Murdock A171.8-UG-D1-BFS Series Installation and operating instructions

CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
7020-985-001
A171.8-UG-D1-BFS Series & A171.8-UG-VR-D1-BFS Series
Barrier Free, Wall Mounted Water Cooler
A171108F-UG-D1-BFS / A171408F-UG-D1-BFS / A171108S-UG-D1-BFS / A171408S-UG-D1-BFS
A171108F-UG-VR-D1-BFS / A171408F-UG-VR-D1-BFS / A171108S-UG-VR-D1-BFS / A171408S-UG-VR-D1-BFS
TECHNICAL ASSISTANCE TOLL FREE TELEPHONE NUMBER:
1.800.591.9360
Technical Assistance E-Mail: [email protected]
Revised: 07/10/2023 A
COMPLIES WITH
Murdock assumes no responsibility for use of void or
suspended data. © Copyright Murdock, City of
Industry, CA Member of Morris Group International.
Please visit www.murdockmfg.com for most
current specifications.
A171408F-UG-D1-BF2S **
A171408S-UG-VR-D1-BF1S
NOTES TO INSTALLER:
1. Please leave this documentation with the owner of the fixture when finished.
2. Please read this entire booklet before beginning the installation.
3. Check your installation for compliance with plumbing, electrical and other applicable codes.
4. IMPORTANT: Water supply to unit from RO Reverse Osmosis filtration systems will damage
fixture components and void product Warranty.
Federal
Public Law
111-380
(No Lead)
ANSI/ASHRAE 18
(220V Compressor Only)
NSF/ANSI/CAN 61
(** Subject to availability)
Member of 15125 Proctor Ave, City of Industry,
CA, 91746 U.S.A.
Phone [phone]
www.murdockmfg.com

Page 2 of 16 A171.8-UG-VR-D1-BFS Revised: 07/10/2023 A
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
7020-985-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
IMPORTANT
This Fixture is not suitable for installation in an area where a water jet could be used as well as in environments where
freezing may occur. This fixture dispenses water that has been lowered in temperature, but otherwise remains
unchanged by the materials in the Water Cooler. It is common for electrical equipment to be grounded to water lines
either within a structure or away from it. Every attempt should be made to prevent this kind of grounding from
generating electrical feedback into the Water Cooler creating electrolysis. Electrolysis will cause a metallic taste or
cause water metal content to increase.
NOTE: A Dielectric Coupling must be used to connect the Water Cooler to the water supply. A nonmetallic Coupler is
furnished with this Water Cooler to meet this requirement.
**NOTE: Only -VR Series units are rated for outdoors. Refer to page 5 for complete details and requirements.
ROUGHING-IN AND DIMENSIONAL DRAWING
Prior to roughing-in, consult with local, state, and federal codes for proper mounting height. All installation and service
may only be performed by authorized personnel. No unauthorized persons shall have access to the service area.
Mounting Carrier: Refer to Installation details provided by Carrier manufacturer when unit is to be installed with In-
®
Wall Mounting Carrier (provided by others). Compatible J.R. Smith brand Carrier model is Figure # 0830.
A171.8-UG-VR-D1-BF Series Wall Mounted Drinking Fountain
NOTES: Dimensions indicated (*) are for ADA frontal approach installation. Adjust vertical dimension (*) as required to comply with federal,
state, and local codes. For Child ADA compliant parallel approach, decrease Bubbler spout height to 30” maximum above finished floor.
Provide clear floor space as required. Compliance is subject to the interpretation and requirements of the Local Code Authority.
GENERAL NOTES:
ALL DIMENSIONS ARE IN INCHES [MM]
ALLOW 4 INCHES [102 MM] MINIMUM CLEARANCE PER SIDE FOR VENTILATION
DIMENSIONS SHOWN ARE FOR ADA ADULT HEIGHT. ADJUST VERTICAL
DIMENSIONS AS NECESSARY TO COMPLY WITH FEDERAL, STATE, & LOCAL CODES
STOP VALVE, P-TRAP, & ELECTRICAL OUTLET NOT SUPPLIED
IMPORTANT: COOLERS MUST BE ATTACHED TO WALL WITH APPROPRIATE
1.
2.
*3.
4.
5.
ANCHOR SCREWS
Electrical Requirements (Chiller Models):
-Provide Duplex Receptacle on GFCI Protected Circuit
- (Standard) 115VAC, 60Hz, 5A
- (220V Option) 220VAC, 60Hz, 3A
D
16"
[408] 131
4"
[337]
*27"
[687]
F
43
4"
[119]
*33"
[838]
21"
[533]
*313
4"
[806]
63
8"
[162]
TYP
A
B
C
E
1315
16"
[354]
177
8"
[454]
221
4"
[565] 193
8"
[492]
2"
[51]
7" [178] TYP
2813
16"
[732]
2" [51]
4 1
4" [108]
5 3
4" [146]
G
A. 3/8" O.D. SUPPLY INLET
B. WASTE OUTLET FOR P-TRAP BY OTHERS FOR
PROVIDED 1-1/4" O.D. TAILPIECE
C. ELECTRICAL SERVICE ROUGH FOR -BF2
D. Ø3/8" HANGER BRACKET PUNCHING, 6 PLACES
FOR ANCHORING HARDWARE BY OTHERS
E. Ø1/4" PUNCHING, 3 PLACES FOR ANCHORING
HARDWARE BY OTHERS
F. 1-1/4" [32] O.D. TAILPIECE FOR P-TRAP BY OTHERS
G. BOTTLE FILLER PUSHBUTTON

