I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Semi-Recessed Bottle Fillers
BF3 & BF4 Series
Semi-Recessed Bottle Filler
MURDOCK
15125 Proctor Ave.
City of Industry, CA
91746 U.S.A.
Phone [phone]
626-336-4561
Fax [phone]
www.murdockmfg.com
Federal
Public Law
111-380
(No Lead)

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
7109-709-001 Date: 07/05/17
Page 2 of 14
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Semi-Recessed Bottle Fillers
BF3 ROUGHING-IN AND DIMENSIONAL DRAWING
Prior to roughing consult with local, state, and federal codes for proper installation.
10"
(255)
143
8"
(365)
BLOCKOUT
4"
(101)
Min.
21
2"
(64)
281
8"
(714)
181
4"
(464)
44"
(1118)
A.F.F.
281
2"
(724)
A.F.F.
31
8"
(80)
Typ.
2"
(50)
A A
11"
(280)
11"
(280)
53
8"
(137)
17
8"
(48)
15
8"
(41)
253
8"
(645)
BLOCKOUT
21
2"
(64)
GENERAL DIMENSIONS:
1. ALL DIMENSIONS ARE IN INCHES (MM)
2. STOP VALVE NOT PROVIDED
NOTE: RIGHT, LEFT, AND REAR WASTE ORIENTATION
ARE OPTIONAL IF NEEDED FOR CALLOUTS INDICATED **.
A. 1/4" PUNCHING, 20 PLACES FOR
ANCHORING HARDWARE BY OTHERS
B. 3/8" NCT SUPPLY INLET
C. 1-1/4" O.D. WASTE OUTLET
A
A
B
** C
BA
231
8"
(588)
A.F.F.
** C

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Semi-Recessed Bottle Fillers
BF4 ROUGHING-IN AND DIMENSIONAL DRAWING
Prior to roughing consult with local, state, and federal codes for proper installation.
10"
(255)
143
8"
(365)
BLOCKOUT
4"
(101)
Min.
21
2"
(64)
31
8"
(80)
Typ.
2"
(50)
A A
11"
(280)
11"
(280)
53
8"
(137)
17
8"
(48)
15
8"
(41)
253
8"
(645)
BLOCKOUT
21
2"
(64)
GENERAL DIMENSIONS:
1. ALL DIMENSIONS ARE IN INCHES (MM)
2. STOP VALVE NOT PROVIDED
NOTE: RIGHT, LEFT, AND REAR WASTE ORIENTATION
ARE OPTIONAL IF NEEDED FOR CALLOUTS INDICATED **.
A. 1/4" PUNCHING, 20 PLACES FOR
ANCHORING HARDWARE BY OTHERS
B. 3/8" NCT SUPPLY INLET
C. 1-1/4" O.D. WASTE OUTLET
D. ELECTRICAL SERVICE ROUGH
17
8"
(48)
31
2"
(89)
A
A
D
B
** C
BA
231
8"
(588)
A.F.F.
7
8"
(22)
D
ALT
** C
281
8"
(714)
181
4"
(464)
44"
(1118)
A.F.F.
281
2"
(724)
A.F.F.
7109-709-001 Date: 07/05/17
Page 3 of 14

