NEC Express5800/R110h-1 User manual

NEC Express5800/R110h-1
System Configuration Guide
Introduction
This document contains product and configuration information that will enable you to configure your system. The
guide will ensure fast and proper configuration of your NEC Express5800 server.
January 26, 2017
Revision 5.0
NEC Corporation

SYSTEM CONFIGURATION GUIDE –NEC Express5800/R110h-1
NEC Corporation Revision 5.0 –January, 2017 2
Contents
TECHNICAL SPECIFICATION........................................................................................3
Key Features..........................................................................................................................................3
Specification..........................................................................................................................................3
EXTERNAL VIEWS .........................................................................................................9
Front and Rear Views ...........................................................................................................................9
Dimensions (mm)................................................................................................................................11
CONFIGURATION DIAGRAM.......................................................................................12
EXPANSION SLOTS .....................................................................................................13
SERVER CONFIGURATION .........................................................................................14
1Base Models.................................................................................................................................14
2Processor .....................................................................................................................................14
3Memory .........................................................................................................................................15
4Internal Hard Disk Drives............................................................................................................16
RAID Configuration..............................................................................................................16
Required Components for RAID Configuration...................................................................18
Supported Drives.................................................................................................................23
5Optical Drive.................................................................................................................................26
6PCI Card........................................................................................................................................26
Network Interface Controller................................................................................................26
External Storage Controller.................................................................................................28
Graphics Accelerator ...........................................................................................................28
Serial Port Adapter ..............................................................................................................28
7Other Add-in Components..........................................................................................................29
Cooling Fan Kit....................................................................................................................29
Trusted Platform Module Kit................................................................................................29
Internal Flash Memory.........................................................................................................29
High temperature resistant Kit.............................................................................................29
Flash FDD............................................................................................................................30
8Add-on Components ...................................................................................................................30
17-inch LCD Console Drawer..............................................................................................30
KVM Switch .........................................................................................................................31
Server Management License...............................................................................................31
REFERENCES...............................................................................................................32
Boot Mode Setting ..............................................................................................................................32
Server Management............................................................................................................................33
Endurance of SSD...............................................................................................................................34
OS Support Matrix for PCI Cards and Embedded Controllers.......................................................35
Supported PCI cards and Installable Slots.......................................................................................36
Secure Boot Mode...............................................................................................................................38
Copyright Notice and Liability Disclaimer........................................................................................39
REVISION HISTORY.....................................................................................................40

SYSTEM CONFIGURATION GUIDE –NEC Express5800/R110h-1
NEC Corporation Revision 5.0 –January, 2017 3
Technical Specification
Key Features
High performance with the latest Intel® Xeon® processor E3-1200 v5 product family
Up to 64 GB of high speed DDR4-2133 memory
High energy efficiency with intelligent fan control, power capping feature and 80 PLUS® Platinum or Gold power supply
Full manageability by integrated EXPRESSSCOPE Engine 3
Specification
2.5-inch Drive Model
(1/2)
Model
R110h-1
Part Number
N8100-2337F
Processor
Type
Intel® Pentium®
Processor G4400
Intel® Xeon®
Processor E3-1220 v5
Intel® Xeon®
Processor E3-1230 v5
Clock Speed
3.30 GHz
3.00 GHz
3.40 GHz
Number of Processor
1
Cache
3 MB
8 MB
Cores and Threads
2C / 2T
4C / 4T
4C / 8T
Chipset
Intel® C236 Chipset
Memory
Type
DDR4-2133 ECC Unbuffered DIMM
Standard Capacity
0 GB
Maximum Capacity
64 GB (4 x 16 GB)
Internal Storage
Standard Capacity
0 GB
Maximum Capacity
SATA HDD: 16 TB (8 x 2 TB)
SAS HDD : 14.4 TB (8 x 1.8 TB)
SATA SSD 12.8 TB (8 x 1.6 TB)
SAS SSD 3.2 TB (8 x 400 GB)
Disk Controller
SATA : 6 Gb/s (Integrated)
SATA/SAS : 6/12 Gb/s (Optional)
RAID
SATA : RAID 0/1/10 (Standard 1 )
SATA/SAS : RAID 0/1/5/6/10/50/60 (Optional)
Hot Plug
Supported
Optical Disk Drive
Optional
Optical Drive Bays
1
Disk Drive Bays
8
Expansion Slots
Total: 3 slots available
1 PCIe 3.0 x16 (x16 connector)
1 PCIe 3.0 x4 (x8 connector)
1 PCIe 3.0 x4 (x8 connector) dedicated RAID slot
Video
Controller (VRAM)
Integrated in Server Management Controller (32MB)
Resolution / Color
1600 x 1200 / 16.7M2
Interfaces
1 VGA (15-pin mini D-sub,1 rear)
1 to 2 Serial (9-pin mini D-sub, RS232-C, 1 to 2 rear)
6 USB 3.0 (2 front, 4 rear) (plus 1 internal USB 3.0)
2 1000BASE-T LAN connector (RJ-45, 2 rear)
Interfaces (Continued)
1 1000BASE-T LAN connector for management (RJ-45, 1 rear)
Server Management
EXPRESSSCOPE Engine 3
Redundant Fan
Optional, non-hot plug
Power Supply
2 450 Watt 80 PLUS® Gold certified Hot plug PSU
100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz
Power Consumption
(Max. Config, Idling)
117 VA
/ 116 Watt
125 VA
/ 124 Watt
(Max. Config, Operating)
286 VA
/ 284 Watt
324 VA
/ 322 Watt
356 VA
/ 353 Watt
Acoustic Noise
Minimum Config.
36 dB
49 dB