Page 3 of 16 A171.8-UG-VR-D1-BFS Revised: 07/10/2023 A
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
7020-985-001
PRIOR TO INSTALLATION:
Important: Some options may slightly alter installation. To ensure proper installation, review the Manual
thoroughly and verify rough-ins before beginning work. Leave this Manual with the owner or
maintenance personnel upon completion of installation.
— Fixture mounting requirements: Industry standard wall construction, adequate to support the fixture
and installer-provided Wall Anchors sufficient to secure the fixture.
— Receptacle(s) must be wired to a GFCI protected circuit. Fixture must be earth grounded per NEC
(National Electric Code).
— Inspect fixture and all parts for damage.
—To avoid a hazard due to instability, fixture must be installed in accordance with the instructions.
IMPORTANT:
1. Waste P-Trap, Water Supply Service Angle Stop Valve, and 2” x 4” Electrical Plug-In Receptacle to
be supplied by others in accordance with local codes. (by others) must be used for theA P-Trap
Drain connection.
2. Provide 4” minimum clear space on fixture sides to allow for proper ventilation through Cabinet
Louvers.
3. Water Supply Inlet is 3/8” Outer Diameter copper Tubing. Waste Outlet is 1-1/4” Outer Diameter.
4. Completely flush supply lines of all foreign debris before connecting to fixture. Water Cooler is
designed to not cause problems with taste, odor, color, or sediment. Optional (-WF1) Water Filter is
available should any of these problems arise from the Water Supply.
5. Do NOT solder Tubing inserted into the Coupler as damage to the O-Ring may result.
6. All burrs must be removed from outside of cut Tubing before inserting into Coupler or other
components.
7. Power Supply must be identical in voltage, cycle and phase to that specified on the Water Cooler
Data Plate. Electrical Outlet and furnished Power Cord with Plug must be used to supply power to
fixture. Do NOT wire Compressor directly to the Power Supply.
8. This unit must be grounded per the requirements of applicable electrical codes.
9. Warranty is voided if installation is not followed per current Murdock Mfg. installation instructions
and if components are assembled to the fixture that are not approved by Murdock Mfg.
10. Fixture is to operate within a water pressure range of 20 PSIG (138 kPa) to 105 PSIG (724 kPa).
Warranty is void if the unit is allowed to operate outside the range of 20 PSIG (138 kPa) to 105
PSIG (724 kPa). Consult with UPC and local codes for maximum allowable water pressures.
11. Due to cold waste water, Murdock Mfg. recommends that P-Trap supplied by installer be insulated
to prevent excessive condensation.
12. 609.10 Water Hammer. Building water supply systems where quick-acting valves are installed shall
be provided with water hammer arrester(s) to absorb high pressures resulting from the quick closing
of these valves. Water hammer arresters shall be approved mechanical devices that comply with
ASSE 1010 or PDI-WH 201 and shall be installed as close as possible to quick-acting valves.
13. 609.10.1 Mechanical Devices. Where listed mechanical devices are used, the manufacturer’s
specifications as to location and method of installation shall be followed.
14. If the Power Supply Cord is damaged, it may only be replaced by authorized qualified persons.
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