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Semi-Recessed Bottle Fillers
PRIOR TO INSTALLATION:
1. Read all installation instructions carefully, before proceeding.
2. Carefully remove fixture from packaging, preventing scratching or damage.
3. Provide mounting surface, sufficient to support the fixture and loads on the fixture.
4. Provide rough-ins as shown on the roughing-in and dimensional drawing, including water supply, drain pipe
and gravel drain well. (See page 2 for rough-in details)
5. Unlock and swing open the hinged door assembly to expose internal components. Disconnect 1/4” O.D.
polyethylene tube and 5/8” O.D. overflow waste connection from the hinged door assembly. Then remove the
hinged door assembly from mounting frame by unlatching insert clip hinges.
8. Completely flush water supply lines of all foreign debris, before connecting to the fixture.
INSTALLATION: (see drainage & mounting roughing-in pg. 2 or 3)
1. Insert mounting frame into the rough-in block out and secure using 1/4-20 UNC mounting hardware
(Provided by others)
2. Make up the 3/8” O.D. Copper inlet supply connection.
3. Loosen slip nuts to orientate P-trap to desired direction then tighten slip nuts and make up 1-1/4” O.D. waste
connection.
4. Attach hinged door assembly to mounting frame by latching insert clip hinges. Make necessary adjustments to
hinges to prevent door from rubbing on wall when opening. Refer to door hinge manufacture for adjustment
instructions.
4.FOR -BF4 ONLY Make up power connections to the ground, neutral & hot within the electrical box.
NOTE: BEFORE PERFORMING STEP 5 REFER TO ELECTRICAL INSTALLATION ON PAGE 6.
5. Test for leaks and proper operation, and then install the door using the hinges provided.
START UP:
Air within the bottle filler system or the structure supply piping will cause an irregular spout outlet stream until
purged out by incoming water. Press and hold pushbutton until steady water stream is achieved.
SENSOR OPERATION INSTRUCTIONS:
Hold container to be filled just below the sensor in the center of the filler spout and then move the container
upward and water flow will start automatically. When the container is almost filled, lower the container below
the sensor until the water stops flowing. (see label on the bottle filler)
7109-709-001 Date: 07/05/17
Page 4 of 14
Aluminum Name Plate
Sensor (BF4)
Fill Spout
Drain
Hemispherical
Pushbutton (BF3)

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Semi-Recessed Bottle Fillers
HAND OPERATION INSTRUCTIONS:
Hold container to be filled just below the filler tube in the center of the unit, then push pushbutton. When the
container is almost filled, release the pushbutton.
WATER TUBING CONNECTIONS:
NOTE: Insulation on all water tubes not shown (all PE water tubes are insulated).
7109-709-001 Date: 07/05/17
Page 5 of 14
3/8" O.D.
Copper Inlet
18" PE Tubing
"Y" Strainer
Air-Control Valve
Inlet Fitting
Air-Control Valve
Outlet Elbow
Fill Spout
Keys

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Semi-Recessed Bottle Fillers
ELECTRICAL INSTALLATION:
NOTE: PLUG IN POWER IS A STANDARD FEATURE.
1A. Plug-In Operation: Plug transformer provided into GFCI protected electrical service, used by the semi-
recessed bottle filler. Plug in transformer to power supply and connect to red sensor wire.
FOR -BAT BATTERY OPERATION OPTION.
1. -BAT Battery Operation: Peel off paper backing from hook & loop pads then press battery holder firmly
in place. (See Ref. Below). Connect the battery holder wires to the red sensor wires. Unit requires six
AA, alkaline or lithium batteries (not included). Note: When the battery holder is connected, the unit
active.
2. Connect the blue sensor wires to the solenoid valve wires.(See Below)
TRANSFORMER WIRING AND WATER TUBING CONNECTIONS:
7109-709-001 Date: 07/05/17
Page 6 of 14
Plug-In Transformer
18" PE Tubing
3/8" O.D.
Copper Inlet
"Y" Strainer
Sensor
Solenoid Valve
Inlet Fitting
Solenoid Valve
Outlet Elbow
Optional -BAT
9V Battery Pack
Fill Spout

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Semi-Recessed Bottle Fillers
7109-709-001 Date: 07/05/17
Page 7 of 14
BOTTLE COUNTER ADJUSTING & RESETTING INSTRUCTIONS:
NOTE: Bottle Counter Has Multiple Functions
Reset/ Mode Button
• Counts refilled bottles, otherwise purchased
• Adjustable for Units with and without filters
• “REPLACEMENT FILTER” alert function
• Alert reset, when filter is replaced
Description
Illuminated LCD display, counts bottles, and has a filter replacement alert function
Bottle Counting Function
The software applies a flow volume of approximately 16.9 fl oz (volume in standard size plastic water
bottle) to each bottle counted. If the flow volume is less than 16.9 fl oz there will be no count but the
volume will accumulate, so that part way through the next cycle the total bottle count will change.
ILLUMINATED LCD DISPLAY

