Nautilus BE STRONG E916 User manual

2NLS_E9.16 ELLIPTICAL BX_010207
NAUTILUS E9.16 ELLIPTICAL BOXED

3NLS_E9.16 ELLIPTICAL BX_010 207
NAUTILUS E9.16 ELLIPTICAL BOXED
153
40
152

4NLS_E9.16 ELLIPTICAL BX_010 207
NAUTILUS E9.16 ELLIPTICAL BOXED
2X 5
3
2X 6
4
7
3X 9
2X 9
11X 9
10
8
1 RIGHT
2 LEFT

5NLS_E9.16 ELLIPTICAL BX_010 207
NAUTILUS E9.16 ELLIPTICAL BOXED
2X 9
8X 9
12
11
13 2X 21
2X 19
2X 117
2X 20
2X 19
2X 17
2X 15
2X 16
2X 15
2X 14
2X 117
2X 15
4X 59
2X 18
POWER CHARGER SM25067
PLUG IN THIS LOCATION

6NLS_E9.16 ELLIPTICAL BX_010 207
NAUTILUS E9.16 ELLIPTICAL BOXED
28
4X 116
10X 9
2X 25
6X 9
4X 9
2X 24
22 RIGHT
23 LEFT
4X 9
26 RIGHT
27 LEFT

7NLS_E9.16 ELLIPTICAL BX_010 207
NAUTILUS E9.16 ELLIPTICAL BOXED
LEFT
RIGHT
29
32
FIXED "T-BAR" CONTACT
HEART RATE GRIPS
35
35
33
34
TO ELLIPTICAL
POWER ELECTRONICS
AND ALTERNATOR
28 CONSOLE
BLACK
REAR
GRIP
RED
FRONT
GRIP
BLACK
REAR
GRIP
RED
FRONT
GRIP
WHITE
RED
BLACK
GREEN
"DISPLAY LOCK
QUICKSTART"
"LEVEL (UP) - (DOWN)"
FROM BOTTOM
OF MAST
38
RIGHT SWINGARM
37
LEFT SWINGARM
36
SWINGARM PCBA
36
SWINGARM PCBA
30
POLAR
SENSOR
CABLETO T.V.
(T.V. ONLY)
31
CHR
POLAR HR
MAIN CABLE

9NLS_E9.16 ELLIPTICAL BX_010 207
NAUTILUS E9.16 ELLIPTICAL BOXED
ALTERNATOR
BROWN
BLACK
(GROUND)
WHITE(B+)
42
SPEED
SENSOR
39
BLACK
WHITE
-
BATTERY
RESISTOR
POWER CONTROL
PCBA
33
+
TO FRONT OF MACHINE
40
115
43
J2J1
J6
J3
POWER
J5
J4
79

10NLS_E9.16 ELLIPTICAL BX_010 207
NAUTILUS E9.16 ELLIPTICAL BOXED
63
4X
47
9
46
62
58
2X
4X
53
49
54
2X
66
9
2X
61
67
41
68
4X
4X
4X
4X
71
70
69
65
64
4X
4
2
4
2X
4X
2X
4X
4X
2X
2X
60
59 51
57
56
55
51
77
77
51
55
78
72
73
74
75
51
55
51
76
1
1
3
2
52
51
50
48
66

11 NLS_E9.16 ELLIPTICAL BX_010 207
NAUTILUS E9.16 ELLIPTICAL BOXED
81
63
43
82
84
83
63
2
80
.040
.020
43
45
1

12NLS_E9.16 ELLIPTICAL BX_010207
NAUTILUS E9.16 ELLIPTICAL BOXED

13 NLS_E9.16 ELLIPTICAL BX_010 207
NAUTILUS E9.16 ELLIPTICAL BOXED
2X
2X
SWING ARM ASSEMBLY RIGHT SIDE
SHOWN EXPLODED. LEFT SIDE IS AN
EXACT DUPLICATE.
85
2X
86
60
RIGHT HAND DYNAMIC HANDLE SHOWN
EXPLODED. LEFT HAND IS A MIRROR
IMAGE WITH COMPONENT CHANGES
NOTED ABOVE
89
88
4
31
87
59
A
DETAIL A
113
83
63
30
90
92
91
8X
6X
6X
90° ±5°
30
4
NYLON
WASHER FIRST
WAVE WASHER
UPPER AND LOWER INGUS
BUSHINGS CAN BE BOUGHT
SEPARATELY #154