Page 4 of 16 A171.8-UG-VR-D1-BFS Revised: 07/10/2023 A
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
7020-985-001
INSTALLATION:
1. Mount Hanger Bracket to wall horizontally level as shown in Roughing-In and Dimensional Drawing.
NOTE: Adjust height of Bracket if Bubbler outlet height is required to vary from that shown
/indicated. Hanger Bracket MUST be securely anchored to wall with fasteners sufficient to support 3
times the weight of Water Cooler.
NOTE: If wall cannot provide adequate support, order and install fixture support carrier.
NOTE: If replacing a you may be able to use existing mounting bracket competitors Water Cooler
2. Remove the Bottom Cover from the Water Cooler and set aside in a safe place. Place the Screws
in a secure location for re-use in later stages of installation.
3. Hang the Water Cooler on the Hanger Bracket, ensuring the Bracket Tabs engage AND seat in the
slots in the back of the Water Cooler. Verify Water Cooler is level, left to right AND front to back from
bottom of unit. NOTE: The Bubbler stream may be adversely affected if unit is not square and level.
Bottom of unit and Louvers should be used as reference to verify unit is square and plumb.
4. Anchor Water Cooler to wall at other mounting points in Base. Shim lower rear mounting points to
level unit, if necessary.
5. Thoroughly flush the 3/8” O.D. supply line and then connect Water Cooler to water supply Angle
Stop Valve (by others) with supplied 3/8” O.D. Copper Tubing.
6. Make up 1-1/4” O.D. Waste Connection for P-Trap (by others).
START UP:
1. Do not connect electrical power to unit: With Bottom Cover removed, turn on fixture water supply
and check all connections for leaks.
2. Air within the Water Cooler system or the structure supply piping will cause an irregular Bubbler
outlet stream until purged out by incoming water. Thoroughly flush and purge air from supply line by
depressing the Pushbutton or activating infrared sensor, until steady water stream is achieved.
3. If water flow requires adjustment, insert a slotted narrow blade Screwdriver through the hole
centered on the Pushbutton to the Flow Regulator. Turning clockwise will increase flow and turning
counterclockwise will decrease flow.
4. Recheck all water and drain connections with water flowing through system.
5. With power still NOT connected, carefully rotate Cooling Fan manually to insure proper clearance
and free Fan action.
6. Plug Water Cooler into Electrical Outlet and make sure unit begins to function. IMPORTANT: After
turning power on to initiate cooler and cool down, immediately purge (chiller) water by operating unit
continuously for approx. 1 minute.
7. IMPORTANT! Thoroughly, inspect all unit connections for water leaks.
7. Assemble Bottom Cover to Water Cooler with Screws furnished.
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

Page 5 of 16 A171.8-UG-VR-D1-BFS Revised: 07/10/2023 A
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
7020-985-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
SIDE VIEW
FRONT VIEW
33"
[838]
Caulking
Caulking
OUTDOOR INSTALLATION INSTRUCTIONS:
IMPORTANT: A171.8-UG-VR-D1-BF Series units are rated for outdoor use.
ŸUnits installed outdoors presume average conditions and require adequate protection to prevent
exposure to extreme hot or cold temperatures which will affect Warranty.
ŸBest practices include installation beneath an overhang and avoiding direct sunlight.
ŸContinual ambient temperatures exceeding 80°F (26.67°C) may cause compressor to wear
prematurely.
ŸUnits are not freeze resistant.
ŸCaulk all around the basin where it contacts the wall and where apron contacts the wall as shown,
to reduce the possibility of rain water from leaking into the cabinet. DO NOT CAULK THE
REMOVABLE LOWER ACCESS COVER.

Page 6 of 16 A171.8-UG-VR-D1-BFS Revised: 07/10/2023 A
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
7020-985-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
A171.8-UG-D1-BF1S, A171.8-UG-D1-BF2S, A171.8-UG-VR-D1-BF1S & A171.8-UG-VR-D1-BF2S
PRESSURIZED SINGLE UNIT PIPE INSTALLATION
Water Supply Tubing
To Bottle Filler
Water Supply Tubing
Valve Assembly

