Napoleon MKRY3 User manual

W415-1230 / 10.08.13
MKRY3 ROCK ASSEMBLY
:ROI6WHHO/WG1DSROHRQ5G%DUULH21/0*&DQDGD    ID[  ZZZQDSROHRQILUHSODFHVFRP
!
WARNING
ENSURE THE UNIT IS COMPLETELY COOL BEFORE STARTING INSTALLATION
TO AVOID DANGER OF SUFFOCATION KEEP THE PACKAGING BAG AWAY FROM BABIES AND CHILDREN.
DO NOT USE IN CRIBS, BED, CARRIAGES OR PLAY PENS. THIS BAG IS NOT A TOY. KNOT BEFORE
THROWING AWAY.
3. Place the #1 rock assembly onto the
studs located on the rear log support as
shown.
4. Place the #2 rock assembly onto the
two corresponding brackets in front of
the #1 rock assembly as shown.
1. Remove the three screws from the
rear log support and burner as shown. 2. Secure the three brackets as shown. Make sure the two rear brackets face
towards the front of the firebox and the
bracket on the burner faces the rear.
INCLUDED IN THIS KIT:
ROCK # PART # DESCRIPTION
#1 W135-0549 REAR ROCK ASSEMBLY
#2 W135-0550 MID REAR ROCK ASSEMBLY
#3 W135-0551 MID RIGHT ROCK ASSEMBLY
#4 W135-0552 MID LEFT ROCK ASSEMBLY
#5 W135-0553 FRONT LEFT ROCK ASSEMBLY
#6 W135-0554 FRONT RIGHT ROCK ASSEMBLY
YOU WILL NEED:
WRENCH WITH 1/4" SOCKET
1
STUDS 2
BRACKETS
NOTE: All the rock assemblies have slots or openings to fit over the studs and brackets.

:ROI6WHHO/WG1DSROHRQ5G%DUULH21/0*&DQDGDWpOpFRSLHXUZZZQDSROHRQIR\HUVFRP
9. Tear the glowing ember material into
small thin pieces and spread evenly on
the front of the burner. NOTE: Do not
overfill.
7. Place the # 5 rock assembly onto the
two corresponding studs located on the
left side of the front as shown.
8. Place the # 6 rock assembly on the
two corresponding studs located on the
right side of the front burner as shown.
5. Place the # 3 rock assembly on the
bracket and stud located onto the right
of the burner cover as shown.
6. Place the # 4 rock assembly onto the
two corresponding studs on the left side
of the burner cover as shown.
W415-1230 / 10.08.13
3
STUD
BRACKET
4
STUDS
5
STUDS
6
STUDS