SYSTEM CONFIGURATION GUIDE –NEC Express5800/R110h-1
NEC Corporation Revision 5.0 –January, 2017 4
Model
R110h-1
(Sound Pressure
Level) 3
Maximum Config.
38 dB
49 dB
Dimensions (W x D x H )
444.0 x 615.2 x 43.6 mm / 17.5 x 24.2 x 1.7 in (1U)
Weight (Minimum / Maximum)
10 kg / 17.5 kg, 22.05 lbs. / 38.58 lbs.
Temperature, Relative Humidity (non-condensing)
Operating: 5° to 40° C / 41° to 104° F (Standard)
or 5° to 45° C / 41° to 113° F (Optional), 20 to 80%
Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 80%
Regulatory and Safety
FCC, c-UL, CE, CB, RoHS, WEEE, BSMI, CCC
Operating Systems and Virtualization Software
Microsoft® Windows Server® 2008 R2 Standard
Microsoft® Windows Server® 2008 R2 Enterprise
Microsoft® Windows Server® 2012 Standard
Microsoft® Windows Server® 2012 Datacenter
Microsoft® Windows Server® 2012 R2 Standard
Microsoft® Windows Server® 2012 R2 Datacenter
Red Hat Enterprise Linux 6.7 or later (x86_64)4
Red Hat Enterprise Linux 7.2 or later 4
VMware ESXi 5.5 Update 3 5
VMware ESXi 6.0 Update 1 5
1Embedded SATA RAID controller is supported only on limited operating systems.
2Maximum resolution available via EXPRESSSCOPE Engine 3 remote console is 1280 x 1024 / 65K colors.
3Noise emission was measured in accordance with ISO 7779, at 25°C. The actual value may vary by the operating environment.
4For Linux support, contact your sales representative or go to the NEC website at:
http://www.nec.com/en/global/prod/express/linux/index.html
5Supported on Xeon processor systems only.

SYSTEM CONFIGURATION GUIDE –NEC Express5800/R110h-1
NEC Corporation Revision 5.0 –January, 2017 5
(2/2)
Model
R110h-1
Part Number
N8100-2337F
Processor
Type
Intel® Xeon®
Processor E3-1240L v5
Intel® Xeon®
Processor E3-1260L v5
Intel® Xeon®
Processor E3-1270 v5
Clock Speed
2.10 GHz
2.90 GHz
3.60 GHz
Number of Processor
1
Cache
8 MB
Cores and Threads
4C / 8T
Chipset
Intel® C236 Chipset
Memory
Type
DDR4-2133 ECC Unbuffered DIMM
Standard Capacity
0 GB
0 GB
0 GB
Maximum Capacity
64 GB (4 x 16 GB)
64 GB (4 x 16 GB)
64 GB (4 x 16 GB)
Internal Storage
Standard Capacity
0 GB
Maximum Capacity
SATA HDD: 16 TB (8 x 2 TB)
SAS HDD : 14.4 TB (8 x 1.8 TB)
SATA SSD 12.8 TB (8 x 1.6 TB)
SAS SSD 3.2 TB (8 x 400 GB)
Disk Controller
SATA : 6 Gb/s (Integrated)
SATA/SAS : 6/12 Gb/s (Optional)
RAID
SATA : RAID 0/1/10 (Standard 1 )
SATA/SAS : RAID 0/1/5/6/10/50/60 (Optional)
Hot Plug
Supported
Optical Disk Drive
Optional
Optical Drive Bays
1
Disk Drive Bays
8
Expansion Slots
Total: 3 slots available
1 PCIe 3.0 x16 (x16 connector)
1 PCIe 3.0 x4 (x8 connector)
1 PCIe 3.0 x4 (x8 connector) dedicated RAID slot
Video
Controller (VRAM)
Integrated in Server Management Controller (32MB)
Resolution / Color
1600 x 1200 / 16.7M2
Interfaces
1 VGA (15-pin mini D-sub,1 rear)
1 to 2 Serial (9-pin mini D-sub, RS232-C, 1 to 2 rear)
6 USB 3.0 (2 front, 4 rear) (plus 1 internal USB 3.0)
2 1000BASE-T LAN connector (RJ-45, 2 rear)
1 1000BASE-T LAN connector for management (RJ-45, 1 rear)
Server Management
EXPRESSSCOPE Engine 3
Redundant Fan
Optional, non-hot plug
Power Supply
2 450 Watt 80 PLUS® Gold certified Hot plug PSU
100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz
Power Consumption
(Max. Config, Idling)
116 VA
/ 115 Watt
118 VA
/117 Watt
126VA
/ 125Watt
(Max. Config, Operating)
274 VA
/ 272 Watt
306 VA
/ 303 Watt
358VA
/ 356Watt
Acoustic Noise
(Sound Pressure
Level) 3
Minimum Config.
49 dB
Maximum Config.
49 dB
Dimensions (W x D x H )
444.0 x 615.2 x 43.6 mm / 17.5 x 24.2 x 1.7 in (1U)
Model
R110h-1
Weight (Minimum / Maximum)
10 kg / 17.5 kg, 22.05 lbs. / 38.58 lbs.
Temperature, Relative Humidity (non-condensing)
Operating: 5° to 40° C / 41° to 104° F (Standard)
or 5° to 45° C / 41° to 113° F (Optional), 20 to 80%
Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 80%
Regulatory and Safety
FCC, c-UL, CE, CB, RoHS, WEEE, BSMI, CCC
Operating Systems and Virtualization Software
Microsoft® Windows Server® 2008 R2 Standard
Microsoft® Windows Server® 2008 R2 Enterprise
Microsoft® Windows Server® 2012 Standard
Microsoft® Windows Server® 2012 Datacenter
Microsoft® Windows Server® 2012 R2 Standard