Page 7 of 16 A171.8-UG-VR-D1-BFS Revised: 07/10/2023 A
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
7020-985-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
PUSH-IN FITTING INSTALLATION
NOTE: FITTINGS AND TUBE SHOULD BE KEPT
CLEAN, BAGGED AND UNDAMAGED PRIOR TO
INSTALLATION.
2. Pull on the fitted Tubing to ensure it is secure. Tube
should not come free from the Fitting. Water test the
Connection assembly prior to leaving the site to ensure
there are no leaks.
DISCONNECTING THE TUBE:
To disconnect the tube from the Fitting, ensure that the
water line is depressurized. Push Collet square towards
the Push-In Fitting Body and hold. While holding the Collet
in, pull on the plastic PE Tubing to remove from the Push-
In Fitting.
TO CUT TUBE:
Cut to fit length of 1/4” PE Tubing and remove any
burrs or sharp edges. Ensure that the outside diameter
is free from scored marks. Tube ends should be
square.
INSERTING THE TUBE:
1. Firmly and fully insert the Tubing end into the Push-In
Fitting up to the Tube Stop located approximately 1/2”
deep.
COLLET
COLLET
O-RING
O-RING
TUBE STOP
COLLET
COLLET
COLLET

Page 8 of 16 A171.8-UG-VR-D1-BFS Revised: 07/10/2023 A
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
7020-985-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
THE HOLES OF THE UNIT FRAME.
DISCONNECT FROM THE POWER SUPPLY.
PLACE FILTER/BRACKET ASSEMBLY 1 ON INSIDE OF
WATER SUPPLY. IF UNIT IS A REFRIGERATED MODEL,
UNIT FRAME AND ALIGN HOLES IN THE BRACKET WITH
REMOVE THE BOTTOM HOUSING AND TURN OFF UNIT
B-
A-
USE THE SCREWS 2 PROVIDED TO PASS THRU THE
FRAME CLEARANCE HOLES AND SCREW INTO THE
C-
CONNECT NEW PE TUBE PROVIDED WITH FILTER TO
EVAPORATOR PUSH-IN INLET, WHERE TUBE WAS
UNION 4 TO WHERE IT CONNECTS TO THE EVAPORATOR.
E-
F-
D- FOLLOW PE TUBE FROM "Y" STRAINER 3 OR PUSH-IN
IMPORTANT: FLUSH 5 GALLONS OF WATER THRU THEG-
TURN ON WATER. CHECK FOR LEAKS.
FILTER BEFORE ALLOWING FIXTURE USE.
CHECK UNIT FOR PROPER OPERATION.
RE-INSTALL BOTTOM HOUSING.I-
IF REFRIGERATED UNIT, TURN ON POWER SUPPLY ANDH-
DISCONNECT TUBE FROM EVAPORATOR, CONNECT TO
REPLACEMENT.
TO DISCONNECT THE TUBE FROM THE PUSH-IN FITTING
TUBE HOLD DOWN GRIPPER AND PULL TUBE OUT
SLOWLY.
WAY TO MAKE A GOOD CONNECTION. CARTRIDGE
TO CONNECT PUSH-IN FITTINGS, PUSH TUBE IN ALL THE
1-
2-
BRACKET HOLES.
REMOVED.
FILTER INLET PUSH-IN CONNECTION.
-WF1, -WF3 INSTALLATION INSTRUCTIONS:
NOTES:
2
4
3
1
1/4" PUSH-IN OUTLET
REPLACEMENT CARTRIDGE
-RWF3 PART # 7012-318-000
-RWF1 PART # 7012-313-000
WF1 / WF3 Filter Assembly Shown
OPTIONAL WATER FILTER INSTALLATION:
REFER TO INSTALLATION DETAILS PROVIDED WITH -WF1EZ
(REFERENCE INSTALLATION DRAWING 7020-009-001)
-WF1EZ FILTER (Detail A):
-WF3 FILTER CARTRIDGE INSTALLATION:
WATER FILTER HAS 3000 GALLON CAPACITY, CARTRIDGE
WILL REQUIRE REPLACEMENT AFTER 100 HOURS OF ACTUAL
OPERATIONAL USAGE. FREQUENCY OF FIXTURE OPERATION
REPLACEMENT.
WILL DETERMINE TIME FRAME FOR CARTRIDGE
-WF1 FILTER CARTRIDGE INSTALLATION:
WATER FILTER HAS 1500 GALLON CAPACITY, CARTRIDGE
WILL REQUIRE REPLACEMENT AFTER 50 HOURS OF ACTUAL
OPERATIONAL USAGE. FREQUENCY OF FIXTURE OPERATION
REPLACEMENT. (-SO, -SOC, -FG MODELS)
WILL DETERMINE TIME FRAME FOR CARTRIDGE
IMPORTANT:
FLUSH 3-5 GALLONS OF WATER THROUGH THE
FILTER BEFORE INITIAL USE!
(Bubbler run time for approximately 10-15 minutes,
Bottle Filler run time for approximately 3-5 minutes.)
Detail A