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Semi-Recessed Bottle Fillers
7109-709-001 Date: 07/05/17
Page 8 of 14
RESET/MODE BUTTON
FILTER REPLACEMENT FUNCTIONS:
NOTE: When the volume accumulates to 1500 gallons (recommended maximum filter flow volume)
the “REPLACE FILTER” alert will appear on the display every time the bottle filler is activated.
Counter Modes
Located on the back of the display you will find the reset button for the mode settings. The Reset/Mode
selection button is accessible by removing the top of the bottle filler, then locate the large hole in the
back of the display mounting bracket. Use your finger or nonconductive implement to depress the
Reset/Mode Selection Button.
!!!DO NOT USE SHARP OR METAL IMPLEMENTS!!!
With this reset button, you are able to indicate whether or not the unit has a filter or does not have a
filter. The reset button will also take away the “REPLACE FILTER” alert once the filter has been
replaced.
Systems With or Without Filter
• Depress the Reset/Mode selection button for 6
Seconds, the number of seconds will count up on the
display.
• At the end of the 6 seconds, “FLTR YES” or “FLTR NO”
WILL APPEAR on the display.
• “FLTR YES” means that there is a filter in the system
and a “REPLACE FILTER” alert WILL APPEAR on the
display when the maximum filter flow volume is reached.
• “FLTR NO” means that there is no filter in the system
and a “REPLACE FILTER” alert WILL NOT APPEAR
on the display.
• Release button when the option required is on the
display (Filter Yes or No)
CLEARING “REPLACE FILTER” ALERT:
NOTE: This Function only applies if the system as a filter
• Replace old filter with new filter.
• Depress the Reset/Mode selection button for 2 SECONDS
• The “REPLACE FILTER” will no longer appear on the display
• Test by actuating the bottle filler, alert will not appear.

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Semi-Recessed Bottle Fillers
7109-709-001 Date: 07/05/17
Page 9 of 14
SOLENOID
CONNECTION
POWER SUPPLY CONNECTION
(BLACK CABLES)
SENSOR CONNECTION
(BLACK & RED CABLES)
SENSOR CONNECTION TRANSFORMER
SOLENOID VALVE
BOTTLE COUNT DISPLAY
SENSOR
BOTTLE FILLER & BOTTLE COUNTER CONNECTIONS:

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Semi-Recessed Bottle Fillers
PUSH-IN FITTING INSTALLATION
NOTE: FITTINGS AND TUBE SHOULD BE KEPT
CLEAN, BAGGED AND UNDAMAGED PRIOR
TO INSTALLATION.
2. Pull on the fitted tubing to ensure it is secure.
Tube should not come free from the fitting. Water
test the connection assembly prior to leaving the
site to ensure there are no leaks.
DISCONNECTING THE TUBE:
To disconnect the tube from the fitting ensure that
the water line is depressurized. Push collet square
towards the push-in fitting body and hold. While
holding the collet in, pull on the PE tubing to remove
from the push-in fitting.
TO CUT TUBE:
Cut to fit length of 1/4” PE tubing and remove any
burrs or sharp edges. Ensure that the outside
diameter is free from score marks. Tube ends
should be square.
INSERTING THE TUBE:
1. Firmly and fully insert the tubing end into the
push-in fitting up to the tube stop located
approximately ½” deep.
COLLET
COLLET
O-RING
O-RING
TUBE STOP
COLLET
COLLET
COLLET
7109-709-001 Date: 07/05/17
Page 10 of 14