SYSTEM CONFIGURATION GUIDE –NEC Express5800/R110h-1
NEC Corporation Revision 5.0 –January, 2017 6
Microsoft® Windows Server® 2012 R2 Datacenter
Red Hat Enterprise Linux 6.7 or later (x86_64) 4
Red Hat Enterprise Linux 7.2 or later 4
VMware ESXi 5.5 Update 3
VMware ESXi 6.0 Update 1
1Embedded SATA RAID controller is supported only on limited operating systems.
2Maximum resolution available via EXPRESSSCOPE Engine 3 remote console is 1280 x 1024 / 65K colors.
3Noise emission was measured in accordance with ISO 7779, at 25°C. The actual value may vary by the operating environment.
4For Linux support, contact our sales representative or go to the NEC website at:
http://www.nec.com/en/global/prod/express/linux/index.html
3.5-inch Drive Model
(1/2)
Model
R110h-1
Part Number
N8100-2334F, N8100-2335F
Processor
Type
Intel® Pentium®
Processor G4400
Intel® Xeon®
Processor E3-1220 v5
Intel® Xeon®
Processor E3-1230 v5
Clock Speed
3.30 GHz
3.00 GHz
3.40 GHz
Number of Processor
1
Cache
3 MB
8 MB
Cores and Threads
2C / 2T
4C / 4T
4C / 8T
Chipset
Intel® C236 Chipset
Memory
Type
DDR4-2133 ECC Unbuffered DIMM
Standard Capacity
0 GB
0 GB
0 GB
Maximum Capacity
64 GB (4 x 16 GB)
64 GB (4 x 16 GB)
64 GB (4 x 16 GB)
Internal Storage
Standard Capacity
0 GB
Maximum Capacity
SATA : 40 TB (4 x 10 TB)
Disk Controller
SATA : 6Gb/s (Integrated)
RAID
SATA : RAID 0/1/10 (Standard 1 ), RAID 5/6 (Optional)
Hot Plug
Supported
Optical Disk Drive
Optional
Optical Drive Bays
1
Disk Drive Bays
4
Expansion Slots
Total: 3 slots available
1 PCIe 3.0 x16 (x16 connector)
1 PCIe 3.0 x4 (x8 connector)
1 PCIe 3.0 x4 (x8 connector) dedicated RAID slot
Video
Controller (VRAM)
Integrated in Server Management Controller (32MB)
Resolution / Color
1600 x 1200 / 16.7M2
Interfaces
1 VGA (15-pin mini D-sub,1 rear)
1 to 2 Serial (9-pin mini D-sub, RS232-C, 1 to 2 rear)
6 USB 3.0 (2 front, 4 rear) (plus 1 internal USB 3.0)
2 1000BASE-T LAN connector (RJ-45, 2 rear)
1 1000BASE-T LAN connector for management (RJ-45, 1 rear)
Server Management
EXPRESSSCOPE Engine 3
Redundant Fan
Optional, non-hot plug
Power Supply
1 400 Watt 80 PLUS® Platinum certified non-Hot plug PSU
2 450 Watt 80 PLUS® Gold certified Hot plug PSU
100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz
Power Consumption
(Max. Config, Idling)
116VA
/ 115 Watt
(Max. Config, Operating)
268VA
/ 266Watt
307VA
/ 305Watt
338VA
/ 336Watt
Acoustic Noise
(Sound Pressure
Level) 3
Minimum Config.
36 dB
49 dB
Maximum Config.
38 dB
49 dB
Dimensions (W x D x H )
444.0 x 615.2 x 43.6 mm / 17.5 x 24.2 x 1.7 in (1U)
Weight (Minimum / Maximum)
10 kg / 17.5 kg, 22.05 lbs. / 38.58 lbs.
Temperature, Relative Humidity (non-condensing)
Operating: 5° to 40° C / 41° to 104° F (Standard)
or 5° to 45° C / 41° to 113° F (Optional), 20 to 80%

