NEC Express5800/320Ma How to use

NEC Solutions (America), Inc.
NR004W
Release Notes:
Express5800/320Ma
Release 4.1.0

Manual Name: Release Notes: Express5800/320Ma Release 4.1.0
Part Number: NR004W
Express5800/320Ma Software Release Number: 4.1.0
Publication Date: January 2006
NEC Solutions (America), Inc.
10850 Gold Center Drive, Suite 200
Rancho Cordova, CA 95670
© 2006 NEC Solutions (America), Inc. All rights reserved.
Notice
The information contained in this document is subject to change without notice.
UNLESS EXPRESSLY SET FORTH IN A WRITTEN AGREEMENT SIGNED BY AN AUTHORIZED REPRESENTATIVE
OF NEC, NEC MAKES NO WARRANTY OR REPRESENTATION OF ANY KIND WITH RESPECT TO THE
INFORMATION CONTAINED HEREIN, INCLUDING WARRANTY OF MERCHANTABILITY AND FITNESS FOR A
PURPOSE. NEC assumes no responsibility or obligation of any kind for any errors contained herein or in connection with
the furnishing, performance, or use of this document.
Software described in NEC (a) is the property of NEC and/or its licensees, (b) is furnished only under license, and (c) may
be copied or used only as expressly permitted under the terms of the license.
NEC documentation describes all supported features of the user interfaces and the application programming interfaces
(API) developed by NEC and/or its licensees. Any undocumented features of these interfaces are intended solely for use
by NEC personnel and are subject to change without warning.
This document is protected by copyright. All rights are reserved. No part of this document may be copied, reproduced, or
translated, either mechanically or electronically, without the prior written consent of NEC Solutions (America), Inc.
The NEC Solutions (America), Inc. logo, Express5800/320Ma, and the Express5800/320Ma logo, are trademarks of NEC
Solutions (America), Inc. ActiveService Network and Active Upgrade are trademarks of Stratus Technologies Bermuda,
Ltd. All other trademarks and trade names are the property of their respective owners.

Contents iii
Contents
Preface v
1. Release Notes 1-1
Release Contents 1-2
Installing Express5800/320Ma Software 1-3
Special Procedures and Restrictions 1-4
Known Problems 1-5
Documentation 1-6
Documentation Updates and Corrections 1-7
Obtaining Documentation 1-7
Getting Help 1-8

Contents
iv Release Notes: Express5800/320Ma Release 4.1.0

Preface v
Preface
Purpose of This Manual
TheReleaseNotes:Express5800/320MaRelease4.1.0describereleasecontentsand
significant known problems. They also document new information that does not yet
appear in other Express5800/320Ma online documentation.
Audience
This document is intended for system administrators who will install this
Express5800/320Ma software release and for others who need an overview of the
release.
Notation Conventions
This document uses the notation conventions described in this section.
Warnings, Cautions, and Notes
Warnings, cautions, and notes provide special information and have the following
meanings:
WARNING
!A warning indicates a situation where failure to take
oravoid a specified actioncouldcausebodilyharmor
loss of life.
CAUTION
!A caution indicates a situation where failure to take or
avoidaspecifiedaction coulddamagea hardware device,
program, system, or data.
NOTE
Anoteprovidesimportantinformationabouttheoperation
of an Express5800/320Ma system.

Preface
vi Release Notes: Express5800/320Ma Release 4.1.0
Typographical Conventions
The following typographical conventions are used in Express5800/320Ma documents:
•The bold font emphasizes words in text or indicates text that you type, the name of
a screen object, or the name of a programming element. For example:
Before handling or replacing system components, make sure that you are
properly grounded by using a grounded wrist strap.
In the System Properties dialog box, click the Hardware tab.
Call the RegisterDeviceNotification function.
•Theitalic fontintroduces new terms and indicatesprogrammingandcommand-line
arguments that the user defines. For example:
Many hardware components are customer-replaceable units (CRUs), which
can be replaced on-site by system administrators with minimal training or tools.
copy filename1 filename2
Pass a pointer for the NotificationFilter parameter
•The monospace font indicates sample program code and output, including
message text. For example:
#include <iostream.h>
The operation completed successfully.
Notices
•All regulatory notices are provided in the site planning guide for your system.
•Although this guide documents modem functionality, modems are not available for
all systems. Ask your sales representative about modem availability.
•ActiveService Network (ASN) is not currently available, but may be ordered in the
future.

Release Notes 1-1
Chapter 1
Release Notes1-
This document provides information about the following topics:
•“Release Contents”
•“Installing Express5800/320Ma Software”
•“Special Procedures and Restrictions”
•“Known Problems”
•“Documentation”
•“Getting Help”
NOTE
The notes for this release may have changed since this
document was printed. Before proceeding, check for an
update at http://support.necsam.com/servers/.
Release Contents
Express5800/320Ma software and documentation are distributed on two compact
discs (CD-ROMs).
•The ExpressBuilder CD (1 of 2), contains the System software required to operate
your system.
•The ExpressBuilder CD (2 of 2), contains Express5800/320Ma documentation in
both online Help and Portable Document Format (PDF) formats.
NOTE
You need both CD-ROMs to complete the installation.
If you ordered Microsoft®Windows®Server 2003, Enterprise Edition, an
ExpressBuilderCDisincluded,tobeused if youneedtoperformaninitialprogramload
(IPL) of Express5800/320Ma System software.