Page 9 of 16 A171.8-UG-VR-D1-BFS Revised: 07/10/2023 A
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
7020-985-001
TROUBLESHOOTING:
IMPORTANT: BEFORE MAKING ANY OF THE REPAIRS LISTED, MAKE SURE THE WATER
COOLER IS DISCONNECTED FROM THE ELECTRICAL SUPPLY AND THE WATER SUPPLY
VALVE IS SHUT OFF.
IMPORTANT : ASSUREZ-VOUS QUE LA FONTAINE D'EAU POTABLE RÉFRIGÉRÉE SOIT
DÉBRANCHÉE DE LA PRISE DE COURANT MURALE ET QUE LE ROBINET D'ALIMENTATION
D'EAU SOIT FRMÉ AVANT D'EFFECTUER LES RÉPARATIONS NÉCESSAIRES.
1. Adjustments:
a. Cartridge – The water flow can be adjusted using a slotted narrow blade Screwdriver and
turning clockwise to increase flow and counterclockwise to decrease flow.
b. Bubbler Stream – Bubbler can be rotated slightly to direct the stream backwards or
forwards. Adjust the stream to minimize splashing. Splashing may occur from Bubbler
stream if the unit is not level. Shim lower mounting points, if necessary, to level Water Cooler.
c. Cold Water Thermostat – IMPORTANT: Thermostat is Factory pre-set. Thermostat settings
should never be field adjusted since damage to fixture may occur, voiding product Warranty.
2. Compressor Does Not Run
a. Check the Power Supply Cord.
b. Check the electrical Receptacle for power and correct voltage. The incoming voltage must be
within 10% of the rated voltage on the Serial Nameplate.
c. The Cold Thermostat is accessible by removing the Bottom Access Cover. If the Cold
Thermostat Capillary Bulb loses its charge or becomes kinked, it will fail in the open position
causing a disruption of power to the Compressor. Unplug the Water Cooler and using an
ohm Meter, check for continuity across the two electrical Terminals on the Thermostat. Install a
new Thermostat if there is no continuity.
d. Check for loose wires within the Compressor Box. The incoming power Leads must be
connected to the Overload and Relay.
e. If all components check positive for continuity, then test the Wiring Harness Plug for
continuity to see if there is a broken Wire within the Wiring Harness insulation.
3. Compressor Runs – Water Is Warm
a. The most common cause for a Water Cooler to run without producing cold water is a
loss of refrigerant. The Water Cooler must be taken to a certified refrigerant technician
for repairs.
b. Make sure the Condenser Fan Motor is operative. The Fan Blade must turn freely to help
remove the heat.
c. An incorrect refrigerant charge, restriction, or defective Compressor (not pumping) will
also cause the Compressor to run without producing cold water. All these signs indicate
a problem within the refrigeration system and the Water Cooler must be checked by an
authorized service company.
4. Compressor Cycling On Overload Protector
a. A dirty Condenser or a blocked Fan will cause a high head pressure and frequent cycling
of the Overload Protector.
b. Check the incoming voltage to make sure it is within 10% of the Serial Nameplate rating.
c. A restriction or moisture in the system will also cause intermittent cycling. A certified
refrigeration mechanic should be contacted in this situation.
d. Change the Overload or Relay if defective.
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

