starts
automatically. When the container is almost filled, remove container. The water will stop flowing.
Fill Spout
Sensor
-BCD Bottle Counter Display
with Illuminated Display

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Surface Mounted Bottle Fillers
7020-957-001 Revised: 08/02/19
Page 10 of 13
“FILTER NONE”
Systems With or Without Filter:
•To reset “REPLACE FILTER” message:
-Press and hold Button until “3” is displayed, then release.
•To change display to match Filter capacity:
“FILTER 3000”
“FILTER 1500”
Counter Modes:
Located on the back of the Display you will find the Reset/Mode Button for the mode settings. The
Reset/Mode Selection Button is accessible by removing the Housing, then locate the large hole in the back of
the Display Mounting Bracket. Use your finger or nonconductive object to depress the Reset/Mode Selection
Button.
CAUTION: DO NOT USE SHARP OR METAL OBJECTS!!!
With this Reset/Mode Button, you are able to indicate whether the unit has a Filter or does not have a Filter.
The Reset/Mode Button is used to remove the “REPLACE FILER” alert after the Filter has been replaced.
FILTER REPLACEMENT FUNCTIONS:
NOTE: When the volume accumulates to programmed Filter volume, the “REPLACE FILTER” alert will
appear on the display every time the Bottle Filler is activated.
-Press and hold Button until the Display matches installed Filter type, then release.
RESET/MODE
BUTTON

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Surface Mounted Bottle Fillers
PUSH-IN FITTING INSTALLATION
NOTE: FITTINGS AND TUBE SHOULD BE KEPT
CLEAN, BAGGED AND UNDAMAGED PRIOR TO
INSTALLATION.
2. Pull on the fitted Tubing to ensure it is secure. Tube
should not come free from the Fitting. Water test the
connection assembly prior to leaving the site to ensure
there are no leaks.
DISCONNECTING THE TUBE:
Prior to disconnecting the Tube from the Fitting, ensure
that the water line is depressurized. Push Collet Square
towards the Push-In Fitting Body and hold. While holding
the Collet in, pull on the PE Tubing to remove from the
Push-In Fitting.
TO CUT TUBE:
Cut to fit length of 1/4” PE Tubing and remove any
burrs or sharp edges. Ensure that the outside diameter
is free from score marks. Tube ends should be square.
INSERTING THE TUBE:
1. Firmly and fully insert the Tubing end into the Push-In
Fitting up to the Tube Stop located approximately 1/2”
deep.
COLLET
COLLET
O-RING
O-RING
TUBE STOP
COLLET
COLLET
COLLET
7020-957-001 Revised: 08/02/19
Page 11 of 13

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Surface Mounted Bottle Fillers
7020-957-001 Revised: 08/02/19
Page 12 of 13
ITEM #
PART NUMBER DESCRIPTION ITEM #
PART NUMBER DESCRIPTION
1 7014-271-002 WALL MOUNTED FRAME ASSY., BF15/16 7 7012-055-000 FOAM PIPE INSULATION
2 CONTACT FACTORY HOUSING ASSEMBLY, BF16-BCD 8 1895-709-000 ELBOW, 1/4" PUSH-IN X 1/4" STEM
3 4970-265-000 P-TRAP 9 2150-005-199 1/8" O.D. LLDPE TUBING, CLEAR
4 0116-123-000 #10-32 x 1" BUTTON HEAD SCREW 10 2566-160-001 PBH S/T SIDE OUTLET PUSHBUTTON
5 7000-021-001 "Y" STRAINER 11 7001-203-001 AIR-TROL VALVE & BRACKET ASSY
6 2169-000-000 1/4" O.D. LLDPE TUBING, BLUE
BOTTLE FILLER PARTS
BREAKDOWN
BF15 PARTS LIST
11
5
1
2
3
4
8
7
6
10
9

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Surface Mounted Bottle Fillers
7020-957-001 Revised: 08/02/19
Page 13 of 13
ITEM #
PART NUMBER DESCRIPTION
ITEM #
PART NUMBER DESCRIPTION
1 7014-271-002 WALL MOUNTED FRAME ASSY., BF15/16 9 0116-123-000 #10-32 x 1" BUTTON HEAD SCREW
2 7014-270-001 HOUSING ASSEMBLY, BF16-BCD 10 7000-021-001 "Y" STRAINER
3 4970-265-000 P-TRAP 11 2169-000-000 1/4" O.D. LLDPE TUBING, BLUE
4 2563-381-001 SENSOR "A" ASSEMBLY 12 7012-055-000 FOAM PIPE INSULATION
5 0110-012-000 #6 x 3/16" TRUSS HEAD SCREW 13 7001-200-001 SOLENOID / VALVE MOUNTING ASSY
6 0716-111-001 BOTTLE COUNTER WITH CONNECTORS 14 0710-731-001 POWER SUPPLY
7 0110-011-000 #6 x 3/16" PAN HEAD SCREW 15 1895-709-000 ELBOW, 1/4" PUSH-IN X 1/4" STEM
8 7014-253-199 SPLASH GUARD
BF16 PARTS LIST
BOTTLE FILLER PARTS
BREAKDOWN 14
13
10
1
2
3
5
4
6
7
8
7
9
15
1211