SYSTEM CONFIGURATION GUIDE –NEC Express5800/R110h-1
NEC Corporation Revision 5.0 –January, 2017 7
Model
R110h-1
Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 80%
Regulatory and Safety
FCC, c-UL, CE, CB, RoHS, WEEE, BSMI, CCC
Operating Systems and Virtualization Software
Microsoft® Windows Server® 2008 R2 Standard
Microsoft® Windows Server® 2008 R2 Enterprise
Microsoft® Windows Server® 2012 Standard
Microsoft® Windows Server® 2012 Datacenter
Microsoft® Windows Server® 2012 R2 Standard
Microsoft® Windows Server® 2012 R2 Datacenter
Red Hat Enterprise Linux 6.7 or later (x86_64) 4
Red Hat Enterprise Linux 7.2 or later 4
VMware ESXi 5.5 Update 3 5
VMware ESXi 6.0 Update 1 5
1Embedded SATA RAID controller is supported only on limited operating systems.
2Maximum resolution available via EXPRESSSCOPE Engine 3 remote console is 1280 x 1024 / 65K colors.
3Noise emission was measured in accordance with ISO 7779, at 25°C. The actual value may vary by the operating environment.
4For Linux support, contact our sales representative or go to the NEC website at:
http://www.nec.com/en/global/prod/express/linux/index.html
5Supported on Xeon processor systems only.
(2/2)
Model
R110h-1
Part Number
N8100-2334F, N8100-2335F
Processor
Type
Intel® Xeon®
Processor E3-1240L v5
Intel® Xeon®
Processor E3-1260L v5
Intel® Xeon®
Processor E3-1270 v5
Clock Speed
2.10 GHz
2.90 GHz
3.60 GHz
Number of Processor
1
Cache
8 MB
Cores and Threads
4C / 8T
Chipset
Intel® C236 Chipset
Memory
Type
DDR4-2133 ECC Unbuffered DIMM
Standard Capacity
0 GB
0 GB
0 GB
Maximum Capacity
64 GB (4 x 16 GB)
64 GB (4 x 16 GB)
64 GB (4 x 16 GB)
Internal Storage
Standard Capacity
0 GB
Maximum Capacity
SATA : 40 TB (4 x 10 TB)
Disk Controller
SATA : 6Gb/s (Integrated)
RAID
SATA : RAID 0/1/10 (Standard 1 ), RAID 5/6 (Optional)
Hot Plug
Supported
Optical Disk Drive
Optional
Optical Drive Bays
1
Disk Drive Bays
4
Expansion Slots
Total: 3 slots available
1 PCIe 3.0 x16 (x16 connector)
1 PCIe 3.0 x4 (x8 connector)
1 PCIe 3.0 x4 (x8 connector) dedicated RAID slot
Video
Controller (VRAM)
Integrated in Server Management Controller (32MB)
Resolution / Color
1600 x 1200 / 16.7M2
Interfaces
1 VGA (15-pin mini D-sub,1 rear)
1 to 2 Serial (9-pin mini D-sub, RS232-C, 1 to 2 rear)
6 USB 3.0 (2 front, 4 rear) (plus 1 internal USB 3.0)
2 1000BASE-T LAN connector (RJ-45, 2 rear)
1 1000BASE-T LAN connector for management (RJ-45, 1 rear)
Server Management
EXPRESSSCOPE Engine 3
Redundant Fan
Optional, non-hot plug
Power Supply
1 400 Watt 80 PLUS® Platinum certified non-Hot plug PSU

SYSTEM CONFIGURATION GUIDE –NEC Express5800/R110h-1
NEC Corporation Revision 5.0 –January, 2017 8
2 450 Watt 80 PLUS® Gold certified Hot plug PSU
100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz
Power Consumption
(Max. Config, Idling)
115VA
/ 114Watt
114VA
/ 114Watt
115VA
/ 114Watt
(Max. Config, Operating)
259VA
/ 257Watt
290VA
/ 288Watt
341VA
/ 338Watt
Acoustic Noise
(Sound Pressure
Level) 3
Minimum Config.
49 dB
Maximum Config.
49 dB
Dimensions (W x D x H )
444.0 x 615.2 x 43.6 mm / 17.5 x 24.2 x 1.7 in (1U)
Weight (Minimum / Maximum)
10 kg / 17.5 kg, 22.05 lbs. / 38.58 lbs.
Temperature, Relative Humidity (non-condensing)
Operating: 5° to 40° C / 41° to 104° F (Standard)
or 5° to 45° C / 41° to 113° F (Optional), 20 to 80%
Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 80%
Regulatory and Safety
FCC, c-UL, CE, CB, RoHS, WEEE, BSMI, CCC
Operating Systems and Virtualization Software
Microsoft® Windows Server® 2008 R2 Standard
Microsoft® Windows Server® 2008 R2 Enterprise
Microsoft® Windows Server® 2012 Standard
Microsoft® Windows Server® 2012 Datacenter
Microsoft® Windows Server® 2012 R2 Standard
Microsoft® Windows Server® 2012 R2 Datacenter
Red Hat Enterprise Linux 6.7 or later (x86_64) 4
Red Hat Enterprise Linux 7.2 or later 4
VMware ESXi 5.5 Update 3
VMware ESXi 6.0 Update 1
1Embedded SATA RAID controller is supported only on limited operating systems.
2Maximum resolution available via EXPRESSSCOPE Engine 3 remote console is 1280 x 1024 / 65K colors.
3Noise emission was measured in accordance with ISO 7779, at 25°C. The actual value may vary by the operating environment.
4For Linux support, contact our sales representative or go to the NEC website at:
http://www.nec.com/en/global/prod/express/linux/index.html