Page 10 of 16 A171.8-UG-VR-D1-BFS Revised: 07/10/2023 A
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
7020-985-001
5. Noisy Operation
a. Check to make sure the fan blade is rotating freely.
b. Make sure the water cooler is correctly mounted to the wall. Absence of the two lower
mounting bolts may cause excess noise and vibration.
c. Check the compressor mounting to make sure the pins and clips are not rattling. If the
compressor appears to be noisy internally, it must be replaced.
6. Restricted Or No Water Flow
a. Ensure water supply service stop valve is fully open.
b. Verify minimum 20 psig supply line flow pressure.
c. Check for twists or kinks in bubbler tubing.
d. Check the water inlet strainer. Sediment from the main supply can get trapped in the
screen along with installation materials such as pipe dope and flux. The screen should
be cleaned and checked on a regular basis and replace if needed.
NOTE: STRAINER SCREEN MUST BE IN PLACE FOR WATER TO FLOW.
e. The cartridge valve located in the water control assembly or bubbler can also become
clogged with foreign material. The cartridge valve can only be replaced and not
repaired.
f. Check flow adjustment. See start up note #3.
g. The water cooler may develop a freezing condition in which the water will become
frozen inside the evaporator coil. This indicates a refrigeration problem or thermostat
failure. Disconnect the electrical power and have the unit checked by a qualified technician.
CLEANING & MAINTENANCE GUIDE:
1. Motors have lifetime lubrication and do not require scheduled maintenance.
2. Excess dirt or poor ventilation will cause the compressor overload protector to turn the compressor
off and it will cycle on and off with no cold water coming out of bubbler. Periodically clean with
vacuum cleaner, air hose or brush the condenser fins and cabinet ventilation louvers. In
environments where dirt and dust is more prevalent, clean more frequently.
3. Periodically remove access panels and clean out in-line strainer.
4. Do NOT use harsh chemicals, abrasive or petroleum based cleaners. Use of these will void the
warranty.
5. Exterior panels can be cleaned using mild household detergents or warm, soapy water. Extra care
must be used cleaning chrome plated items and mirror finished stainless steel. They can scratch
easily and should only be cleaned using a clean, soft cloth and mild soap with water or a mild glass
cleaner.
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
TROUBLESHOOTING (CONTINUED):

Page 11 of 16 A171.8-UG-VR-D1-BFS Revised: 07/10/2023 A
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
7020-985-001
A171.8-UG-VR-D1-BFS VANDAL RESISTANT CARTRIDGE REPLACEMENT/ STRAINER
MAINTENANCE
Note: Use the -VR maintenance tool to perform the following:
1. Strainer plug 4 must be removed before cartridge replacement and strainer
maintenance (no need to turn the water off at the angle stop). Some residual water will drain
during plug removal.
2. Clean strainer 4 as needed using clean water.
3. Cartridge replacement - Rotate and remove -VR pushbutton escutcheon 6 to release pushbutton 7 and springs 8 9 to
access cartridge.
4. Remove cartridge retaining nut 10 . Remove and replace cartridge 2 . When replacing cartridge be sure to align the inlet
and outlet ports on the cartridge with the ports in the valve body.
5. Install item 10 using maintenance tool 5 (Be careful not to over tighten)
6. Install button assembly items 6 7 8 9 using maintenance tool 5 . Insure springs are installed in button correctly.
7. Reinstall strainer 4 and plug 3 using maintenance tool 5 .
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
NOTE: STRAINER FILTER SCREEN
MUST BE IN PLACE FOR
WATER TO FLOW.
2
4
3
1
5
5
6
7
8
9
10
11
ITEM PART NUMBER DESCRIPTION
1 7003-095-001 VALVE ASSEMBLY
2 7000-060-000 FLOW REGULATOR CARTRIDGE(0.5 GPM)
3 7003-097-001 O-RING &STRAINER PLUG
4 7003-864-000 STRAINER FILTER SCREEN
5 7003-194-199 (-VR) MAINTENANCE TOOL
6 7003-197-199 (-VR) PUSHBUTTON ESCUTCHEON, CHROME
7 7003-196-199 (-VR) PUSHBUTTON, CHROME
8 7003-195-000 (-VR) PUSHBUTTON OVERTRAVEL SPRING
9 7003-193-000 (-VR) PUSHBUTTON RETURN SPRING
10 7000-052-000 RETAINING NUT
11 7003-099-001 (-VR) PUSHBUTTON ASSY - ITEMS #5 THRU #9

Page 12 of 16 A171.8-UG-VR-D1-BFS Revised: 07/10/2023 A
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
7020-985-001
Standard A171.8-UG-VR-BFxS series refrigerated ADA cooler shown. All 1/4" O.D. Plastic tubing 23 must be insulated with
24 foam insulation.
NOTE: See next page for table of part numbers corresponding to drawing above.
A171.8-UG-VR-D1-BFS COOLER PARTS BREAKDOWN
NOTE: See following page for fixture drawing corresponding to table of parts below.
Universal Maintenance Tool
-Button Removal
-Cartridge Retaining Nut
-Strainer Plug
-Removal of P.E. Tubing
from Push-in Fittings
26
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
16
12
5
4
3
2
1
23
18
6
24 27"
8
9
10
24 13"
15
14
736
13
17
24 15"
VANDAL RESISTANT BUTTON &
VALVE BREAKDOWN
NOT TO SCALE
10
27
28
32
32
34
35
32
31
28
30
29
5
4
3
2
1
20
19
23 27"
21
11
9
10
23 13"
25
7
26
23 15"
VANDAL RESISTANT BUTTON &
VALVE BREAKDOWN
NOT TO SCALE