Release Contents
1-2 Release Notes: Express5800/320Ma Release 4.1.0
New Features Available in This Release
Express5800/320Ma System software includes the following new features:
•Support for Express5800/320Ma Dual-Core systems. These systems use
dual-core Intel®Xeon®processors for increased performance.
•Support for Express5800/320Ma Active Upgrade™ technology. Using the
optionalActiveUpgradeproduct,youcan,inmanycases,installsoftwareupgrades
or hot fixes on your system with only a few seconds of interruption to your
application processing. See the Express5800/320Ma: Active Upgrade User’s
Guide for information about this product.
•Rapid Disk Resync (RDR) enhancements. The following enhancements have
been added:
– Improved performance during disk verification. Also, the action Stop Verify
has been added to ftSMC.
–Break Physical Disk from RDR Virtual Disk in ftSMC. This action allows you
to temporarily isolate a physical disk from an RDR virtual disk so that you can
back up a snapshot of the disk contents.
– Support for GUID Partition Table (GPT) disks. GPT partition style, new with
Microsoft Windows Server 2003 Service Pack 1, is now supported for data
(non-system) disks only, in addition to master boot record (MBR) partition style.
See the Express5800/320Ma: System Administrator’s Guide for information about
RDR disk verification and Break Physical Disk from RDR Virtual Disk.
•ActiveService™ Network (ASN) related enhancements. The following features
have been added to enhance ASN functionality:
– Autonomous Call-Home. Virtual Technician Modules (VTMs) can now send
alarms over the ASN even when the Windows operating system is not running
(for example, in the rare case when a Fault-Resilient Boot (FRB) is unable to
start the system).
– Internet Dial-In. A modem is no longer necessary for the NEC Technical
Support to dial in and provide system support over the ASN, if your VTMs are
connected to a network with Internet access.
– Modem control from ftSMC. You can now take an ASN modem out of service
during replacement procedures and return it to service from ftSMC. See the
Express5800/320Ma: System Administrator’s Guide for details.
NOTE
ActiveService Network (ASN) is not currently available.
NEC may offer this optional service in the future.

Installing Express5800/320Ma Software
Release Notes 1-3
For a list of new and updated documents for this release, as well as information not yet
included in the documents, see “Documentation” on page 1-5.
Installing Express5800/320Ma Software
Table 1-1 lists the Express5800/320Ma system installation and configuration
documents. There are two documents associated with each model:
•The document listed in the Initial Installation column explains how to install
Express5800/320Ma software for the first time or how to complete the installation
of software preinstalled on a new system.
•The document listed in the Configuration, Upgrade, and Remote Management
column explains how to configure your system after it has been installed, how to
install Express5800/320Ma System software, Windows, and firmware upgrades,
and how to install Express5800/320Ma System software on PCs for remote
management.
Special Procedures and Restrictions
The following are special procedures and restrictions that apply to this release.
Preserving Application Data When Using Active Upgrade™ Software
When you perform an upgrade using Active Upgrade™ software with saved
configuration files, the software does not provide a warning when itdiscovers a system
disk (that is, a disk that has a boot partition or a paging file) that has not been declared
in the configuration files.
CAUTION
!If you place a paging file on adisk that contains persistent
(non-temporary) application data, the Active Upgrade™
software will automatically declare that disk to be a
system disk. When the upgrade is committed, the disk on
the production side will be overwritten, possibly with stale
data, from theupgradeside, which may result in data loss.
Table 1-1. Express5800/320Ma Installation and Configuration Documentation
Model Initial Installation Configuration, Upgrade, and Remote Management
Express580
0/320Ma Express5800/320Ma: Installation Guide Express5800/320Ma: Software Installation and Configuration Guide

Known Problems
1-4 Release Notes: Express5800/320Ma Release 4.1.0
Follow these guidelines to avoid data loss during upgrades:
•When configuring applications, make sure that you do not write persistent
application data to a disk that has a boot partition or a paging file, or is declared to
be a system disk in an Active Upgrade configuration file.
•When creating Active Upgrade configuration files, do not declare a disk that
contains persistent application data to be a system disk.
•When configuring paging files, do not place them on disks that contain persistent
application data.
For information about correctly using Active Upgrade™ software, see the
Express5800/320Ma: Active Upgrade User’s Guide.
Avoiding Problems with the EMC®SANSurfer FC HBA Manager Utility
If your Express5800/320Ma system is connected to an EMC Storage System, avoid
installing the EMC utility SANSurfer FC HBA Manager. This utility prevents failover of
QLogic®host bus adapters (HBAs). It also prevents Active Upgrade from working .
CAUTION
!If you do install the SANSurfer FC HBA Manager utility to
update the firmware on a QLogic HBA, uninstall it
immediately after use. While it is installed, your system
cannot fail over a QLogic HBA, so that the fault tolerance
of your system is compromised.
Configuring VTMs
The SMM Admin Dialback Number, a configuration setting for Virtual Technician
Modules(VTMs),isnotyetimplemented.Youcanconfigureadialback numberfor your
administrator account, but when you dial in to a VTM, it does not hang up the
connection and dial the dialback number. When you dial into and log into the VTM, the
connection remains established until you log out and hang up. See the
Express5800/320MaVirtualTechnicianModule User’sGuideforadditionalinformation
on configuring VTMs.
Known Problems
This section describes known problems in this release.
Message Box May Block Shutdown or Restart
Description Intermittently, a message dialog box with the following message may
appear when the system is being shut down or restarted:

Documentation
Release Notes 1-5
This application has failed to start because
WINHTTP.dll was not found. Re-installing the
application may fix this problem.
The shutdown or restart will not proceed until the message dialog box
is closed.
Workaround This message can be safely ignored. Click OK to close the dialog box,
and the shutdown or restart will proceed normally.
PROSet May Not Correctly Set Ethernet Team Names in Windows
Description When you create two or more teams on a new system or a system on
which an IPL has just been performed, one of the teams may not have
the name you assigned it. In the PROSet utility, the team name
appears to be set correctly, but in Windows Network Connections, it is
not the name you specified.
Workaround Use the PROSet utility to rename the incorrectly-named team.
To rename an incorrectly-named team
1. In PROSet, right-click the team name in the Network Components
tree, and click Rename Team.
2. If you want to use the original name, type a temporary name in the
Enter Team Name fieldoftheRenameTeamdialogbox, and clickOK.
Otherwise skip to Step 5.
3. In the main PROSet dialog box, click Apply.
4. Again, right-click the team name, and click Rename Team.
5. In the Rename Team dialog box, type the desired name for the team
in the Enter Team Name field. and click OK. If you skipped Steps 2
through 4, this name must be different from the original name.
Otherwise, Windows Network Connections will not be updated.
6. In the main PROSet dialog box, click Apply to apply the change or OK
to apply the change and close PROSet.
Documentation
Someupdatesandcorrectionsthatarenotyetincludedinthe documentationarelisted
laterin this section. Youcan view nearlyallExpress5800/320Madocumentationonline.
Table 1-2 lists documents for Express5800/320Ma 3.2 GHz, 3.6 GHz, and Dual-Core
systems.

Documentation
1-6 Release Notes: Express5800/320Ma Release 4.1.0
Documentation Updates and Corrections
The following information does not yet appear in the documentation.
Software Availability Manager (SAM) and Microsoft Outlook®Express 6
Ifyouarerunning OutlookExpress 6 as your default mail handler, you must change the
default setting of the Warn me when other applications try to send mail as me
option before you can use the SAM email alert feature. Change the setting as follows:
1. In Outlook Express, click the Tools menu and then click Options.
2. Click the Security tab.
3. Clear the check box next to Warn me when other applications try to send mail
as me, and then click OK.
If you leave the box checked, Outlook Express blocks the sending of SAM email alerts.
Obtaining Documentation
Almost all Express5800/320Ma documentation is available online.
To gain access to the documents on the World Wide Web, point your browser to the
Express5800/320Ma web site:
http://support.necsam.com/servers/
Table 1-2. Documentation
Document
Release Notes: Express5800/320Ma Release 4.1.0
Express5800/320Ma: Software Installation and Configuration Guide
Express5800/320Ma: System Administrator’s Guide
Express5800/320Ma: Technical Reference Guide
Express5800/320Ma: PCI Adapter Guide
Express5800/320Ma ActiveService Network Configuration Guide
Express5800/320Ma Virtual Technician Module User’s Guide
Express5800/320Ma: Site Planning Guide
Read Me First: Unpacking Express5800/320Ma Cabinets
Express5800/320Ma: Installation Guide
Express5800/320Ma: Operation and Maintenance Guide

Getting Help
Release Notes 1-7
Getting Help
If you have a technical question about Express5800/320Ma hardware or software, try
these online resources first:
•Online support from NEC Technical Support. You can find the latest technical
information about an Express5800/320Ma through online product support at the
NEC Technical Support Web site:
http://support.necsam.com/servers/
•Online product support for Microsoft®products. Your primary source for
support is the computer manufacturer who provided your software, or an
authorized Microsoft Support Provider. You can also find the latest technical
informationaboutMicrosoftWindows®andotherMicrosoftproductsthroughonline
product support at the Microsoft Help and Support Web site:
http://support.microsoft.com/
If you areunable to resolve your questions with the help available at these online sites,
and the Express5800/320Ma system is covered by a service agreement, please
contact NEC Technical Support (866-269-1239).

Getting Help
1-8 Release Notes: Express5800/320Ma Release 4.1.0