SYSTEM CONFIGURATION GUIDE –NEC Express5800/R110h-1
NEC Corporation Revision 5.0 –January, 2017 9
External Views
Front and Rear Views
Front View for 2.5-inch Drive Model
Front View for 3.5-inch Drive Model
Legend
A.
Drive Bays
H.
Dump (NMI) Switch
B.
Optical Drive Bay
I.
BMC Reset Button
C.
USB Connector
J.
System Status LED 1
D.
USB Connector
K.
System Status LED 2
E.
Power Button / Power LED
L.
Power Capping LED
F.
UID LED Button
M.
Data LAN 1 Activity LED
G.
Reset Button
N.
Data LAN 2 Activity LED
BA
CD
E F G H I J K L M N
BA
CD
E F G H I J K L M N

SYSTEM CONFIGURATION GUIDE –NEC Express5800/R110h-1
NEC Corporation Revision 5.0 –January, 2017 10
Rear View for Non-redundant PSU Configuration
Rear View for Redundant PSU Configuration
Legend
A.
PCI Slot 1B
G.
Power LED
B.
PCI Slot 1C
H.
Data LAN 1 Connector
C.
AC Inlet
I.
Data LAN 2 Connector
D.
Power Unit
J.
USB 3.0 Connectors
E.
Serial Port Connector
K.
Management LAN Connector
F.
VGA Connector
L.
UID LED / Button
C
JL
DAB
H
E
F
I
GK
DAB
H I
K L
E
FC
D
CJ G

SYSTEM CONFIGURATION GUIDE –NEC Express5800/R110h-1
NEC Corporation Revision 5.0 –January, 2017 11
Dimensions (mm)
With non-Hot plug PSU
With Hot plug PSU
43.6 mm

SYSTEM CONFIGURATION GUIDE –NEC Express5800/R110h-1
NEC Corporation Revision 5.0 –January, 2017 12
Configuration Diagram
2.5-inch Drive Model
Legend: Standard Components Mandatory components
3.5-inch Drive Model (Non-redundant PSU)
Legend: Standard Components Mandatory components

SYSTEM CONFIGURATION GUIDE –NEC Express5800/R110h-1
NEC Corporation Revision 5.0 –January, 2017 13
3.5-inch Drive Model (Redundant PSU)
Legend: Standard Components Mandatory components
Expansion Slots
Legend
#1A
PCIe 3.0 (x4) x4 lanes, x8 connector, for a dedicated RAID controller
#1B
PCIe 3.0 (x16) x16 lanes, x16 connector, Low profile, up to 173 mm length
#1C
PCIe 3.0 (x4) x4 lanes, x8 connector, Low profile, up to 173 mm length
PCI 1B PCI 1C
PCI 1A

SYSTEM CONFIGURATION GUIDE –NEC Express5800/R110h-1
NEC Corporation Revision 5.0 –January, 2017 14
Server Configuration
1 Base Models
Product Name / Description
Part Number
NEC Express5800/R110h-1
No CPU, no RAM, no 3.5-inch HDD, no Cooling FAN, no ODD
Including:
3.5-inch Drive Cage, 1x 400 Watt non-hot plug power supply, Front bezel
N8100-2334F
NEC Express5800/R110h-1
No CPU, no RAM, no 3.5-inch HDD, no Cooling FAN, no ODD
Including:
3.5-inch Drive Cage, 2 x 500 Watt hot plug power supply, Front bezel
N8100-2335F
NEC Express5800/R110h-1
No CPU, no RAM, no 2.5-inch HDD, no Cooling FAN, no ODD
Including:
2.5-inch Drive Cage, 2 x 500 Watt hot plug power supply, Front bezel,
N8100-2337F
NOTE:
The base model must be ordered with a processor kit, a memory kit, a cooling fan kit, and internal hard drive cable
For Windows Server 2008 R2 installation, EXPRESSBUILDER DVD is required.
2 Processor
Available sockets: 1
Category
Product Name / Description
Part Number
Processors
Required
Pentium G4400 Processor Kit
Intel® Pentium ® Processor G4400 (3.30 GHz, 2C/2T, 3 MB)
N8101-939F
Xeon E3-1220 v5 Processor Kit
Intel® Xeon ® Processor E3-1220 v5 (3.00 GHz, 4C/4T, 8 MB)
N8101-941F
Xeon E3-1230 v5 Processor Kit
Intel® Xeon ® Processor E3-1230 v5 (3.40 GHz, 4C/8T, 8 MB)
N8101-942F
Xeon E3-1240L v5 Processor Kit
Intel® Xeon ® Processor E3-1240L v5 (2.10 GHz, 4C/8T, 8 MB)
N8101-943F
Xeon E3-1260L v5 Processor Kit
Intel® Xeon ® Processor E3-1260L v5 (2.90 GHz, 4C/8T, 8 MB)
N8101-944F
Xeon E3-1270 v5 Processor Kit
Intel® Xeon ® Processor E3-1270 v5 (3.60 GHz, 4C/8T, 8 MB)
N8101-945F
NOTE:
The processor kit must be ordered with the base model.
VMware ESXi is not supported on Pentium processor systems.