Page 13 of 16 A171.8-UG-VR-D1-BFS Revised: 07/10/2023 A
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
7020-985-001
Repairs must be made with Murdock Manufacturing parts only. Please order through your local representative or distributor.
A171.8-UG-VR-D1-BFS COOLER PARTS BREAKDOWN TABLE
NOTE: See previous page (16) for fixture drawing corresponding to table of parts below.
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
ITEM # PART NUMBER DESCRIPTION
1 7003-871-199 BASIN TOP w/ Ø1/2" HOLE
7000-012-001 STAINLESS STEEL BUBBLER ASSEMBLY
7000-099-002 LOW-FLOW FLEXIBLE BUBBLER ASSEMBLY
3 0124-036-000 #8 x 3/4" LG PHIL FLAT HD TORX C/R SCREW
4 7000-006-000 FLAT DRAIN GASKET
5 7003-180-001 DRAIN TAILPIECE
6 7003-900-199 BACK PANEL
7 7003-007-199 SUPPORT STRUT
8 7003-250-000 COLD CONTROL
7003-952-021 APRON ASSEMBLY - GRAY
7003-211-004 APRON ASSEMBY - STAINLESS STEEL
10 7003-095-001 VALVE ASSEMBLY
7003-951-020 COVER - GRAY
7003-035-299 COVER - STAINLESS STEEL
12 7003-201-000 CONDENSER
7012-801-000 COMPRESSOR
7012-030-001 COMPRESSOR - 220V
7012-802-000 START RELAY
7012-031-000 START RELAY - 220
7012-803-000 START CAPACITOR
7012-032-000 START CAPACITOR - 220
16 7003-350-000 FAN BLADE
7003-302-000 FAN MOTOR
7012-062-001 FAN MOTOR - 220V
18 7003-125-001 EVAPORATOR ASSEMBLY
19 7003-950-199 HANGER BRACKET
20 1895-123-000 SUPPLY INLET CONNECTION
21 0124-031-000 #8 x 3/8" LONG SLOTTED HEX WASHER HD SCREW
22 0124-036-000 #8 x 1/2" LONG TORX BUTTON HEAD C/R SCREW
23 2169-000-000 1/4" O.D. TUBING
24 7012-055-000 TUBE INSULATION
25 7003-093-001 FLOW RESTRICTOR - LOW-FLOW BUBBLER ONLY
26 7003-194-199 (-VR) MAINTENANCE TOOL
27 7003-198-199 (-VR) PUSHBUTTON MOUNTING SLEEVE
28 0124-055-000 #8x3/4 PHILLIPS ROUND HEAD SS SM SCREW
29 7003-199-000 AUTO-STOP CONDENSATION GASKET, UPPER
30 7003-200-000 AUTO-STOP CONDENSATION GASKET, LOWER
31 7003-193-000 (-VR) PUSHBUTTON RETURN SPRING
32 0161-062-000 #6-32 x 1/2" S/S PHIL FLAT HD SCREW
33 7003-195-000 (-VR) PUSHBUTTON OVERTRAVEL SPRING
34 7003-196-199 (-VR) PUSHBUTTON, CHROME
35 7003-197-199 (-VR) PUSHBUTTON ESCUTCHEON, CHROME
36 1895-710-000 1/4" O.D. PUSH-IN TEE
2
9
17
11
13
14
15

Page 14 of 16 A171.8-UG-VR-D1-BFS Revised: 07/10/2023 A
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
7020-985-001
(INCLUDED AS REFERENCE SUBJECT TO AVAILABILITY)
A171.8-UG-D1-BFS CARTRIDGE REPLACEMENT/ STRAINER MAINTENANCE (NOT FOR -VR)
Note: Use the Universal Maintenance Tool to perform the following:
1. Strainer Plug must be removed before Cartridge replacement and Strainer
maintenance (no need to turn the water off at the Angle Stop). Some residual water will drain
during Plug removal.
2. Clean Strainer as needed using clean water.
3. Cartridge Replacement - insert diamond end of the Universal Tool into Pushbutton, rotate 90
degrees and pull firmly to remove the Button. Remove Cartridge Retaining Nut . Remove and
replace Cartridge. When replacing Cartridge, be sure to align the inlet and outlet Ports on the
Cartridge with the Ports in the Valve Body.
— NOTE: STRAINER SCREEN MUST BE IN PLACE FOR WATER TO FLOW.
2
4
3
1
5
ITEM PART NUMBER DESCRIPTION
5 7003-830-000 UNIVERSAL MAINTENANCE TOOL
4 7003-864-000 STRAINER FILTER SCREEN
3 7003-097-001 O-RING &STRAINER PLUG
2 7000-060-000 FLOW REGULATOR CARTRIDGE (0.5 GPM)
1 7003-095-001 VALVE ASSEMBLY
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of