14NLS_E9.16 ELLIPTICAL BX_010 207
NAUTILUS E9.16 ELLIPTICAL BOXED
92
96
2X
93 95
94

15 NLS_E9.16 ELLIPTICAL BX_010 207
NAUTILUS E9.16 ELLIPTICAL BOXED
6X
2X
97
9
2X
4X
9
98
4X
9
99
100
101
2X 9
9

16NLS_E9.16 ELLIPTICAL BX_010 207
NAUTILUS E9.16 ELLIPTICAL BOXED
GREEN
(TOP)
BLACK
(BOTTOM)
RED
(TOP)
WHITE
(BOTTOM)
FIXED "T-BAR" CONTACT HEART RATE GRIPS
34
TO CONSOLE
29
CABLE TO T.V.
(T.V. COMPATIBLE ONLY)
FROM BOTTOM
OF MAST
31

17 NLS_E9.16 ELLIPTICAL BX_010 207
NAUTILUS E9.16 ELLIPTICAL BOXED
(INCLUDES #40964,
WELDMENT(#155), AND 40680)
RED
BLACK
35
102
89
155

18NLS_E9.16 ELLIPTICAL BX_010207
NAUTILUS E9.16 ELLIPTICAL BOXED
BLACK
RED
(INCLUDE 40957,
WELDMENT AND
40680)
103
35
156
88

19 NLS_E9.16 ELLIPTICAL BX_010 207
NAUTILUS E9.16 ELLIPTICAL BOXED
108
107
44
105
106
109
1
1 2
104
2X
2X
2X
RIGHT SIDE FOOTLINK ASSEMBLY

20NLS_E9.16 ELLIPTICAL BX_010 207
NAUTILUS E9.16 ELLIPTICAL BOXED
111
44
105
106
112
109
1
2
1
110
2X
2X
2X
LEFT SIDE FOOTLINK ASSEMBLY