SYSTEM CONFIGURATION GUIDE –NEC Express5800/R110h-1
NEC Corporation Revision 5.0 –January, 2017 15
3 Memory
Available slots: 4
Product Name / Description
Part Number
4GB DDR4-2133 UNB Memory Kit
1 x 4GB Unbuffered ECC DIMM, DDR4-2133
N8102-656F
8GB DDR4-2133 UNB Memory Kit
1 x 8GB Unbuffered ECC DIMM, DDR4-2133
N8102-657F
16GB DDR4-2133 UNB Memory Kit
1 x 16GB Unbuffered ECC DIMM, DDR4-2133
N8102-658F
NOTE:
Minimum one memory kit must be installed.
It is recommended to install memory kits in pairs of two identical DIMMs for dual-channel symmetric memory configurations to
increase memory transfer speed.
At least 5 GB of memory is required for VMware ESXi™ 5.5 and VMware ESXi™ 6.0
Maximum Available Memory
See the table below for the maximum memory size that you can actually use on your system.
The maximum available memory is less than the maximum physical memory supported by your system because some chipsets
require PCI resource space of about 750MB. PCI resource requirements vary depending on the type and the number of PCI cards you
are using.
Maximum Memory Size Supported by Operating Systems
Maximum Available Memory
Microsoft Windows Server 2008 R2 Standard1
32 GB
32 GB
Microsoft Windows Server 2008 R2 Enterprise1
2 TB
64 GB
Microsoft Windows Server 2012 Standard1
Microsoft Windows Server 2012 Datacenter1
Microsoft Windows Server 2012 R2 Standard1
Microsoft Windows Server 2012 R2 Datacenter1
4 TB
64 GB
Red Hat Enterprise Linux 6 (x86_64)
Red Hat Enterprise Linux 7
6 TB
64 GB
VMware ESXi 5.52
4 TB
64 GB
VMware ESXi 6.0 3
6 TB
64 GB
1The maximum available memory size of Hyper-V systems are below:
- Windows Server 2008 R2 Standard : 32 GB
- Windows Server 2008 R2 Enterprise : 1TB
- Windows Server 2012, Windows Server 2012 R2 : 4 TB
2Up to 1TB of main memory is available to each virtual machine.
3Up to 4TB of main memory is available to each virtual machine.

SYSTEM CONFIGURATION GUIDE –NEC Express5800/R110h-1
NEC Corporation Revision 5.0 –January, 2017 16
4 Internal Hard Disk Drives
RAID Configuration
Refer to the section in accordance with your disk form factor and RAID configuration.
2.5-inch Drive
Operating System
Supported RAID configuration
Supported
HDD/SSD
RAID and Cache
Section
Windows Server 2008 R2
VMware ESXi 5.5
VMware ESXi 6
Non-RAID (Embedded SATA)
4.2.1
4.3.1
RAID 0/1 (Embedded SATA RAID)
(WS2008R2 only)
4.2.2
4.3.2
RAID 0/1/10 No Cache
4.2.3
4.3.3
RAID 0/1/10 1GB Cache
4.2.4
RAID 5/6/50/60 1GB Cache
4.2.5
RAID 5/6/50/60 2GB Cache
4.2.6
Windows Server 2012
Windows Server 2012 R2
Non-RAID (Embedded SATA)
4.2.1
4.3.1
RAID 0/1 (Embedded SATA RAID)
4.2.2
4.3.2
RAID 0/1/10 No Cache
4.2.3
4.3.4
RAID 0/1/10 1GB Cache
4.2.4
RAID 5/6/50/60 1GB Cache
4.2.5
RAID 5/6/50/60 2GB Cache
4.2.6
Red Hat Enterprise Linux 6
Red Hat Enterprise Linux 7
Non-RAID (Embedded SATA)
4.2.1
4.3.1
RAID 0/1/10 No Cache
4.2.3
4.3.4
RAID 0/1/10 1GB Cache
4.2.4
RAID 5/6/50/60 1GB Cache
4.2.5
RAID 5/6/50/60 2GB Cache
4.2.6
NOTE:
Up to four drives can be installed when you choose the Embedded SATA non-RAID controller.
All drives within a RAID array should be of the same type, capacity and rotation speed.
Up to two kinds of drives selected from SAS 10K HDDs (512n), SAS 10K HDDs (512e), SAS 15K HDDs, SATAHDDs SAS SSDs,
SATA SSD (ME), and SATA SSD (VE) can be mixed.
To configure a large-capacity RAID array, it is recommended to configure in RAID 6 or RAID 60 in order to minimize the risk of
becoming multiple hard drives failure during the RAID rebuilding process.
Slot 2
Slot 3 Slot 4
Slot 5
Slot 6
Slot 7
Slot 0 Slot 1