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Semi-Recessed Bottle Fillers
TROUBLE SHOOTING:.
1. RESTRICTED OR NO WATER FLOW:
a. Ensure Water Supply service stop valve is fully open.
b. Verify minimum 20 psig supply line flow pressure.
c. Check for twist or kinks in spout tubing.
d. Check the water inlet “Y’’ strainer. Sediment from the main supply can get trapped in the
screen along with installation materials such as pipe dope and flux. The screen should be
cleaned and checked on a regular basis and replace if needed.
e. Flow control in solenoid valve outlet elbow clogged remove & clean.
SENSOR TROUBLE SHOOTING:
1. IF LIGHT WITHIN SENSOR DOES NOT FLASH ONCE WHEN USER IS WITHIN RANGE:
a. Verify 9VDC output of battery pack.
b. Replace defective batteries.
c. Sensor in “Security Mode” after 30 seconds of constant detection. Remove source of
detection and wait 30 seconds before checking.
d. Sensor is picking up a highly reflective surface. Eliminate cause of reflection and wait 30
seconds before checking.
2. IF LIGHT WITHIN SENSOR LENS FLASHES ONCE WHEN THE USER IS WITHIN RANGE:
a. Repair bad connection from sensor to solenoid.
b. There is debris or scale in the solenoid assembly. Remove solenoid, pull out plunger and
spring. Clean with scale remover solution.
c. There is debris or scale in center or two holes in convolution of the water diaphragm.
Remove and clean.
CLEANING & MAINTENANCE GUIDE:
For Powder coated units: Units should be cleaned using a mild soap solution with a sponge or cotton cloth.
Wipe down surfaces then rinse with clean water.
For Stainless steel units:
1. To remove water spots or rust spots, stainless steel cleaner/polish on a cloth is
recommended.
2. If there are stubborn spots or if you wish to treat a scratch, synthetic abrasive general
purpose pads such as scotch brite are recommended.
3. Apply stainless steel cleaner/ polish to the synthetic abrasive pads and carefully rub the
panel with the grain.
4. DO NOT use harsh chemicals, abrasive or petroleum based cleaners. Use of these will
void the Murdock warranty. DO NOT use abrasives on powder coated units.
5. Stainless steel should be kept clean at all times. If a coating of stainless steel cleaner/
polish is maintained, stainless steel surfaces will retain their new, clean, polished
appearance indefinitely.
6. Periodically remove access panel of cooler and clean out inline “Y’’ strainer
7109-709-001 Date: 07/05/17
Page 11 of 14

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Semi-Recessed Bottle Fillers
FILTER CARTRIDGE REPLACEMENT (Murdock p/n 7012-313-000):
1. , this allows access to the filter.
2. Pull the filter assembly straight up about six inches and then turn the small valve, on the filter inlet, a
1/4 turn to shut off the water supply to the filer.
3. While holding the filter assembly up about six inches, unscrew the lower filter cartridge from the top of
the filter assembly. Then move the top of the filter assembly to the side and finish removing the filter
cartridge from the unit.
4. Reverse the steps to install a new filter cartridge.
5. Test for leaks and proper operation, then install top.
Unlock and swing open bottle filler door
OPTIONAL -BAT BATTERY REPLACEMENT:
1. Unlock and swing open bottle filler door and remove battery pack from placed location. Do not
disconnect the wires from the battery pack unless necessary.
2. Replace the six alkaline AA batteries while observing polarity.
3. Place the battery pack back to mounted location and test for proper operation. Then close bottler filler
door and lock.
WIRING DIAGRAM:
BATTERY PACK
SOLENOID
SENSOR
RED WIRES
7109-709-001 Date: 07/05/17
Page 12 of 14