20NLS_E9.16 ELLIPTICAL BX_010 207
NAUTILUS E9.16 ELLIPTICAL BOXED
119

21 NLS_E9.16 ELLIPTICAL BX_010 207
NAUTILUS E9.16 ELLIPTICAL BOXED
REF # DESCRIPTION PART # REF # DESCRIPTION PART #
1 ASSY,CRANK,W/CRANK COVER,RH,V 2 SM 40783
2 ASSY,CRANK,W/CRANK COVER,LH,V 2 SM 40784
3 KEY,. 250 SQUARE X .750 LONG SM1 2212
4 KIT,CRANK COVER HW SM 40756
5 COVER,CRANK,STEEL, V3 SM 403 83
6 SPACER,CRANK SHAFT SM 40616
7 COVER,DRIVTRAIN,TOP SM 40527
8 KIT,SIDE COVER,W/DECAL,E916,LH SM 40917
9 COVER SCREW (BAG OF 10) SM 4065 4
10 KIT,SIDE COVER,W/DECAL,E916,RH SM 4091 8
11 COVER,FRONT,BOTTOM,LEFT SM 40556
12 COVER,FRONT,BOTTOM,RIGHT SM 4055 8
13 FRAME HW KIT SM 40233
14 NUT,.500-13,NYLON INSERT SM 22042
15 WASHER,FLAT,.56 2x1.375 x .109 SM 22046
16 SHAFT, SWING ARM PIVOT SM 4035 8
17 SCREW,.500-13x 4.50,HEX HD CAP SM 26669
18 WASHER,TEFLON, .890-ID X 1.505-OD SM 40989
19 RING,RETAINING,EXTERNAL,15MM SM 40751
20 PLUG,F/1.50 DIA.TUBING,1 4-20GA SM 40890
21 ASSEMBLY,CONNECTING ARM, V 2 SM 40884
22 COVER,POD,TOP,RIGHT SM 40596
23 COVER,POD,TOP,LEFT SM 4059 2
24 COVER, KNUCKLE, FRONT LEFT SM 40426
25 COVER, KNUCKLE, FRONT RIGHT SM 40427
26 COVER,POD,BOTTOM,RIGHT SM 40597
27 COVER,POD,BOTTOM,LEFT SM 40593
28 KIT,CONSOLE,C51,LCD,E916 SM 41531
29 ASSY,CABLE, VSL PLUG-IN, POLAR SM 40836
30 RECEIVER,PLUG-IN,POLAR SM 25165
31 ASSY,HARNESS,TV/PWR,EV916/E916 (
TV ONLY)
SM17 841
32 CABLE ASSY,CONSOLE-INLINE,ELLI SM 40710
33 CABLE ASSY,MAIN LOWER,EV916 SM 40844
34 CABLE,ASSY,T-BAR GRIPTO CONSO SM 40679
35 ASSY,CABLE,ELLIPTICAL SWINGARM SM 40680
36 PCB ASSEMBLY,ELLIPT SWINGARM SM 4069 2
37 KEYPANEL,HANDRAIL,LEFT EV916/
E916
SM 40465
38 KEYPANEL,HANDRAIL,RIGHT EV916/
E916
SM 40466
39 CABLE,ASSY,BATTERY,ELLIPTICAL SM 4067 8
40 POWER BOARD KIT SM1357 2
41 ASSY,RESISTOR & BRACKET,STRIDE SM 40603
42 CABLE,ALTERNATOR,3300CE/3900RC SM135 84
43 ASSY.,SPEED SENSOR,CLIM.SYS,CL SM 2144 5
44 SCREW, 5/16-18 X.75 SM002-0552
45 ASSY,FIELD,DIODE SM 21204
46 ASSEMBLY,LOWER CONTROL BOARD SM 40601
47 DRIVE PULLEY ASSY,W/SCREWS SM 40530
48 SCREW, SET,SOCKET,3/ 8-16 X .3 8 SM 2288 3
49 BELT,POLY-V,61”,J,10 RIBS SM 40909
50 BEARING,1” PILLOW BLOCK,NO COL SM 4073 4
51 WASHER, 3/ 8 USS FLAT SM 22030
52 SCREW,.375-16 X 3.50,HX HD CAP SM 22937
53 SHAFT,CRANK SM 40611
54 KEY, . 250 SQ X 3.00 LONG SM1 2760
55 NUT,.375-16,NYLON INSERT SM 22029
56 SCREW,.375-16 X 1.75 HX HD CAP SM 24 640
57 WASHER, 3/ 8 SPLIT LOCK SM 23729
58 SHAFT,INTERMEDIATE PULLEY SM 4060 8
59 NUT,JAM HEX,1/ 2-13 SM 222 05
60 LEVELING PAD SM176 86
61 KIT,WHEEL SM 2597 8
62 SCREW,. 250- 20X 2.50,HEX HD CAP SM 22116
63 WASHER,FLAT,1/ 4 ID X 5/ 8 OD SM 22 047
64 SCREW,#6 X .50 PHIL,TYPET SM 22663
65 SPACER,INTERMEDIATE SHAFT,RIGH SM 40610
66 SCREW,SET,SOCKET,. 250- 28 X .3 8 SM 228 78
67 WELDMENT, INT PULLEYTENSIONER SM 40605
68 SPACER,INTERMEDIATE SHAFT,LEFT SM 40609
69 ASSEMBLY,INTERMEDIATE PULLEY SM 4095 2
70 BELT,POLY-V,3 8”,J,6 RIB SM 40910
71 REAR FRAME,WELMENT, ASSY SM 40501
72 WELDMENT, ALTERNATORTEBSION -
ER
SM 4059 8
73 WASHER, FLAT, .31 2 SAE SM 222 14
74 WASHER,.31 2 SPIT LOCK SM 22070
75 SCREW,.31 2-18X.75,HEX HD CAP SM 22093
76 SCREW,.375-16 x 4.50 HEX HD CP SM 21448
77 WASHER,SHOULDER,.3 8 I.D. SM 22191
78 ASSEMBLY,ALTERNATOR SM 40953
79 ASSY,MAIN POWER,ELLIPTICAL SM 40677
80 KIT,5100 ALTERNATOR ASSY SM 4075 4
81 NUT,. 250- 20,NYLON INSERT SM 22 036
82 CLAMP,CABLE,11/16” DIA. SM 22884
83 WASHER,. 250 SPLIT LOCK SM 22027
84 SCREW,. 250- 20X1. 25,HEX HD CAP SM 22164
85 WELDMENT, CONSOLE MOUNT, V 2 SM 40892
86 SWING ARM HW KIT SM 40234
87 KIT,ASSY,SWING ARM,W/
BEARINGS,E916
SM 40955
88 KIT, ASSY, UPPER SWING ARM, W/ RIGHT
WELDMENT, E916
SM 40957
89 KIT, ASSY, UPPER SWING ARM, W/ LEFT
WELDMENT, E916
SM 40956