SYSTEM CONFIGURATION GUIDE –NEC Express5800/R110h-1
NEC Corporation Revision 5.0 –January, 2017 17
3.5-inch Drive
Operating System
Supported RAID configuration
Supported
HDD/SSD
RAID and Cache
Section
Windows Server 2008 R2
VMware ESXi 5.5
VMware ESXi 6
Non-RAID (Embedded SATA)
4.2.7
4.3.5
RAID 0/1 (Embedded SATA RAID)
(WS2008R2 only)
4.2.8
RAID 0/1/10 No Cache
4.2.9
RAID 0/1/10 1GB Cache
4.2.10
RAID 5/6/50/60 1GB Cache
4.2.11
RAID 5/6/50/60 2GB Cache
4.2.12
Windows Server 2012
Windows Server 2012 R2
Non-RAID (Embedded SATA)
4.2.7
4.3.5
RAID 0/1 (Embedded SATA RAID)
4.2.8
RAID 0/1/10 No Cache
4.2.9
4.3.6
RAID 0/1/10 1GB Cache
4.2.10
RAID 5/6/50/60 1GB Cache
4.2.11
RAID 5/6/50/60 2GB Cache
4.2.12
Red Hat Enterprise Linux 6
Red Hat Enterprise Linux 7
Non-RAID (Embedded SATA)
4.2.7
4.3.5
RAID 0/1/10 No Cache
4.2.9
4.3.6
RAID 0/1/10 1GB Cache
4.2.10
RAID 5/6/50/60 1GB Cache
4.2.11
RAID 5/6/50/60 2GB Cache
4.2.12
NOTE:
All hard drives within a RAID array should be of the same capacity.
Slot 0 Slot 1 Slot 2 Slot 3

SYSTEM CONFIGURATION GUIDE –NEC Express5800/R110h-1
NEC Corporation Revision 5.0 –January, 2017 18
Required Components for RAID Configuration
Embedded SATA non-RAID Controller for 2.5-inch Drives
Category
Product Name / Description
Part Number
Storage Controller
Embedded SATA Controller
4 x 6Gb/s SATA
(Standard)
Cable
Internal SAS/SATA Cable
1 x Mini SAS HD to 1 x Mini SAS HD, 1 set
(Standard)
Drive Cage
2.5-inch Drive Cage
8 x 2.5-inch Hot-plug hard drive bays
(Standard)
NOTE:
Hot plug insertion/removal is not supported with the embedded SATAnon-RAID controller.
Embedded SATA RAID Controller for 2.5-inch Drives
Category
Product Name / Description
Part Number
Storage Controller
Embedded SATA Controller
4x 6Gb/s SATA, RAID 0/1/10 capable
(Standard)
Cable
Internal SAS/SATA Cable
1 x Mini SAS HD to 1 x Mini SAS HD, 1 set
(Standard)
Drive Cage
2.5-inch Drive Cage
8 x 2.5-inch Hot-plug hard drive bays
(Standard)
NOTE
Embedded SATARAID controller is supported only on limited OS. For more details, please see OS Support Matrix for PCI Cards
and Embedded Controllers.
All hard drives within a RAID array should be of the same capacity.
RAID 0/1 Controller without Cache for 2.5-inch Drives
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (RAID 0/1)
Avago(LSI) MegaRAID SAS 9341-8i
RAID 0/1/10, non-cache, Int. 8, PCIe 3.0 x8, SAS 12Gb/s, SATA 6Gb/s
N8103-188
Cable
Internal SAS/SATA Cable
1 x Mini SAS HD to 1 x Mini SAS HD, 1 set
(Standard)
Internal SAS/SATA Cable
1 x Mini SAS HD to 1 x Mini SAS HD, 1 set, for 5th - 8th hard drives
K410-348(00)
Drive Cage
2.5-inch Drive Cage
8 x 2.5-inch hot plug drive bays
(Standard)
NOTE:
Up to two kinds of drives selected from SAS 10K HDDs, SAS 15K HDDs, SATA HDDs SAS SSDs, SATA SSD (ME), and SATA
SSD (VE) can be mixed.
All drives within a RAID array should be of the same type, capacity and rotation speed.

