National Public Seating SLT3-2448P User manual

TABLE COMPONENTS INCLUDED HARDWARE
TOOLS FOR ASSEMBLY
Drill Allen Wrench
16x Screws 4x Nylon-Insert
Lock Nut
Wrench
1 Fasten each leg onto tabletop
frame by inserting the leg’s
hanger bolt into the corner
brackets. Then fasten the legs
using the included lock nuts.
ASSEMBLY INSTRUCTIONS
STEEL FRAME SCIENCE AND HEAVY DUTY TABLES
2Secure the legs to the tabletop
by installing 4 screws through
each leg plate.
Congratulations, your table is now assembled and ready to be used!
Dear Customer,Thank you for your purchase. Although extreme care goes into manufacturing &
packaging of this product, mistakes are possible. If you encounter any missing parts or diculty in
assembly, please contact our customer service Toll Free at 1-800-261-4112 or
[e-mail] for courteous & immediate resolution to your problem.
Tabletop 4x Legs
Ensure that all nuts are fastened tightly.
Page 1 of 3
www.nationalpublicseating.com
1-800-261-4112

21.25"
22.25"
23.25"
24.25"
25.25"
26.25"
27.25"
28.25"
29.25"
30.25"
31.25"
32.25"
33.25"
34.25"
35.25"
36.25"
The height of the legs can be easily adjusted by removing the safety screws
and adjusting them to the desired height, the legs can be lifted 1" at a time.
After obtaining the desired height,don't forget to fasten the safety screws.
EXAMPLE
In order to adjust table to your desired height, subtract the tabletop
thickness (listed in below chart) from your desired height, and then follow
the below guideline to adjust the legs to the remaining height.
The leveling glides can be used to add up to an additional .75"
TABLETOP TYPE
Phenolic
Chemical Resistant
Science
High Pressure Laminate
Whiteboard
Butcherblock
Standard
High Pressure Laminate
Supreme
High Pressure Laminate
SAMPLE MODEL NUMBER
SLT3-2448P
SLT3-2448C
SLT3-2448H
HDT3-2448W
HDT3-2448B
HDT3-2448H
HDT3-2448S
THICKNESS
.75"
1"
1.2"
1.2"
1.75"
.75"
1.2"
Model
Number
SLT3-2448P
Desired Table
Height
30"
Table Thickness
(Listed below)
.75"
Height to
Adjust Legs
29.25"
- =
Ensure that both screws are fastened tightly.
*Below dimensions are with standard leveling glides installed at their lowest height (excluding tabletop thickness).
Leveling glides can be used to add .75" to the table height when needed. See next page for leg heights with optional casters installed.
LEG HEIGHT ADJUSTMENT
Page 2 of 3
www.nationalpublicseating.com
1-800-261-4112

CASTERS x4
To install the casters, remove the
glides and swivel the casters into
place using a wrench.
GUSSETSx4
Align each gusset onto all four
inside corners.
Fasten each gusset to the frame
and leg structure by installing 8
screws through each plate.
OPTIONAL CASTER/GUSSET INSTALLATION AND LEG HEIGHT ADJUSTMENT
Below dimensions are to be used when using optional casters.
See previous page for detailed height adjustment instructions.
24.5"
25.5"
26.5"
27.5"
28.5"
29.5"
30.5"
31.5"
32.5"
33.5"
34.5"
35.5"
36.5"
37.5"
38.5"
39.5"
Ensure that both screws are fastened tightly.