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Semi-Recessed Bottle Fillers
BF3 PARTS LIST
ITEM
PART NUMBER DESCRIPTION ITEM PART NUMBER DESCRIPTION
1 7013-139-001 FRONT PANEL ASSEMBLY 13 B054-034-000 FLEXIBLE PVC TUBE
2 7013-109-001 MOUNTING FRAME ASSEMBLY 14 0326-018-000 RETAINING CLIP
3 6354-012-000 INSERT CLIP HINGE 15 7013-128-199 OVERFLOW EXIT ADAPTER
4 6354-020-000 0MM CLIP BASE PLATE 16 0116-003-000 #10-32 x 1/2" S/S HEX SCREW
5 1895-709-000 1/4" PUSH-IN ELBOW 17 7013-118-199 LATCH ADJUSTMENT BRACKET
6 7013-137-001 AIR CONTROL VALVE ASSEMBLY 18 7013-108-003 CYLINDER LOCK ASSEMBLY
7 0110-003-000 #8-3/4" PAN HEAD SCREW 19 2169-000-000 1/4" O.D. BLUE TUBING
8 7013-102-002 DRAIN TRAY 20 7000-021-001 "Y" STRAINER ASSEMBLY
9 7000-006-000 DRAIN ADAPTER GASKET 21 2566-150-001 HEMISPHERICAL PUSHBUTTON
10 7003-186-199 1-1/4" x 2-3/4" PLASTIC DRAIN TUBE 22 7013-103-199 MESH SCREEN
11 4970-265-000 1-1/4" P-TRAP 23 7013-114-199 SCREEN RING
12 0358-010-000 HOSE CLAMP 24 0302-005-000 1/4-20 UNC STN. STL. HEX NUT
7109-709-001 Date: 07/05/17
Page 13 of 14
20
11
10
912
13
21
6
3
16
4
16
17
19
15
16
5
3
15
14
8
18
2
1
7
22
23
24
25

MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Semi-Recessed Bottle Fillers
ITEM
PART NUMBER DESCRIPTION ITEM PART NUMBER DESCRIPTION
1 7013-108-001 FRONT PANEL ASSEMBLY 16 0710-730-001 9V PLUG-IN TRANSFORMER
2 7013-109-001 MOUNTING FRAME ASSEMBLY 17 7013-118-199 LATCH ADJUSTMENT BRACKET
3 6354-012-000 INSERT CLIP HINGE 18 7013-108-003 CYLINDER LOCK ASSEMBLY
4 6354-020-000 0MM CLIP BASE PLATE 19 2169-000-000 1/4" O.D. BLUE TUBING
5 1895-709-000 1/4" PUSH-IN ELBOW 20 7000-021-001 "Y" STRAINER ASSEMBLY
6 7013-133-001 VALVE ASSEMBLY 21 7013-125-001 SOLENOID BRACKET ASSEMBLY
7 7013-102-002 DRAIN TRAY 22 7013-009-001 NANO SENSOR SPACER
8 7000-006-000 DRAIN ADAPTER GASKET 23 7013-057-002 NANO SENSOR ASSY
9 7003-186-199 1-1/4" x 2-3/4" PLASTIC DRAIN TUBE 24 7013-019-199 FOAM TAPE
10 4970-265-000 1-1/4" P-TRAP 25 7013-010-199 NANO SENSOR BRACKET
11 0358-010-000 HOSE CLAMP 26 0302-003-000 #8-32 HEX NUT
12 B054-034-000 FLEXIBLE PVC TUBE 27 7013-103-199 MESH SCREEN
13 0326-018-000 RETAINING CLIP 28 7013-114-199 SCREEN RING
14 7013-128-199 OVERFLOW EXIT ADAPTER 29 0302-005-000 1/4-20 UNC STN. STL. HEX NUT
15 0116-003-000 #10-32 x 1/2" S/S HEX SCREW 30 0110-003-000 #8-3/4" PAN HEAD SCREW
BF4 PARTS LIST
7109-709-001 Date: 07/05/17
Page 14 of 14
20
10
9
8
11
12
21
6
3
16 15
4
15
17
19
15
15
5
3
14
13
7
18
2
1
26
25
24 2223
27
28
29
30