SYSTEM CONFIGURATION GUIDE –NEC Express5800/R110h-1
NEC Corporation Revision 5.0 –January, 2017 19
RAID 0/1 Controller with 1 GB Cache for 2.5-inch Drives
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (1GB, RAID 0/1)
Avago(LSI) MegaRAID SAS 9362-8i
RAID 0/1/10, 1GB, Int. 8, PCIe 3.0 x8, SAS 12Gb/s, SATA 6Gb/s
N8103-176
Flash Backup
Recommended
Flash Backup Unit
for Avago(LSI) MegaRAID SAS 9362-8i
650mm Cable for Flash Backup Unit included
N8103-181
Cable
Internal SAS/SATA Cable
1 x Mini SAS HD to 1 x Mini SAS HD, 1 set
(Standard)
Internal SAS/SATA Cable
1 x Mini SAS HD to 1 x Mini SAS HD, 1 set, for 5th - 8th hard drives
K410-348(00)
Drive Cage
2.5-inch Drive Cage
8 x 2.5-inch hot plug drive bays
(Standard)
NOTE:
Up to two kinds of drives selected from SAS 10K HDDs, SAS 15K HDDs, SATA HDDs SAS SSDs, SATA SSD (ME), and SATA
SSD (VE) can be mixed.
All drives within a RAID array should be of the same type, capacity and rotation speed.
RAID 5/6 Controller with 1 GB Cache for 2.5-inch Drives
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (1GB, RAID 0/1/5/6)
Avago(LSI) MegaRAID SAS 9362-8i
RAID0/1/5/6/10/50/60, 1GB, Int. 8, PCIe 3.0 x8, SAS 12Gb/s, SATA
6Gb/s
N8103-177
Flash Backup
Recommended
Flash Backup Unit
for Avago(LSI) MegaRAID SAS 9362-8i
650mm Cable for Flash Backup Unit included
N8103-181
Cable
Internal SAS/SATA Cable
1 x Mini SAS HD to 1 x Mini SAS HD, 1 set
(Standard)
Internal SAS/SATA Cable
1 x Mini SAS HD to 1 x Mini SAS HD, 1 set, for 5th - 8th hard drives
K410-348(00)
Drive Cage
2.5-inch Drive Cage
8 x 2.5-inch hot plug drive bays
(Standard)
NOTE:
Up to two kinds of drives selected from SAS 10K HDDs, SAS 15K HDDs, SATAHDDs SAS SSDs, SATASSD (ME), and SATA
SSD (VE) can be mixed.
All drives within a RAID array should be of the same type, capacity and rotation speed.
To configure a large-capacity RAID array, it is recommended to configure in RAID 6 or RAID 60 in order to minimize the risk of
becoming multiple hard drives failure during the RAID rebuilding process.

SYSTEM CONFIGURATION GUIDE –NEC Express5800/R110h-1
NEC Corporation Revision 5.0 –January, 2017 20
RAID 5/6 Controller with 2 GB Cache for 2.5-inch Drives
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (2GB, RAID 0/1/5/6)
Avago(LSI) MegaRAID SAS 9362-8i
RAID0/1/5/6/10/50/60, 2GB, Int. 8, PCIe 3.0 x8, SAS 12Gb/s, SATA
6Gb/s
N8103-178
Flash Backup
Recommended
Flash Backup Unit
for Avago(LSI) MegaRAID SAS 9362-8i
650mm Cable for Flash Backup Unit included
N8103-181
Cable
Internal SAS/SATA Cable
1 x Mini SAS HD to 1 x Mini SAS HD, 1 set
(Standard)
Internal SAS/SATA Cable
1 x Mini SAS HD to 1 x Mini SAS HD, 1 set, for 5th - 8th hard drives
K410-348(00)
Drive Cage
2.5-inch Drive Cage
8 x 2.5-inch hot plug drive bays
(Standard)
NOTE:
Up to two kinds of drives selected from SAS 10K HDDs, SAS 15K HDDs, SATA HDDs SAS SSDs, SATA SSD (ME), and SATA
SSD (VE) can be mixed.
All drives within a RAID array should be of the same type, capacity and rotation speed.
To configure a large-capacity RAID array, it is recommended to configure in RAID 6 or RAID 60 in order to minimize the risk of
becoming multiple hard drives failure during the RAID rebuilding process.
Embedded SATA non-RAID Controller for 3.5-inch Drives
Category
Product Name / Description
Part Number
Storage Controller
Embedded SATA Controller
4 x 6Gb/s SATA
(Standard)
Cable
Internal SAS/SATA Cable
1 x Mini SAS HD to 4 x Single SATA, 1 set
(Standard)
Drive Cage
3.5-inch Drive Cage
4 x 3.5-inch Hot-plug hard drive bays
(Standard)
NOTE
Hot plug insertion/removal is not supported with the embedded SATAnon-RAID controller.
Embedded SATA RAID Controller for 3.5-inch Drives
Category
Product Name / Description
Part Number
Storage Controller
Embedded SATA Controller
4x 6Gb/s SATA, RAID 0/1/10 capable
(Standard)
Cable
Internal SAS/SATA Cable
1 x Mini SAS HD to 4 x Single SATA, 1 set
(Standard)
Drive Cage
3.5-inch Drive Cage
4 x 3.5-inch Hot-plug hard drive bays
(Standard)
NOTE:
Embedded SATARAID controller is supported only on limited OS. For more details, please see OS Support Matrix for PCI Cards
and Embedded Controllers.
All hard drives within a RAID array should be of the same capacity.