Page 15 of 16 A171.8-UG-VR-D1-BFS Revised: 07/10/2023 A
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
7020-985-001
Standard A171.8-UG-BFxS series refrigerated ADA Water Cooler shown. All 1/4" O.D. Plastic Tubing
24 must be insulated with 25 foam insulation.
NOTE: See next page for table of part numbers corresponding to drawing above.
A171.8-UG-D1-BFS (INCLUDED AS REFERENCE SUBJECT TO AVAILABILITY)
WATER COOLER PARTS BREAKDOWN
NOTE: See following page for fixture drawing corresponding to table of parts below.
NOTE: (*) Flow Restrictor Only Available with Low Flow Bubbler
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Universal Maintenance Tool
-Button Removal
-Cartridge Retaining Nut
-Strainer Plug
-Removal of P.E. Tubing from
Push-in Fittings
27
17
13
5
4
3
2
1
23
21
20
19
6
25
24 27"
22
12
11
8
9
10
25
24 13"
26
16
15
728
27
14
18
25
24 15"

Page 16 of 16 A171.8-UG-VR-D1-BFS Revised: 07/10/2023 A
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
WATER COOLERS
7020-985-001
Repairs must be made with Murdock Manufacturing parts only. Please order through your local
representative or distributor.
A171.8-UG-D1-BFS WATER COOLER PARTS BREAKDOWN TABLE
(INCLUDED AS REFERENCE SUBJECT TO AVAILABILITY)
NOTE: See previous page for fixture drawing corresponding to table of parts below.
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
ITEM # PART NUMBER DESCRIPTION
1 7003-871-199 BASIN TOP w/ Ø1/2" HOLE
7000-099-002 LOW-FLOW FLEXIBLE BUBBLER ASSEMBLY
7000-012-001 STAINLESS STEEL BUBBLER ASSEMBLY
3 0124-036-000 #8 x 3/4" LG PHIL FLAT HD TORX C/R SCREW
4 7000-006-000 FLAT DRAIN GASKET
5 7003-180-000 DRAIN TAILPIECE
6 7003-900-199 BACK PANEL
7 7003-007-199 SUPPORT STRUT
8 7003-250-000 COLD CONTROL
7003-953-002 APRON ASSEMBLY - GRAY
7003-826-002 APRON ASSEMBY - STAINLESS STEEL
10 7003-095-001 VALVE ASSEMBLY
11 7003-099-000 PUSHBUTTON
7003-951-020 COVER - GRAY
7003-035-299 COVER - STAINLESS STEEL
13 7003-201-000 CONDENSER
7012-801-000 COMPRESSOR
7012-030-001 COMPRESSOR - 220V
7012-802-000 START RELAY
7012-031-000 START RELAY - 220
7012-803-000 START CAPACITOR
7012-032-000 START CAPACITOR - 220
17 7003-350-000 FAN BLADE
7003-302-000 FAN MOTOR
7012-062-001 FAN MOTOR - 220V
19 7003-125-001 EVAPORATOR ASSEMBLY
20 7003-950-199 HANGER BRACKET
21 1895-123-000 SUPPLY INLET CONNECTION
22 0124-031-000 #8 x 3/8" LONG SLOTTED HEX WASHER HD SCREW
23 0124-036-000 #8 x 1/2" LONG TORX BUTTON HEAD C/R SCREW
24 2169-000-000 1/4" O.D. TUBING
25 7012-055-000 TUBE INSULATION
26 7003-093-001 FLOW RESTRICTOR - LOW-FLOW BUBBLER ONLY
27 7003-830-000 UNIVERSAL MAINTENANCE TOOL
28 1895-710-000 1/4" O.D. PUSH-IN TEE
2
9
18
12
14
15
16
